Summary of Contents for FLYFINE FP-5000B-US
- Page 1 FP-5000B-US/FP-5000B-EU User Manual 5kWh Mobile Energy Storage Generator User Manual...
- Page 2 User Manual Catalogs Preface Precautions Product Size Technical Parameters Steps for Usage Packaging, Transportation and Storage User Manual...
- Page 3 User Manual Preface Welcome to use the portable power statio FP-5000B-US/FP-5000B-EU. This short manual will help you. Please take the time to read this manual and use this product according to the instructions below. Just read through it once and you will fully understand how to use this product.
-
Page 4: Product Size
User Manual Product Size 337mm 292mm 543mm User Manual... -
Page 5: Technical Parameters
User Manual Technical Parameters Category ltems FP-5000B-US FP-5000B-EU 1680W/120V*14A AC input Power 3450W/230V 15A 2160W/240V*9A PV Input Power(Max.) 3000W MPPT Voltage Range 30V-150V Input PV Input Current(Max.) 3000W(Single Phase) EV Input Power(Max.) 5000W 5000W(Split Phase) AC Input Power 5000W(Max.); DC Input Power 3000W(Max.)；... - Page 6 User Manual Cooling Method Air Cooling Certificate UN38.3,MSDS,UL UN38.3,MSDS,CE The system Weight 70±3KGs Dimensions (W*D*H) 543*337*677(mm) Accessories User Manual, AC plug Steps for Usage Power on and off: Open the anti-accidental touch cover and press the power button. REMAINING TIME...
- Page 7 User Manual When the system power is low, the output is best not to carry high power.If con- tinued use, the product will be over discharged and it may cause automatic shutdown protection. After the shutdown, you need to wait for 2 minutes and then press the switch to restart it.
- Page 8 User Manual PV IN AC IN AC IN PV input: it has two groups of positive and negative interaces. The total input power of the two groups is 3000W. Each group of interaces suppors maximum 15A current. There fore, when the PV input current is too large, the PV array needs to be divided into two groups, and connects to the two groups of interaces at the same time.
- Page 9 Mennekes (Type 2) AC Output Ports; US version FP-5000B-US: There are four AC output ports on the left side, of which OUT1, OUT2 and OUT3 support single-phase voltage of 120V; OUT4 is compatible with single-phase and split-phase, supporting 120/240V voltage, and the output frequency is 60Hz; the output power of OUT1, OUT2 and OUT3 shall be 2500W(Max.), the output power of OUT4 shall be 5000W(Max.),...
- Page 10 User Manual European version FP-5000B-EU: There are three AC output ports on the left side, the voltage is 230V, and the output frequency is 50Hz; the output power of each port shall not exceed 3500W, and the maximum total output power shall not exceed 5000W.
-
Page 11: Packaging, Transportation And Storage
User Manual Packaging, Transportation and Storage 1. Packaging There are product name, model, manufacturer's logo, inspection certificate from the manufacturer's quality department, manufacturing date, etc. on the box; There is a list of accessories inside the packaging box. Cushioning Material...
