Unique Gas Products Cosnul CQE22 Series Manual

Hide thumbs

Advertisement

Table of Contents

CO Alarming Device
with Safety Shut-off
Model 9RV SSO
3/14/2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cosnul CQE22 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Unique Gas Products Cosnul CQE22 Series

Summary of Contents for Unique Gas Products Cosnul CQE22 Series

  • Page 1 CO Alarming Device with Safety Shut-off Model 9RV SSO 3/14/2008...
  • Page 2 NOTE: The Combination Carbon Monoxide Alarm & Safety Shut-Off Instructions (CM Model), battery, Owners/Installation Manual are stored inside the refrigerator. For Unique Gas Products Support, Call Toll Free 1-877-427-2266 Regular maintenance of the fridge is critical to prevent unsafe levels of Carbon Monoxide. Before lighting the refrigerator at any time, clean the flue tube as per the Owner’s Manual &...

  • Page 3: Table Of Contents

    T able of Contents Chapters Caring for Gas Refrigerators First Steps Controls Gas Installation How to get the best out of your Refrigerator Technical Description Periodic Maintenance & Troubleshooting Specifications Parts Carbon Monoxide Instructions (CM Model) Warranty...

  • Page 5: First Steps

    ENGLISH • Put the plastic caps over the leveling legs; • Carefully lift the Refrigerator to its normal position; 1. Introduction Clean the Refrigerator with a damp cloth and then wipe it We are pleased to add you to the growing number of dry with a clean cloth.

  • Page 6: Controls

    2.2 Door Hinging To ensure uninterrupted operation, we recommend that the gas supply system be fed from two gas cylinders, with an automatic switchover device. The specified fuel is If you need to change the door hinging to facilitate access propane and the supply pressure must be 11 inches into the Refrigerator proceed as follows;...

  • Page 7: Gas Installation

    5. How to get the best out of your Refrigerator Check whether the flame is centered in rela- tion to the heater pipe (chimney). 5.1 How to make it work (Fig. B) If it is not, turn the product off and call a ser- vice agency.
  • Page 8 • When at room temperature, the food should be placed in the main compartment of the Refrigerator, to precool for a few hours. Do not store flammable substances such as gasoline and kerosene in • Later on, preferably in the evening, place the food in your Refrigerator to avoid the risk of contact with the bottom of the upper compartment.

  • Page 9: Technical Description

    5.6 Shutting down the Refrigerator (Fig. D) The absorption Refrigerator is built to work continuously for many years. There are no moving parts and thus no Do not use flame to check for friction. At times, however, it needs to be turned off: leakage in the gas tubes.
  • Page 10 • • The first time you use your Refrigerator, it is most likely Let the Refrigerator operate for at least 30 minutes, that there is air in the gas lines. However, keep the during this time check if there is any gas leakage. selector valve button pressed for 1 or 2 minutes, and Check each connection from the source to the gas use the ignite button every 3 to 5 seconds until the...

  • Page 11: Periodic Maintenance & Troubleshooting

    6.5 The igniter 7.2 Cleaning the parts at the rear of the Refrigerator The igniter (B5) is the piezoelectric type, which causes a high-voltage spark to jump between the electrode (G3) Move the Refrigerator away from its permanent position, and the burner (G2). If it fails to operate, the fault may making sure the flexible connector does not kink.

