Voice Caddie T11 PRO Instructions Manual

Hide thumbs Also See for T11 PRO:

Advertisement

Quick Links

Download this manual
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the T11 PRO and is the answer not in the manual?

Questions and answers

Related Manuals for Voice Caddie T11 PRO

Summary of Contents for Voice Caddie T11 PRO

  • Page 3 The smartest round with T11 PRO 1. Starting Golf Mode Starting the Golf Mode with a touch of a button.  2. Automatic Golf Course Recognition Automatically find the golf course by your location ...
  • Page 4 3. Hole Information and Tee Shot Guide Once you arrive at the tee box, the system  will automatically recognize the hole and provide you with essential information. *User Tips* Distance to the pin: 385y * My driver distance is about 219y, but there are two bunkers at the landing area.
  • Page 5 4. Check the green undulation on your approach In locations where on-green is required, the slope of the green  automatically changes to a guided approach view. *User Tips* This hole is a front pin and downhill to the pin. I am going to play behind the pin to be safe.

  • Page 6: Device Outline

    1. Swipe down for Bluetooth connection screen 2. Touch the slide bar to turn the Bluetooth on 3. Check T11 PRO device ID 4. Confirm matching security code on both the device and the app. * Calls/text/SNS notification, APL (Real-Time Pin Location), Quick GPS, Score Management, Golf Course Database and Firmware Update available when connected to MVC App.
  • Page 7 T11 PRO Charging Clean the charging terminal with a cotton swap to keep it contaminant-free. Charging on a contaminated terminal may cause malfunction and damage. 1. Connect the USB (Type-C) cable to the charging cradle. (USB cable sold separately) 2. Place the device on the cradle correctly aligned to connect...

  • Page 8: Watch Face Screen

    Clock Mode Watch Face screen In the clock mode, swipe up/down/left/right to enter other modes.
  • Page 9 Watch face change 1. Touch and hold the watch face to enter the watch face settings mode. 2. Change the watch face by swiping left or right. 3. Change the color by touching the middle of the screen. 4. Touch Confirm to complete the change. Main menu Golf Mode / Scorecard / Settings / Tempo Pedometer...

  • Page 10: Screen Brightness

    Bluetooth 1. Bluetooth On 2. Bluetooth Off Screen brightness 1. Auto : Adjust the screen brightness to your environment automatically. 2. Manual: Manually adjust screen brightness. (5 Levels)
  • Page 11 Settings 1 Golf Settings 1.1 Hole Change: You can change the hole when you want to preview another hole in golf mode. 1.2 Units of Measurement: You can select between m/km, yard/mile, yard/km 1.3 Scoring - Advance Mode: Enter categorized score (shots, putts, penalty) - Simple Mode: Enter the number of strokes for the hole...
  • Page 12 1.4 Slope - On: Use complete functions of T11 (Displays slope adjusted distance) - Off: Displays straight distance. (Adjusted distance Off, Green Undulation Off) 1.5 Club Settings - Driver distance: Enter the user's driver distance to view the expected landing area in the Course View. - Club Recommendation: When selecting a user IP by touching the course map in the course view, we recommend a club that matches the distance.
  • Page 13 1.8 Golf Mode Screen Settings - Basic: Displays the Default screen recommended by Voice Caddie in Golf Mode. - Custom: Displays the screen set by the user in MVC (app) in golf mode. 1.9 Red Tee Box - On: Displays the Big Data information (Fairway Hits/GIR) based on the Red Tee Box.
  • Page 14 - Automatic: Adjusts OLED brightness automatically. - Manual: Adjusts OLED brightness manually. 1.13 Reception notifications - Preview : On: Preview smartphone notifications in T11 PRO. Off: Do not display previews of smartphone notifications in T11 PRO - Vibration On: Vibrates when a notification is received.
  • Page 15 1.18 Time (Displays local time when connected to GPS in Golf Mode) - Date: Set the date. - Current time: Set the current time. - Time format: 12 hours/24 hours format. - DST: Turn the Daylight Savings Time On or Off...

