Summary of Contents for Franklin Electric EVO Series
- Page 1 FUELING SYSTEMS EVO™ SERIES GRID SOLUTIONS LCD TOUCHSCREEN EV SYSTEMS I N S T A L L G U I D E 10000017488 r1 MODEL NUMBER EVO-LCD...
- Page 2 Copyright © 2024 Franklin Electric Co., Inc., Madison, WI 53718. All world rights reserved. No part of this publication may be stored in a retrieval system, transmitted, or reproduced in any way, including, but not limited to, photocopy, photograph, magnetic, or other record, without the prior written permission of Franklin Electric.
-
Page 3: Table Of Contents
Contents 1 Introduction ........................1 1.1 Documentation ......................1 1.1.1 Symbol Legend ....................1 2 Safety/Security ........................2 2.1 General Safety Information..................2 2.2 Installation & Service Access ..................2 2.3 Documentation Availability ..................2 2.4 Hazard Assessment ....................3 2.5 Required Personal Protective Equipment (PPEs) ............3 2.6 Cyber Security ......................3 2.7 Qualifications and Responsibilities ................4 2.7.1 Qualifications for Programming ...............4 2.7.2 Responsibilities ....................4... - Page 4 Intentionally Blank...
-
Page 5: Introduction
• The Illustrations depict a typical setup and are for instruction and description purposes only. • It is the installer’s responsibility to ensure that correct and safe procedures are followed at the worksite. • This document and related documents are available from Franklin Electric at www.franklinfueling.com. 1.1.1 Symbol Legend... -
Page 6: Safety/Security
The station owner or operator of the console is only allowed to access the user interface. Access to areas internal to the console is prohibited. *If your console is serviced by someone who is not a Franklin Electric certified installer, service (technician), or programmer, your warranty will be void. -
Page 7: Hazard Assessment
The manufacturer, Franklin Electric, and its affiliates are not liable for damages and / or losses related to such security breaches, unauthorized access, interference, intrusion,... -
Page 8: Qualifications And Responsibilities
Qualifications and Responsibilities 2.7.1 Qualifications for Programming Online Training Certification To be considered “qualified”, a technician shall possess the following applicable Controller Specialist certification criteria: • EVO™ 600/6000 Installation & Wiring • EVO™ 550/5000 Installation & Wiring 2.7.2 Responsibilities SCAN / CLICK The following responsibilities are for guidance only and are not limited to those listed here. -
Page 9: Installation
• Check all items for damage. • If any item shows damage or is not Figure 1 in accordance with the order, inform Franklin Electric immediately. • Confirm the existing Interface Board of the EVO™ console is REV 5 or higher. Required Tools... -
Page 10: Pre-Install Replacement Lcd Prep
Pre-Install Replacement LCD Prep 1. Turn the LCD over and gently lift and swivel the black plastic connector upwards 90° to ensure it is open. It should be perpendicular to the board. • Connect the ribbon cable by inserting it into the black plastic connector* and then lightly press down on the connector until the cable is secure. -
Page 11: Installing Replacement Display
Installing Replacement Display 1. Remove power to the EVO™. Perform all necessary safety steps as required by federal, state and local regulations in relation to working with electrical equipment (lockout / tag out). Figure 5 – Electrical lockout. 2. Open the EVO™ console door (Figure 6a). 3. - Page 12 4. Determine if the EVO™ console has a NEW style Interface Board, REV.4 (or higher – Figure 7) or REV.3 (or lower – Figure 8). • Replace the existing interface board if it is REV.3 (or lower) or if it is damaged. Figure 7 –...
- Page 13 8. Grasp the LCD and gently pull it towards you while carefully prying the tabs from the LCD frame (Figure 10). After the display is unlatched from the tabs, continue pulling it towards you to remove it. Figure 10 – Lift LCD and remove. Installing the New LCD Display 9.
- Page 14 11. Plug the display cable into the J5 connector ( ) and push the sides of the black plastic push tab upwards to secure the connection. (Figure 13). 12. Plug the white plastic connector into the J4 backlight connector ( ) (Figure 13). 13.
-
Page 15: Troubleshooting
NOTE: The black plastic connector for the ribbon cable is breakable and requires caution when handling. If broken, the display will require replacement (Figure 15). Figure 15 • If this does not resolve the issue, contact Franklin Electric Technical Support... -
Page 16: Care And Maintenance
Care and Maintenance WARNING: Only Franklin Electric certified technicians are authorized (see § 2.2) to open the EVO™ console. Electrical hazards exist and injury or death may occur if the console interior is accessed by unauthorized personnel. Console Care Gently wipe the outer areas of the console using a soft, damp cloth to eliminate any residue or buildup. -
Page 17: Appendix
Appendix Related Documents Documentation can be found online at www.franklinfueling.com. Part Number Description 000-2173 TS-550 / 5000evo® Programming Guide 000-2170 TS-550 / 5000evo® Installation Guide 228180033 EVO™ 600/6000 Series Installation Guide 228180061 EVO™ 600/6000 Series Programming Guide 10000002562 EVO™ 600/6000 Series Operation Guide... -
Page 18: Notes
Notes... - Page 20 FUELING SYSTEMS GRID SOLUTIONS EV SYSTEMS 10000017488 r1 August 13, 2024...
