- Page 1 1Cover ENGLISH (Original instructions) OPERATOR'S MANUAL Pro Edge Attachment 99944200875 WARNING READ THE INSTRUCTIONS CAREFULLY AND FOLLOW THE RULES FOR SAFE OPERATION. FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY.
- Page 2 Always keep your manual in a place where it is readily accessible. If you have lost your manual or it is damaged and no longer readable, please purchase a new one from your ECHO DEALER.
-
Page 3: Table Of Contents
Contents For safe use of your product....................4 Warning notices ......................4 Other indicators ......................4 Symbols ......................... 4 Location in which a safety decal is attached..............5 Handling the product ..................... 6 Packing list.......................... 9 Description........................10 Before you start ........................ 11 Assembly ........................ -
Page 4: For Safe Use Of Your Product
For safe use of your product For safe use of your product Be careful to read this section before using your product. The precautions described in this section contain important safety information. Please observe them carefully. You must also read the precautions that appear in the body of the manual itself. Text following a [diamond mark] mark describes the potential consequences of failing to observe the precaution. -
Page 5: Location In Which A Safety Decal Is Attached
For safe use of your product Location in which a safety decal is attached The safety decal shown below has been attached to the products described in this manual. Ensure that you understand what the decal means before using your product. ... -
Page 6: Handling The Product
For safe use of your product Handling the product General precautions WARNING Operator's manual Loaning or assigning your product Be careful to read the operator's manual When loaning your product to another party, ensure properly before using your product in or- that the person borrowing the product receives the op- der to ensure correct operation. - Page 7 For safe use of your product WARNING Users of the product Vibration and cold The product should not be used by: It is believed that a condition called Raynaud's Phenome- people who are tired non which affects the fingers of certain individuals may be ...
- Page 8 For safe use of your product Protective gear WARNING Wear protective gear Always wear the following protective gear. a Head protection (helmet): Protects the head b Ear muffs or ear plugs: Protect the hearing c Safety goggles: Protect the eyes d Face shield: Protects the face e Safety gloves: Protect the hands from cold and vibration f Work clothes that fit (long sleeves, long trousers): Pro-...
-
Page 9: Packing List
The following parts are packed separately in the packing box. When you have unpacked the box, please check the parts that it contains. Contact your ECHO DEALER if anything is missing or broken. 1. Power edger attachment 4. -
Page 10: Description
Description Description 1. Blade Rotates to provide cutting action. 3. Drive shaft assembly Contains a specially designed liner 2. Debris shield/flap Mounted over the cutting attachment. and the flexible drive shaft. Helps protect operator by deflecting debris produced 4. Wheel Adjustable up/down, sets depth of blade. during the edging operation. -
Page 11: Before You Start
Before you start Before you start Assembly WARNING Read the operator's manual carefully to ensure that you assemble the product correctly. Using a product that has been incorrectly assembled could lead to an accident or serious injury. Power head shaft/lower shaft assembly Set power head/shaft assembly on a level surface. -
Page 12: Operation
Operation Operation Before operation a complete check of the unit must be performed; Check unit for loose/missing nuts, bolts and screws. Tighten and/or replace as needed. Inspect shield for damage and is securely in place. Replace if shield is damaged or missing. ... -
Page 13: Maintenance And Care
Maintenance and care Maintenance and care WARNING Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects away from all openings. Always stop engine, disconnect the spark plug wire, and make sure all moving parts have come to a com- plete stop before removing obstructions, clearing debris, or servicing unit. - Page 14 Maintenance and care IMPORTANT Never reuse old split pin. Install new split pin (A) to secure nut. Drive shaft (lower) IMPORTANT Lower and upper drive shaft must be lubricated with high tem- perature automotive grease every 25 hours of operation, oth- erwise drive shaft assembly overheating and failure can result.
-
Page 15: Storage
Storage Storage Storage hook installation Insert small end of hook into locating hole on attachment shaft. Slide plastic cap onto end of attachment shaft. -
Page 16: Specifications
Specifications Specifications 99944200875 External dimensions: Length × Width × Height 790 × 225 × 296 Mass: Unit without cutting attachment Unit with specified cutting attachment Cutting attachment: Specified blade diameter Specified blade width Specified blade thickness Number of cutting teeth Blade center hole diameter 25.4... -
Page 17: Declaration Of Conformity
YAMABIKO CORPORATION 7-2 SUEHIROCHO 1-CHOME OHME; TOKYO 198-8760 JAPAN declares that the hereunder specified new unit: PRO ATTACHMENT™ SERIES Brand: ECHO Type: PAS-265ES + 99944200875 assembled by: ECHO, INCORPORATED 400 Oakwood Road Lake Zurich, Illinois 60047-1564 U.S.A. complies with: * the requirements of Directive 2006/42/EC: (use of harmonized standard ISO 11806-1) - Page 18 1Notes and rear cover MEMORANDUM X770-001 17 3 X770 209-250 3 2008...
- Page 19 MEMORANDUM X770-001 17 3 X770 209-250 3 2008...
- Page 20 7-2 SUEHIROCHO 1-CHOME, OHME, TOKYO 198-8760, JAPAN PHONE: 81-428-32-6118. FAX: 81-428-32-6145. X770-001 17 3 Printed in Japan 0x0xxxx zzzz ES X770 209-250 3 © 2008...
