- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Electrolux FFHS2611LW2 Owner's Manual Shop genuine replacement parts for Electrolux FFHS2611LW2 Find Your Electrolux Refrigerator Parts - Select From 901 Models -------- Manual continues below --------...
-
Page 2: Table Of Contents
All about the & Care Refrigerator of your TA B L E O F C O N T E N T S Important Safety Instructions .........2 Automatic Ice & Water Dispenser ......14 Features at a Glance ..........4 Changing the Filter ..........18 Installation ............5 Normal Operating Sounds and Sights ....19 Door Removal Instructions ........7... -
Page 3: Important Safety Instructions
IMPOrTANT SAFETy INSTrUCTIONS Installation Checklist WARNING Doors Please read all instructions before using this refrigerator. Handles are secure and tight Door seals completely to cabinet on all sides For your Safety Freezer door is level across the top • DO NOT store or use gasoline, or other flammable liquids in the vicinity of this or any other appliance. - Page 4 IMPOrTANT SAFETy INSTrUCTIONS Child Safety Fault Interrupter (GFI) circuit. Do not use an extension cord or adapter plug. Destroy or recycle the carton, plastic bags, and any • If the power cord is damaged, it should be replaced exterior wrapping material immediately after the by an authorized service technician to prevent any refrigerator is unpacked.
-
Page 5: Features At A Glance
FEATUrES AT A GLANCE Features may vary according to model ® SpillSafe Adjustable Shelf ® SpillSafe Adjustable Shelf IMPORTANT Features not included with your refrigerator can be purchased at www.frigidaire.com or by calling 1-800- 944-9044. -
Page 6: Installation
INSTALLATION Toe Grille Installation and removal This Use & Care Guide provides general operating instructions for your model. Use the refrigerator only as To install toe grille instructed in this Use & Care Guide. Before starting the 1 Open both doors. Slide left and right sides of toe refrigerator, follow these important first steps. - Page 7 INSTALLATION Door Opening To level the doors using the adjustable lower hinge: NOTE NOTE The refrigerator doors are designed to shut by Some models will not have a set screw. For those themselves within a 20 degree opening. models follow steps 2 through 4.
-
Page 8: Door Removal Instructions
DOOr rEMOVAL INSTrUCTIONS Getting through narrow spaces If your refrigerator will not fit through an entrance area, you can reduce its size by removing the doors. Check first by measuring the entrance. required Tools You will need the following tools: Top Hinge Tools Necessary: Top Hinge Cover Rear Cover Front Screw Screw Hinge Bottom Screw Hinge Screw Socket Adjustable 3/8” Fixed Phillips Head ™... - Page 9 DOOr rEMOVAL INSTrUCTIONS To remove the freezer top hinge cover: 3 Detach the water tube from the connector located below the freezer door. The connector 1 Remove the two screws from each cover over the releases when you press its outer sleeve inward. top door hinges.
-
Page 10: Connecting Water Supply
CONNECTING THE WATEr SUPPLy To Connect Water Supply Line To Ice Maker Inlet Valve WARNING 1. Disconnect refrigerator from electric power source. 2. Place end of water supply line into sink or bucket. To avoid electric shock, which can cause Turn ON water supply and flush supply line until death or severe personal injury, disconnect water is clear. -
Page 11: Controls
CONTrOLS Cool Down Period To ensure safe food storage, allow the refrigerator to operate with the doors closed for at least 8 to 12 hours before loading it with food. refrigerator & freezer controls NOTE When changing control settings, wait 24 hours for the temperature to stabilize before making additional changes. Temperature adjustment • After 24 hours, adjust the controls as needed. Adjust temperatures gradually;... - Page 12 CONTrOLS Allowing Cooling Time Before Use To ensure safe food storage, allow your refrigerator to operate with the doors closed for at least 8 to 12 hours before placing food inside. During this cooling period, you do not need to adjust the controls, which are preset at the factory. Setting Cooling Temperatures Your refrigerator comes with a state-of-the-art electronic digital control system.
