  • Page 1: Fcc Warning

    Corporation. All other trademarks belong to their respective proprietors. Copyright Statement No part of this publication may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from Benq...

  • Page 2: Table Of Contents

    1.2.5 Basic Functions..............6 1.2.6 VLAN................10 1.2.7 Class-of-Service (CoS) Support ........14 1.2.8 GVRP................14 1.2.9 IGMP Snooping and IP Multicast Filtering ....... 15 1.2.10 Switch Management ............16 1.3 Product outlook and LED display ......17 1.3.1 Product Outlook ............... 17 1.3.2 LED Display ..............
  • Page 3 2.4.1 Gigabit Fiber/Copper Module Installation ......25 2.4.2 100FX Fiber Module Installation ........26 3. Switch Management ......... 27 3.1 Management Access Overview........ 28 3.2 Administration Console ..........30 3.3 Web Management ............ 32 3.4 SNMP-Based Network Management ....... 32 3.5 Protocols ..............
  • Page 4 4.7 Restore Default Settings ........136 4.8 Reboot..............136 5. Web-Based Browser Management ....137 5.1 Logging on to the switch......... 137 5.2 Understanding the Browser Interface..... 139 5.3 Performing File Activities........141 5.3.1 Start with Selection Menu ..........141 5.3.2 Saving Setting..............
  • Page 5 6. SNMP & RMON Management ......212 6.1 Overview ..............212 6.2 SNMP Agent and MIB-2 (RFC 1213) ..... 213 6.3 RMON MIB (RFC 1757) and Bridge MIB (RFC 1493) ..................214 7. Trouble Shooting ..........216 Appendix: ............217...

  • Page 6: Introduction

    Gigabit ports, it allows options of fiber type and wavelength at user’s discretion. This switch brings a simple answer for today’s complicated networking environments. To get the best view of this manual, you should have an understanding of Ethernet networking basic concepts. In this manual, you will find:...

  • Page 7: Features And Specifications

    1.2 Features and Specifications 1.2.1 Features 24x10/100BASE-TX ports with RJ-45 connectors, Optional 2x100BASE-FX fiber ports, each allows for multi-mode SC, ST, VF-45, MT-RJ fiber module or single-mode SC fiber module. Optional gigabit module slots, each allows 1000Base-SX/LX fiber module or 1000BASE-T copper module...
  • Page 8 802.1Q compliant tagged VLAN, up to 255 groups TRUNKING Port trunking is provided by 3 groups. Group 1 & group 2, each allows up to 4 ports trunking selected from port 1 ~ port 24 while group 3 allows 2 gigabit ports trunking.
  • Page 9 4-level transmission priorities: 4 queues per output port Packet transmission scheduled using Weighted Round Robin (WRR) User-defined weights Classification of packet priority can be based on either a VLAN tag on packet or a user-definable port priority INTERNETWORKING PROTOCOLS Bridging: 802.1D Spanning Tree...

  • Page 10: Physical Specifications

    Bridge MIB (RFC1493) RMON MIB (RFC1757) – statistics, history, alarm and events VLAN MIB (802.1Q/RFC2674) Private MIB Java applet-based MIB browser Web browser support based on HTTP server and CGI parser Kermit/TFTP software-upgrade capability 1.2.3 Physical Specifications Power 100~240VAC 50-60Hz 0°C ∼...

  • Page 11: Physical Ports

    Below is additional information about tasks that the switch performs during unicast and multicast switching. UNICAST SWITCHING VLAN CLASSIFICATION When the switch receives a frame, it classifies the frame in one of two ways: If the frame is untagged, the switch classifies the frame to an associated VLAN.
  • Page 12 If the frame is tagged, the switch uses the tagged VLAN ID to identify the broadcasting domain of the frame. LEARNING After VLAN classification, the switch checks the <source MAC address, VLAN> pair in the switching database (SDB) to see whether the <source MAC address, VLAN>...
  • Page 13 MULTICAST SWITCHING For multicast switching, the switch checks whether the received frame is a BPDU. If a BPDU is received, the switch forwards the frame to the CPU for processing by the spanning tree protocol. Otherwise, the switch performs the following processes: VLAN CLASSIFICATION Same as for unicast switching.
  • Page 14 Whether the source MAC address or destination MAC address is to be filtered. Whether the source port ID is the same as destination port If any of these conditions are met, the switch drops the receiving. Otherwise, it continues with the forwarding process described below.

  • Page 15: Vlan

    1.2.6 VLAN A virtual LAN (VLAN) is a network of computers that behave as if they are connected to the same wire, even though they may actually be physically located on different segments of a LAN. VLANs are analogous to a group of end stations, perhaps on...
  • Page 16 In traditional networks, traffic broadcasts to all network devices, whether they are the intended recipients or not. However, VLANs can be set up to contain only those devices that need to communicate with each other. As a result, VLANs significantly reduce network congestion.
  • Page 17 Port-based VLANs are organized by physical port number. For example, switch ports 1, 2, 4 and 6 can be grouped on VLAN, while server ports 3, 5, 7 and 8 can be on another VLAN. Broadcasts from servers within each group would only go to the members of its own VLAN.
  • Page 18 GVRP is used to communicate VLAN registration information to other VLAN-aware switches, so that a VLAN member can cover a wide span of switches on a network. GVRP allows both VLAN-aware workstations and switches to issue and revoke VLAN memberships. VLAN-aware switches register an propagate VLAN membership to all ports that belong to the active topology of the VLAN.

  • Page 19: Class-Of-Service (Cos) Support

    1.2.7 Class-of-Service (CoS) Support The switch provides four transmit queues on each port, with a weighted round-robin scheme. These functions can be used to provide independent priorities for various types of data including real-time video, real-time voice, and best-effort data.

  • Page 20: Igmp Snooping And Ip Multicast Filtering

    Routers periodically query the LAN to determine if known group members are still active. If there is more than one router on the LAN performing IP multicasting, one of the routers is elected “querier” and assumes the responsibility of querying the LAN for group members.

  • Page 21: Switch Management

    Note, however, IGMP neither alters nor routes any IP multicast packets. Since IGMP is not concerned with the delivery of IP multicast packets across subnetworks, an external IP multicast router is needed if IP multicast packets have to be routed across different subnetworks. 1.2.10 Switch Management...

  • Page 22: Product Outlook And Led Display

    EXTERNAL SNMP-BASED NETWORK MANAGEMENT APPLICATION The switch can also be configured via SNMP. For more information on switch management, refer to the “Switch Management” section on page 14. 1.3 Product outlook and LED display 1.3.1 Product Outlook Front View of SM2224 Rear view of SM2224 1.

  • Page 23: Led Display

    Transmitting or receiving data. Flashing (Green) ACT stands for ACTIVITY. 100M 100M mode (Green) 10M mode Connection in full duplex mode. FDX stands for FULL-DUPLEX. FDX/COL Collision occurred. Flashing (Yellow) COL stands for COLLISION. Connection in half-duplex mode. Fiber module connected...

  • Page 24: Package Contents

    1.4 Package contents When you unpack the product package, you shall find the items listed below. Please inspect the contents, and report any apparent damage or missing items immediately to your authorized reseller. ü SM2224 x 1 ü This User’s Guide ü...

