  • Page 1 NV41PZ / NV45PZ...
  • Page 3 Preface Notebook Computer NV41PZ / NV45PZ Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 Preface About this Manual This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the NV41PZ / NV45PZ series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 LCD (NV45PZ) ................A-6 MB ....................A-7 Overview ..................1-1 Schematic Diagrams......... B-1 Specifications ..................1-2 External Locator - Top View with LCD Panel Open ......1-4 System Block Diagram ..............B-2 External Locator - Front & Right Side Views .........1-5 Processor 1/13 .................B-3 External Locator - Left Side &...
  • Page 12 Preface Misc - GPIO, I2C, ROM .............. B-29 PEX_VDD ..................B-61 NVIDIA Power Sequence ............B-30 FBVDDQ ..................B-62 GPU NVVDD, FBVDDQ ............B-31 OVR-M ..................B-63 GPU GND ..................B-32 1V8_AON/RUN ................B-64 Audio Codec ................. B-33 M Key PCIE SSD ................. B-34 USB Charger, TPM ..............

  • Page 13: Introduction

    Introduction Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the NV41PZ / NV45PZ series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri-vers (e.g.

  • Page 14: Specifications

    Introduction Specifications Processor Options Security Intel® Core™ i7 Processor Security (Kensington® Type) Lock Slot i7-1260P (2.10GHz) BIOS Password Intel® Core™ i5 Processor Intel PTT for Systems Without TPM Hardware  i5-1240P (1.70GHz) (Factory Option) TPM 2.0 Latest Specification Information Intel® Core™ i3 Processor Video Adapter i3-1220P (1.50GHz) The specifications listed here are correct at the...
  • Page 15 Introduction Communication Environmental Spec Built-In 10/100/1000Mb Base-TX Ethernet LAN Temperature 1.0M HD Webcam ° ° Operating: 5 C - 35 Non-Operating: -20°C - 60°C (Factory Option) Windows Hello Camera Module Relative Humidity WLAN/ Bluetooth M.2 Modules: Operating: 20% - 80% (Factory Option) Intel®...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Webcam (Factory Option) Windows Hello Camera 2. *Camera LED *When the PC camera is in use, the LED will be illuminated in white. 3. Built-In Array Microphone 4.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View FRONT VIEW Figure 3 Right Side View 1. Speaker 2. 2-In-1 Audio Jack (Headphone / Microphone) RIGHT SIDE VIEW 3. USB 3.2 Gen 2 Type-C Port 4. USB 3.2 Gen 1 Type-A Port 5.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Security Lock Slot 2. RJ-45 LAN Jack 3. USB 3.2 Gen 1 LEFT SIDE VIEW Type-A Port 4. Multi-in-1 Card Reader 5. Thunderbolt 4 Port with Power Delivery (DC-In) 6.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent 2. RJ-45 LAN Jack 3. Speakers  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. KBC-ITE IT5570 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. CPU 2. Memory Slots DDR4 SO-DIMM Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. DC-In Jack 2. Power Button 3. HDMI-Out Port 4. USB 3.2 Gen 1 Type-A Port 5. USB 3.2 Gen 2 Type-C Port 6. 2-In-1 Audio Jack (Headphone / Microphone) 7.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. Fan Connector 2. CMOS Battery Connector 3. M.2 Card Connector 4. WLAN/BT Connector 5. Speaker Connecto 6. Touchpad Connector 7. Battery Connector 8. Card Reader 9. USB 3.2 Gen 1 Type-A Port 10.
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Disassembly Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the NV41PZ / NV45PZ series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart. Procedures such as upgrading/replacing the RAM, optical device and hard disk are included in the User’s Manual but are repeated here for your convenience.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a removal and/or replacement job, take the following precautions: Power Safety Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other components Warning could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: 1. Remove the battery page 2 - 5 To remove the Keyboard: 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn off the computer, turn it over. 2. Remove screws on the bottom case (Figure 1a). a. Remove the screws. 3. Carefully lift the bottom case up from point (Figure 1b). b.

  • Page 30: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 2 Keyboard Removal Turn off the computer, turn it over, remove the battery (page 2 - Remove screws from the bottom of the computer a. Remove the screws and Open it up with the LCD on a flat surface before pressing at point to release the keyboard module (use a special eject stick press at point to un-...

