Installation, operation, and maintenance instructions
for the Puropal-Complete-2, Puropal-Complete-12,
Puropal-Complete-25, & Puropal-Complete-50 H
Function
The Puropal-Complete filters lime and aggressive dissolved substances such as sulfates, nitrates and
chlorides out of the make-up water. The device operates on the basis of a mixed bed ion exchange
resin and provides completely demineralized water. This method does not release any chemical
additives into the water and operates without an external power supply.
Permanent connection
PUROPAL Complete is pressure-tested to 87 psi (600 kPa) and is therefore suitable for making a
permanent connection between the domestic water supply and the hydronic heating or cooling
system.
Depending on national or local regulations, a direct connection may be subject to technical
conditions (back flow prevention device) which must be observed.
Simplified permanent connections
Safety instructions
The regulations of the water utility
must be observed when
connecting directly to the
domestic water supply
After use, valves to the heating
system and main supply must be
closed.
2615 Wentz Avenue, Saskatoon, SK S7K 5J1 Ph: (306) 651-1815 Fax: (306) 651-2293
email: sales@axiomind.com website: www.axiomind.com
demineralizers
O
2
Advertisement
Summary of Contents for Axiom Puropal-Complete-2
- Page 1 Installation, operation, and maintenance instructions for the Puropal-Complete-2, Puropal-Complete-12, Puropal-Complete-25, & Puropal-Complete-50 H demineralizers Function The Puropal-Complete filters lime and aggressive dissolved substances such as sulfates, nitrates and chlorides out of the make-up water. The device operates on the basis of a mixed bed ion exchange resin and provides completely demineralized water.
- Page 2 Use with a heating system fill hose If the PUROPAL Complete is used to occasionally refill a closed loop system or to pre-mix demineralized water with glycol via a fill hose, the cartridge should be pre-flushed with fresh tap water in order to displace the initial flow water. After pre-flushing the cartridge, ensure the demineralization media is working by checking the integral combined meter to ensure complete demineralization.
- Page 3 3. Close valves; remove hoses Safety instructions PUROPAL Complete 2 should be pre-flushed with approx. 10 L water before each use in order to displace the initial flow water. It is not permissible for a heating system fill hose to remain permanently connected. The refill appliance should never be left unattended whilst in use.
-
Page 4: Operating The Combined Meter
Operating the combined meter The combined meter is battery-operated. It measures the flow rate in L/min, the total volume in litres and the concentration of dissolved minerals (electrical conductivity), either in microsiemens or TDS. In addition, a limit can be set for the maximum concentration of minerals tolerated in the demineralized water (Complete outlet). The limit and flow rate total can both be reset. - Page 5 Complete 2 provides 53 gal (200 l) of completely demineralized water, Puropal Complete 12 provides 500 gal (1900 l), Puropal Complete 25 provides 850 gal (3250 l), and Puropal Complete 50 provides 1780 gal (6750 l). See separate graphs below for capacity of each model Puropal-Complete-2 capacity: volume of completely demineralized water 29.2 26.3...
- Page 6 Replacing the resin in the Puropal Complete 12 Puropal-Complete-12 Capacity: volume of completely demineralized water 29.2 26.3 23.4 20.4 17.5 14.6 11.7...
- Page 7 Replacing the resin in the Puropal Complete 25/50 50 0 29.2 26.3 45 0 40 0 23.4 35 0 20 .4 30 0 17 .5 25 0 14 .6 20 0 11 .7 15 0 10 0 50 0 29.2 26.3 45 0 23.4...