  • Page 25: Installation

    This chapter gives step-by-step instructions about how to install the switch: 2.1 Operating Environment As with any electric device, you should place the switch where it will not be subjected to extreme temperatures, humidity, or electromagnetic interference. Specifically, the site you select...

  • Page 26: Connecting To Your Network

    2.2. Connecting to Your Network 2.2.1 Cable Type & Length It is necessary to follow the cable specifications below when connecting the switch to your network. Use appropriate cables that meet your speed and cabling requirements. Cable Specifications Max. Port Speed...

  • Page 27: Cabling

    2.2.2 Cabling Step 1: First, ensure the power of the switch and end devices is turned off. <Note> Always ensure that the power is off before any installation. Step 2: Prepare cable with corresponding connectors for each type of port in use.

  • Page 28: Connecting To Power

    2.3 Connecting to Power Step 1: Connect the supplied AC power cord to the receptacle on the back of the switch, and then plug it into a standard AC outlet with a voltage range from 100 to 240 Vac. Step 2: Disconnect the power cord if you want to shut down the switch.
  • Page 29 This option is to download the manufacturer’s diagnostics. Refer to Download Runtime Software for download requirements. When the file transfer is completed, the target system jumps to the entry point of the diagnostic program and starts executing the diagnostic code. The Main Menu of the diagnostic program appears, where you can initiate tests or obtain system information.

  • Page 30: Optional Module Installation

    Remove the plate and keep it for future use when you decide to remove the module With the power off, slide the module into the slot Once it is slid in fully, snap in the module to make a proper connection and fasten the screws Turn on the power...

  • Page 31: 100Fx Fiber Module Installation

    Remove the plate and keep it for future use when you decide to remove the module With the power off, slide the module into the slot Once it is slid in fully, snap in the module to make a proper connection and fasten the screws Turn on the power...

  • Page 32: Switch Management

    3. Switch Management This chapter explains the methods that you can use to configure management access to the switch. It describes types management applications communication and management protocols that deliver data between your management device (workstation or personal computer) and the system. It also contains information about port connection options.

  • Page 33: Management Access Overview

    3.1 Management Access Overview The switch gives you the flexibility to access and manage the switch using any or all of the following methods. The administration console and web browser interface support are embedded in the switch software and are available for immediate use.
  • Page 34 DISADVANTAGES Security can be compromised (Hackers need only know the IP address and subnet mask) May encounter lag times on poor connections External SNMP-based network management application ADVANTAGES Communicates with switch functions at the MIB leve Based on open standards...

  • Page 35: Administration Console

    The administration console is an internal, character-oriented, menu-driven user interface for performing system administration such as displaying statistics or changing option settings. Using this method, you can view the administration console from a terminal, personal computer, Apple Macintosh, or workstation connected to the switch’s console port.
  • Page 36 The switch echoes characters that it receives as input on the modem port to the current administration console session. The console appears to be directly connected to the external modem.

  • Page 37: Web Management

    The switch provides a browser interface that lets you configure and manage the switch remotely. After you set up your IP address for the switch, you can access the switch’s web interface applications directly in your web browser by entering the IP address of the switch. You can then...

  • Page 38: Protocols

    Macintosh, a PC, or a UNIX workstation. Because Telnet runs over TCP/IP, you must have at least one IP address configured on the switch before you can establish access to it with a virtual terminal protocol <Note> Terminal emulation is different from a virtual terminal protocol in that you must connect a terminal directly to the console port.

  • Page 39: Management Architecture

    (e.g. console port) are immediately displayed the other management methods (e.g. SNMP agent of web browser). The management architecture of the switch adheres to the IEEE open standard. This compliance assures customers that the switch is compatible with, and will interoperate with other solutions that adhere to the same open standard.

  • Page 40: Menu-Driven Console Management

    For the later, you must specify an IP address for the switch first. This chapter describes how to configure the switch using its menu-driven console. * For initial IP settings, you must configure the switch through its RS232 port. 4.1 Logging on to the switch AT THE SCREEN PROMPT...

  • Page 41: Switch Management Screen

    Factory Default Password: no password, press <Enter> directly. <Note> Only one console and three telnet users can log on to switch concurrently. However, recommended that multiple users modify configuration at the same time. 4.2 Switch Management Screen 4. Menu-Driven Console Management -37...
  • Page 42 Refer to page 51 for performing advanced management activities. LOGOUT Highlight this option and press Enter to log out. SAVE SETTINGS Highlight this option and press Enter to save the current settings and remain in the configuration program. 4. Menu-Driven Console Management -38...
  • Page 43 The console interface consists of a series of menu boxes. Each menu box has several options, which are listed vertically. Move the highlight to select an option as you wish; press the Enter key to activate that option. Press this key…...

  • Page 44: Basic Management

    4.3.1 Start with Selection Menu Step 1: Highlight [Basic Management] from [Switch Management] screen and press <Enter>. The [Basic Management] screen appears: Step 2: Highlight a desired option and press <Enter>. Or press <Esc> to exit. 4. Menu-Driven Console Management -40...

  • Page 45: General Management Configurations

    4.3.2 General Management Configurations Step 1: Highlight [General] from [Basic Management] screen and press <Enter>. System Name Step 2: System Name is highlighted. Press <Enter> if you want to change it. Location Move to highlight Location and press <Enter> if you Step 3: want to change it.
  • Page 46 Password Step 5: Move to highlight guest Password and press <Enter> if you want to change it. Statistics Collection Move to highlight Statistics Collection and press Step 6: <Enter> if you want to change it, Disabled or Enabled. Reboot-On-Error Step 7: Move to highlight Reboot-On-Error and press <Enter>...

  • Page 47: Lan Port Configurations

    Step 1: Highlight [LAN Port] from [Basic Management] screen and press <Enter>. SPEED & FLOW CONTROL Step 2: Speed & Flow Control is highlighted. Press <Enter> if you want to set speed or flow control on port. 4. Menu-Driven Console Management -43...
  • Page 48 Step 3: Highlight All (10/100M or 1000M) Ports and press <Enter> to configure at one time. Otherwise, move to highlight each port and press <Enter> to configure individually. Step 4: Port Setting Options screen appears. Highlight Speed & Flow Control and press <Enter>.
  • Page 49 Line Speed Step 5: For Line Speed, move to highlight a desired setting from Speed Options and press <Enter>. <Note> In the Speed Options, Auto denotes auto negotiation on speed and duplex mode, and FD denotes full-duplex. Press <Esc> to previous screen. Highlight Flow Step 6: Control and press <Enter>...
  • Page 50 Step 7: For Flow Control, move to highlight a desired setting from the Flow Cntl Options and press <Enter>. Step 8: Press <Esc> to a previous screen as shown in Step 3. Admin. Control Step 9: Highlight All Ports and press <Enter> to configure at one time.
  • Page 51 Step 10: For Admin Control, move to highlight Up or Down from admin Status Options. Step 11: E.g. Port 4 is set as Admin Down to stop TX/RX transmission. To allow TX/RX transmission on Port 4, move to highlight Up from the options in Step 10.
  • Page 52 <Note> The other ports are set Admin Up but no link. (Down denotes no link). PHYSICAL PORT ADDRESS Step 12: Press <Esc> to a previous screen as shown in Step 1. Step 13: Move to highlight Physical Address to view physical port address.

