Product Code:[4L3/1209 (MC054V)]
i
- Detection is possible through doors, panels and thin walls.
- If the sensor is close to high density materials this will reduce or block the microwaves, this could cause nuisance switching.
- Do not place close to fans or other moving objects as these will trigger the sensor.
- The distance between any two sensors should be at least 3m to avoid interference with each other.
6
Only 100%/75%/50% detection sensitivity is workable when installed at 10m
Detection Area (metres)
Fast walk
100%
75%
50%
25%
4
2
2
4
Mounting height: 3m
Fast walk
100%
75%
50%
4
2
2
4
Mounting height: 10m
mounting height. 25% sensitivity is not able to detect motion signal.
Microwave Frequency: 5.8GHz+/-75MHz
Microwave Power: <0.5mW
Mounting Height: 3 - 15m
IP Rating: IP65 (Indoor Use Only)
