Summary of Contents for ECD AC10
- Page 1 LECTRO- HEMICAL EVICES, INC. MODEL AC10 Air Blast Spray Cleaner ELECTRO-CHEMICAL DEVICES, INC. 1500 North Kellogg Dr., Anaheim, CA, 92807, USA Tel: +1-714-695-0051, +1-800-729-1333, FAX: +1-714-695-0057 Email: sales@ecdi.com, Web: www.ecdi.com Rev: B – H0719...
- Page 2 PREFACE Purchasing products from Electro-Chemical Devices, Inc. provides you with the finest liquid analytical instrumentation available. If this is your first purchase from ECD, please read this manual before installing and commissioning your new equipment. If there are any questions concerning this equipment, please contact your local ECD representative, or the factory directly at: Electro-Chemical Devices, Inc.
-
Page 3: Table Of Contents
2.2 Wiring ..............................4 2.2.1 Wire Connections ......................... 4 3.0 Configuring the Controller ........................6 3.1 C22 Configuration ..........................6 3.1.1 Single Channel AC10 ........................6 3.1.2 Dual Channel AC10 ........................6 3.2 T80 Configuration ..........................6 3.2.1 Single Channel AC10 ........................6 3.2.2 Dual Channel AC10 ........................ -
Page 4: Warranty
This warranty is in lieu of any other warranty, expressed or implied. ECD reserves the right to make changes in the design or construction of its products at any time, without prior notification, and without incurring any obligation to make any changes in previously delivered products. -
Page 5: Unpacking The Instrument
3. Save the original packing material until you are satisfied with the contents. In the event the product(s) must be returned to ECD, the packing material will allow you to properly ship it to ECD. 4. Familiarize yourself with the instrument before installation, and follow proper installation and wiring procedures. -
Page 6: General Description
The AC10 can be wall mounted or use the optional 2” handrail mounting system that uses stainless steel support rails with two 2” galvanized pipe clamps. The C22 or T80 Analyzer/Controller uses its internal Timers and Relays to control the Period and Duration of the cleaning cycles. -
Page 7: Specifications
Less than 10 minutes per hour Temperature: minimum: -10°C (14°F) maximum: 50 °C (122°F) Power: 115 VAC 60 Hz 5.5 A 220 VAC 50 Hz 2.1 A AC10 Single Channel Fuses: 3AG T10A 250V 3AG T0.5A 250V Enclosure: Fiberglass reinforced Polyester, NEMA 4X Dimensions: 15.5”x 13.3”x 8.2”(39.4 x 33.7 x 20.7 cm) -
Page 8: Installation
2.0 INSTALLATION The AC10 is suitable for indoor or outdoor installation and it should be mounted out of direct sunlight to avoid overheating. Choose a location with access to electrical power within 30 ft of the sensor. 2.1 M OUNTING The AC10 is designed for wall mounting. -
Page 9: Wiring
2.2.1.1 C22 Wiring The Single Channel AC10 controller connections can be wired with a standard two wire communications cable as shown below. The Dual Channel AC10 is wired as shown below and standard communications cable can be used. Page 4 Spray Cleaner... - Page 10 2.2.1.2 T80 Wiring The Single Channel AC10 controller connections can be wired with a standard two wire communications cable as shown below. The Dual Channel AC10 is wired as shown below and standard communications cable can be used. Model AC10 Page 5...
-
Page 11: Configuring The Controller
ONFIGURATION The recommended settings for the timed relay controlling the AC10 is a period of 1 hours, a spray duration of 1 minute, and the readings on hold for the duration +30 seconds. Two C22’s are required to control the Pump On/Off and Diverter for a Dual Channel AC10 whereas only one T80 is required. -
Page 12: Engineering Documentation
4.0 ENGINEERING DOCUMENTATION Model AC10 Page 7... -
Page 13: Specifications
4.2 P UMBERS Part# Description 1280100-1 (-5 Dual Ch) AC10 Air Blast Cleaner, 115 VAC, Wall Mount 1280100-2 (-6 Dual Ch) AC10 Air Blast Cleaner, 220 VAC, Wall Mount 1280100-3 (-7 Dual Ch) AC10 Air Blast Cleaner, 115 VAC, Handrail Mount... - Page 14 1500 North Kellogg Drive ● Anaheim, CA 92807 ● +1-714-695-0051 ● FAX +1-714-695-0057 ● ecdi.com...