  • Page 31: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 3 RAM Module The computer has two memory sockets for 260 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR4 3200MHz. The main memory can be expanded up to 64GB. The total memory size is automatically detected by the POST routine once you turn on your computer.
  • Page 32 Disassembly 5. Pull the latches to release the second module if necessary. 6. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. 7. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot as it will go.

  • Page 33: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 4 Wireless LAN 1. Turn off the computer, turn it over to remove the battery (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 4a).

  • Page 34: Wireless Lan, And Combo Module Cables

    Disassembly Wireless LAN, and Combo Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 35: Removing And Installing The M.2 Ssd Module

    Disassembly Removing and Installing the M.2 SSD Module Figure 5 M.2 SSD Module M.2 SSD Removal Procedure Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 2. The M.2 SSD module will be visible at point on the mainboard (Figure 5a).

  • Page 36: Removing The Ccd

    Disassembly Removing the CCD Figure 6 CCD Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 2. Lift up the inner frame and run your fingers around the inner frame of the LCD panel at the points as indicated by a.
  • Page 37 Disassembly 4. Disconnect the cable (Figure 7c). Figure 7 5. Remove the CCD module (Figure 7d). CCD Removal 6. Reverse the process to install a new CCD module. (cont’d.) c. Disconnect the cable. d. Remove the CCD mod- ule.  6.
  • Page 38 Disassembly 2 - 14...

  • Page 39: Part Lists

    Appendix A: Part Lists This appendix breaks down the NV41PZ / NV45PZ series notebook’s construction into a series of illustrations. The com- ponent part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 40: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part NV41PZ NV45PZ Location page A - 3 page A - 4 Bottom page A - 5 page A - 6 page A - 7 A - 2...

  • Page 41: Top

    Figure A - 1 Top A - 3...

  • Page 42: Bottom

    Bottom Figure A - 2 Bottom A - 4 Bottom...

  • Page 43: Lcd (Nv41Pz

    LCD (NV41PZ) Figure A - 3 LCD (NV41PZ) LCD (NV41PZ) A - 5...

  • Page 44: Lcd (Nv45Pz

    LCD (NV45PZ) Figure A - 4 LCD (NV45PZ) A - 6 LCD (NV45PZ)
  • Page 45 Figure A - 5 MB A - 7...
  • Page 46 A - 8...

  • Page 47: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the NV41PZ / NV45PZ notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1 System Block Diagram - Page B - 2 VGA Frame Buffer A - Page B - 23 Type-C Con - Page B - 44...
  • Page 48 Schematic Diagrams System Block Diagram NV40PNJ/PNK/PNH/PZ AlderLake P System Block Diagram 2400/2666/3200 MHz Thunderbolt MP2964 Controller DDR4 SHEET 47 DDIA RETIMER TPS65993ADYBGR SHEET 17 JHL8040R VCORE Power Stage SHEET 43 SYSTEM SMBUS DDR4 DDIB HDMI SHEET 18 SHEET 41,42 SHEET 48 SO-DIMM A USB3.1 SHEET 15...

  • Page 49: Processor 10/13

    Schematic Diagrams Processor 1/13 U24A INS24995490 TCP=TypeC Port BMAP_REV = 0.52 DDIA_TXP_3 TCP0_TXRX_P1 TCP0_TXRX1_DP EDP_TXP_3 EDP_TXN_3 DDIA_TXN_3 TCP0_TXRX_N1 TCP0_TXRX1_DN eDP PANEL DDIA_TXP_2 TCP0_TXRX_P0 EDP_TXP_2 TCP0_TXRX0_DP DDIA_TXN_2 TCP0_TXRX_N0 TCP0_TXRX0_DN EDP_TXN_2 EDP_TXP_1 DDIA_TXP_1 TCP0_TX_P1 TCP0_TX1_DP DIFF=85ohm EDP_TXN_1 DDIA_TXN_1 TCP0_TX_N1 TCP0_TX1_DN DDIA_TXP_0 TCP0_TX_P0 TCP0_TX0_DP EDP_TXP_0 DIFF=85ohm...
  • Page 50 Schematic Diagrams Processor 2/13 U24B INS25456044 BMAP_REV = 0.52 M_A_DQ[63:0] DDR4(IL) / DDR4(NIL) / DDR5(NIL) / LP4x-LP5(NIL) M_A_DQ63 DH58 CD49 DDR0_DQ_0_7/DDR0_DQ_0_7/DDR0_DQ_0_7/DDR0_DQ_0_7 DDR0_CLK_P_1/DDR3_CLK_P/DDR3_CLK_P/DDR3_CLK_P/DDR1_CLK_P_1 M_A_CLK_DDR1 M_A_DQ62 DG57 CD48 DDR0_DQ_0_6/DDR0_DQ_0_6/DDR0_DQ_0_6/DDR0_DQ_0_6 DDR0_CLK_N_1/DDR3_CLK_N/DDR3_CLK_N/DDR3_CLK_N/DDR1_CLK_N_1 M_A_CLK_DDR#1 M_A_DQ61 DH56 CH61 DDR0_DQ_0_5/DDR0_DQ_0_5/DDR0_DQ_0_5/DDR0_DQ_0_5 NC/DDR2_CLK_P/DDR2_CLK_P/DDR2_CLK_P/DDR1_CLK_P_0 M_A_DQ60 DG60 CF61 DDR0_DQ_0_4/DDR0_DQ_0_4/DDR0_DQ_0_4/DDR0_DQ_0_4 NC/DDR2_CLK_N/DDR2_CLK_N/DDR2_CLK_N/DDR1_CLK_N_0 M_A_DQ59 DL60 CN49 DDR0_DQ_0_3/DDR0_DQ_0_3/DDR0_DQ_0_3/DDR0_DQ_0_3...