  • Page 53: Console Port Configurations

    [Basic Management] screen. Baud Rate Step 2: Baud Rate is highlighted. Press <Enter> if you want to change the current console baud rate. Flow Control Step 3: Move to highlight Flow Control and press <Enter> if you want to change the current flow control method.
  • Page 54 Step 8: When SLIP IP address is entered, move to highlight SLIP Subnet Mask and press <Enter>. Enter a suitable subnet mask. <Note> You must enter a SLIP address before you can enter a SLIP subnet mask. 4. Menu-Driven Console Management -50...

  • Page 55: Advanced Management

    4.4 Advanced Management Advanced management activities consist of L2 Switching DataBase / IP Networking / Bridging / Static Filtering / Spanning Tree / SNMP / Other Protocols / Port Trunking / Port Mirroring / File Transfer. 4.4.1 Start with Selection Menu...
  • Page 56 View and change IP settings, ARP and routing table parameters, DHCP gateway settings, and ping settings. BRIDGING View and change the aging period for a MAC address and the flood limit for all ports. STATIC FILTERING View / add / delete / search all source or destination MAC addresses to be filtered.
  • Page 57 View and change GVRP and IGMP settings. PORT TRUNKING Assign a range of ports to trunking groups. PORT MIRRORING Mirror one port to Port 1 or Port 13. FILE TRANSFER Send files using the TFTP or Kermit protocol. 4. Menu-Driven Console Management -53...

  • Page 58: L2 Switching Database

    <Enter>. VLAN Perspective Step 1: The VLAN Perspective is highlighted. Press <Enter> to view VLAN info of the default VLAN or if you want to obtain a VLAN perspective instead of the default VLAN. <Note> Default VLAN: The IEEE802.1Q standard defines VLAN ID #1 as the...
  • Page 59 [＋] to create VLAN: press [+] on keypad [－] to delete VLAN: press [-] on keypad Create VLAN Step 2: Press [+] on keypad to enter New VLAN Settings. Enter new VLAN ID and VLAN name. Enter a new VLAN ID as either a 12-bit decimal or hexadecimal value.
  • Page 60 Add New Switch Ports Step 3: Press <Esc> and appears the following screen. Press [+] to add new switch ports to the newly created VLAN. [＋] to add switch ports: press [+] on keypad [－] to delete switch ports: press [-] on keypad * No precautionary message appears before you delete a switch port.
  • Page 61 Move to highlight a suitable option from Port Options Step 4: and press <Enter>, e.g. Untagged Ports. From Select Untagged Ports, press <Enter> to select Step 5: All Ports or move to highlight each port individually and press <Enter>. Similar procedure when you select Tagged Ports and Forbidden Ports in Step 4 4.
  • Page 62 Step 4 and Step 5. Step 6: Press <Esc> to a previous screen as shown in Step 1. Delete VLAN Step 7: Delete VLAN: highlight a VLAN ID and press [-] to delete it.
  • Page 63 Step 8: Press <Esc> to a previous screen as shown in Step 1 when completed with deleting a VLAN. VLAN Info Step 9: Highlight an existing VLAN and press <Enter> to view VLAN information. 4. Menu-Driven Console Management -59...
  • Page 64 Step 10: Move to highlight VLAN Activities and press <Enter> to view or search activity information. Step 11: Return to Step 9. Move to highlight VLAN Settings and press <Enter>. The screen appears as shown in Step 3 for adding or deleting switch ports.
  • Page 65 MAC ADDRESS PERSPECTIVE Step 1: Move to highlight [MAC Address Perspective] from [L2 Switching DataBase] screen on page 54, and press <Enter>. Step 2: Enter a MAC address to view characteristics information, corresponding VLANs, and corresponding ports in the switching database.
  • Page 66 Per Port VLAN Activities Step 2: Per Port VLAN Activities is highlighted. Press <Enter>. Step 3: Move to highlight a port and press <Enter>. E.g. select Port 18 to view corresponding VLAN Activities. 4. Menu-Driven Console Management -62...
  • Page 67 Step 4: View or search by MAC address individually. Step 5: Press <Esc> to return to a previous screen as shown in Step 1. Per Port Statistics Step 6: Move to highlight Per Port Statistics and press <Enter>. <Enter> to view by port...
  • Page 68 Step 7: Move to highlight a port and press <Enter>. E.g. select Port 1 to view corresponding VLAN Activities. Press <R> to reset counter for this port. 4. Menu-Driven Console Management -64...
  • Page 69 Per Port MAC limit Step 8: Move to highlight Per Port MAC Limit and press <Enter>. 4. Menu-Driven Console Management -65...
  • Page 70 Move to highlight a port and press <Enter>. E.g. select Port 1 to view corresponding MAC limit. User can choose to set MAC learning function as 1. limit with range: 0~16; or 2. Unlimited learning; or 3. No MAC learning...

  • Page 71: Ip Networking

    4.4.3 IP Networking Move to highlight [IP Networking] from [Advanced Management] screen and press <Enter>. IP & RIP SETTINGS Step 1: Highlight [IP & RIP Settings] from [IP Networking] and press <Enter>. 4. Menu-Driven Console Management -67...
  • Page 72 Step 2: The screen shows a list of VLAN IDs, IP addresses, subnet masks, proxy ARPs, and RIPs currently defined. Before you can define a VLAN’s IP settings, you must first create a VLAN as described in previous section. Step 3: Move to highlight the row that contains the parameters you want to change, and then press <Enter>.
  • Page 73 Step 4: Move to highlight a parameter you want to change, and then press <Enter> for modifications. Otherwise, you may press <-> to delete that parameter. Initial IP Settings Step 5: Move to highlight IP Address and press <Enter>. Step 6: Type an IP address and press <Enter>...
  • Page 74 <Enter>. The screen shows the ARP table entries that have been defined or learned. Add/Delete Static ARP Table Entries Step 2: Press [+] on keypad to add an entry into the ARP Table. Enter Internet/Physical Addresses then. 4. Menu-Driven Console Management -70...
  • Page 75 Step 3: Press [-] on keypad if you want to delete a static entry from the ARP Table. * No precautionary message appears before you delete an entry from the ARP table. * Be sure you want to delete it before doing so.
  • Page 76 4. Menu-Driven Console Management -72...
  • Page 77 ROUTING TABLE Step 1: Move to highlight [Routing Table] from [IP Networking] and press <Enter>. The screen shows the Routing Table allows you to view, add, delete or search a particular routing path. 4. Menu-Driven Console Management -73...
  • Page 78 The number of hops needed between the switch and the destination network. VLAN The VLAN within which the gateway or destination resides. Type The IP route type for the IP subnetwork. There are six IP route types: Direct A directly connected subnetwork. Remote A remote IP subnetwork or host address.
  • Page 79 * No precautionary message appears before you delete an entry from the routing table. * Be sure you want to delete it before doing so. Search for Routing Table Entries Step 4: Press <S> to search a network address. Enter the network address you want you are looking for.
  • Page 80 DHCP GATEWAY SETTINGS Step 1: Move to highlight [DHCP Gateway Settings] from [IP Networking] and press <Enter>. Step 2: Move to highlight a row you want to change the DHCP Gateway Settings, and press <Enter> 4. Menu-Driven Console Management -76...
  • Page 81 Add/Delete Relay IP Step 3: Press [+] on keypad to add a relay IP. Choose a suitable interface or All Interfaces from Select Outbound Relay Interfaces. Otherwise, you may press [-] on keypad to delete a relay IP. * No precautionary message appears before you delete a relay IP.
  • Page 82 Preferred Server Step 9: Move to highlight Preferred Server and press <Enter>. Step 10: Enter IP address for the Preferred Server. Step 11: To specify up to three more Preferred Servers, repeat the above steps. 4. Menu-Driven Console Management -78...
  • Page 83 Enter 4 decimal bytes (dot separated) as the IP address to ping. Count Move to highlight Count and press <Enter>. Step 4: Step 5: Specify a packet count number from 1 to 999, or type 0 for an infinite packet count. Press <Enter>. 4. Menu-Driven Console Management -79...
  • Page 84 Timeout (sec) Move to highlight Timeout and press <Enter>. Step 8: Step 9: Specify a timeout value from 1-999. Press <Enter>. Step 10: Press <Esc> to start to ping when completed with the ping parameters. 4. Menu-Driven Console Management -80...