- Page 13 CONTrOLS Indicator Cooling System On/Off Button NOTE Pressing the On/Off button on the control panel disables your refrigerator’s cooling system but does not disconnect power to lights and other electrical components. To turn off power to your refrigerator you must unplug the power cord from the wall outlet.
-
Page 14: Storage Features
STOrAGE FEATUrES fresh produce. The fresh drawers feature humidity control CAUTION which allows you to adjust the humidity within the drawer. This can extend the life of fresh vegetables that To avoid personal injury or property damage, handle keep best in high humidity. Wash items in clear water and tempered glass shelves carefully. -
Page 15: Automatic Ice & Water Dispenser
AUTOMATIC ICE & WATEr DISPENSEr Features may vary according to model. EXTrEME To freeze food at a faster rate to preserve freshness, push the Touch Pad for 3-5 seconds to activate FREEZE this feature. A green light will appear above the Touch Pad. Push the Touch Pad again for 3-5 seconds to deactivate. - Page 16 AUTOMATIC ICE & WATEr DISPENSEr Features may vary according to model. cube crush light light water Crushed Press the Crushed Touch Pad to get crushed ice. A red indicator will appear above the Touch Pad. Press glass against ICE dispensing paddle as far up as possible to catch all ice. Cubed Press the Cubed Touch Pad to get cubed ice.
- Page 17 AUTOMATIC ICE & WATEr DISPENSEr Priming the Water Supply System Using the Ice Maker after Installation Your refrigerator’s water supply system includes several Before making ice for the first time, be sure to prime the tubing lines, an advanced water filter, a distribution valve water supply system. Air in new plumbing lines can result bank, and a reserve tank to ensure ample supply to the in two or three empty ice maker cycles.
- Page 18 AUTOMATIC ICE & WATEr DISPENSEr Cleaning the Ice Maker IMPORTANT Clean the ice maker and ice bin at regular intervals, particularly before you take a vacation or move. Small ice cubes or ice chips jamming in the ice maker may be a sign that your water filter needs changing. To clean the ice maker: If you have a side mounted ice maker you may also 1 Turn Off the ice maker.
-
Page 19: Changing The Filter
5 Push firmly until the cartridge snaps into at 877-808-4195, or by visiting the dealer where you place (you should hear a click as the cartridge purchased your refrigerator. Electrolux recommends engages the snap-in connector). that you order extra filters when you first install your 6 Press a drinking glass against the water dispenser refrigerator, and that you replace your filters at least once while checking for any leaks at the filter housing. -
Page 20: Normal Operating Sounds And Sights
NOrMAL OPErATING SOUNDS AND SIGHTS Understanding the Sounds you may Hear Your new, high-efficiency refrigerator may introduce NOTE unfamiliar sounds. These sounds normally indicate your refrigerator is operating correctly. Some surfaces Energy efficient foam in your refrigerator is not a sound on floors, walls, and kitchen cabinets may make these insulator. sounds more noticeable. Following is a list of major components in your refrigerator and the sounds they can cause: ... -
Page 21: Care And Cleaning
CArE & CLEANING Protecting your investment Keeping your refrigerator clean maintains appearance and prevents odor build-up. Wipe up any spills immediately and clean the freezer and fresh food compartments at least twice a year. When cleaning, take the following precautions: • Never use CHLORIDE or cleaners with bleach to clean stainless steel. -
Page 22: Before You Call
BEFOrE yOU CALL 1-800-944-9044 (United States) Visit our web site at www.frigidaire.com. 1-800-265-8352 (Canada) PROBLEM CAUSE COrrECTION AUTOMATIC ICE MAKEr Ice maker is not mak- ON position. (side • Ice maker wire signal arm is in • Move wire signal arm to the “down” or ing any ice. - Page 23 BEFOrE yOU CALL (CONTINUED) PROBLEM CAUSE COrrECTION rUNNING OF rEFrIGErATOr Compressor does not • Freezer control is set to “OF” • Set freezer control. run. or “0”. • Refrigerator is in defrost cycle. • This is normal for a fully automatic defrost refrigerator. The defrost cycle occurs periodically, lasting about 30 minutes.
-
Page 24: Major Appliance Warranty
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by Electrolux Major Appliances North America, a division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by Electrolux Canada Corp.