  • Page 51: Processor 11/13

    Schematic Diagrams Processor 3/13 U24C INS25468363 BMAP_REV = 0.52 M_B_DQ[63:0] DDR4 / LP4x / LP5_ascend / LP5_descend / DDR5 M_B_DQ63 BB58 DDR0_DQ_4_7/DDR1_DQ_0_7/DDR2_DQ_0_7/DDR4_DQ_0_7 DDR1_CLK_P_1/DDR7_CLK_P/DDR7_CLK_P/DDR7_CLK_P/DDR3_CLK_P_1 M_B_CLK_DDR1 M_B_DQ62 BA57 DDR0_DQ_4_6/DDR1_DQ_0_6/DDR2_DQ_0_6/DDR4_DQ_0_6 DDR1_CLK_N_1/DDR7_CLK_N/DDR7_CLK_N/DDR7_CLK_N/DDR3_CLK_N_1 M_B_CLK_DDR#1 M_B_DQ61 BB56 AB61 DDR0_DQ_4_5/DDR1_DQ_0_5/DDR2_DQ_0_5/DDR4_DQ_0_5 NC/DDR6_CLK_P/DDR6_CLK_P/DDR6_CLK_P/DDR3_CLK_P_0 M_B_DQ60 BA60 DDR0_DQ_4_4/DDR1_DQ_0_4/DDR2_DQ_0_4/DDR4_DQ_0_4 NC/DDR6_CLK_N/DDR6_CLK_N/DDR6_CLK_N/DDR3_CLK_N_0 M_B_DQ59 BE60 AG49 DDR0_DQ_4_3/DDR1_DQ_0_3/DDR2_DQ_0_3/DDR4_DQ_0_3 NC/DDR5_CLK_P/DDR5_CLK_P/DDR5_CLK_P/DDR2_CLK_P_1...
  • Page 52 Schematic Diagrams Processor 4/13 U24E W/TPM W/O TPM INS25048267 BMAP_REV = 0.52 SMB_CLK 5.1_1%_04 15_1%_04 SMB_DATA SPI_SCLK SPI0_CLK SMB_CLK R848 5.1_1%_04 TPM(5.1_1%_04)/ woTPM(15_1%_04)=6-13-15R01-28C EG56 EL38 R270 *14mil_02 SPI0_CLK GPP_C0/SMBCLK SMB_CLK_DDR 15,16 SPI_HOLD# SPI0_IO3 SMB_DATA R884 5.1_1%_04 TPM(5.1_1%_04)/ woTPM(15_1%_04)=6-13-15R01-28C EC59 EK38 R273 *14mil_02 SPI0_IO3...

