- Page 2 T E C T I Q W A L L R E A D E R A N D U P D A T E T E R M I N A L Installation instructions abus.com TECTIQ...
- Page 3 This manual contains all the important information on handling the product described in Connection with the ABUS TECTIQ access control system. The information in this manual has been compiled to the best of our knowledge and is regularly checked and updated. Keep the manual for the duration of the product's service life and ensure that you always have the appropriate manual for the product available.
-
Page 4: Table Of Contents
General information 1.1. Introduction 1.2. Intended use 1.3. Target groups 1.4. Notes in these instructions Product description 2.1. Function 2.2. Scope of delivery 2.3. Variants 2.4. Accessories 2.5. Spare parts 2.6. Technical data 2.7. Dimensions 2.8. Structure and individual parts 2.9. -
Page 5: General Information
Further information can be found at www.abus.com or - for dealers and installers - in the partner portal at www.partner-asc.abus.com 1.2. -
Page 6: Notes In These Instructions
1.4. Notes in these instructions Warnings and safety instructions Warnings indicate danger to life and limb. Warnings differentiate according to the severity of the danger and use one of the following signal words: Symbol Signal Meaning word DANGER! Refers to an immediate danger which, if not avoided, will result in death or serious injury. -
Page 7: Product Description
2. Product description 2.1. Function The combination of TECTIQ reader unit and TECTIQ wall reader controller unit forms the TECTIQ wall reader. It is used to control actuators for operating door drives, electric strikes, barriers or gates, for example. Combined with the appropriate IP44 or IP67 frame, the TECTIQ wall readers are suitable for indoor or outdoor use. -
Page 8: Variants
Screws (e.g. ø 4.5 mm) and dowels (e.g. ø 6 mm) suitable for the installation location *) ABUS Updater cable (optional, article number: ACAC00043) *) not by ABUS. Please contact your specialist dealer. TECTIQ UPDATE TERMINAL | TECTIQ WALL READER... -
Page 9: Spare Parts
2.5. Spare parts TECTIQ controller unit connection terminals (article number: TTSG90001) TECTIQ UPDATE TERMINAL | TECTIQ WALL READER... -
Page 10: Technical Data
TTSG10010: max. 890 events Time buffering Max. 3 h IP communication Ethernet 10/100 Mbit/s Connection USB-Micro Line type ABUS Updater cable→ see chapter 2.4 Accessories Conformity 2014/35/EU Low Voltage Directive (LVD) 2014/30/EU Electromagnetic Compatibility Directive (EMC) 2014/53/EU Radio Equipment Directive (RED) -
Page 11: Dimensions
2.7. Dimensions 71 mm 45 mm 12 mm 71 mm 51 mm 110 mm 16 mm 18 mm 118 mm Reader unit Controller unit wall reader / controller unit update terminal Frame inside Exterior frame 2.8. Structure and individual parts Reader unit Controller unit Status LED... -
Page 12: Labelling
Type designation Mark of Type designation Mark of Article/serial number conformity Article/serial number conformity TEC-SG-UP-ON TEC-WL-44-x TTWL10044x#L5840015ABA TTSG10000#L5840015ABA ABUS ABUS MAC address __:__:__:__:__:__ QR code with QR code with Manufacturer MAC address (opt.) Manufacturer article and serial article and address... -
Page 13: Safety Instructions
3. Safety instructions DANGER! Danger of electric shock! Electric shock when touching live parts in the installation environment. Electric shock can lead to death. • Disconnect before working on the device (switch off the power supply and secure against being switched on again). •... -
Page 14: Assembly Notes
(e.g. together with controller units for other doors). 4.2. Distance to other components ABUS TECTIQ uses wireless transmission technology (RFID), which is influenced by the immediate surroundings. For undisturbed operation, keep the following distances: •... - Page 15 • The cable should be laid in a protected location so that unauthorised access is not possible. • CH /... Distance between the cable of the reading unit and power cables min. 1 m. 230/400V > 1 m NOTE High-energy events in the power grid, e.g. as a result of a lightning strike, can destroy electronic devices through overvoltage.
-
Page 16: Assembly
Use the bottom part of the frame as a template to mark the drill holes or find the right drilling template in the downloads www.abus.com/product/TTWL10044S www.abus.com/product/TTWL10067S The controller unit can also be installed in combination with other switch ranges. To do this, the... -
Page 17: Compact Assembly
5.3. Compact assembly With compact mounting, the controller unit and reader unit are installed together in one place. Before installation, check that you have ordered the correct reader unit. Exchanges after shortening the cable are not possible! Compact installation for indoor use only IP20. Step 1: Installing the appliance box and drilling holes ▹... - Page 18 Step 3: Route the cable from the reader unit to the controller unit ▹ Feed the cable of the reader unit (1) through the frame bottom section (2). ▹ Feed the cable of the reader unit through the cable bushing of the controller unit (3) to the rear. Step 4: Connect the reader unit cable to the plug ▹...
