Contrive TraxGateway.ETH Quick Start Manual

TM
TraxBus is a dedicated fieldbus specifically designed
to operate in very harsh environments where electrical
noise generated by ignition transformers makes very
difficult to operate for any standard physical layer.
PROFINET® is an industry technical standard for data
communication over Industrial Ethernet, designed for
collecting data from, and controlling equipment in
industrial systems, with a particular strength in
delivering data under tight time constraints.
TraxGateway.ETH allows to control, from PROFINET-IO
controllers, up to 99 burners operated by QBK (Burner
Control Units) in a TraxBus network.
Read and understand this manual before installing, operating, or servicing this unit. This unit must be installed
according to this manual and local regulations. The drawings may show units without covers or safety shields to
illustrate details. Disconnect power supply and follow all usual safety precautions before carrying out any operation
on the device. Be sure to reinstall covers or shields before operating any devices.
The device is not user serviceable, a faulty device must be put out of order and sent back for servicing.
CONTRIVE manufactures products used as components in a wide variety of industrial systems and equipment. The
selection and application of products remain the responsibility of the equipment manufacturer or end user.
CONTRIVE accepts no responsibility for the way its products are incorporated into the final system design. All systems
or equipment designed to incorporate a product manufactured by CONTRIVE must be supplied to the end user with
appropriate warnings and instructions as to the safe use and operation of that part.
Any warnings provided by CONTRIVE must be promptly provided to the end user.
CONTRIVE guarantees for two years from the date of manufacture of its product to replace, or, at its option, to repair
any product or part thereof (except fuses and with some limitations for tubes and photocells) which is found defective
in material or workmanship or which otherwise fails to conform to the description of its sales order. CONTRIVE makes
no warranty of merchantability or any other warranty express or implied. CONTRIVE assumes no liability for any
personal injury, property damage, losses, or claims arising from misapplication of its products.
© 2022 CONTRIVE • B1361.EN
SAFETY INFORMATION
Please perform the following tasks after receiving the TraxGateway:
▪ Inspect the unit for damage. If the unit appears damaged upon
receipt, contact the shipper immediately.
▪ Verify receipt of the correct unit by checking the label on the right
side of the unit.
▪ If you have received the wrong model or the device does not
function properly, contact your supplier.
0523
TraxGateway.ETH
TraxBus to PROFINET CONVERTER
RECEIVING
1
