- Page 1 CORDLESS JIGSAW INSTRUCTION MANUAL CORDLESS JIGSAW INSTRUCTION MANUAL 5 YEAR T-SHANK BLADES WARRANTY LITHIUM ION 220040...
-
Page 2: General Power Tool Safety Warnings
CORDLESS JIGSAW INSTRUCTION MANUAL GENERAL POWER TOOL SAFETY WARNINGS 220040 switch or energising power tools that have the switch on WARNING Read all safety warnings and all invites accidents. instructions.Failure to follow the warnings and Remove any adjusting key or wrench before turning instructions may result in electric shock, fire the power tool on. - Page 3 CORDLESS JIGSAW INSTRUCTION MANUAL 220040 When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another.
-
Page 4: Know Your Product
CORDLESS JIGSAW INSTRUCTION MANUAL KNOW YOUR PRODUCT 220040 1 - TRIGGER LOCK-OFF 2 - TRIGGER 10 - PENDULUM ADJUSTING SWITCH BATTERY INSERTS HERE 9 - LED LIGHT (ANY 18V CHARGE-ALL BATTERY WILL FIT) CHARGE-ALL 8 - SAFETY GUARD 7 - BLADE HOLDER... - Page 5 CORDLESS JIGSAW INSTRUCTION MANUAL HOW TO FIT/REPLACE BLADE 220040 WARNING REMOVE BATTERY BEFORE REMOVING OR INSERTING BLADES HOW TO INSERT BLADE 1. Holding jigsaw upside down, rotate blade holder (7) 2. While holding the blade holder in place, insert the jigsaw clockwise as far as it will go and hold.
- Page 6 CORDLESS JIGSAW INSTRUCTION MANUAL HOW TO ADJUST JIGSAW ANGLE 220040 1. Use the supplied Hex Key (3mm) to loosen the 2. Slide the base plate (5) towards the rear of the 2 bolts on the underside of the Jigsaw. unit.
- Page 7 CORDLESS JIGSAW INSTRUCTION MANUAL HOW TO USE THE JIGSAW 220040 CHARGE-ALL 1. ENSURE SAFETY 2. MAKE SURE YOU HAVE THE RIGHT BLADE Always wear safety glasses when working with Ensure you have the correct blade for the job. The the jigsaw. Make sure to secure your hair and any blade supplied is for cutting wood.
-
Page 8: Maintenance
* Standard 3 year warranty with an additional 2 year warranty available subject to online 5 YEAR registration via katanapowertools.com.au. Warranty on this Katana product is given by Kincrome Australia Pty Ltd of 3 Lakeview Drive, Caribbean Park, Scoresby, Victoria, Australia (Tel +61 3...
