Do not use powered screw drivers for adjustment.
FITTINGS
2 of M6x35 Socket head machine screw
8 of 4x16 Self tapping screw
1 Allen key
COMPONENTS
A. Bottom mounting plate
B. Rotating cover
C. Upper socket
D. Tube
E. Backing plate
F. Basket
MAINTENANCE
Clean with a soft, dry cloth. Avoid using solvents or abrasive.
TOOLS
A
C
B
D
Storg Elska Lazy Susan
ST22LZP.900.CPWH
E
F
Advertisement
Summary of Contents for Furnware Storg Elska Lazy Susan
- Page 1 Storg Elska Lazy Susan ST22LZP.900.CPWH Do not use powered screw drivers for adjustment. FITTINGS 2 of M6x35 Socket head machine screw 8 of 4x16 Self tapping screw 1 Allen key COMPONENTS A. Bottom mounting plate B. Rotating cover C. Upper socket D.
- Page 2 4 of 4x16 Self tapping screw Attach the bottom mounting plate (A) to the cabinet base in the position shown. Insert the tube (D) in the rotating cover (B), then insert everything into the bottom mounting plate (A).
- Page 3 Screw the upper socket (C) on the top of the cabinet ensuring the post is plumb.
- Page 4 2 of M6x35 Socket head machine screw Insert the basket (F) in the tube, and screw it in place tightening the screw into the backing plate (E).
