All In One Heat Pump Water Heater

INSTALLATION & USER MANUAL

Thank you very much for purchasing our product.

Before operating your unit, please read this manual carefully and keep it for future reference.

Table of Contents

Need help?

Do you have a question about the WH265A-RE and is the answer not in the manual?

Questions and answers

Summary of Contents for Hitech WH265A-RE

Page 1 All In One Heat Pump Water Heater INSTALLATION & USER MANUAL Thank you very much for purchasing our product. Before operating your unit, please read this manual carefully and keep it for future reference.
Page 2 IMPORTANT: RISK OF FIRE OR EXPLOSION! FLAMMABLE REFRIGERANT USED ◼ Place in well ventilated area to prevent accumulation of refrigerant. ◼ Repair and disposal must be carried out by trained service personnel. Propan ◼ No naked flame during servicing or repair. (R290) WARNIN Must be installed in an outdoor environment...
Page 3 ◼ THE APPLIANCE IS NOT INTENDED TO BE CONNECTED TO THE WATER BY A HOSE-SET. ◼ THE WATER MAY DRIP FROM THE DISCHARGE PIPE OF THE PRESSURE RELIEF DEVICE AND THAT THIS PIPE MUST BE LEFT OPEN TO THE ATMOSPHERE. ◼...
Page 4 Model Name: WH265A-RE/WH265A-CE WH265A-R/WH265A-C - 3 -...
Page 5 WH315A-RE/WH315A-CE WH315A-R/WH315A-C - 4 -...
Page 6: Table Of Contents
Contents Pages 1. Safety information 2. Preparation of installation 3. Installations 4. Trial-running 5. Operation 6. Troubleshooting 7. Maintenance Specifications Maintenance WIFI connection - 5 -...
Page 7: Safety Information
1. Safety information Please carefully read thoroughly all of the instructions before installing or operating the unit. Following safety symbols are very important, please carefully read and always obey all safety symbols. CAUTION If the precaution is not taken, it may cause minor or moderate injury If the warning is not heeded, it can cause death or serious injury.
Page 8 CAUTION The ground wire’s pole of socket must be grounded well, make sure that power supply socket and plug are dry and connected well. To check the power supply socket and plug are qualified Step 1: Turn on the power supply. Step 2: Keep the unit running for a half hour.
Page 9: Preparation Of Installation
2. Preparations of installation 2.1 Transport In order to avoid scratch or deformation of the unit surface, please use guard boards to contacting surface. No contact of fingers and other things with the vanes. Do not incline the unit more than 45° to move. When install the unit, please keep the unit vertical. ＞...
Page 10 CAUTION The ambient air temperature must also be considered when installing this unit, in heat pump mode the ambient air temperature must be above -10°C and below 43°C. If the ambient air temperature falls outside these upper and lower limits, the electrical elements will be activated to meet the hot water demand and the heat pump does not operate.
Page 11: Installations
2.5 Unit dimension Model WH265A-CE 640mm 1800mm WH265A-C 640mm 1800mm WH265A-RE 640mm 1800mm WH265A-R 640mm 1800mm WH315A-CE 640mm 2010mm WH315A-C 640mm 2010mm WH315A-RE 640mm 2010mm WH315A-R 640mm 2010mm 3 . Installations It is NECESSARY for installation to conform with AS/NZS 3500.4.
Page 12 3.2 Water system piping diagram - 11 -...
Page 13 CAUTION Water piping system as the above figure. When install the unit at a place where outside temperature below freezing point, the insulation must be provided for all hydraulic components. The handle of PTR valve should be pulled out once per half a year to confirm that there is no jam of the valve. At the same time, please take care of hot water from the valve and burning.
Page 14 3.3 Condensate water drainage To smoothly drain the condensate water, please install the unit at a horizontal floor. At the same time, please ensure the drainage joint is at the lowest level. Recommending the inclination angle of the unit to the ground should be no more than 2°...
Page 15 3.4.2 Specifications of power supply Power supply 220-240V~, 1Ph, 50Hz Min. diameter of power supply cord 2.5mm Earth cord 2.5mm Manual switch capacity/ Fuse 30A / 30A 30mA, ≤0.1Sec Creepage circuit breaker Please choose the power supply cord according to the above table, and it should comply with local electric standard.
Page 16: Trial-Running
3.5.4 Checkingof the electrical connections The water heater requires 220-240VAC for proper operation. Wiring size and connections comply with all local applicable codes and the requirements of this manual. Water heater and electrical supply are properly grounded. Proper overload fuse or circuit breaker protection installed. 3.5.5 Postinstallation review Understand how to use the controller to set the various parameters and functions.
Page 17: Operation
4.3 Trial-running Checking list before commissioning: Correct installation of the system. Correct connection of the water and wiring. Condensate draining smoothly well insulation work for all hydraulic part. Correct power supply. No air in the water pipeline and all valves opened. Effective electric leakage protector installation.
Page 18 After the unit is powered on, the display screen will display all the icons for 3 seconds, and it will be display the regular interface automatically. 5.3 Buttons Icons Name Icons Name On/Off button Setting button ▲ Increase/up button Timer button ▼...
Page 19 5.3.4 Timer button Press the timer button to set the clock and timer on/off. Clock setting - Step 1: Press the Timer button to set the clock. So the hours of clock begins to flash. Step 2: Press Increase or Decrease button to set correct hours of clock. After setting the hours, press the Timer button again to begin to set the minutes of clock.
Page 20 Timer setting - Step 1: Keep pressing the Timer button for 5 seconds till the icon of timer on is flashed and the icon of timer off displayed. So timer on can be set now.At the same time, hours of timer on flashes. Step 2: Press Increase or Decrease button to set required hours of timer on.