  • Page 12: Specifications

    • Remove the cloth from the burner and reinstall the burner box. The baffle may contain burnt dust and light Now check the operation. surface corrosion. The tip, however, must be intact, not corroded. Soot must not be present, • Turn on the Refrigerator and examine the flame.
  • Page 13 Flame does not light or goes out Refrigerator too cold TROUBLE-SHOOTING Low cooling output Odor in or out of Refrigerator Excessive gas consumption PROBLEMS CAUSES REMEDIES Flame not lit. See problem No. 1. Empty gas cylinder or closed valve. Take required action. Supply pressure not within specifications.
  • Page 14 FIG. A FIG. B FIG. C...
  • Page 15 FIG. F FIG. D FIG. G...
  • Page 16 Cut out in order accommodate the lower hinge. A découper pour la charnière inférieure. FIG. E...
  • Page 17 FIG. H Note: The correct flame, at “COLDEST” setting, should have a bright blue crown at the base of the flame. Remarque: La base de la flamme correcte, au réglage “LE PLUS FROID”, doit être d’un bleu vif.
  • Page 19 Distributed by: UNIQUE GAS PRODUCTS LTD. 2245 WYECROFT RD.,#5 OAKVILLE, ON, CANADA L6L 5L7 Toll Free #1-877-427-2266 - Fax (905) 827-2027 www.PropaneFridge.com Manufactured by: Whirlpool S.A. Mail: Caixa Postal 267, 89219-900 Joinville - SC - BRAZIL Head Office: Estrada Dona Francisca, 7200 Joinville - SC Telephone: 55 47 3441-4141 C.N.P.
  • Page 20 Chapter Consul CQE22E, UNIQUE 8.0 White and Stainless Look Parts Diagram and Listing...

