Summary of Contents for Excalibur EVO

Page 1 ELECTRIC VEHICLE ELECTRIC VEHICLE USER MANUAL USER MANUAL...
Page 2 Congratulations on the purchase of your EXCALIBUR Electric Vehicle. Electric Vehicle. To ensure and maintain correct operation of your new electric electric vehicle, please read these instructions carefully before use. The information he information contained within this manual is essential to preserve your warranty and contained within this manual is essential to preserve your warranty and assure your new vehicle will function properly for years to come.
Page 3: Table Of Contents
TABLE OF CONTENTS Operating Instructions 3 - 10 Body Maintenance Pre-trip Checklist Battery & Charger Information Electrical Maintenance Mechanical Maintenance Maintenance and Safety Warranty Additional Information Contact Information...
Page 4: Operating Instructions
OPERATING INSTRUCTIONS 1. Turning ON the Vehicle IMPORTANT  Ensure that the Forward/Reverse switch is in the Neutral Position (See STEP 2).  Insert the key and rotate clockwise. PARKING BRAKE  This vehicle is equipped with an Electric Parking Brake.
Page 5 2. Forward / Reverse Switch (D) - Forward (N) - Neutral (R) - Reverse NOTES  Always be sure to engage the parking brake when the vehicle is parked.  Turn the key to the OFF position when the vehicle is stopped. ...
Page 6 3. Starting and Stopping FORWARD  Turn ON the ignition (key).  Depress the brake pedal then disengage the parking brake if engaged (See SECTION 1) and set the Forward/Reverse Switch to F (Forward).  Gently press the accelerator pedal. REVERSE ...
Page 7 4. Dashboard Digital Display The digital display will provide important information information about your vehicle. Additionally, It will control the built in about your vehicle. Additionally, It will control the built in stereo and display the backup camera image when the stereo and display the backup camera image when the vehicle is put in to reverse.
Page 8 VEHICLE INFORMATION SCREEN - continued 6) FAULT CODE INDICATOR FAULT 06C - Cart Operation Lockout – Lockout will occur when the ignition is turned on while the cart is in Forward or Reverse. The cart MUST be in Neutral(N) when the key is turned on. To reset the fault, turn the key off, place the cart in Neutral and turn the key back on.
Page 9 HOME SCREEN 1) FM - FM Tuner and presets. 2) MUSIC - Bluetooth music controls. 3) BT - Bluetooth devices. 4) TELEPHONE - Telephone controls. 5) MOVIE - Video player. Plays videos from a USB source. USB device must be plugged into the upper source.
Page 10 USB Port Horn, Light Switch & High/Low Beam...
Page 11 5. Other Features Automotive style LED lights with daytime ru Automotive style LED lights with daytime running light Charging Port – Please see the BATTERY & CHARGING BATTERY & CHARGING INFORMATION section...
Page 12: Body Maintenance
BODY MAINTENANCE Protection from corrosion is of the utmost importance. Corrosion can result from the following factors: 1. Accumulation of salt, dust, moisture or chemicals on the body, chassis or components of the vehicle. 2. Gravel, stone, dirt, etc. can lead to flaking, scratches, and/or damage.
Page 13 Corrosion Protection The most effective way to prevent corrosion is through regular cleaning of the vehicle. It is advisable to arrange a schedule of regular cleaning with special attention paid to cleaning before and after any periods of storage. It is important to remember to dry the vehicle’s body, chassis and components completely after cleaning.
Page 14: Pre-Trip Checklist
PRE-TRIP CHECKLIST 1. Ensure the vehicle is fully charged. 2. Perform a visual inspection of the following components: Tire tread depth Inspect tires for wear, cracks, damage, nails, stones or other foreign objects iii. Ensure wheel nuts are tight 3. Check headlights, brake lights and horn are functioning as normal.
Page 15: Battery & Charger Information
BATTERY & CHARGING INFORMATION Your new EXCALIBUR Golf Car is equipped with a High-Capacity Lithium (LiFePO) battery pack. OPERATION To turn on/off the battery pack, press the main switch located on the side of the battery pack near the battery cable connections (under the seat).
Page 16 NOTES Fully recharging the lithium pack will reset the state of charge meter to read accurately. If you are low on battery power or the pack runs out of power, it is acceptable to “opportunity charge” the battery pack for a short period in order to drive the cart. Lithium batteries are not affected by partial charging.
Page 17 The Lithium battery pack and all of its internal components are warrantied against defects in materials and workmanship as follows: YEARS 1 - 3: Full repair or replacement at EXCALIBUR’s sole discretion based on the failure situation. YEARS 4 - 5: Pro-rated to maximum 25% of the replacement cost for full repair or replacement at EXCALIBUR’s sole discretion...
Page 18: Electrical Maintenance
ELECTRICAL MAINTENANCE Regular Maintenance  Check that the exposed wiring and connections are secure and free of dust and debris.  Verify that the function of both the accelerator and direction switches is correct.  Inspect the motor and confirm that the connection between the battery and the cables is secure.
Page 19: Mechanical Maintenance
MECHANICAL MAINTENANCE Regular Maintenance  The braking system should be inspected monthly. If braking performance appears degraded, the vehicle should be brought in for service/maintenance.  Re-apply fresh grease to all grease fittings once per year minimum.  Check all components monthly for wear and to verify all fasteners remain secure.
Page 20: Maintenance And Safety
MAINTENANCE AND SAFETY INFORMATION  Maintenance should be performed every 500 km.  Check and top-up lubricants as necessary.  Only use the original charger supplied with the vehicle to prevent shortened battery life and/or battery damage.  DO NOT modify the charger in any way. ...
Page 21: Warranty
WARRANTY Your new EXCALIBUR Golf Car is warrantied bumper to bumper for a period of 2 years or 2500km. The following occurrences will VOID the vehicle warranty: 1. Disassembly or modification of the vehicle and/or the use of non-genuine parts.
Page 22: Additional Information
ADDITIONAL INFORMATION The use of genuine (OEM) parts is strongly recommended. Genuine parts are manufactured according to specifications of the highest quality and performance standards. If parts other than genuine (OEM) parts are used to modify, upgrade or repair the vehicle, performance and life-span are likely to be affected and the vehicle will no longer be covered under warranty.
Page 23: Contact Information
Thank you for your purchase of the Thank you for your purchase of the EXCALIBUR EV NEED ASSISTANCE? SISTANCE? (866) 403-3334 WWW.EXCALIBUR- -EV.CA...
Page 24 ONTARIO, CANADA ONTARIO, CANADA 1.866.403.3334...