  • Page 85: Bridging

    4.4.4 Bridging Move to highlight [Bridging] from [Advanced Management] screen, and press <Enter>. 4. Menu-Driven Console Management -81...
  • Page 86 AGING TIME Step 1: Move to highlight Aging Time and press <Enter>. Aging Options Set Aging Time is highlighted. Press <Enter>. Step 2: Enter a decimal number as bridge aging period in seconds. 4. Menu-Driven Console Management -82...
  • Page 87 Otherwise, you may move to highlight No Aging, and Step 3: press <Enter>. FLOOD LIMIT FOR ALL PORTS Step 1: Move to highlight [Flood Limit for All ports] and press <Enter>. 4. Menu-Driven Console Management -83...
  • Page 88 Flooding Options Set Flood Limit is highlighted. Press <Enter>. Step 2: Enter a decimal number as flood limit in packets per second. Otherwise, you may move to highlight Unlimited, and Step 3: press <Enter>. 4. Menu-Driven Console Management -84...

  • Page 89: Static Filtering

    4.4.5 Static Filtering Move to highlight [Static Filtering] from [Advanced Management] screen, and press <Enter>. 4. Menu-Driven Console Management -85...
  • Page 90 If you select destination MAC addresses, the DST MAC Out-Filter appears * No precautionary message appears before you delete a specific MAC address from being filtered. * Be sure you want to delete it before doing so. 4. Menu-Driven Console Management -86...
  • Page 91 Add/Delete/Search Step 2: Press [+] on keypad to add a specific MAC address to be filtered. Press [-] to delete a specific MAC address from being filtered. Press <S> to search through current list of MAC addresses in the static filtering database. The static filtering database maximum capacity is 64.

  • Page 92: Spanning Tree Functions

    Add/Delete/Search Step 3: Press [+] on keypad to add a specific MAC address to be filtered. Press [-] to delete a specific MAC address from being filtered. Press <S> to search through current list of MAC addresses in the static filtering database. The static filtering database maximum capacity is 64.
  • Page 93 SPANNING TREE CONFIGURATIONS Step 1: Move to highlight [Spanning Tree Configurations] if you want change Spanning Tree Protocol Configurations. Read-only values Move Down for more User configurable Spanning Tree Protocol Step 2: Press <Enter> to enter Spanning Tree Options. Decide to have it Disabled or Enabled.
  • Page 94 Step 6: Type a decimal number for the forward delay. SPANNING TREE PORT STATES Step 1: Move to highlight [Spanning Tree Port States] if you want to change per port administration status, and press <Enter>. 4. Menu-Driven Console Management -90...
  • Page 95 Step 2: Move to highlight a port if you want to change its administration status, and press <Enter>. ‘Disabled (Link Down)’ denotes Admin Status Up without a link. ‘Forwarding’ denotes Admin Status Up with a link. ‘Admin Status Down’ denotes no TX/RX transmission allowed ‘Admin Status Up’...
  • Page 96 Move to highlight All Ports or each port individually, Step 2: and press <Enter>. For new path cost, type a decimal number and press <Enter>. SPANNING TREE PORT PRIORITIES Step 1: To change the priority level per port, move to highlight [Spanning Tree Port Priorities] and press <Enter>.

  • Page 97: Snmp Functions

    4.4.7 SNMP Functions Move to highlight [SNMP] from [Advanced Management] screen, and press <Enter>. Factory-default values Move Down for more SNMP Options Move to highlight SNMP and press <Enter>. Step 1: Decide to have it Disabled or Enabled. Get Community Name...
  • Page 98 Trap Community Name Step 3: Move to highlight Trap Community Name 1 and press <Enter>. Enter text and press <Enter>. Repeat to specify up to three more trap community names. Trap Host IP Address Move to highlight Trap Host 1 IP Address and press Step 4: <Enter>.
  • Page 99 Step 9: Move to highlight Authentication Failure Trap and press <Enter>. Decide to have it Disabled or Enabled. Rising Alarm Trap Step 10: Move to highlight Rising Alarm Trap and press <Enter>. Decide to have it Disabled or Enabled. Falling Alarm Trap Step 11: Move to highlight Falling Alarm Trap and press <Enter>.

  • Page 100: Other Protocols

    4.4.8 Other Protocols Move highlight [Other Protocols] from [Advanced Management] screen, and press <Enter>. 4. Menu-Driven Console Management -96...
  • Page 101 GVRP Move to highlight GVRP and press <Enter>. Step 1: Step 2: Decide to have it Disabled or Enabled. 4. Menu-Driven Console Management -97...
  • Page 102 IGMP Move to highlight IGMP and press <Enter>. Step 1: Step 2: Decide to have it Disabled or set in either Passive or Active mode. 4. Menu-Driven Console Management -98...

  • Page 103: Port Trunking

    Move to highlight [Port Trunking] from [Advanced Management] screen, and press <Enter>. Port trunking is provided by 3 groups. Group 1 & group 2, each allows up to 4 ports trunking selected from port 1 ~ port 24 while group 3 allows 2 gigabit ports trunking.
  • Page 104 Select Trunk Ports Step 3: E.g. Port 1-24 is highlighted. Move and press <Enter> to select a trunk port. You can select a maximum of four ports for each Trunk group. Step 4: Press <Esc> when completed with selecting ports...

  • Page 105: Port Mirroring

    4.4.10 Port Mirroring Move to highlight [Port Mirroring] from [Advanced Management] screen, and press <Enter>. 4. Menu-Driven Console Management -101...
  • Page 106 Step 1: Move to highlight Mirror index 1 or 2. E.g. Index 1 is highlighted. Press <Enter> to enter Port Mirroring Options. Mirror To(From) Press <Enter> to enter Mirror To Options, listing the Step 2: ports that can be mirrored to; Options Mirror From Options, listing the ports that can be mirrored from.