  • Page 22: Parts

    PARTS LIST FOR MODEL CQE22E, UNIQUE 8.0 WHITE AND STAINLESS LOOK - SM & CM FRIDGE REF. DESCRIPTION CBP2AE10 HINGE, TOP CBP2DE02 TOP HINGE COVER CBP2FSS01 TOP HINGE COVER - STAINLESS LOOK UNIT CBP2E13 UPPER HINGE SHIM CBP2DE03 CENTER HINGE SHIM CBP2DI01 CENTER HINGE CBP2UI05...
  • Page 23 PARTS LIST FOR MODEL CQE22E, UNIQUE 8.0 WHITE AND STAINLESS LOOK - SM & CM FRIDGE REF. PART # DESCRIPTION CBPUB01 BRUSH, CHIMNEY CBP2DI21 CAPILLARY TUBE CLAMP CBP2UB02 DEFLECTOR & STRANGLER SCREW CBP2UB04 BURNER HEAD CBP2UB05 ELECTRODE CBP2UB06 THERMOCOUPLE CBP2UE04 EVAPORATOR BOX CBPUB02 RUBY ORIFICE...
  • Page 24 PARTS LIST FOR MODEL CQE22E, UNIQUE 8.0 WHITE AND STAINLESS LOOK - SM & CM FRIDGE REF. PART# DESCRIPTION CBP2UE09 ELECTRODE CLAMP SCREW SCREW SCREW WASHER CLAMP CBP2EI02 BUSHING SELECTOR, BACK ON/OFF VALVE (DOES NOT INCLUDE UNION OR CBP2UB10 ADAPTOR) CBP2UB11 UNION (GAS CONTROL) CBP2UB12...
  • Page 25 PARTS LIST FOR MODEL CQE22E, UNIQUE 8.0 WHITE AND STAINLESS LOOK - SM & CM FRIDGE REF. PART# DESCRIPTION CBP2DI13 FRIDGE DOOR GASKET CBP2DI10 TRIM - TOP CBP2DI12 TRIM – MIDDLE (2) CBP2DI11 TRIM- BOTTOM CBP2DI15 EGG HOLDERS BUSHING, BOTTOM HINGE, BOTTOM OF FRIDGE DOOR, CBP2DI08 RIGHT SIDE HINGED, AND LEFT HANDED OPENING.
  • Page 26 PARTS LIST FOR MODEL CQE22E, UNIQUE 8.0 WHITE AND STAINLESS LOOK - SM & CM FRIDGE REF. PART# DESCRIPTION CBP2DE09 FREEZER DOOR ONLY CBP2FSS09 FREEZER DOOR ONLY - STAINLESS LOOK UNIT CBP2DI14 FREEZER DOOR GASKET BUSHING, CENTER HINGE, BOTTOM OF FREEZER DOOR, CBP2DI07 LEFT SIDE HINGED, AND RIGHT HANDED OPENING.
  • Page 27 Please read this owner's manual carefully so you will have a better understanding of the effects of CO poisoning and the COSTAR 9RV-SSO Alarm in conjunction with our COSTAR propane refrigerator. To your good health and safety, Unique Gas Products WARNING: Failure to replace this product by the “REPLACE BY DATE”...
  • Page 28 WHAT YOU SHOULD KNOW ABOUT CO Carbon monoxide (CO) is an insidious poison. It is a colorless, odorless and tasteless gas. It is a cumulative poison. The following symptoms are related to CARBON MONOXIDE POISONING and should be discussed with ALL members of the household: MILD EXPOSURE Slight headache, nausea, vomiting, fatigue (often described as "flu–like"...
  • Page 29 WHAT YOU SHOULD DO IF THE ALARM SOUNDS WARNING Activation of this device indicates the presence of carbon monoxide (CO) which can KILL YOU. If alarm sounds: For Users in the United States, follow the protocol in steps 1 through 4 below: Operate reset/silence button;...
  • Page 30 IMPORTANT CONSIDERATIONS: 9RV-SSO has been designed and is warranted to operate for COSTAR six years. Never disconnect the battery to silence an alarm. The alarm will automatically sense when the level of CO in the air falls below the danger level.
  • Page 31 IMPORTANT: WHAT YOUR CO ALARM CAN AND CANNOT This unit is designed to detect carbon monoxide (CO) and shutoff an appliance for safety only. This CO alarm is designed for use within a single residential living unit. It is designed to detect carbon monoxide (CO) entering its sensing chamber.
  • Page 32 LOCATIONS TO AVOID: Nuisance alarms are caused by placing units where they will not operate properly. To avoid nuisance alarms, do not place units: – Within 5 feet (1.5m) of any cooking appliance or furnace. – Near an open window or door, because the fresh air entering the opening may delay CO from reaching the alarm.
  • Page 33 INSTALLATION INSTRUCTIONS: READ CAREFULLY BEFORE INSTALLING ALARM CAUTION: THIS UNIT IS SEALED. THE COVER IS NOT REMOVABLE! Select proper location (See section 5.0) A mounting plate is provided on the back of the alarm. Remove the mounting plate from the back of the alarm by holding the mounting plate and twisting the alarm in the direction indicated by the "OFF"...
  • Page 34 To insure aesthetic alignment of the alarm with the hallway or wall, the UP ↑ arrow on the mounting plate must be vertical when wall mounting: (See Step A in Figure 2 ) As described in Figure 2, attach the mounting plate on the wall. Use the screws and anchors provided to secure the mounting plate.
  • Page 35 ALARM SIGNALS 7.1. NORMAL OPERATION: RED L.E.D. flashes once every 30 seconds, indicating that the alarm is powered ALARM CONDITION: Repeating signal pattern: RED LED turns "on" for 2 seconds with 4 short beeps and then 5 seconds of silence. Pushing and holding the test/reset button for 3 seconds will silence the alarm for about 4 minutes.
  • Page 36 9.0 BATTERY REPLACEMENT: NOTE: IF TAMPER RESISTANT PIN HAS BEEN USED, REFER STEP UNDER INSTALLATION INSTRUCTIONS FOR REMOVAL INSTRUCTIONS. (See Figure 3) To replace the battery remove the alarm from the mounting plate by rotating the alarm in the direction of the "OFF" arrow on the cover (See Figure 2 Step D).
  • Page 37 WARNING: THIS TEST PROCEDURE WILL TURN OFF THE APPLIANCE ONCE ALARM RESUMES NORMAL OPERATION, RE-LIGHT APPLIANCE FOLLOWING LIGHTING INSTRUCTIONS. WARNING: RESIDENTIAL USE: TEST ALARM OPERATION AT LEAST ONCE PER WEEK DURING USE OR IF APPLIANCE WAS TURNED OFF FOR A PERIOD OF TIME. 11.0 SERVICE AND WARRANTY If after reviewing this manual you feel that your CO Alarm is defective in any way, do not tamper with the unit.
  • Page 38 UNIQUE GAS PRODUCTS LTD. warrants the enclosed carbon monoxide alarm to be free from defects in materials and workmanship under authorized use and service, as specified in the owner's manual, for a period of six (6) years from the date of manufacture.

  • Page 39: Warranty

    This Warranty is made only to the first purchaser (”original purchaser”) who acquires this refrigerator for his/her own use and will be honored by Unique Gas Products Ltd. and by the Seller.