  • Page 53: Processor 12/13

    Schematic Diagrams Processor 5/13 U24F INS25447720 BMAP_REV = 0.52 UART2_TXD EN48 EY28 GPP_H11/UART0_TXD/M2_SKT2_CFG1 GPP_D14/ISH_UART0_TXD/I2C4B_SCL SSD1_PW R_EN# UART2_RXD EN46 EV28 GPP_H10/UART0_RXD/M2_SKT2_CFG0 GPP_D13/ISH_UART0_RXD/I2C4B_SDA W LAN_W AKEUP# GPP_H13 EL41 EY36 GPP_D16 GPP_H13/I2C7_SCL/UART0_CTS#/M2_SKT2_CFG3/ISH_GP7B/DEVSLP1B GPP_D16/ISH_UART0_CTS#/I2C7B_SCL GPP_H12 GPP_D15 EK41 EW36 GPP_H12/I2C7_SDA/UART0_RTS#/M2_SKT2_CFG2/ISH_GP6B/DEVSLP0B GPP_D15/ISH_UART0_RTS#/I2C7B_SDA GPP_D18 EW30 FA34 GPP_D3 GPP_D18/UART1_TXD/ISH_UART1_TXD GPP_D3/ISH_GP3/BK3/SBK3 GPP_D17...
  • Page 54 Schematic Diagrams Processor 6/13 U24I USB TYPEA INS25201182 BMAP_REV = 0.52 TYPEC PORT2 SATA1_TXP *0.01u_16V_X7R_04 DY10 PCIE12_TXP/SATA1_TXP USB2P_10 USB_PP10 SATA1_TXN *0.01u_16V_X7R_04 DY11 PCIE12_TXN/SATA1_TXN USB2N_10 USB_PN10 C667 *0.01u_16V_X7R_04 SATA1_RXP T104 PCIE12_RXP/SATA1_RXP SATA1_RXN C666 *0.01u_16V_X7R_04 EL18 USB TYPEA T103 PCIE12_RXN/SATA1RXN USB2P_9 EN18 USB2N_9 EB10 PCIE11_TXP/SATA0_TXP...

  • Page 55: Processor 13/13

    Schematic Diagrams Processor 7/13 ADL-P PEG,PCIE U24H INS25198788 BMAP_REV = 0.52 C662 10p_50V_NPO_04 PCIE4_TXP3_SSD PCIEX4_A_TX_P_3 PCIEX8_TX_P_7 PCIEX4_A_TX_N_3 PCIEX8_TX_N_7 PCIE4_TXN3_SSD PCIEX4_A_RX_P_3 PCIEX8_TX_P_6 PCIE4_RXP3_SSD PCIE4_RXN3_SSD PCIEX4_A_RX_N_3 PCIEX8_TX_N_6 PEG10 PCIEX8_TX_P_5 38.4Mhz PCIEX4_A_TX_P_2 PCIEX8_TX_N_5 R672 PCIE4_TXP2_SSD Use a shielded crystal GND and PCIEX4_A_TX_N_2 PCIEX8_TX_P_4 PCIE4_TXN2_SSD XTAL19001-X-022-3 isolation external GND...
  • Page 56 Schematic Diagrams Processor 8/13 ADL-P CSI, CNV ADL-P RSVD U24J U24T INS25252733 BMAP_REV = 0.52 INS25253960 BMAP_REV = 0.52 AD41 FC46 CSI_D_DP_1/CSI_C_DP_2 CNV_WT_D1P CNVI_W T_D1P AB41 FA46 CSI_D_DN_1/CSI_C_DN_2 CNV_WT_D1N CNVI_W T_D1N EF48 BF43 TP_RSVD_22 AG41 EV43 RSVD_17 RSVD_TP_22 TP_RSVD_2 CSI_D_DP_0/CSI_C_DP_3 CNV_WT_D0P CNVI_W T_D0P AF41...
  • Page 57 Schematic Diagrams Processor 9/13 ADL-P SYSTEM POWER MANAGEMENT 3.3VS SYS_RESET# R107 10K_04 U24L 3.3VA INS26786689 SLP_S0# BMAP_REV = 0.52 R248 *10K_04 TBTA-PCH_I2C_INT R241 *10K_04 EN53 EM61 36,38,51 SLP_SUS# SLP_SUS# GPD3/PWRBTN# PW R_BTN# PM_BATLOW # VDD3 EM56 GPD0/BATLOW# 3.3VS SLP_S5# EG60 EJ59 GPD10/SLP_S5# GPD1/ACPRESENT...
  • Page 58 Schematic Diagrams Processor 10/13 ADL-P CPU POWER U24M VCORE VCORE VDDQ VCCGT INS25333782 BMAP_REV = 0.52 U24O 160A 2.57A BA44 INS25334074 VCCCORE_1 VCCCORE_51 BB43 BMAP_REV = 0.52 VCCCORE_2 VCCCORE_52 BB45 CG14 VCCCORE_3 VCCCORE_53 BC44 VCCCORE_4 VCCCORE_54 AD61 CP44 VDD2_1 VCCGT_1 BD43 VCCCORE_5 VCCCORE_55...
  • Page 59 Schematic Diagrams Processor 11/13 ADL-P PCH POWER U24N VCCIN_AUX VCCPRIM_1P8 VCCIN_AUX INS25337532 47u_6.3V_X5R_06*8 Reserved*2 3.3VA VCCP_3P3 BMAP_REV = 0.52 10u_4V_X6S_06*8 Reserved*2 R162 0_04 PSLB30E227M Reserved*1 1.533A 34.2A AL20 DW20 VCCIN_AUX_1 VCCPRIM_1P8_1 PRIMARY SIDE VCCIN_AUX AL32 DW22 VCCIN_AUX_2 VCCPRIM_1P8_2 AN20 DW27 VCC_RTC VCCIN_AUX_3 VCCPRIM_1P8_3...
  • Page 60 Schematic Diagrams Processor 12/13 ADL-P GND U24P U24Q U24R U24S INS28917330 INS28917782 INS28918234 INS28918689 BMAP_REV = 0.52 BMAP_REV = 0.52 BMAP_REV = 0.52 BMAP_REV = 0.52 AL15 BF58 CD58 DC47 ED58 AL17 CE51 DC54 AL22 BG12 CE55 DC57 ED60 BG44 CF47 DC59 FA40...
  • Page 61 Schematic Diagrams Processor 13/13 ADL-P CPU JTAG, PCH JTAG, MISC VCCST PU/PD for JTAG signals XDP_TCLK 51_04 XDP_TRST# *51_04 1K_04 H_THRMTRIP_N CPU_EAR *1K_04 3.3VS U24V 10K_04 SMI# VCCST INS25303075 R259 10K_04 SCI# BMAP_REV = 0.52 XDP_TDI *51_04 PCH_TDO 100_04 1K_04 H_CATERR# AF15 XDP_TRST#...

