BMP EASY 01 User Manual

Automation control window door
Hide thumbs

Advertisement

Table of Contents

Automation Control WINDOW DOOR
The equipment controls, via inverters, all industrial locks equipped with MOTORS THREE-PHASE
ELECTRIC MOTORS.
Acceleration, deceleration ramps, electric brake and working times are controlled; all parameters
can be set via display interface or by self-learning.
The board provides operation with limit switches (FCA and FCC) and encoders. Slowing down
opening and closing and photocell exclusion is done by counting the working time and/or
revolutions of the
rotating.
The board via microcontroller controls the working current of the motor and the temperature of
the heatsink of the schedad4, providing for signaling and handling of any malfunctions.
All inputs are signaled via LEDs
Alarm signals are indicated by the flashing LAMP_RGB and LED on cover
The control board is powered at 230Vac
Accessories: 12Vdc/500mA MAX output.
The motor characteristics are given below:
Engine
The equipment has 230Vac-50Hz power supply input.
Low-voltage isolated inputs for control and safety accessories
Output for accessory power supply 12Vdc/500mA max.
Connection with ESP_OUT board
connection with LAMP_RGB board
Connection with UPS
Output for three-phase motor power supply 230Vac
Output for 105Vdc electrobrake power supply
Output for flashing power supply clean contact/40W MAX
User's Manual EASY_01
1. Inputs-Outputs
1
V
230 V THREE-PHASE
230 V THREE-PHASE
CONNECTION
Triangle
Triangle

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EASY 01 and is the answer not in the manual?

Questions and answers

Summary of Contents for BMP EASY 01

  • Page 1 User's Manual EASY_01 Automation Control WINDOW DOOR The equipment controls, via inverters, all industrial locks equipped with MOTORS THREE-PHASE ELECTRIC MOTORS. Acceleration, deceleration ramps, electric brake and working times are controlled; all parameters can be set via display interface or by self-learning. The board provides operation with limit switches (FCA and FCC) and encoders.
  • Page 2 Update sw via trastier with micro SD (formatted FAT32 if new), capacity maximum SD 2Gb, update file name: inv_star.enc (without folders) NET FUSE NETWORK INPUT POWER SUPPLY Led indicatore scarica MOTOR OUTPUT condensatori BUS THREE-PHASE FLASHING OUTPUT Led activity (DRY CONTACT) microcontroller BRAKE OUTPUT DIP SWITCH...

  • Page 3: Limit Switch

    3. Terminals/connections Clamp CONNECTION N° Power supply output +12Vdc Power supply output 0 Vdc (-) Communication serial Anti-jamming sensor Pedestrian Start (Opening with UPS) Input common (+12Vdc) Photocell Limit switch Open FCA/ Channel A (encoder) N.C. Limit switch Closes FCC/ Channel B (encoder) N.C.
  • Page 4 4. ESP_OUT interface card connection Connect the inverter to the interface board via RJ11 cable and enable communication by putting DIP4-ON (on ESP_OUT board)
  • Page 5 Not used Not used Pedestrian entrance Pedestrian entrance standard becomes entrance closes man present Negative brake Positive brake Communication Off Communication On By enabling DIP2 in on, the close command is via pedestrian man present (enabling this function does not allow UPS management) Output operation based on door operation Relay outputs CONTACT...
  • Page 6 5. COLLEGAMENTO LAMP_RGB...

  • Page 7: Ups Connection

    6. UPS CONNECTION Before installing, check that there is no power supply. Connect the ups as in the figure Enable operation with ups by setting dip2 of SW1 to ON. To give the open command for power failure, mount a 230V N.C.(K) relay with contact on input 12 and coil in parallel on line voltage By enabling this function, ESP_OUT cannot be managed.
  • Page 8 7. Led/buttons on front of box BUTTON PROGRAMMING P2 BUTTON CLOSE P3 BUTTON OPEN P1 LDS LED STATUS INDICATION DOOR/ERRORS STATUS SIGNALLING SIGNALLING DOOR LED IN OPERATION LED IN LEARNING CLOSED GREEN FIXED GREEN FIXED (on limit switch) BLINKING BLINKING OPENING BLINKING RED RED/VERDE...

  • Page 9: Error Code

    8. ERROR CODE The error code is indicated by the LDS LED on metal box cover: 1 GREEN blink followed by many RED blinks corresponding to the error number.
  • Page 10 ES: error 3 = 1 green and 3 red flashes In case of encoder programming, errors cod: 9/10 occur occur when the encoder fails to adjust itself via the photocell after the inverter is turned off. 9. POSITION LEARNING AUTOMATIC CLOSING(LIMIT SWITCH) Action Description Close the door to the limit switch.
  • Page 11 AUTOMATIC CLOSING (ENCODER) Action Description Close the door to the limit switch. Push button panel led: steady green. Press PRG for 5s. Button panel led: flashing green/red. Bring the curtain up to the open door position and press PRG button. Button panel led: flashing red.
  • Page 12 PEDESTRIAN (LIMIT SWITCH/ENCODER) Action Description Close the door to the limit switch. Push button panel led: steady green. Press PRG for 5s. Button panel led: flashing green/red. Pedestrian press Button panel led: flashing red. Pedestrian press Button panel led: steady red. Pedestrian press Button panel led: flashing green/red.

  • Page 13: Declaration Of Conformity

    EN60034, EN60335-1, EN 60335-2-41, EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3, EN 61000-3-4, EN 61000-3-12, EN292-1, EN292-2, EN50-178 Quality products since 1997 BMP EUROPE HIGH SPEED DOORS Strada della Freisa 1 - Villanova d’Asti 14019 (AT) +39 0141 948843 www.bmpdoors.com - info@bmpeurope.eu...
