- Page 1 Tumble dryer WT46G4000W User manual and installation instructions Register your product on My Siemens and discover exclusive services and offers. siemens-home.bsh-group.com/welcome The future moving in. Siemens Home Appliances...
-
Page 2: Table Of Contents
Futher information and explanations are available online: Table of contents 1 Safety ........... 4 9 Programmes ...... 22 1.1 General information.... 4 9.1 Automatic programmes... 22 1.2 Intended use...... 4 9.2 Timed programmes .... 23 1.3 Restriction on user group.. 4 10 Accessories...... 25 1.4 Safe installation ...... - Page 3 15 Basic settings...... 33 15.1 Overview of the basic set- tings........ 33 15.2 Changing the basic set- tings........ 34 16 Cleaning and servicing ... 34 16.1 Tips on cleaning and care .. 34 16.2 Base unit ....... 34 16.3 Moisture sensor..... 36 17 Troubleshooting...... 38 18 Transportation, storage and disposal ........ 42...
-
Page 4: Safety
en Safety 1 Safety Observe the following safety instructions. 1.1 General information ¡ Read this instruction manual carefully. ¡ Keep the instruction manual and the product information safe for future reference or for the next owner. ¡ Do not connect the appliance if it has been damaged in transit. 1.2 Intended use Only use this appliance: ¡... -
Page 5: Safe Installation
Safety en 1.4 Safe installation WARNING ‒ Risk of electric shock! Incorrect installation is dangerous. ▶ Connect and operate the appliance only in accordance with the specifications on the rating plate. ▶ Connect the appliance to a power supply with alternating cur- rent only via a properly installed socket with earthing. ▶... - Page 6 en Safety WARNING ‒ Risk of injury! The high weight of the appliance may result in injury when lifted. ▶ Do not lift the appliance on your own. If this appliance is not correctly installed in a washer-dryer stack, the installed appliance may fall. ▶...
-
Page 7: Safe Use
Safety en ▶ Wear protective gloves when installing and transporting the ap- pliance. 1.5 Safe use WARNING ‒ Risk of electric shock! If the appliance or the power cord is damaged, this is dangerous. ▶ Never operate a damaged appliance. ▶ Never pull on the power cord to unplug the appliance. Always unplug the appliance at the mains. - Page 8 en Safety WARNING ‒ Risk of poisoning! Condensation water from this appliance is not suitable for drinking and may be contaminated with fluff. ▶ Do not drink or reuse the condensation water from the appli- ance. Detergents and care products may result in poisoning if con- sumed.
-
Page 9: Safe Cleaning And Maintenance
Safety en CAUTION ‒ Risk of injury! The covering plate may break if you stand on or climb onto the appliance. ▶ Do not stand on or climb onto the appliance. The appliance may tip over if you sit on or lean against the open door. - Page 10 en Safety WARNING ‒ Risk of injury! The use of non-original spare parts and non-original accessories is dangerous. ▶ Only use the manufacturer's original spare parts and original ac- cessories. WARNING ‒ Risk of poisoning! Poisonous fumes may be given off if you use cleaning agents that contain solvents.
-
Page 11: Preventing Material Damage
Preventing material damage en Clean the appliance with nothing ▶ 2 Preventing material but water and a soft, damp cloth. Remove all detergent residue, damage ▶ spray residue or other residues im- mediately if they come into contact ATTENTION! with the appliance. The functionality of the appliance may be impaired if you use the wrong quantity of fabric softener, de-... -
Page 12: Energy Saving Mode
en Installation and connection Check the appliance for visible After drying, clean the fluff filter damage. → Page 27. Open the door. a If the fluff filter is dirty, this reduces Remove any accessories from the the air flow in the appliance, ex- drum. -
Page 13: Requirements For The Install- Ation Location
Installation and connection en 4.3 Requirements for the in- Installation loca- Requirements tion stallation location In a washer-dryer Only use the ori- ATTENTION! stack ginal connection If the appliance is tilted at an angle set from the greater than 40°, residual water may dryer manufac- leak out of the appliance and cause turer when set-... -
Page 14: Aligning The Appliance
en Installation and connection 4.4 Aligning the appliance In order to reduce vibrations and noises, align the appliance correctly. To align the appliance, turn the ap- ▶ pliance feet. Check that the appli- ance is level using a spirit level. All appliance feet must stand firmly on the ground. -
Page 15: Familiarising Yourself With Your Appliance
Familiarising yourself with your appliance en 5 Familiarising yourself with your appliance 5.1 Appliance You can find an overview of the parts of your appliance here. On certain models, specific details such as the colour and shape may differ from those pictured. Ventilation opening Maintenance flap on the base unit → Page 34 Fluff filter → Page 27... -
Page 16: Wool Basket
en Familiarising yourself with your appliance 5.2 Wool basket Securing foot Wool basket Insert Tab for securing in the hook 5.3 Control panel You can use the control panel to configure all functions of your appliance and to obtain information about the operating status. Programmes → Page 22 Programme selector → Page 26... -
Page 17: Display
Display en 6 Display The display shows the current settings, options or relevant information. Example: Display Display Designation Description 0:40 Programme dura- Expected programme duration or pro- tion/programme gramme time remaining in hours and time remaining minutes. 1:25 Timed programme The timed programme is set. → "Timed programmes", Page 23 Programme end → "Buttons", Page 20... -
Page 18: Dryness Level
en Display Display Designation Description Dryness level ad- The adjusted dryness level is activated. justed → "Dryness level", Page 21 Crease-reduction The crease-reduction function is activated. function Gentle drying Gentle drying is activated for delicate fab- rics. → "Buttons", Page 19 Quiet drying Quiet drying with no audible signals is ac- tivated. - Page 19 Buttons en 7 Buttons Below is an overview of the buttons and their setting options. Button Selection Description ¡ Start Start, cancel or pause 卉始/添衣 the programme. ¡ Cancel ¡ Pause ¡ Activate Activate or deactivate the 按3秒童縯 childproof lock. ¡ Deactivate Disable the control panel to prevent unwanted or accidental operation.
