rackit 01921 Assembly Instructions

YOUR HEADACHE-FREE GUIDE TO RACK IT LIKE A BOSS
You've got this! We know because you take pride in your passions. Take care of your stuff. That's why you purchased this Rack It 1000KG
Peg Board. You're particular. And we like that. Because we know you'll take the time to check off all the Parts listed below and to read
through these Assembly Instructions before you start Cue Farnsey (or Beyoncé – whatever lifts you). Let's get this started.
PARTS LIST:
Peg Board x1
This is where your Peg Board adventure begins. Pay attention to the Pics, do it right and you'll set yourself for future Peg Boarding glory.
Attach all 4x Brackets to the back of your Peg Board. Insert the
STEP 1
Top Brackets into the 1st and 3rd Hole positions (see Pic 1A).
Insert the Bottom Brackets into the 7th and 9th Hole positions.
Note: Back of Peg Board
STEP 3
Insert Safety Pins into all 4x Brackets
and you'll stop your Peg Board doing
anything crazy, like tipping over.
Give yourself (and your friend) a hi-five! You've got this pegged.
MADE IN CHINA | DISTRIBUTED BY:
Zenexus (AUS) Ph. 1300 734 714 Zenexus (NZ) Ph. 0800 443 058
PEG BOARD
ASSEMBLY INSTRUCTIONS
ITEM CODE: 01921
OPTION 1: SINGLE PEG BOARD
STEP
1st
3rd
7th
9th
Hot tip:
For best results attach the Bottom Brackets into the 2nd and 3rd Upright Slots above a Workbench
Shelf. Then you can marvel at those perfectly stashed precious things whenever you like.
x1 in each
Bracket
AUSTRALIA: RACK-IT.COM.AU
Angled Bracket x1
Nuts x 6 Bolts x 6
This is where your friend comes in handy. Lift the Peg Board by
2
the Brackets and mount it onto your existing Uprights at your
desired height.
NEW ZEALAND: RACK-IT.CO.NZ
TOOLS REQUIRED: Rubber Mallet
(or Hammer – gently does it)
Phillips Head Screwdriver
10mm Spanner or Shifter
And it pays to grab a friend, as it'll
be easier with 2 of you.
WARNING: HANDLE CUT METAL
EDGES CAREFULLY
SAFETY TIP
When assembling or installing this product
wear protective gloves and eyewear
Brackets x4
3rd
2nd
1st
View of
pin in
place
