Summary of Contents for schweisskraft EG 1
- Page 1 Operating Instructions Electrode Grinder EG 1 EG 1...
-
Page 2: Table Of Contents
Passing on as well as copying of this document, the use and distribution of its content are prohibited if not explic- itly permitted. Contraventions are liable to compensa- tion. Subject to technical modifications and error. EG 1 | Version 2.06 | EN... -
Page 3: Introduction
This combination of symbols and signal words indica- tes a possibly dangerous situation which may lead to death or severe injuries if they are not avoided. EG 1 | Version 2.06 | EN... -
Page 4: Responsibility Of The Operator
Protective goggles protect the eyes from flying parts. ved. The following applies in particular: Hearing protection Hearing protection protects the ears from hearing damage caused by noise. EG 1 | Version 2.06 | EN... -
Page 5: General Safety Regulations
Intended Use Intended Use Protective gloves The electrode grinder EG 1 is solely intended for the pur- The protective gloves protect the hands from sharp- pose of grinding standard TIG welding electrodes.. The edged components, as well as from friction, abrasi- device is only to be used for electrode diameters of 1.0... -
Page 6: Technical Data
- Collets for electrodes 1.6 / 2.4 / 3.2 mm - Allen key 2 mm - Allen key 4 mm - Open-end wrench 13/17 - Open-end wrench 13/14 - Disposal bag for disposable filters - Plastic case EG 1 | Version 2.06 | EN... -
Page 7: Description Of Device
Description of device Description of device 6.1 General view Fig. 2: Description of device EG 1 EG 1 | Version 2.06 | EN... -
Page 8: Side View
Description of device 6.2 Side view Fig. 3: Holder EG 1 6.3 Collet Stop (14A) Electrode holder (5) Collet (16) Collet Electrode diameter Tungsten electrode Fig. 4: Collet EG 1 EG 1 | Version 2.06 | EN... -
Page 9: Mounting And Commissioning
When operating the EG 1 ma- chines, you must ensure correct ventilation across the entire filter area. If the EG 1 is to be operated when sta- tionary in a fixed, clamped support, it must be moved into the horizontal position. -
Page 10: Start-Up
(Pos. 5, Fig. 3 & Fig. 4) is reached. on the diamond grinding disk (Pos. 3, Fig. 3). EG 1 | Version 2.06 | EN... -
Page 11: Safety Precautions For Tungsten Electrodes Containing Thorium Oxide
- Replacing the grinding disc dance with EN 149. - Purging the grinding head The protective earth connection on the motor`s front end plate is subject to the test specification laid down by DIN VDE 0702T.1. EG 1 | Version 2.06 | EN... -
Page 12: Filter Replacement
Step 6: Push new grinding disc (Pos. 3, Fig. 3) onto shaft doubt, please contact your municipal waste disposal. As end and tighten. necessary, a specialized waste disposal company can help be used for the treatment. EG 1 | Version 2.06 | EN... -
Page 13: Spare Parts
The supplier shall determine the shipping type if no relevant data was provided. Data on the machine type, item number and year of manufacture is listed on the type plate attached to the device. EG 1 | Version 2.06 | EN... -
Page 14: Spare Parts Drawing
The following spare parts drawing is intended to help identify the necessary spare parts. To order, please send a copy of the list of spare parts with the marked components to your dealer, Fig. 6: Spare parts drawing EG 1 EG 1 | Version 2.06 | EN... -
Page 15: Ec Declaration Of Conformity
DIN EN 60204-1:2007-06 Safety of machinery - Electrical equipment of machines - Part 1: General requirements Responsible for documentation: Kilian Stürmer, Stürmer Maschinen GmbH, Dr.-Robert-Pfleger-Str. 26, D-96103 Hallstadt Hallstadt, 20.10.2020 ______________________ Kilian Stürmer Managing Director EG 1 | Version 2.06 | EN... - Page 16 www.schweißkraft.de...