  • Page 107: Qos

    Step 3: Move to highlight the port you want to mirror to and press <Enter>; apply same policy to choose the port you want to mirror from. Mirror Mode Step 4: Move to select Mirror Mode. From Mode Options, decide whether the port to be mirrored from will be receiving or transmitting.
  • Page 108 4.4.11.1 Setting global settings Move to highlight Global Setting. Press <Enter> to Step 1: enter DiffServ Expedite Forwarding Step 2: Move to highlight DiffServ Expedite Forwarding mode and press <Enter>; user can select to set enable or disable. 4. Menu-Driven Console Management -104...
  • Page 109 <Enter>; user can select to choose TOS or VLAN tag. Select bits of TOS for transmit priority Step 4: Move to select ToS for Xmit, and press <Enter> to select Bit[4~2] or Bit[7~5] of ToS as transmit priority. 4. Menu-Driven Console Management -105...
  • Page 110 Move to select ToS for Drop, and press <Enter> to Step 5: select Bit[4~2] or Bit[7~5] of ToS as drop priority; similar to step 4. Set QoS Status Step 6: Move to select QoS Status, and press <Enter> to enable or disable QoS mode. 4. Menu-Driven Console Management -106...
  • Page 111 Step 7: Move to select WRED Drop Priority Setting, and press <Enter> Step 8: To change Low drop percentage, press <Enter> to see below screen. Note that only Level 2’s percentage can be modified; while Level 1 and 3 remain fixed at 0% and 100%.
  • Page 112 Step 9: Highlight the appropriate percentage and press <Enter>. Step 10: To change high drop percentage, follow same steps in low percentage. Note that Level 3’s percentage remains fixed at 100%. Only Level 1 & 2’s percentage can be modified.
  • Page 113 4.4.11.2 specifying tcp/udp logical port settings Step 1: From the QoS menu, move to highlight Logical Port then press <Enter>. 4. Menu-Driven Console Management -109...
  • Page 114 With the highlight of User-Define Port, press <Enter>. Step 2: Then screen appears as follows: Step 3: Use the down or up arrow key to highlight the appropriate port, then press <Enter> to see following screen: 4. Menu-Driven Console Management -110...
  • Page 115 Step 4: In the setting submenu, user can: * choose to set drop priority as low or high * change to transmit priority ; ranges from 0 to 7 * change port status as enabled or disabled as following screens:...
  • Page 116 Well-Known Port Step 5: The well-Known Port index screen works the same way the User-Define Port Index screen works, except that the well-known port number is preset and cannot be changed. 4. Menu-Driven Console Management -112...
  • Page 117 Step 6: Move to select Range Logical Port from Logical Port submenu, then press <Enter> to see following screen. Step 7: To change the low port number, press the <Enter> key with the highlight on Low Port Number; then type in the low port number in decimal notation.
  • Page 118 Also note that the available range for both low and high port number is from 1 to 65535. Step 9: To change the Drop priority, press the <Enter> key with the highlight on Drop priority; two choices are available: low or high.
  • Page 119 Move to highlight VLAN from the QoS menu. Press Step 1: <Enter> to see the following VLAN priority index screen Step 2: Select a port and press <Enter> to enter this port’s VLAN priority setting submenu. 4. Menu-Driven Console Management -115...
  • Page 120 To change Drop Priority, press <Enter> with the highlight of the item and select it as high or low. Step 4: To change Transmit Priority, press <Enter> with the highlight of the item and choose a integer from 0 to 7. 4. Menu-Driven Console Management -116...
  • Page 121 4.4.11.4 specifying the tos priority Step 1: Move to highlight TOS from the QoS menu. Press <Enter> to see the following TOS priority index screen Step 2: Select a port and press <Enter> to enter this port’s TOS priority setting submenu.
  • Page 122 Step 4: To change Transmit Priority, press <Enter> with the highlight of the item and choose a integer from 0 to 7; similar to the previous section. 4. Menu-Driven Console Management -118...
  • Page 123 4.4.11.5 selecting a QoS profile Step 1: Move to highlight Profile from QoS menu to see the following screen. Megabit Profile Step 2: With the highlight of Megabit Profile, press <Enter> to enter Megabit Profile, listing all megabit ports. 4. Menu-Driven Console Management -119...
  • Page 124 Step 3: Choose one megabit port and press <Enter> to see the setting submenu. Step 4: In the megabit port setting, three items are available for change: * To change Profile name Move to highlight Profile Name and press <Enter> to type in a new profile name 4.
  • Page 125 Move to highlight Bandwidth partitions and press <Enter> to select as following screen * To set QoS with flow control Move to highlight QoS with flow control and press <Enter> to select as enabled or disabled. 4. Menu-Driven Console Management -121...
  • Page 126 Gigabit Profile Step 5: Choose one Gigabit port and press <Enter> to see the setting submenu. Step 6: Choose one megabit port and press <Enter> to see the setting submenu. 4. Menu-Driven Console Management -122...
  • Page 127 Step 7: In the Gigabit port setting, four items are available for change; three are the same as in Megabit port setting, another available setting is Sharper Configuration. User can following the above steps for Megabit setting to complete similar items.
  • Page 128 4.4.11.6 specifying the port configuration Move to highlight Port Configuration from QoS menu Step 1: and press <Enter> to see the following screen. Step 2: Choose one port and press <Enter> to enter each port’s configuration. 4. Menu-Driven Console Management -124...
  • Page 129 Note that other attributes are read-only. <Note> For Gigabit ports, e.g. port 25 and port 26 are all assigned to a fixed profile. They can’t be modified under this menu.
  • Page 130 Step 2: Pressing <Enter> to with the Rate Control highlighted, user can choose to enable or disable Rate Control mode. Step 3: To change the port number setting, press the arrow key to highlight Port number and press Enter. 4. Menu-Driven Console Management -126...
  • Page 131 Step 4: Move to highlight the desired port you want to modify and a screen showing the average rate and traffic type settings for the selected port appears. Average Rate Step 5: In selected port’s submenu move to highlight Average Rate and press <Enter>, then choose a appropriate...
  • Page 132 Traffic Type Step 6: In selected port’s submenu move to highlight Traffic Type and press <Enter>, then select traffic type as streaming or bursting. <Note> No rate control configurable feature available for Gigabit ports, e.g. port 25 & 26. 4. Menu-Driven Console Management -128...

  • Page 133: File Transfer

    Move to highlight [File Transfer] from [Advanced Management] screen, and press <Enter>. If you access the administration console by connecting an RS232 cable directly to the console port at the back of the switch, you will see a different [File Transfer] screen, as shown below.
  • Page 134 4.4.12.1 Receive File Via TFTP Move to highlight Receive File Via TFTP and press Step 1: <Enter>. Step 2: Type the name of the file you intend to receive and press <Enter>. 4. Menu-Driven Console Management -130...
  • Page 135 Step 3: Move to highlight IP Address and press <Enter>. Type the IP address from where the file will be obtained. Step 4: Press <Esc> when completed. 4. Menu-Driven Console Management -131...
  • Page 136 Step 5: A dialog box appears to ask if you want to transfer file now. Highlight [Yes] and press <Enter> to start file transfer. Otherwise, move to highlight [No] and press <Enter> to deny it. Step 6: Press <Esc> to a previous screen.
  • Page 137 If the default File Type is not the one you intend to Step 2: send, press <Enter>. Select the file type you intend to send and press <Enter>. Step 3: Repeat Step 3-5 on page 131. 4. Menu-Driven Console Management -133...
  • Page 138 Step 1: In [File Transfer] screen obtained via console port, move to highlight Receive File Via Kermit and press <Enter>. Step 2: A dialog box appears to ask if you want to transfer file now. Move to highlight [Yes] and press <Enter> to start file transfer.
  • Page 139 Step 4: Press <Esc> to a previous screen. 4. Menu-Driven Console Management -135...

