ASUS ZENBOOK DUO UX482E series
Repair Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZENBOOK DUO UX482E Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Asus ZENBOOK DUO UX482E Series

  • Page 1 ASUS ZENBOOK DUO UX482E series Repair Manual...
  • Page 3: Service Overview

    Service Overview • ASUS is not responsible for direct, indirect, intentional o unintentional damages resulting from improper installation and operation. • Carefully read through this Service Guide for a look at various components of the device before performing any service and repairs.
  • Page 4 Pre-repair checklist • Read the entire manual before starting any service procedures and follow all instructions. • Back up the data on your device. • Place your device on a clean and stable surface. • Turn off your device. • Disconnect all connected peripherals and cables.
  • Page 5: Bottom View

    ASUS ZENBOOK DUO UX482E series Overview Top View Bottom View ❶ Camera indicator ❷ Camera ❸ Touch Screen panel ❹ Keyboard ❶ Air Vent ❺ Power button ❷ Audio speaker ❻ Touchpad ❶ Status indicator Right View ❷ MicroSD card slot ❸...
  • Page 6 Components Top View LCD MODULE MAIN BOARD SPEAKER SSD PAD WIFI ANTENNA WIFI BD Mylar Panel Control Board LCD PANEL TP CABLE BATTERY BASE CASE WIFI BD ANTENNA MYLAR THERMAL MODULE ASSY WIFI BD FPC SSD ABSORBER KEYBOARD MODULE 2ND PANEL HINGE L IMR R IMR Back...
  • Page 7 Components Bottom View KEYBOARD MODULE LCD PANEL BASE CASE THERMAL MODULE ASSY MAIN BOARD Back...
  • Page 8 Repair Overview This chapter describes disassembly and assembly (Assemble document please look up from the last page), please follow the information provided in this section to perform the complete disassembly procedure. Precautions: Before you perform any service or repair on the notebook, please pay special attention to the cautions prevent any damages to the notebook. 1.
  • Page 9 Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the ASUS ZENBOOK DUO UX482E series notebook. Screwdriver Alcohol 95% Glove Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. Plastic Blade Thermal Pad G500 Thermal Grease Plastic Tweezers Use a pair of tweezers to remove/insert/tidy cables.
  • Page 10: Bottom Case

    BOTTOM CASE Disassembly Notice Remove bottom case Step 1 : Remove 5 rubbers. Step 2 : Remove 9 screws. Step 3 : Use plastic blade to pry the bottom case. Step 4 : Remove bottom case. Screws Spec Torque (kgf-cm) SCREW M2*4.5+0.5(3.3,0.3)(K)+H 2.5±0.1 SCREW M2*2.5+0.5 K SUS T5 NY...
  • Page 11 BATTERY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. Step 1 : Disconnect the battery connector. Step 2 : Remove 6 screws.
  • Page 12 Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the 1 screw. Screws Spec Torque (kgf-cm) Step 2 : Remove SSD Pad. M2*2.5L K B-ZN #1 NY 2.0±0.1 Step 3 : Tear off ABSORBER. Step 4 : Remove SSD at right side.
  • Page 13 SPEAKER Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the SPEAKER connector. Step 2 : Remove SPEAKER. Assembly Notice For Speaker assembly, please follow the mark below to tidy cable, and put the Rubber in Right place.
  • Page 14 Antenna Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the WIFI board Mylar. Assembly Notice Step 2 : Remove the ACETATE TAPE. Step 3 : Disconnect Antenna cable. Step 4 : Remove Antenna. For Antenna assembly, please follow the mark below to tidy cable.
  • Page 15 WiFi BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the TP FFC. Disconnect the TP FFC Screws Spec Torque (kgf-cm) Step 2 : Remove 4 Screws. M2*2.5L K B-ZN #1 NY 1.0±0.1 Step 3 : Disconnect WIFI board FPC.
  • Page 16 SECOND PANED CONTROL BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect 3 cables. Step 2 : Remove 2 Screws. Screws Spec Torque (kgf-cm) Step 3 : Remove Touchpanel Control board. M1.6*2L K B-NI #0 1.0±0.1 Disconnect 3 cables...
  • Page 17: Thermal Module

    THERMAL MODULE Screws Spec Torque (kgf-cm) Disassembly Notice Please be sure to pull out adapter and disconnect the battery. M2*3L D4.5 (K) W-NI NY 2.0±0.1 Step 1 : Disconnect (Blue mark) connector. M2*2.5L K B-ZN #1 NY 2.0±0.1 Step 2 : Remove 5 Screws from Fan (Orange and Red mark). Step 3 : Follow the Screws number to remove screws from thermal (Yellow mark).
  • Page 18: Main Board

    MAIN BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect LCD TP BD Cable (Yellow Mark) Screws Spec Torque (kgf-cm) Step 2 : Disconnect 2ND Panel Cable (Orange Mark). Step 3 : Disconnect LCD EDP Cable (Green Mark). M2.0*1.5L K W-NI #0 NY 2.0±0.1 Step 4 : Remove 8 Screws (Red Mark).
  • Page 19 MAIN BOARD CONNECTOR Mainboard connector placement EDP CABLE Touch cable WiFi FFC speaker cable BATTERY Second Panel Cable CN1 FPC CN2 FPC BL cable CN3 cable K/B cable TP FFC Back...
  • Page 20 MAIN BOARD Materials on mainboard UX482EA VGA MYLAR//滕藝 Notice: The sub material is only for UX482EG/UX482EGR UX482EA HDMI MYLAR//滕藝 UX482EA CPU BKT ASSY UX482EA MB TOP MYLAR//滕藝 UX482EA LED RUBBER//GREAT HIGH Back...
  • Page 21 SECOND PANEL Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove 8 Screws from Right hinge. Screws Spec Torque (kgf-cm) Step 2 : Remove Right and Left hinge. Step 3 : Turn the Main Screen to 120 degrees. M2*2.5L K B-ZN #1 NY 2.0±0.1 Step 4 : Remove 2nd Panel.
  • Page 22 LCD MODULE & KEYBOARD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove 6 Screws from Right Hinge. Screws Spec Torque (kgf-cm) Step 2 : Separate Keyboard module and LCD module. SCREW M2.5*4L K B-ZN #1 2.5±0.1 Remove 6 Screws from Right Hinge...
