Summary of Contents for CBORD Schlage AD-300
- Page 1 Schlage AD-300 Locks ® Installation Guide for Squadron Access Control ® The CBORD Group, Inc. Ithaca, NY...
- Page 2 © 2010-2013 The CBORD Group, Inc. All rights reserved. CBORD, CS Gold, and Squadron are registered trademarks, and CS Access and CS Notify are trademarks, of The CBORD Group, Inc. All other brand and product names are believed to be trademarks, registered trademarks, or service marks of their...
-
Page 3: Table Of Contents
IPB Enhancements ..................24 Monitor Request to Enter Status..............25 Fixed-Length PIN ..................25 Local Alarms ....................25 MIK Credential Reader ................... 26 Appendix A Device Configuration Parameters ............27 Appendix B Troubleshooting ................29 Schlage AD-300 Locks Installation Guide... - Page 4 Schlage AD-300 Locks Installation Guide...
-
Page 5: Introduction
Up to 32 AD-300 locks connect to a ® ™ single CS Access V1000 EVO via CBORD RS485 Hubs. The Hub is not required when only one or two locks are being connected to a given V1000 EVO. AD-300 Hardwired Online Lock AD-300 online lock features include: ... -
Page 6: Training
For information about training courses and prerequisites, go to: www.cbord.com/support/training Customer Support ® CBORD is committed to providing full support to both customers and suppliers through person-to-person as well as online support options. Phone number: 1-866-789-2977 eSupport Portal: https://esupport.cbord.com/portal Schlage AD-300 Locks Installation Guide... -
Page 7: Cs Access Integration
Schlage Utility Software User Guide: At the Schlage Web site, click AD-Series Locks, click the View link for AD-300 Wireless Lock and Installation Manuals in the grid, and then click the Schlage Utility Software User Guide link at the bottom of the page. Schlage AD-300 Locks Installation Guide... -
Page 8: Parts And Accessories
Parts and Accessories There are many variations of AD-300 lock hardware available to fit various physical requirements. Contact your CBORD Sales Representative to select the appropriate part numbers. Physical Mounting Refer to the appropriate procedures in Section 3 and to the Schlage installation instructions accompanying the AD-300 lock hardware. -
Page 9: Specifications
Table 2-1: AD-300 Power Requirements and Operating Environment Item Specification Power Supply 12 VDC or 24 VDC Max. Current Requirement Up to 250 mA Operating Temperature -31° to 151° F (-35° to 66° C) Operating Humidity 0 - 100% condensing Schlage AD-300 Locks Installation Guide... -
Page 10: Installation
When applying a template directly to a door, use a template that has been provided and printed by Ingersoll Rand (IR). If you print a template, check at least one horizontal and one vertical measurement for accuracy with a ruler before you use the template. Schlage AD-300 Locks Installation Guide... -
Page 11: Wiring To The V1000 Evo
Figure 3-1: Connections for Two AD-300s Wired to V1000 EVO For installations with three or more AD-300 locks connected to a given V1000 EVO, RS485 Hubs are required and should be connected as described in this section (refer to Figure 3-2). Schlage AD-300 Locks Installation Guide... - Page 12 CMN3007502 75-Ohms ¼ watt EXP3004702 47-Ohms ¼ watt Power to the RS485 Hubs should be supplied from a battery-backed 12 VDC power supply that is usually located in the wiring closet with the RS485 Hubs. Schlage AD-300 Locks Installation Guide...
- Page 13 Figure 3-2: Wiring Example – RS485 Hub Wiring to a V1000 EVO Schlage AD-300 Locks Installation Guide...