  • Page 140: Logout

    <Enter>. 4.7 Restore Default Settings To restore the factory default settings, highlight [Restore Default Settings] from [Switch Management] and press <Enter>. The switch will be rebooted after confirming Yes as to restore the default settings. 4.8 Reboot reboot...

  • Page 141: Web-Based Browser Management

    This chapter describes how to configure the switch using its web-based browser interface. 5.1 Logging on to the switch SWITCH IP ADDRESS In your web browser, specify the IP address of the switch. LOGIN ID Enter the factory default login ID: admin. 5. Web-Based Browser Management -137...
  • Page 142 PASSWORD Enter the factory default password (no password, press Enter directly). Otherwise, enter a user-defined password if you followed the instructions later and changed the factory default password. 5. Web-Based Browser Management -138...

  • Page 143: Understanding The Browser Interface

    In addition, you can click any port on the switch image to view the switch’s current speed, duplex, and activity status. The Basic Setup/General parameters appear at the lower field of the screen.
  • Page 144 Click to see LED status FILE Save settings configured in the browser interface / download upgraded software via TFTP / reboot the switch / logout of the browser interface. BASIC SETUP Perform general, LAN port, and console port activities. 5. Web-Based Browser Management -140...

  • Page 145: Performing File Activities

    / static MAC filters / SNMP / port trunking / port mirroring…tasks. 5.3 Performing File Activities 5.3.1 Start with Selection Menu Click the [File] button at the upper field of the main display, the menu options appear. 5. Web-Based Browser Management -141...

  • Page 146: Saving Setting

    When you click it, a message asks ”Are you sure you Step 2: want to save setting? ”, click OK to save it or Cancel to abort it. 5.3.3 Receive File Via TFTP Click Receive File Via TFTP on the [File] display Step 1: <Note>...

  • Page 147: Reboot

    For File Name, type the name of the file you intend to Step 2: receive. For IP Address, type the IP address from where the Step 3: file will be obtained. Click Receive Now! . Step 4: 5.3.4 Reboot Step 1: Click Reboot on the [File] display.

  • Page 148: Logout

    Step 2: When you click it, a message asks ”Are you sure you want to save setting? ”, click OK to save it or Cancel to abort it. 5.3.5 Logout Step 1: Click Logout on the [File] display. When you click it, a message asks ”Are you sure you Step 2: want to save setting? ”, click OK to save it or Cancel...

  • Page 149: Performing Basic Setup Activities

    5.4 Performing Basic Setup Activities 5.4.1 Start with Selection Menu Click the [Basic Setup] button at the upper field of the main display, the menu options appear. 5. Web-Based Browser Management -145...

  • Page 150: General Management Configuration

    5.4.2 General Management Configuration Click General and the screen shows the Basic Step 1: Setup/General parameters. The screen here is the same as shown on page 139 when you first access the switch browser interface. Read-only information System Name Click in System Name text box on the field of Basic Step 2: Setup/General.
  • Page 151 Location Step 4: Click in Location text box on the field of Basic Setup/General. Step 5: Type a location name if it is blank, or replace the current location name with a new one. Statistic Collection Step 6: To enable or disable statistics collection at the switch, click the appropriate option from Statistic Collection drop-down menu.

  • Page 152: Lan Port Configuration

    Click Update Setting. A confirmation window appears. Step 9: Click any button at the upper field of the screen to exit. 5.4.3 LAN Port Configuration To access the LAN configuration parameters, click Basic Setup button first and then point to LAN Port and click a suitable option.
  • Page 153 5.4.3.1 Port Status Control Step 1: Click Speed & Flow Control to view the line speed and flow control for all ports. 5. Web-Based Browser Management -149...
  • Page 154 5.4.3.2 Port setting Click Basic Setup _LAN Port _Port Setting to Step 1: access the configuration information for all ports. Step 2: In the Port column, click the port you want to configure. E.g. click Port 1. 5. Web-Based Browser Management -150...
  • Page 155 Click the drop-down menu under Admin Setting, Step 3: decide to disable or enable it. <Note> Disable: places the port in DOWN state. In this state, packets cannot be switches to and from the port Enable: places the port in UP state. In this state, packets can be switched to and from the port.
  • Page 156 Enable: turns on flow control at all times. Click Update Setting when completed. A confirmation Step 6: window appears. <Note> The information here displayed automatically updates every 15 seconds, without requiring you to refresh the window. 5. Web-Based Browser Management -152...

  • Page 157: Console Port Configuration

    5.4.4 Console Port Configuration To access the console port configuration parameters, click Basic Setup button first and then click Console Port. Baud Rate Click an appropriate speed from Baud Rate drop-down Step 1: menu on the field of Basic Setup/Console Port Configuration.
  • Page 158 Flow Control Step 2: Click a flow control method from Flow Control drop-down menu. Modem Control Click an appropriate option from Modem Control Step 3: drop-down menu to disable or enable a modem connection to the console port. Modem Setup String Flag...
  • Page 159 SLIP Subnet Mask If you enable SLIP, type a SLIP subnet mask in SLIP Step 8: Subnet Mask text box. Click Update Setting when completed. A confirmation Step 9: window appears. <Note> If you enable SLIP, a message tells you that the console port becomes accessible only through the SLIP protocol after you click Update Setting.

  • Page 160: Performing Advanced Setup Activities

    5.5 Performing Advanced Setup Activities 5.5.1 Start with Selection Menu Click the [Advanced Setup] button at the upper field of the main display, the menu options appear. 5. Web-Based Browser Management -156...

  • Page 161: Mac Address Management

    5.5.2 MAC Address Management From the Advanced Setup menu, point to MAC Address Management to view VLANs and their associated MAC addresses. 5. Web-Based Browser Management -157...
  • Page 162 Per VLAN View Click Per VLAN View first, and click on the VLAN ID Step 1: that you want to view. Step 2: Click to close the VLAN Activities window when finished viewing. 5. Web-Based Browser Management -158...

  • Page 163: Mac Address

    Advanced Setup Address Step 1: Click Management _ Per Port View first, and click on the port that you want to view. If there is a list of MAC addresses here, you may click any one to view information by individual MAC address.
  • Page 164 INDIVIDUAL MAC VIEW Step 1: Click Advanced Setup _ MAC Address Management _ Individual MAC View. Click in the Enter MAC Address text box and type the Step 2: MAC address that you want to view. Step 3: Then click on the Get Information button.