- Page 20 en Buttons Button Selection Description Up to 24 hours Set the programme end 预约 time. The programme duration is already included in the set number of hours. Once the programme has started, the pro- gramme duration is dis- played. Multiple selection Set the programme dura- 定时程序...
-
Page 21: Adjusting The Dryness Level
Dryness level en 8 Dryness level Each automatic programme has a specified dryness level. The dryness level defines how dry or damp your laundry is after the programme ends. Dryness level Laundry Drying result Normal, single-layered The laundry is dry. laundry. Normal, single-layered The laundry is still slightly damp. -
Page 22: Programmes
en Programmes 9 Programmes You can dry your fabrics using either an automatic programme or a timed pro- gramme. 9.1 Automatic programmes Automatic programmes are pro- Tips grammes in which humidity sensors ¡ Select the dryness level according measure the residual moisture in the to the type of fabric or the desired laundry during the drying cycle. -
Page 23: Timed Programmes
Programmes en Programme Description Max. load (kg) Hygiene Dry hard-wearing, heat-resistant fabrics made of cotton or linen. Note: Particularly suitable for strict hy- giene requirements. Jeans Dry jeans and thick, double-layered items made of cotton. Note: Turn laundry inside out before dry- ing. Sportswear Dry self-drying sportswear made of per- formance fibres, microfibres and synthet-... - Page 24 en Programmes Programme Description Max. load (kg) Cold Dry all types of fabric except for wool and silk. Also suitable for freshening up or airing clothing that has hardly been worn. Note: This programme is suitable for dry- ing using the wool basket. → "Wool basket", Page 30 Warm Dry all types of fabric except for wool and...
-
Page 25: Accessories
Accessories en 10 Accessories Use original accessories. These have been made especially for your appli- ance. Note: Some accessories are avail- able in other colours. Contact → "Customer Service", Page 43. Order number Connection kit with pull- To save space, stack the WZ2742S out worktop appliance on a suitable washing machine of the same width and depth... -
Page 26: Laundry
en Laundry 12.2 Setting a programme 11 Laundry Turn the programme selector and set the required programme. 11.1 Preparing the laundry → "Programmes", Page 22 If required, adjust the programme ATTENTION! settings. Objects remaining in the laundry may damage the laundry and the drum. 12.3 Loading laundry Remove all items from any pock- ▶... -
Page 27: Changing The Activated Programme End Time
operation en 12.5 Changing the activated 12.9 Switching off the appli- programme end time ance You can repeatedly change the set Turn the programme selector to ▶ and activated programme end time before starting the programme. 12.10 Fluff filter Requirements ¡ The programme is set. During drying, fluff from the laundry is → "Setting a programme", Page 26 collected in the fluff filter. - Page 28 en operation Remove the fluff filter. Remove the fluff. Remove the fluff from the recess. Clean the fluff filter thoroughly un- der warm, running water and then dry it off. Ensure that no fluff falls into the air channel. Open the fluff filter. Close the fluff filter.
-
Page 29: Condensation Container
operation en Insert the fluff filter. Pull out the condensation con- tainer, keeping it level. Close the door. Empty the condensation container. 12.11 Condensation con- tainer Condensation forms during drying, which your appliance uses for auto- matic cleaning. By default, the con- densation is collected in the appli- ance's condensation container. -
Page 30: Childproof Lock
en Childproof lock Inserting the condensation 14 Wool basket container Push the condensation container Use the wool basket to gently dry ▶ in as far as it will go. delicate fabrics, soft toys or sports shoes in a stationary position. Note: You can order this optional → "Accessories", Page 25 from our customer service. -
Page 31: Starting A Programme With The Wool Basket
Wool basket en 14.2 Starting a programme Laundry item Programme duration in with the wool basket hours:minutes ATTENTION! Thin woollen Approx. 1:20 If items of laundry in the wool basket pullover touch the rotating drum or the ribs of Thick woollen Approx. 1:30 - the drum, the laundry may cause ma- pullover 3:00... - Page 32 en Wool basket Example Pullover Sports shoes Lift the tongues of the shoes. Remove the in- soles or heel cushions. Place a rolled-up hand towel in the wool basket to create an in- clined surface. Place the shoes on the towel with the heels facing down.
