Moen 920-004 Specifications

DESCRIPTION
·
Smart home water detector monitoring moisture, humidity, and room temperature.
OPERATION
·
Can be used as a standalone detector or in conjunction with the Flo Smart Water Monitor and
Shutoff (option in the mobile app to trigger automatic water shutoff to a home if the detector
detects moisture and a smart water shutoff is installed on the home's main water line)
·
Wi-Fi enabled device for smartphone connectivity (WLAN connectivity /
IEEE 802.11bgn, 2.4 GHz range)
·
Smartphone app available for iOS and Android that provides customizable alerts for:
-Moisture Detection through base unit or included remote sensing disc
-Humidity Range: customizable between 0-100% Relative Humidity (RH)
-Room Temperature: customizable between 0 to 140 deg F / -18 to 60 deg C
-Battery Level: customizable between 0-100%
·
Automatic water shutoff feature: if a detector senses moisture, it can trigger the smart
water shutoff to close (only available if the Flo Smart Water Monitor and Shutoff is installed
on the main water supply line)
·
Battery type: CR123A Lithium Cell (lasts up to 2 years, included with detector)
·
Operating Temperature Range: -20 to 140 deg F / -29 to 60 deg C
INSTALLATION NOTES
·
Detector can be placed directly on the floor without the wall mount base attached.
·
With the wall mount base attached to detector and 48" (122 cm) remote sensing disc
connected to wall mount base, detector can be mounted on a wall or baseboard and the
remote sensing disc can be placed in low profile/hard-to-reach areas to monitor for moisture.
.
Optional 6' (1.8 m) Leak Sensing Cable that detects water at any point along the cable (SKU
sold separately: 920-006) (up to 3 cables can be linked together for further leak sensing).
STANDARDS
·
Third party certified to meet Industry Canada RSS-210 IC ID: 25926-920004.
·
FCC ID: 2AU5H-920004 to CFR 47 Part 15 Subpart C.
WARRANTY
·
Moen® warrants that the product will be free from defects in materials and workmanship
for a period of one (1) year from the date of delivery following the original retail purchase.
·
Visit moen.com/customer-support/warranty for complete details and limitation.
* Supplier agrees to comply with all applicable laws and regulations when shipping the materials.
Detector
2-5/8"
(67mm)
Off-the-
Wall Depth
1-1/2"
(38mm)
10/22
Remote Sensing Disc
3-1/4"
(83mm)
48"
(1219mm)
CRITICAL DIMENSIONS
S P E C I F I C AT I O N S
1-1/16"
(27mm)
(DO NOT SCALE)
FOR MORE INFORMATION CALL: 1-844-633-8356
Moen™ Smart
Leak Detector
Models: 920-004 (1 pack)
920-005 (3 pack)
CR123A
Battery
Included with 920-004 product:
(1) Moen Smart Leak Detector, (1) CR123A Battery,
(1) 48" (122cm) Remote Sensing Disc, (1) Wall Mount Base with
optional self-adhesive mounting sticker, (2) Wall Mount Screws,
(2) Dry Wall Anchors.
Included with 920-005 product:
(3) Moen Smart Leak Detector, (3) CR123A Batteries
(3) 48" (122cm) Remote Sensing Discs, (3) Wall Mount Base with
optional self-adhesive mounting stickers, (6) Wall Mount Screws,
(6) Dry Wall Anchors.
moen.com
Reset
Button