  • Page 165: Ip Networking

    5.5.3 IP Networking To access the IP networking parameters, click the Advanced Setup button, and Point to IP Networking from the selection menu. 5. Web-Based Browser Management -161...
  • Page 166 5.5.3.1 IP & RIP Settings Step 1: Click IP & RIP Settings to access IP and RIP settings. A list of VLAN IDs appears, along with their corresponding IP address and subnet mask. 5. Web-Based Browser Management -162...
  • Page 167 IP address. * No precautionary message appears before you delete the IP address. * Be sure you want to delete it before doing so. The IP address is not deleted until you click Update Setting. 5. Web-Based Browser Management -163...
  • Page 168 IP Subnet Mask Step 4: Click in the text box and type a new address. Frame Type Step 5: Click a value from the drop-down list. BOOTP Step 6: Click a value from the drop-down list. Proxy ARP Step 7: Click a value from the drop-down list.
  • Page 169 Specify whether you want to broadcast, multicast, or neither from the drop-down list. Advertise Routes Step 10: Specify whether you want to advertise routes. Advertise Default Route Step 11: Specify whether you want to advertise the default route. 5. Web-Based Browser Management -165...
  • Page 170 Accept RIP V1/V2 Updates Step 12: Specify whether you want to accept RIP V1/V2 updates. Accept Default Route Updates Step 13: Specify whether you want to accept default route updates. Use Split Horizon Step 14: Specify whether split horizon is to be used.
  • Page 171 Use Poisoned Reverse Step 15: Specify whether poisoned reverse is to be used. Send Triggered Responses Step 16: Specify whether the switch is to send triggered responses. Step 17: When you finished with these selections, click Update Setting. Step 18: A confirmation window appears. Click to close the confirmation window.
  • Page 172 Step 2: For Default Gateway, click in the text box and type the IP address of the router at the next hop. Metric Step 3: For Metric, click in the text box and type the number of hops needed between the switch and the destination network.
  • Page 173 5.5.3.3 ARP Table Click Advanced Setup _ IP Networking _ ARP Step 1: Table to view ARP table settings. The information here is read-only. 5. Web-Based Browser Management -169...
  • Page 174 Step 1: Click Advanced Setup _ IP Networking _ DHCP Gateway Settings to view and/or change settings. Step 2: In the VLAN ID column, click on a VLAN ID that you want to view or change its DHCP gateway settings.

  • Page 175: Per Port Statistics

    Click in the text box and type a decimal number to configure the delay in seconds. Preferred Server Step 6: Click in the text box and type an IP address for it. Repeat to specify up to three more Preferred Servers 5.5.4 Per Port Statistics...
  • Page 176 Step 2: Click a port to view statistic data. 5. Web-Based Browser Management -172...

  • Page 177: Bridging

    Step 1: Click the drop-down list for Disabled (No Aging) or Set Aging Time. Aging Time Step 2: When Set Aging Time is selected, click in this text box and type a decimal number as bridge aging period in seconds.

  • Page 178: Static Mac Filter

    Step 5: Click Update Setting when completed. 5.5.6 Static MAC Filter To access the static MAC filter parameters, click the Advanced Setup button, and point to Static MAC Filter in the selection menu. 5. Web-Based Browser Management -174...
  • Page 179 5.5.6.1 Source MAC Address Step 1: Click Source MAC Address. Add Source MAC Address Step 2: Click Add MAC Addr button to add a source MAC address for static filtering. The Static Source MAC Filter window appears. Step 3: Click in the Source MAC Address Filter text box and type a unique MAC source address you want to add.
  • Page 180 Delete Source MAC Address Step 6: If you no longer need a source MAC address, click Delete MAC Addr button to delete it in Step 2. Step 7: The Delete Source MAC Address window appears. Click the Select a MAC Address drop-down list and select the source MAC address you want to delete.
  • Page 181 Step 1: MAC Filter in the selection menu. Click Destination MAC Address. Step 2: Click Add MAC Addr button to add a destination MAC address for static filtering. Refer to Step 2~5 in Source MAC Address section for similar procedure.

  • Page 182: Ip Multicast Group

    5.5.7 IP Multicast Group To view the IP multicast group addresses, click the Advanced Setup button, and click IP Multicast Group in the selection menu. The information is read-only. 5. Web-Based Browser Management -178...

  • Page 183: Vlan Perspective

    5.5.8 VLAN Perspective To view the VLAN configuration information, click the Advanced Setup button, and point to VLAN Perspective in the selection menu. 5. Web-Based Browser Management -179...
  • Page 184 Click VLAN Configuration. Step 2: Click the Add VLAN button and below screen appears. For VLAN ID, type a unique VLAN identifier ranges from 2 to 4094. For VLAN Name, type a name that identifies this VLAN. 5. Web-Based Browser Management -180...
  • Page 185 Under VLAN ID, click the VLAN whose setting you want to view or set. Then click the appropriate button to add or delete a port. For each switch, the port options include add/delete Tagged Ports, Untagged Ports, or Forbidden Ports.
  • Page 186 Step 2: To Add a ports, e.g to add a forbidden port: Click the Add Forbidden button to see the screen as below: Click the ports you want to add as forbidden ports. 5. Web-Based Browser Management -182...
  • Page 187 Finally press Add button to confirm addition action. Step4: User can add untagged and tagged VLAN port following the same steps. After each addition of VLAN ports, the updated group member will appear in the VLAN configuration window. 5. Web-Based Browser Management -183...
  • Page 188 Forbidden Ports, Delete Untagged Ports, Delete Untagged Ports button to delete ports. The process is just like the one in Add ports. And the revise VLAN information appears after delete action confirmed. 5.5.8.3 deleting a VLAN Under VLAN configuration window:...

  • Page 189: Spanning Tree Perspective

    Step 2: Choose the required VLAN ID and click Delete to confirm delete action. Note that a precautionary message does not appear before the VLAN is deleted. And also note that the default VLAN(VLAN ID=1) can not be deleted. 5.5.9 Spanning Tree Perspective...
  • Page 190 Spanning Tree Protocol Step 2: Specify whether you want to have it Disabled or Enabled by clicking the drop-down list. Bridge Priority Step 3: Click in the text box and type a decimal number between 0 and 65535. Hello Time Step 4: Click in the text box and type a decimal number between 0 and 10.
  • Page 191 Max Age Step 5: Click in the text box and type a decimal number between 6 and 40. Forward Delay Step 6: Click in the text box and type a decimal number between 4 and 30. Click Update Setting. A confirmation window appears.
  • Page 192 0 and 255. A low value gives the port a greater likelihood of becoming a Root port. Path Cost For Path Cost, click in the text box and type a decimal Step 4: number as a new path cost value.

  • Page 193: Snmp

    Community Name value is public. SNMP Step 1: Specify whether it is Disabled or Enabled by clicking the drop-down list. Get Community Name Step 2: Click in the text box and type a get community name. 5. Web-Based Browser Management -189...
  • Page 194 Step 4: Click in the text box and type a trap community name. Trap Host IP Address Step 5: Click in the text box and type a IP address for trap host 1~4. Cold Start Trap Step 6: Specify whether it is Disabled or Enabled by clicking the drop-down list.
  • Page 195 Authentication Failure Trap Step 10: Specify whether it is Disabled or Enabled by clicking the drop-down list. Rising Alarm Trap Step 11: Specify whether it is Disabled or Enabled by clicking the drop-down list. Falling Alarm Trap Step 12: Specify whether it is Disabled or Enabled by clicking the drop-down list.

  • Page 196: Other Protocols

    5.5.11 Other Protocols To enable or disable the GVRP and/or IGMP protocols, click the Advanced Setup button, and click Other Protocols in the selection menu. 5. Web-Based Browser Management -192...