  • Page 62: Ddr4 So-Dimm A

    Schematic Diagrams DDR4 SO-DIMM A SO-DIMM A VDDQ VDDQ_VTT J_DIMMAA J_DIMMAB M_A_DQ[63:0] M_A_DQ7 M_A_CLK_DDR0 CK0_T M_A_DQ2 VDD19 2.5V M_A_CLK_DDR#0 CK0_C VDD18 M_A_DQ3 M_A_CLK_DDR1 CK1_T VDD17 M_A_DQ0 M_A_CLK_DDR#1 CK1_C M_A_DQ6 VDD16 VPP2 VDD15 VPP1 M_A_DQ5 M_A_CKE0 CKE0 VDD14 M_A_DQ4 M_A_CKE1 CKE1 VDD13 M_A_DQ1 3.3VS...

  • Page 63: Ddr4 So-Dimm B

    Schematic Diagrams DDR4 SO-DIMM B SO-DIMM B VDDQ_VTT VDDQ J_DIMMBA J_DIMMBB M_B_DQ[63:0] M_B_DQ23 M_B_CLK_DDR0 CK0_T VDD19 M_B_DQ20 2.5V M_B_CLK_DDR#0 CK0_C VDD18 M_B_DQ16 M_B_CLK_DDR1 CK1_T VDD17 M_B_DQ19 M_B_CLK_DDR#1 CK1_C VDD16 VPP2 M_B_DQ21 M_B_DQ22 VDD15 VPP1 M_B_CKE0 CKE0 VDD14 M_B_DQ17 M_B_CKE1 CKE1 VDD13 M_B_DQ18 3.3VS...

  • Page 64: Panel

    Schematic Diagrams Panel PANEL CONNECTOR (For coaxial cable) eDP panel 30PIN PLVDD J_LCD1 C621 PANEL BACKLIGHT 1u_6.3V_X5R_02 EDP_TXN0 BKL_EN C625 0.1u_10V_X5R_04 EDP_TXN_0 EDP_TXP0 C628 0.1u_10V_X5R_04 3.3V EDP_TXP_0 3.3V EDP_TXN1 BLON C627 0.1u_10V_X5R_04 EDP_TXN_1 EDP_TXP1 C632 0.1u_10V_X5R_04 74LVC08APW EDP_TXP_1 *0.33u_6.3V_X5R_04 74LVC08APW EDP_TXN2 C636 0.1u_10V_X5R_04...

