300LED DENTAL LIGHT
Thank you for purchasing TAKARA BELMONT product.
This manual provides operating instructions for the 300LED DENTAL LIGHT
TYPE 320M.
The instructions contained in this booklet should be thoroughly read and understood
before operating the 300LED DENTAL LIGHT TYPE 320M.
After the installation has been completed, keep this manual in a safe place and refer
to it for future maintenance.
If you have any questions about this manual or this product, please contact us.
If manual becomes unreadable or is lost, please request a new manual by
contacting your dealer.
Installation should be conducted by authorized personnel only.
Follow instructions on installation manual.
DENTAL LIGHT
INSTRUCTIONS FOR USE
IMPORTANT
TYPE
320M UNIT MOUNT
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Belmont 320M
- Page 1 TYPE 320M. The instructions contained in this booklet should be thoroughly read and understood before operating the 300LED DENTAL LIGHT TYPE 320M. After the installation has been completed, keep this manual in a safe place and refer to it for future maintenance.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Important Notes Compliance with Directive Intended Use of the Product Symbols Safety Precautions Overview and Major Components Descriptions of Operation and Functions of Components Main Switch ......4 Functional Description . -
Page 4: Important Notes
Patients should not be allowed to operate or handle the product unless he/she is so instructed. Important Notes In case of the troubles, please contact a Takara Belmont offices or your dealers. Do not disassemble or attempt to repair. Disassembly, repair or modifications should only be done by a qualified repair technician. - Page 5 Safety Precautions Before use, read the “Safety precautions” carefully to ensure proper use. The following information is designed to ensure safe use of this product and to prevent injury and damage to you and others. The precautions contained here are classified with [WARNING], [CAUTION], [NOTICE] depending on the severity and degree of imminence of possible injury or damage resulting from improper use.
- Page 6 Safety Precautions WARNING 9. Use with caution in the presence of electromagnetic interference waves Do not place this product around equipment generating electromagnetic waves (including communications equipment, elevators, etc.) as incorrect operation of this product may occur in the presence of electromagnetic interference waves. Do not use equipment generating electromagnetic waves, such as mobile phones, around this product.
-
Page 7: Safety Precautions 1~3
Safety Precautions CAUTION 9. Cleaning of grease leak If grease leaks from arm section, please wipe grease off. 10. Irradiation light of LED Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. 11. -
Page 8: Descriptions Of Operation And Functions Of Components
Description of Operation and Functions of Components Main Switch When the main switch of the dental unit is turned on, the dental light power is also turned on. Refer to the instruction manual of the dental unit for main power operation. WARNING •... -
Page 9: Care And Maintenance
Care and Maintenance Cleaning Wipe the surfaces with dry and soft cloth. If the stain is hard to remove, wipe it off with the cloth moistened with 10% detergent solution diluted using water, be sure to wipe with dry cloth to wipe remaining moist. Neutral Soft cloth Detergent... -
Page 10: Before Asking For Repairs
Before Asking for Repairs If any of phenomena described below has occurred, make the following checks before asking for repairs. Action to be taken Phenomenon Check point and result The light does not Main switch is not on. Turn on the main switch. light up Hand must pass by within 65mm Confirm distance of a touchless switch. -
Page 11: Specifications
Specifications Control No. : AL-320MR-EUN This product power is supplied from CREDIA G1 Rated Voltage : DC19V Rated Input : 0.72A Weight : 3.5kg Light Source : LED (5 LEDs) Optical Performance : Focal Distance 650mm : Light Intensity (Normal treatment mode) 3100 ~ 28000 Lux : Light Intensity (Composite mode) 4300 Lux : Correlated Color Temperature... -
Page 12: Maintenance And Inspection 8~9
Maintenance and Inspection Guide for daily maintenance and inspection (Maintenance and inspection by user) Management of maintenance and inspection of medical equipment should be implemented by the user (medical institution). In case the user does not implement such management, it is permitted that such management is outsourced to a qualified entity such as a medical equipment repair company. -
Page 13: Electromagnetic Compatibility (Emc)
Maintenance and Inspection Guide for Periodical Check-up Some parts and components of the products are degraded or deteriorated depending on the frequency of use. Annual check-up and maintenance, as well as replacement of consumable parts, are required. The required parts (including consumable parts) are listed below. It may be different from the following list depending on the option of the unit. -
Page 14: Declaration Of Conformity
MDR(EU)2017/745 and RoHS Directive: 2011/65/EU based on category 8 of Annex I. Product : DENTAL LIGHT (CLASS I) Model : 300LED DENTAL LIGHT TYPE 320M " CLASS I " has been defined by the rule 13 of MDR Annex VIII. - Page 16 TAKARA COMPANY EUROPE GmbH BELMONT MANUFACTURING CO., LTD. (Manufacturer) Berner Strasse 18, 60437 Lot I-2, Long Duc Industrial Park, Long Duc Ward, Frankfurt am Main, Germany Long Thanh District, Dong Nai Province, Vietnam Tel:+49 69 506878 0 TEL.: +84-2513-201-100 / FAX.: +84-2513-201-096...