  • Page 197: Port Trunking

    Specify whether it is Disabled or Enabled by clicking the drop-down list. IGMP Step 2: Specify whether it is Disabled or Passive or Active by clicking the drop-down list. Step 3: Click Update Setting when completed. A confirmation window appears. Click to close the confirmation window 5.5.12 Port Trunking...
  • Page 198 Click to assign a maximum of four ports to the trunk group. <Note> That Trunk group 1 and 2 can include any four ports from port 1 ~ port 24. And Trunk group 3 only includes gigabit ports, e.g. port 25(G1) and port 26(G2)

  • Page 199: Port Mirroring

    Mirroring in the selection menu. In this feature, two sets of mirroring port pairs are available. Mirror To Step 1: In the Mirror To column, select a “mirror to” port by clicking the drop-down list. Note that data port should not be set as “mirror to” port.

  • Page 200: Qos

    Mirror Mode Step 3: In the Mirror Mode column, specify whether the “mirrored from” port will be receiving or transmitting data by clicking the drop-down list. Click Update Setting when completed. A confirmation Step 4: window appears. Click to close the confirmation window.
  • Page 201 Click the Global Setting then the following window Step 1: appears: Click in the DiffServ Expedite Forwarding box to Step 2: specify whether you want to enable or disable this feature. Click in the ToS/VLAN drop-down list to specify the Step 3: priority you want to use.
  • Page 202 * High drop percentage for level 1. * Low drop and high drop percentages for level 2. <Note> that the low drop percentage foe level 1 remains fixed at 0%, while the low drop and high drop percentages for level 3 remain fixed at 100% When you finish, click the Update Setting button.
  • Page 203 5.5.14.2 logic port Under VLAN configuration window, click the Logic Port to enter : User-defined ports Under logic port, click the User-defined ports and a Step 1: window following appears. 5. Web-Based Browser Management -199...
  • Page 204 Click a number under Logic Port Index. A window Step 2: similar to the following appears. User can change the logical port number in the Logic Step 3: port number field. Click a new value from the Transmit Priority Step 4: drop-down list to change the transmit priority, ranges from 0 to 7.
  • Page 205 Well-defined ports Under logic port, click the Well-defined ports and a Step 8: window following appears. Click a number under Logic Port Index. Then Step 9: following the similar policy in User-defined ports setting, user can set up all related parameters in Well-defined ports.
  • Page 206 Range logic ports Following the similar policy in User-defined ports Step 10: setting, user can set up all related parameters in Range logic ports. Such as High/Low Port Number, Transmit priority, Drop Priority, etc. 5. Web-Based Browser Management -202...
  • Page 207 Click VLAN then the below windows shows: Step 1: Step 2: For each VLAN Priority, user can select the left drop-down list to select a transmit priority (range:0~7) and select a high or low drop priority. Click the Update Setting button to finish.
  • Page 208 Click Type of Service then the below windows Step 1: shows: Step 2: For each Type of Service Priority, user can select the left drop-down list to select a transmit priority (range:0~7) and select a high or low drop priority. Click the Update Setting button to finish.
  • Page 209 5.5.14.5 Profile settings Under QoS configuration window: 10/100M Profile Setting Step 1: Under Profile, click the 10/100M Profile Setting to enter below window: 5. Web-Based Browser Management -205...
  • Page 210 Click a profile index number or profile name. A Profile Attribute window below appears: Step 3: To change the name of this profile, enter a new name in the Profile Name field. Step 4: To change the active profile assigned to this profile name, click a new name from the Assigned to Active Profile drop-down list.
  • Page 211 Gigabit Profile Setting Step 8: Under Profile, click the Gigabit Profile Setting to enter below window: Step 9: Click a profile index number or profile name. A Profile Attribute window below appears: 5. Web-Based Browser Management -207...
  • Page 212 Step 10: To change the name of this profile, enter a new name in the Profile Name field. Step 11: To change the active profile assigned to this profile name, click a new name from the Assigned to Active Profile drop-down list.
  • Page 213 Click a port number under Port. A window below Step 2: shows: Use the Active Profile drop-down list to choose a Step 3: different active profile. Click the Update Setting button to finish. Step 4: 5. Web-Based Browser Management -209...
  • Page 214 5.5.14.7 Rate Control Under QoS configuration window: Step 1: Click the Rate Control to enter below window: Use the Rate Control drop-down list to enable or Step 2: disable rate control. Click a port number under Port. A window below...
  • Page 215 Use the Average Rate drop-down list to select an Step 4: average rate percentage. Use the Traffic Type drop-down list to select bursting Step 5: or streaming traffic. Click the Update Setting button to finish. Step 6: 5. Web-Based Browser Management -211...

  • Page 216: Snmp & Rmon Management

    The management workstation collects the statistics that the RMON probe gathers. The workstation can reside on the same network as the probe, or it can have an in-band or out-of-band connection to the probe. The switch provides RMON capabilities that allow network administrators to set parameters and view statistical counters defined in MIB-II, Bridge MIB, and RMON MIB.

  • Page 217: Snmp Agent And Mib-2 (Rfc 1213)

    MIB-II defines a set of manageable objects in various layers of the TCP/IP protocol suites. MIB-II covers all manageable objects from layer 1 to layer 4, and, as a result, is the major SNMP MIB supported by all vendors in the networking industry. The switch supports a complete implementation of SNMP Agent and MIB-II.

  • Page 218: Rmon Mib (Rfc 1757) And Bridge Mib (Rfc 1493)

    MIB variable. An alarm can be associated with Low Threshold, High Threshold, or both. A trigger can trigger an alarm when the value of a specific MIB variable exceeds a threshold, falls below a threshold, or exceeds or falls below a threshold.
  • Page 219 The dot1dStp Group – contains objects that denote the bridge’s state with respect to the Spanning Tree Protocol. If a node does not implement the Spanning Tree Protocol, this group will not be implemented. This group is applicable to any transparent only, source route, or SRT bridge that implements the Spanning Tree Protocol.

  • Page 220: Trouble Shooting

    « Please check whether the RJ-45 cable is functional. Replace with another working cable and see whether the condition can be improved. « Use another port on the SM2224. If a link can be established way, the first port is faulty. Please contact your local acercm dealer assistant.

  • Page 221: Appendix

    MFF001-ST 100Base-FX Fiber Module, Multi Mode, ST connector 99.33228.003 MFF001-VF45 100Base-FX Fiber Module, Multi Mode, VF-45 connector 99.33228.004 MFF001-MTRJ 100Base-FX Fiber Module, Multi Mode, MT-RJ connector 99.33228.005 MFF001-SC20 100Base-FX Fiber Module, Single Mode 20Km, SC connector 99.33228.006 MFF001-SC40 100Base-FX Fiber Module, Single Mode 40Km, SC connector 99.33228.007...
  • Page 222 Benq Authorized Reseller. This limited warranty also does not extend to any network product that has been damaged or rendered defective (a) as a result of use of the network product other than for its normal intended use, failure to use the network product in accordance with the User's Manual which accompanies the network product or other misuse, abuse or negligence to the net work product;...
  • Page 223 This Limited Warranty gives you specific legal rights. You may also have other rights that vary from state to state. You are advised to consult applicable state laws for a full determination of your rights. C. TECHNICAL SUPPORT Please visit our support website http://www.benq.com.tw, the most frequently asked questions are answered here.

Table of Contents
