ELEKTROPLANET AiO CITY BIKE Installation And Operation Manual

Dimensional drawing
92 134
Technical parameters
Housing steel
Standard color Black - structure
Degree of protection IP65
Impact Resistance IK08
Installation ground
Power source 3 solar panels
Light source LED 1W
Batteries Li-Ion, 2x2200mAh, 3,7V
Active time 5-300s (adjustable)
Loading time dependent on weather conditions
Warning!
Damage caused by failure to follow the instructions results in warranty void. We do
not assume responsibility for consequential damages. This user manual must be
thoroughly read before starting to use the product.
Installation
No wires are required for the operation of the AiO CITY BIKE luminaire.
Optimal location
The luminaire should be placed in a location with an open view of the sky,
avoiding trees and other overhangs to ensure full exposure to sunlight. It is also
Maintenance
The device require maintenance,
approximately 2 years.
Solar panels should be kept free from contaminants to ensure optimal sunlight
capture.
Spare parts
To ensure proper operation of the luminaire, only original replacement parts should
be used, especially for the control system, solar panels, and, if necessary, batteries!
(SE-SOL-116-74-01)
(ME-BAT-00008)
battery replacement after
AiO CITY
BIKE
INSTALLATION AND OPERATION MANUAL