- Page 19 Step 5: Connect the supply voltage, door controller unit and network cable Twist the wires of the Ethernet cable up to the connection terminal. Tightening torque for the connector strip: approx. 0.15 Nm. ▹ For update terminal - or for supply via Ethernet/PoE: Connect Ethernet cable to connector K1.
- Page 20 Step 6: Installing the controller unit in the appliance box ▹ Install the controller unit in the appliance box. Normally, the cables behind the controller unit hold the connectors K1 and K2 in position. If necessary, it may be advisable to additionally secure the plugs against slipping out.
- Page 21 NOTE: Do not crimp the cables when inserting the reader unit! ▹ Place the reader unit (1) on the bottom part of the frame. T10H TX10 1Reader unit inside IP44 2Reader unit outside IP67 For the IP44 frame: ▹ Place the upper part of the frame (2) on the reader unit and the lower part and clip on all round.
-
Page 22: Remote Mounting
5.4. Remote mounting With remote mounting, the controller unit and reader unit are installed in separate locations: • when mounting the reader unit outdoors, • when installing the reader unit in public areas, e.g. at public authorities, • if no further connection cables are to be routed to the installation location of the reader unit (network, door control), •... - Page 23 Step 3: Assemble the frame and reader unit Reader unit IP44: ▹ Mount the bottom part of the frame. The "IP44" labelling should point downwards. Reader unit IP67: ▹ Insert the foam rubber seal (1) into the back of the IP67 frame base (2).
- Page 24 Reader unit IP44: ▹ Place the upper part of the frame (2) on the lower part and clip it on all round. ▹ Press the screws (3) into the upper part of the frame (2), e.g. using a screwdriver knob. Reader unit IP67: ▹...
- Page 25 Step 4: Connect the controller unit Twist the wires of the Ethernet cable in pairs up to the connection terminal. Tightening torque for the connector strips: approx. 0.15 Nm. Controller unit Update Terminal - or for supply via Ethernet/PoE: ▹ Connect the Ethernet cable to connector K1. ▹...
- Page 26 ▹ Connect plugs K1 and K2 to the controller unit. Step 5: Installing the controller unit in the appliance box ▹ Install the controller unit in the appliance box. Normally, the cables behind the controller unit hold the connectors K1 and K2 in position. If necessary, it may be advisable to additionally secure the plugs against slipping out.
-
Page 27: Electrical Connection
6. Electrical connection Importan Malfunction during operation possible! Power failure, e.g. as a result of a short circuit of other devices in the same circuit, leads to a functional failure of the controlled door. • Provide separate circuits for the TECTIQ controller units and also for the controlled doors and secure them separately. -
Page 28: Connection Example: Tectiq Update Terminal With Poe Without Door Control
6.2. Connection example: TECTIQ Update Terminal with PoE without door control • Controller unit update terminal • Supply via Ethernet/PoE • 1 reading unit Ethernet/PoE EIA/TIA 568A EIA/TIA 568B Brown Brown-white Blue Blue and white Orange Green Orange-white Green-white Green Orange Green-white Orange-white... -
Page 29: Connection Example: Tectiq Update Terminal / Tectiq Wall Reader With Poe And Door Activation
6.3. Connection example: TECTIQ Update Terminal / TECTIQ Wall Reader with PoE and door activation • For TECTIQ Update Terminal: Controller unit Update Terminal • For TECTIQ wall readers: Control unit Wall Reader • Supply via Ethernet/PoE • 1 reading unit •... -
Page 30: Connection Example: Tectiq Wall Reader With Door Opener
6.4. Connection example: TECTIQ Wall Reader with door opener • Wall reader controller unit • Separate supply • 1 reading unit • 1 door with electromechanical door opener EIA/TIA 568A EIA/TIA 568B Brown Brown-white Blue Blue and white Orange Green Orange-white Green-white Green... -
Page 31: Commissioning
Commissioning of the product is described in the ABUS TECTIQ system documentation at . TECTIQ 8. Operation abus.com/product/TTAM10000 The operation of the product is described in the ABUS TECTIQ system documentation. 9. Care and maintenance 9.1. Clean product NOTE The product may be damaged. -
Page 32: Decommissioning And Dismantling
10. Decommissioning and dismantling 10.1. Dismantling the reader unit Reader unit with IP44 frame: ▹ Loosen the screws on the front using a TX10 hexagonal spanner until the start of the thread appears flush with the frame surface. ▹ Lever the upper part of the frame off the lower part. Further disassembly is carried out in the reverse order to assembly. - Page 33 Dispose of the device in accordance with the Waste Electrical and Electronic Equipment EU Directive 2012/19/EU - WEEE (Waste Electrical and Electronic Equipment). If you have any questions, please contact the local authority responsible for disposal. Information on collection points for your old appliances can be obtained, for example, from the local municipal or city administration, the local waste disposal companies or from your dealer.
