Summary of Contents for Green Solutions HOME E5
- Page 1 HOME Document Link: Installation Manual Issue: 1.2 Date: Mar 2024 Installation Manual Date: Apr 2023...
-
Page 2: Table Of Contents
The information included in this manual is accurate at the time of publication. However, this manual is subject to change without prior notice. In addition, the illustrations in this manual are meant only to help explain system configuration concepts and installation instructions. Please note the images shown are for illustration purposes only. -
Page 3: General Information
01 General Information 1.1 Introduction This manual provides the installation instruction of the Green Solution Inc. (referred as GS in this document) residential battery E5 (referred as E5 in this document). Please keep this manual in good condition for later reference. -
Page 4: Product Introduction
1.5 Warning labels Cautions, risk of electric shock. Keep the battery pack away from children. Keep the battery pack away from open flame or ignition sources. The battery pack should not be disposed of with household waste at the end of its working life. The battery pack should be disposed of at a proper facility for recycling. -
Page 5: Product Specifications
2.2 Product specifications 2.2.1 Dimensions and weight Item Measurement Length 726 mm/28.6 in Width 234 mm/9.21 in Height 497 mm/19.6 in Weight 65 kg 2.2.2 Product specifications Item Specifications Nominal voltage 51.2 V Voltage range 40-58.2 V Nominal capacity 100.0 Ah Nominal/Usable energy 5.1/4.9 kWh Max. -
Page 6: Part List
2.3 Part list 2.3.1 Parts included in the package E5 x1 Mounting bracket x1 SEMS screws x2 Floor mounting bracket x2 Used in 3.4.2 Used in 3.4.4 Used in 3.4.5 Part 1 Part 2 Part 3 Part 4 Floor mounting bracket Ground connection nuts 2 m Power cables red x1, 3 m Communication cable... -
Page 7: Installation
03 Installation 3.1 Prerequisites 3.1.1 Make sure the installation location satisfies the following conditions. ⚫ E5 is certified for IP65 and can be installed indoors as well as outdoors. If installed outdoors, do not allow E5 to be exposed to direct sunlight, rain and snow. ⚫... -
Page 8: Unboxing The Carton
3.3 Unboxing the carton 3.3.1 Carton The E5 packaging carton is made from cardboard paper. ⚫ Set the carton on a stable platform. 3.3.2 Open the carton Open the carton and remove the top cover by pulling it upwards. Take out the parts in the order from 1 to 5 as illustrated in the diagram above. - Page 9 3.4.2 Clearance The clearances shown in the diagram below are required for the E5 installation. The E5 should be installed <1 meter from the ground to avoid damages in case of dropping. Ensure the E5 is installed in an environment with good ventilation. Please see the wall-mounting bracket on the left.
- Page 10 3.4.4 Mounting the E5 on the bracket ⚫ Align the E5 to the center mounting bracket. ⚫ Open the protection front cover. ⚫ Drive the M5*12mm SEMS wall mount lock screws through the mounting bracket into the mounting holes and tighten them to a torque of 2.5 N.m. 3.4.5 Installing the E5 on the ground ⚫...
-
Page 11: Connect The E5 To An Inverter
3.5 Connect the E5 to an inverter ⚫ Open the protection cover and remove the waterproof cover with a screwdriver. ⚫ Ensure the E5 breaker is switched to OFF position. ⚫ Making positive (+, red) and negative (-, black) power connections to that of an inverter (refer to the diagrams below for instructions) ⚫... -
Page 12: Operating Instructions
⚫ Re-install waterproof cover and close the protective cover. 04 Operating Instructions 4.1 Power switch and connection panel The connection panel of the E5 shown below allows the users to access to all the connection terminals of the product. Items Connector Type Remark ○... -
Page 13: Power On/Off Procedures
4.3 Power On/Off procedures 4.3.1. Power On procedure ⚫ After connecting all the cables to the E5 battery, switch the breaker to ON position. ⚫ Push the BMS switch. ⚫ Check the LED panel on the E5 for a green status light. (It takes 1 min for the E5 to be powered up. During the initialization period, all FOUR capacity LED will blink at 3s. -
Page 14: Others
05 Others 5.1 Certifications Item Standard Pack certifications UL1973/IEC62619/CE/FCC/UKCA/MSDS UL1973/UL9540A/IEC62619 Cell certifications JIS8715-2/SII Crush & Nail UN38.3 Transportation certifications UN38.3 5.2 System maintenance The E5 must be charged at least once every three months if it is not in use. It is NOT recommended to have the E5 stayed in idle or turned off for more than three months. -
Page 15: Uninstallation
⚫ Failure to follow safety cautions and instructions. ⚫ Unauthorized maintenance and modification. ⚫ Inverter failure or overcurrent. ⚫ Force majeure. ⚫ External influences, such as unusual physical or electrical stress. ⚫ Paired and used with incompatible inverter. 5.5 Uninstallation ⚫... -
Page 16: Appendix 1: E5 Wi-Fi Setup Procedures
Appendix 1: E5 Wi-Fi setup procedures ⚫ Turn on the E5 battery. ⚫ Locate the Wi-Fi button and press for 7 seconds until a flashing green LED is obtained, then E5 enters into a paring mode. ⚫ Turn on the Wi-Fi and Bluetooth on a smartphone/tablet that has connected to the home Wi-Fi. - Page 17 ⚫ Search in the Apple App store or Google Play store for “Smart Life – Smart Living”. Click download and open. ⚫ Click “Sign up” and then register. Follow the steps to select country/region and enter email address. ⚫ Click “Get Verification Code” A verification code will be sending to the email address. Enter the Verification Code...
- Page 18 ⚫ After the verification is completed. Set and enter a password to complete the user registration. ⚫ Use the email address and password to login to the APP. Select both “Data Analysis” and “Personalization” and click “Go to App”.
- Page 19 (green Wi-Fi LED blinking). When it shows “Discovering devices”, click the “Add” button. ⚫ Choose the home Wi-Fi and click “Next”. HOME E5 will show up. Wait for the installation to complete. When the pairing up is successful, the green Wi-Fi LED will stay solid on.
- Page 20 ⚫ When the installation is completed. A notice “Home E5 added successfully” will be shown. After the setup is completed, battery information can be checked from the APP interface. ⚫ For connecting to a second E5 battery, repeat the step 8 to 11 above.
-
Page 21: Appendix 2: Deye Inverter Power-On / Power-Off Procedures
Appendix 2: Deye inverter power-on / power-off procedures A2.1 Power-on the Deye inverter ⚫ Unload the protective cover of the inverter. ⚫ Connect the E5 properly by following the procedures in the E5 installation manual. ⚫ Ensure the inverter is connected properly with grid and PV (if available). ⚫... - Page 22 A2.2 Power-off the Deye inverter ⚫ Unload the protective cover of the inverter. ⚫ If there is a grid connection, turn the main grid switch (AC) to off position. ⚫ If there is a PV connection, disconnect the PV by turning the DC switch to off position. ⚫...
- Page 23 www.greensolutions.co...
