- Page 1 Quick Installation Guide Z BOX-H Battery Cabinet H 372-2H Product Model: C372L-D-EU...
-
Page 2: Table Of Contents
Table of Contents 1. Product features 2. Installation tools 3. Requirement on installation space 4. Floor requirements 5. Cabinet lifting requirements 6. Locking requirements 7. Power cable installation requirements 8 - 9 8. UPS, Grid, Fire COM, PCS COM and ETH installation requirements 9. -
Page 3: Product Features
1. Product features Figure 1-1 Dimensions Weight 3550±50kg Dimensions (W*D*H) 1370*1330*2270mm... -
Page 4: Installation Tools
2. Installation tools Name Purpose Picture For stripping the outer thick insulation of multi- Cable stripping knife core cable For stripping the inner thin insulation of multi- Wire stripper core cable Power drill For drilling mounting holes on the ground (with 10-11mm drill bit) PH2 cross-head For disassembling the bottom cover of the... -
Page 5: Requirement On Installation Space
3. Requirement on installation space Fig. 3-1 Requirement on installation space · At least 600mm of clearance shall be reserved at the back of the cabinet for the maintenance access of the fan. · At least 2,000mm clearance shall be reserved in front of the cabinet for door opening. ·... -
Page 6: Floor Requirements
4. Floor requirements Figure 4-1 Floor Requirements (top view) · The floor shall be flat with 1,470*1,430mm leveled area; four M12*30 anchor bolts shall be driven into the ground for installation of the cabinet. · The 130mm perimeter and 90mm transom are reinforcement areas and need to support a load of ≥4T. -
Page 7: Cabinet Lifting Requirements
5. Cabinet lifting requirements · Cabinet lifting · Take out the four M24 rings and washers according to the packing list. Install them into the holes at the top of the cabinet. Tools: NO. 15 in the tool list. · Install the rope through the four rings and conduct lifting to a height of 800mm, so that the rope angle is greater than 60°. -
Page 8: Locking Requirements
6. Locking requirements Figure 6-1 Locking Requirements · After the cabinet is located onto the anchor bolts, it shall be locked tight with M12 nuts, spring washers and flat washers. 7. Power cable installation requirements Figure 7-1 Power Cable · The power cable, preferably AWG #1 DC1500V, shall enter the cabinet through the bottom. -
Page 9: Ups, Grid, Fire Com, Pcs Com And Eth Installation Requirements
8. UPS, Grid, Fire COM, PCS COM and ETH installation requirements Figure 8-1 External Cable Connection... - Page 10 Terminal definition Terminal Definition Functions Remarks XT1-1L Grid-220L Grid XT1-2L Grid-220N XT1-3L UPS-220L XT1-5L UPS-220N XT2-1L EMU_485A EMU↔PCS XT2-2L EMU_485B XT2-3L BMS_CANH BMS↔PCS XT2-4L BMS_CANL XT2-5L DRY1_IN_P PCS COM EMU→PCS XT2-6L DRY1_IN_N XT2-7L DRY3_IN_P BMS→PCS XT2-8L DRY3_IN_N XT2-9L DRY1_OUT_COM PCS→EMU XT2-10L DRY1_OUT_NO XT2-11L...
-
Page 11: Requirements After Cable Connection
9. Requirements after cable connection · Reinstall the forklift cover. · Turn tight the waterproof joint of the power cable, and fill in the necessary sealing material. · Turn tight the waterproof joint of the communication cable, and fill in the necessary sealing material. - Page 12 VISIT FOLLOW WEBPAGE Energy for Life...
