INSTALLATION MANUAL
TIS WI-FI PLUG
Portable Power Outlet
Model: AIR-Socket-S
Power supply
Output
Output switching current
Output service life
Output switching times
TIS AIR
Socket Type
Operation
Weight
Dimensions
Housing
BARCODE (UPC-A)
6
58921
79693
1
PRODUCT INFORMATION
Equipped with an internal WI-FI, this product is
designed to be automatically linked to the Internet
to control lights and any other electrical appliances
that are connected to it.
P R O D U C T S P E C I F I C AT I O N S
Input voltage
Output power
Protection
Current consumption
Number of channels
Nominal voltage
Nominal current per channel
Max. switching current
Max. continues current
Max. switching voltage
Mechanical endurance
Operating time
Releasing time
Max. operating frequency
WIFI signal
Protocol standard
Optional
Touch buttons
Backlit
TIS AIR
Upgrading
Without packaging
Length × Width × Height
Materials
Internal parts color
IP rating
110-230 VAC 50/60 Hz
3W / 12V
Internal protection fuse
20 mA / 12 V DC
1
110 – 230 V AC 50/60 Hz
10 A / 230 VAC
16A/230 VAC resistive
8A/230 VAC florescent
10A/230 VAC
440VAC / 125VDC
> 10,000,000 OPS
15 mS (at nomi. Volt)
8 mS (at nomi. Volt)
20 cycle/min
2.4 GHz
802.11 b/g/n
EU, UK, US or universal type
1 control button
LED indicators
TIS protocol messages & commands
Over WIFI connection
20g
62mm × 68mm × 102mm
Fireproof PC
White
IP 50