-
Page 33: Basic Settings
Basic settings en 15 Basic settings You can configure the basic settings for your appliance to meet your needs. 15.1 Overview of the basic settings Basic setting Programme Value Description position End signal 0 (off) Set the volume of the signal at the 1 (quiet) end of the programme. -
Page 34: Changing The Basic Set- Tings
en Cleaning and servicing 15.2 Changing the basic set- nothing but water and a damp tings cloth. Set the programme selector to po- Remove all de- Fresh deposits sition 1. tergent residue, are easier to re- spray residue or move without other residues leaving any immediately. - Page 35 Cleaning and servicing en Open the lever for the heat ex- Clean the heat exchanger cover changer cover. under running water and dry it. Make sure that you remove all dirt Pull out the heat exchanger cover from the seal. by the handle. Pull out the heat exchanger hori- zontally.
-
Page 36: Moisture Sensor
en Cleaning and servicing Clean the opening with a soft, Insert the heat exchanger cover by damp cloth. the handle. Slide the heat exchanger in hori- Close the lever for the heat ex- zontally as far as it will go. changer. Ensure that the heat exchanger is Close the maintenance flap. - Page 37 Cleaning and servicing en ance changes the duration of the Note: If you do not clean the appli- automatic programme depending on ance as described, the appliance's the residual moisture in the laundry. functionality may be impaired. Open the door. Cleaning the moisture sensor Clean the moisture sensor with a Over time, residue from limescale, sponge.
-
Page 38: Troubleshooting
en Troubleshooting 17 Troubleshooting You can rectify minor faults on your appliance yourself. Read the troubleshoot- ing information before contacting after-sales service. This will avoid unneces- sary costs. WARNING Risk of electric shock! Incorrect repairs are dangerous. Repairs to the appliance should only be carried out by trained specialist ▶... - Page 39 Troubleshooting en Fault Cause and troubleshooting Creasing. Activate the Anti-Crease function. ▶ → "Buttons", Page 19 and programme Condensation tank filled. terminated. → "Emptying the condensation container", Page 29. → "Inserting the condensation container", Page 30. → "Starting the programme", Page 26. Water drain hose is caught or jammed. Ensure that the water drain hose is not kinked or trapped.
- Page 40 en Troubleshooting Fault Cause and troubleshooting The drying time is too Fluff filter is soiled. long. → "Cleaning the fluff filter", Page 27 ▶ The ambient temperature is greater than 30 °C. Ensure that the appliance is only operated in a well ▶ ventilated location.
- Page 41 Troubleshooting en Fault Cause and troubleshooting The laundry is too Drying target not adjusted. damp. → "Adjusting the dryness level", Page 21. ▶ Load too small. Set a timed programme for the subsequent drying. ▶ → "Programmes", Page 22 Moisture sensor dirty. → "Cleaning the moisture sensor", Page 37. ▶...
-
Page 42: Transportation, Storage And Disposal
en Transportation, storage and disposal 18.2 Disposing of old appli- 18 Transportation, stor- ance age and disposal Valuable raw materials can be re- used by recycling. 18.1 Preparing the appliance for transportation WARNING Risk of harm to health! Tip: The appliance may contain re- Children can lock themselves in the sidual water, which may drip out of it appliance, thereby putting their lives when transported. -
Page 43: Customer Service
Customer Service en Weight 41.1 kg 19 Customer Service Maximum load 8.0 kg Detailed information on the warranty Mains voltage 220-240 V, period and terms of warranty in your 50 Hz country is available from our after- Minimum in- sales service, your retailer or on our stallation protec- website. - Page 44 en Applicable standard GB 17625.1 Electromagnetic GB 4706.20 Safety of house- compatibility – hold and similar Limits – Limits electrical appli- for harmonic cur- ances – Particu- rent emissions lar requirements (equipment input for tumble dryers current ≤16 A per phase)
- Page 48 BSH Hausgeräte GmbH Carl-Wery-Straße 34, 81739 München, GERMANY 总经销商：博西家用电器（中国）有限公司 地址： 中国江苏省南京市鼓楼区清江南路18号3幢 客户服务热线：400 889 9999 客户服务电子邮箱： careline.china@bshg.com siemens-home.bsh-group.cn Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG *9001791327* 9001791327 (030124)