-
Page 14: Wiring To The Rs485 Hub
Each AD-300 on any particular V1000 EVO must have a unique address assigned in the RS 485 Address field. The supported address range is 128-159. As part of your planning, decide which address will correspond to which door. Schlage AD-300 Locks Installation Guide... -
Page 15: Ad-300 Optional Configuration
Refer to the Couple HHD to Lock section of the Schlage Utility Software User Guide for instructions (refer to Section 1.4 for more information). Coupling the HHD to each AD-300 is optional but recommended. Schlage AD-300 Locks Installation Guide... -
Page 16: Ad-300 Configuration
AD-300 Configuration If this is your first experience with an HHD, CBORD recommends that you familiarize yourself with HHD procedures before attempting to configure the AD-300 locks. Refer to the following information in the Schlage Utility Software User Guide for how to: ... -
Page 17: Cs Gold Configuration
Physical Address: Enter the physical address configured for the AD-300 in step 6 of the procedure in section 3.6. Term Type: Select 2118 - CSGold RS485 VIP Interface from the drop-down list. Sub Type: Select 115 - RS485 VIP Interface from the drop-down list. Schlage AD-300 Locks Installation Guide... -
Page 18: Ad-300 Tps Node Configuration
Sub Type: Select 41 - Schlage 300 MGK, 42 – Schlage 300 PRK, or 43 – Schlage 300/400 SMK raw CSN from the drop-down list. Note: Subtype 43 (available as of Squadron version 4.0.11) allows Schlage AD-300 locks to read MIFARE™ cards and other smart cards used to read card serial numbers (CSNs). -
Page 19: Physical Dead Bolt
Physical Dead Bolt CBORD recommends that Privacy mode be enabled for AD-300 and AD-400 locks equipped with a physical dead bolt. Having Privacy mode enabled will cause the door to be physically secured (locked) from the outside if a patron enters an unlocked door and engages the dead bolt. -
Page 20: Terminal Types
41 – Schlage 300 MGK 2119 – CS Gold RS485 VIP Reader 42 – Schlage 300 PRK AD-300 43 – Schlage 300/400 SMK raw CSN 2118 – CS Gold RS485 VIP Interface 115 – RS485 VIP Interface Schlage AD-300 Locks Installation Guide... -
Page 21: Log Firmware Version And Serial Numbers
R: precedes the serial number of the radio. Note: The radio version will always be 0.0 and the radio serial number will always show Unknown on an AD-300 lock as there is no radio on the wired online locks. Schlage AD-300 Locks Installation Guide... -
Page 22: Reader Operation
In Privacy Secure: Normal or Flash both red slow x1 Toggle credential presented Permit: Slow green flash x1, then fast red flash x1 upon (Open) relock. ACP granted privacy (Relock) Double-swipe unlock: Solid green. Schlage AD-300 Locks Installation Guide... - Page 23 2. Left and right red slow flash while not communicating (Red flashes slowly) USB active with no physical Left flashing green connection (Green flashes) USB device connected to lock Flashing red while connected (out of sequence) (Red flashes) Schlage AD-300 Locks Installation Guide...
- Page 24 Bootloader active with valid app Right green blinking for 5 (waiting for USB device, HHD) seconds (Green blinks for 5 seconds) Bootloader active with invalid app Right red blinking for 5 seconds (Red blinks for 5 seconds) Schlage AD-300 Locks Installation Guide...
-
Page 25: Licensing
= 3 and a.node_sid = b.node_sid and b.term_type_sid = 2002 and a.status = ’ACT’ and exists (select c.node_sid from node_type_term c where a.parent_node_sid = c.node_sid and c.term_type_sid = 2000) group by parent_node_sid) q); InitLicenseInfo( LicenseList, ’Locations’, ’CS Locations’, MyCount ); Schlage AD-300 Locks Installation Guide... - Page 26 0 is returned, verify that the license has been added and that its count is greater than or equal to this count before applying the CS Gold upgrade: select count(*) from node, node_type_term where node.node_sid= node_type_term.node_sid and node.status=’ACT’ and node_type_term.term_type_sid=2119; Schlage AD-300 Locks Installation Guide...
-
Page 27: Enhancements
11 - HID ProxPoint or 15 - HID iClass Prox. If an AD-400 wireless lock is used, select subtype 39 - Schlage 400 PRK. If an AD-300 wired lock is used, select subtype 42 - Schlage 300 PRK. Schlage AD-300 Locks Installation Guide... -
Page 28: Apartment Mode
IPB LED blinking green three times. o Office Mode: Entering Office mode by pressing the IPB will result in the IPB LED blinking green or red three times, depending on whether the door is being unlocked or locked respectively. Schlage AD-300 Locks Installation Guide... -
Page 29: Monitor Request To Enter Status
As of Squadron Access Control version 5.2.0, the strike relay on an AD-300 or AD-400 lock can be used as an input trigger for a local alarm action. For example, unlocking an AD-300 can trip a relay on a V300 output board (or any other local alarm action). Schlage AD-300 Locks Installation Guide... -
Page 30: Mik Credential Reader
Location Configuration on individual lock locations or at the device level for device type 2114 - CSGold Wyreless WAPM: RDR_SmartCard_iClassUID = FALSE RDR_SmartCard_15693ISOXsecure = TRUE Schlage AD-300 Locks Installation Guide... -
Page 31: Appendix A Device Configuration Parameters
RDR_SmartCard_14443EV1 Enable or disable support for 13.56 MHz Smart Card 14443 EV1 (also known as aptiQ). Default is True. RDR_SmartCard_14443PIV Enable or disable support for 13.56 MHz Smart Card 14443 PIV (open). Default is True. Schlage AD-300 Locks Installation Guide... - Page 32 Bit0=HID Bit1=GE4001/CASI Bit2=AWID Bit3=GE4002 RDR_Backlight_Timeout Keypad backlight timeout in (sec). Default is 3 seconds. RDR_RECV_Timeout Controls the ACP Communications Timeout when applied to AD-300 and AD-400 lock locations. Value in milliseconds. Schlage AD-300 Locks Installation Guide...
-
Page 33: Appendix B Troubleshooting
The issue may be that the screws that secure the anti-rotation plate to the mortise lock body are too tight. Using the installation instructions that accompanied the lock as a reference, remove that outer escutcheon and loosen the two screws. Schlage AD-300 Locks Installation Guide... - Page 34 Schlage AD-300 Locks Installation Guide...