Page 21 Step 3: Press Increase or Decrease button to set required minutes of timer on. Finally, press the Timer button again to confirm the timer on setting and begin to set timer off. At this time, the icon of timer off and hours of timer off will flashing.
Page 22 Step 5: Press Increase or Decrease button to set required minutes of timer off. Finally, press the Timer button again to confirm the timer offsetting and exit the timer setting. Notes: Once timer on/off is successfully set, the icons of timer on and off will be displayed. Canceling timer setting - In the process of timer on/offsetting, press the Set button, and all the timer setting will be canceled.
Page 23: Troubleshooting
Heat Pump Model Legionella control WH265A-R The legionella weekly boost will occur between 1-7am once per WH265A-RE week The sensor located with at least 90%of tank volume above it has WH315A-R a 61 deg set point and a 1k dead band...
Page 24 6.3 Error phenomenon shooting Possible reason Error phenomenon Solution Bad connection between power Plugin again. supply plug and socket. Cold water tapped out and display Setting water temperature is too low. Set the water temperature higher. screen extinguished Temperature sensor or PCB is Contact service center.
Page 25: Maintenance
Code Description Corrective action Check the low pressure switch connection is not well. Check if pressure switch is broken. Check if refrigerant system is block. Low pressure protection Check for leakage in refrigerant system to repair. Check refrigerant volume isn’t too low. Replace PCB if broken.
Page 26: Specifications
Every 1 year ensure that water can be flowed out. PTR valve If water does not flow freely when operating the handle, replace PTR valve with a new one. 8. Specifications Model WH265A-RE WH265A-R WH315A-RE WH315A-R WH265A-CE WH265A-C WH315A-CE WH315A-C...
Page 27: Maintenance
Information on servicing WARNING BEFORE CARRYING OUT MAINTENANCE OPERATIONS, PLEASE CAREFULLY READ THE FOLLOWING INSTRUCTIONS AND STRICTLY FOLLOW THE INSTRUCTIONS. PLEASE OPERATE STRICTLY ACCORDING TO THE REQUIREMENTS, OTHERWISE IT MAY CAUSE PERSONAL INJURY OR DEATH ACCIDENTS. DD.4.2 Checks to the area Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimized.
Page 28 DD.4.9 Checks to the refrigerating equipment Where electrical components are being changed, they shall be fit for the purpose and to the correct specification. At all times the manufacturer’s maintenance and service guidelines shall be followed. If in doubt, consult the manufacturer’s technical department for assistance. The following checks shall be applied to installations using flammable refrigerants: –...
Page 29 DD.8 Detection of flammable refrigerants Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks. A halide torch (or any other detector using a naked flame) shall not be used. The following leak detection methods are deemed acceptable for all refrigerant systems. Electronic leak detectors may be used to detect refrigerant leaks but, in the case of flammable refrigerants, the sensitivity may not be adequate, or may need re-calibration.
Page 30 Operation guide diagram for remove refrigerant Operation guide diagram for vacuum DD. 1 0 Charging procedures In addition to conventional charging procedures, the following requirements shall be followed. • Ensure that contamination of different refrigerants does not occur when using charging equipment. Hoses or lines shall be as short as possible to minimized the amount of refrigerant contained in them.
Page 31 •Charge according to the rated refrigerant weight on the nameplate, Extreme care shall be taken not to overfill the refrigerating system. Prior to recharging the system, it shall be pressure-tested with the appropriate purging gas. The system shall be leak-tested on completion of charging but prior to commissioning. A follow up leak test shall be carried out prior to leaving the site.
Page 32 DD.12 Labelling Equipment shall be labelled stating that it has been decommissioned and emptied of refrigerant. The label shall be dated and signed. For appliances containing flammable refrigerants, ensure that there are labels on the equipment stating the equipment contains flammable refrigerant. DD.13 Recovery When removing refrigerant from a system, either for servicing or decommissioning, it is recommended good practice that all refrigerants are removed safely.
Page 33: Wifi Connection
10. WIFI connection 10.1 Search "Tuya Smart" in APP store, download and install it, turn on Bluetooth on your mobile phone and connect to WIFI (the software only supports 2.4 GHz WIFI). 10.2 Software registration and configuration 10.2.1 RegistrationW Users without an account can click "Register" to create an account: Register →...
Page 34 Login If you have an existing account, you can log in directly. 10.2.2. WIFI module configuration steps Step 1: When power is on, press and hold for 3 seconds at the same time to enter the intelligent distribution network mode, the icon flashes, and the mobile phone can start network distribution ;...
Page 35 Step 3: Open "Tuya Smart" APP, login to enter the main interface, click "+" on the upper right corner or "Add Device" on the interface, generally you will be prompted to add a device, just click "Add". If you cannot add it, you need to set it manually, enter the device type selection, select "Water Heater"...
Page 36 10.3 Software function operation After the device connects successfully, enter the operation interface of "Water Heater" (device name modifiable) On the main interface of "Tuya Smart", click "Water Heater" to enter the operation interface. (1) Back (2) More : You can change the device name, select the device installation location, check the network status, add shared users, create device groups, view device information, etc.