  • Page 16: Golf Mode

    Golf Mode (UI may be deleted or changed due to firmware update.) Entering Golf Mode Touch the golf mode icon to recognize the hole automatically after GPS reception. - Enable Start Right Away Golf Mode: Golf mode starts immediately when the power is turned on. - Disable Start Right Away Golf Mode: Touch golf mode in the main menu.
  • Page 17 Golf Mode Screen Navigation Swipe the screen left or right to switch views. (Putt view is activated when on the green) For golf courses without course/green  maps, a yardage view will be displayed on the screen.  Images may vary depending on the region and specific golf course conditions.
  • Page 18 Golf Mode Screen Description Course View ① Shot & Putt Indicator: Automatically recognizes and displays shots and putts. ② Dual Pin Arc: Displays the distance of 50m/100m from the pin to help you attack the course. (You can change the distance in MyVocieCaddie (APP)) ③...
  • Page 19 Smart Features of Course View ① USER IP: Touching strategic points on the course map displays the distance from the current position to the strategic point and from the strategic point to the pin. ② Bunker/Hazard Information: Touching bunkers or hazards displays the distance from the current position to the front of the bunker and to the back of the bunker.
  • Page 20 ④ Wind Direction/Speed : Tap the wind direction/speed icon of the current location to check the wind direction/speed information (MVC (app) connection required) ⑤ Distance Icon: Displays the distance of the previous shot, and touching it allows you to check the tempo and distance of the previous shot.
  • Page 21 Approach Veiw ① Back of the Green from Pin ② Green Slope Arrows: Calculates and displays areas with significant slopes using arrows. ③ Green Undulation: Displays green undulation using a 58-step scale ④ Front of the Green from Pin ⑤ Distance from Current Position to Front of the Green ⑥...
  • Page 22 Smart Features of approach View 1. Active Green Automatically rotates the green based on changes in the golfer's position. 2. Pin Position Adjustment Manually moves the pin position by touching the green. 3. Green Enlargement Pop-upTouch the green for a long time to enter the enlarged pop-up. You can see the size of the green and the overall slope at a glance.
  • Page 23 Putt View ① Pin icon: touching it moves the pin to your location. ② Current Pin Location ③ Slope Lines from Ball to Pin ④ Ball Fix Icon: Fixes the ball in place so that the distance from the ball to the pin does not change even if your position changes.
  • Page 24 Smart Features of Putt View 1. Ball Icon - Ball Fixation 1) Touching the ball icon on the screen fixes the ball to the current position. 2) Touching the green fixes the ball to that point. Ball Unfix: Touching the ball icon (lock) releases the ball fixation.

  • Page 25: Quick Menu

    3. Putt Guide When the distance between the pin and the ball is more than 5 m when fixing the ball , we will guide you to aim for a long putt. - Aim at the hole - Aim Left/Right of the hole cup. - Aim Left/Right, one club or more.
  • Page 26 Green Pointing : Points like a compass in the center of the green, and is useful when used on a course where the pins are not visible. 3. Flashback: Displays previous records of the course for reviewing the last round. (Requires MVC (App) connection & previous records of the same golf course) 4.
  • Page 27 - Move View: Move Course View/Approach View/Putt View in order.(Putview is activated only when the user enters the green) - Quick Menu: Go to Quick Menu. - Score: Moves to the score recorded so far and can be modified. - Club Input: Goes to the club input of the previous shot. - No setting: No action.
  • Page 28 2. Shot Feedback Popup Automatically recognizes shots and allows you to check the tempo. * Enter Club: Touch Enter Club to enter the club of the previous shot.(MVC (app) connection required: You can check the distance/tempo statistics for each club, and we recommend the exact club that suits the golfer with the distance average for each club.) 3.
  • Page 29 SCORECARD View saved scorecard records. 1. Up to 200 records can be stored, and when exceeding 200, older records will be deleted. 2. When connected to MVC (App), scorecard records are automatically transmitted, and you can view scorecards, score statistics, tee shot tempo, shot tracking, and other information on the MVC (App).
  • Page 30 swings. Select the Tempo Practice mode from the menu screen to practice. Why is tempo important? A consistent tempo will help you get each step of your swing exactly and timing it right. Too fast or too slow a tempo can cause you to lose balance during your swing, which can lead to inaccurate shots.
  • Page 31 T11 PRO Product Specifications Product Name Low Power Wireless Device (Wireless Data Communication System) Model Name T11 PRO V-Algorithm™, Flashback, Action Key, Putt Guide, Course Preview, Putt Main Functions View, Real Green Undulation, Shot & Putt Tracking, Automatic Shot Marking, Weather, MyVoiceCaddie App Support Watch: 50.0mm x 50.0mm x 15.65mm / 46.3g Charging Cradle:...
  • Page 32 T11 PRO Quality Guarantee This product is produced through strict quality management and thorough inspection processes. According to the Consumer Compensation Regulation of the Korea Consumer Agency, we compensate consumers for legitimate damages. If a malfunction occurs during the warranty period under normal usage conditions, free service is available.
  • Page 33 Caution Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the • receiver is connected. Consult the dealer or an experienced radio/TV technician for help. •...

  • Page 34: Warranty

    Caution This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FEE Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 35: Product Warranty

    Customers can return or exchange the product within 14 days of Exchange Policy: purchase, provided it's in unused condition. T11 PRO Battery Life ㆍWatch Mode: Approximately 2 days ㆍGolf Mode: Approximately 36 holes ㆍBattery life may vary depending on usage and environment.
