A-dec
Universal Light
®
I
G
NSTALLATION
UIDE
Product Models and Versions Covered in this Document
Models
Versions
378L/578L
A
Before You Begin
Check with local building and code authorities about installation
requirements specific to your location.
Recommended Tools
• Hex key set
• Phillips head screwdriver
• Socket wrench set
• Lubriplate™
Failure to turn off or disconnect the power before you
WARNING
begin this procedure can lead to product damage and result in
serious injury or death.
Circuit boards are sensitive to static electricity.
ATTENTION
Electrostatic Discharge (ESD) precautions are required when
touching a circuit board or making connections to or from the
circuit board. Circuit boards should be installed only by an
electrician or qualified service person.
86.0287.00 Rev G
Description
Dental Light
578L
378L
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Adec 378L
- Page 1 NSTALLATION UIDE Product Models and Versions Covered in this Document Models Versions Description 578L 378L 378L/578L Dental Light Before You Begin Check with local building and code authorities about installation requirements specific to your location. Recommended Tools • Hex key set •...
- Page 2 NOTE Shock hazard. When you remove or replace the covers, WARNING dual unit bases. The A-dec 378L can be mounted only in the single take care not to damage any wiring or tubing. Verify that the covers unit base. are secure after you replace them.
- Page 3 Install the Light Base If the bench top does not have holes for the light base: 1. Refer to the diagrams below to prepare the bench top for the light base. 3-1/4" 4-21/32" 82.6 mm 118.1 mm 3/8" 3/8" 9.5 mm 9.5 mm 2"...
- Page 4 2. Install the power cables and cords: Remove the data cable Feed the data cables up through the bottom of the Feed the power cables and data cords through from the light base. light base, and connect the cables (one to each the hole in the bottom of the light base and into available adaptor board).
- Page 5 Install the Flexarm to the Light Post 3. Use the attached cable tie to pull the light cable through the bottom of the light post. It may be easier to lay the flexarm and light post on a flat surface while installing the flexarm.
- Page 6 5. Single Unit Only: Use a 3/16" hex key to remove the screw at the base of 7. Reinstall the screw in the light arm. This screw will prevent the light post the light post in order to pass the light post through the hole in the top of from being pulled out of the light base once installation is complete.
- Page 7 Mount the Light Post and Make Wire 4. Use wire connectors to connect the light cable power wires to the transformer as follows: Connections ○ Black to black ○ White to gray 1. Feed the light cable through the lower opening in the base mounting hub using the attached cable tie.
-
Page 8: Complete The Installation
Complete the Installation Test the Light See the section for your system’s configuration. Shock hazard. When you remove or replace the covers, WARNING take care not to damage any wiring or tubing. Verify that the covers A-dec 578L are secure after you replace them. 1. - Page 9 ○ Lights with touchpad functionality – Move your hand within 3" (76 mm) of the touchless on/off sensor several times to verify the 1. To verify the light turns on and toggles between intensity modes (378L: light switches between off and on.
- Page 11 86.0287.00 Rev G Universal Light Installation Guide...
-
Page 12: Regulatory Information And Warranty
Regulatory Information and Warranty For required regulatory information and the A-dec warranty, see the Regulatory Information, Specifications, and Warranty document (p/n 86.0221.00) available in the Resource Center at www.a-dec.com. For quick access to this document online, scan, tap, or click this QR code, which points to a-dec.com/regulatory-guide.
