INSTRUCTION MANUAL
FOR INSTALLING ALUMINIUM
CHEST, UPRIGHT & GULLWING
PRODUCTS
PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS AND WARNINGS
BEFORE ASSEMBLING, INSTALLING OR USING THIS PRODUCT.
Need help or information?
AU 1300 760 717
NZ 0080 230 004
www.weatherguard.au
Advertisement
Related Manuals for Weather Guard WARNERCO
Summary of Contents for Weather Guard WARNERCO
- Page 1 INSTRUCTION MANUAL FOR INSTALLING ALUMINIUM CHEST, UPRIGHT & GULLWING PRODUCTS PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS AND WARNINGS BEFORE ASSEMBLING, INSTALLING OR USING THIS PRODUCT. Need help or information? AU 1300 760 717 NZ 0080 230 004 www.weatherguard.au...
- Page 2 WARNINGS: Use the specific mounting components when installing WEATHER GUARD ® products. Always use appropriate PPE (eyes, hearing, skin, clothing, footwear) when installing WEATHER GUARD products. ® TOOLS REQUIRED Tape Measure ♦ Marker ♦ Centre Punch ♦ Hammer Drill ♦ 8.5mm Drill Bit ♦ 13mm Spanner...
- Page 3 75mm Max. 75mm Max. 8.5mm (x4) 75mm Max. 75mm Max. (Figure 1.) Typical Mounting Hole Positions for CHEST Products 75mm Max. 75mm Max. 8.5mm (x4) (Figure 2.) Typical Mounting Hole Positions for UPRIGHT Products 75mm Max. 75mm Max. 8.5mm (x4) (Figure 3.) Typical Mounting Hole Positions for GULLWING Products...
- Page 4 Vehicle Floor Plate Washer (Figure 4.) Typical Assembly 12V Electrical Access WEATHER GUARD products are ® manufactured with a 12 Volt electrical access grommet for easy electrical fit-ups. To use, simply cut along one of more perforations in the grommet and pass the wire through.
