Ronstan 120 Series Manual

Furler System Information
The furler you have purchased is designed for the furling of sails with a "straight" luff, such as code zero sails,
screechers or staysails. These sails are generally for sailing at true wind angles less than 90°. The furler is
designed to have the tack of the sail attached to the furler and the head of the sail attached to the top swivel.
This will provide furling along the whole luff of the sail.
The sail must be either completely unfurled or completely furled – the furler cannot be used with a partially
furled sail.
You will require a synthetic luff cable (torsion line) with a thimble at each end, connected between the fork of
the furler at the bottom and the swivel at the top. We recommend you discuss options with your sail maker for
torsion line type, diameter and length, to suit your requirements.
Ronstan provides a range of accessories to suit this furler which can be found at the end of this manual.
FURLER SETUP –
STRAIGHT LUFF SAILS:
Torsion rope
1
Continuous Furling Line
2
Top Swivel
3
Thimble
4
Furler
5
Shackle, Snap Shackle or
6
2:1 Fairlead
FURLING LINE ALIGNMENT
It is important that the furling line is correctly aligned with the guide as shown below.
Blocks or fairleads should be used to guide the line where required.
The furling line can be cleated to keep the sail from unfurling.
3
4
1
4
5
6
3
4
1
4
5
6
7
CONTINUOUS LINE FURLERS
Series 120 Furler Manual
2
As furling drum rotates, sail furls around the luff cable
along its entire length.