  • Page 65: Hdmi

    Schematic Diagrams HDMI HDMI CONNECTOR ( W/O LEVELSHIFT) HDMI_5VS 100mA VOUT C748 C753 C752 C759 J_HDMI1 C128G1-K1909-L *10u_6.3V_X5R_06 1u_6.3V_X5R_04 0.1u_6.3V_X5R_02 *22u_6.3V_X5R_06 APL3517A HDMI_HPD-C R402 20K_04 HOT PLUG DETECT B Y P L A T F R O M R788 DDC/CEC GND HDMI_SDA-C B Y P L A T F R O M HDMI_SCL-C...

  • Page 66: Vga Pci Express

    Schematic Diagrams VGA PCI Express 1V8_AON NV PCI EXPRESS 1V8_AON R762 *10K_04 R810 0_04 PEXVDD 1uF x 4 29,58 NVVDD_PWRGD R806 *0_04 DGPU_PWRGD R740 PEXVDD 4.7uF x 3 10K_04 PEXVDD 10uF x 2 2SK3018S3 PEG_CLKREQ# PEXVDD 22uF x 2 R739 1V8_AON Place near balls Place between...

  • Page 67: Gpu Frame Partition

    Schematic Diagrams GPU Frame Partition U25B U25C 2/17 FBA Page5: MEMORY: GPU Partition A/B 3/17 FBB G6 x16 MODE_3 CMD MAPPING GA1XX GDDR6 CMD Mapping Upper 32..63 FBA_D[31..0] FBB_D[31..0] Lower 0..31 FBA_D[31..0] FBB_D[31..0] DRAM2 FBA_D0 1V8_FB_PLL_REF FBB_D0 DRAM1 FBA_D0 FB_PLLVDD 1V8_FB_PLL_REF FBB_D0 CHA-Byte 4,5...

  • Page 68: Vga Frame Buffer A

    Schematic Diagrams VGA Frame Buffer A FRAME BUFFER PARTITION A 31..0 FBA_DBI[3..0] FBA_DBI[3..0] FBA_DBI0 FBA_DBI1 FBA_DBI2 FBA_CMD[24..0] FBA_DBI3 FBA_CMD[24..0] FBVDDQ FBA_EDC[3..0] FBA_EDC[3..0] FBA_EDC0 FBA_EDC1 FBA_EDC2 FBA_EDC3 FBA_D[31..0] FBA_D[31..0] FBA_CMD1 FBA_VREFC CA0_A VREFC FBA_CMD13 CA1_A FBA_CMD12 CA2_A FBA_CMD24 CA3_A R673 FBA_CMD11 CA4_A FBA_CMD15 1K_1%_04...
  • Page 69 Schematic Diagrams VGA Frame Buffer A FRAME BUFFER PARTITION A 63..32 FBA_DBI[7..4] M10D FBA_DBI[7..4] FBVDDQ FBA_DBI4 FBA_DBI5 FBA_DBI6 FBA_DBI7 M10C FBA_EDC[7..4] FBA_CMD[52..28] FBA_EDC[7..4] FBA_CMD[52..28] FBA_EDC4 FBA_CMD33 FBA_VREFC_H CA0_A VREFC FBA_EDC5 FBA_CMD45 CA1_A FBA_EDC6 FBA_CMD35 CA2_A FBA_EDC7 FBA_CMD46 CA3_A R733 FBA_CMD36 CA4_A FBA_D[63..32] FBA_CMD43...

  • Page 70: Vga Frame Buffer B

    Schematic Diagrams VGA Frame Buffer B FRAME BUFFER PARTITION B 31..0 FBB_DBI[3..0] FBB_DBI[3..0] FBB_DBI0 FBB_DBI1 FBB_DBI2 FBB_DBI3 FBB_EDC[3..0] FBB_EDC[3..0] FBVDDQ FBB_CMD[24..0] FBB_EDC0 FBB_CMD[24..0] FBB_EDC1 FBB_EDC2 FBB_EDC3 FBB_D[31..0] FBB_CMD1 FBB_VREFC CA0_A VREFC FBB_D[31..0] FBB_CMD13 CA1_A FBB_CMD12 CA2_A FBB_CMD24 CA3_A FBB_CMD11 CA4_A R659 FBB_CMD15 CA5_A...
  • Page 71 Schematic Diagrams VGA Frame Buffer B FBB_DBI[7..4] FRAME BUFFER PARTITION B 63..32 FBB_DBI[7..4] FBB_DBI4 FBB_DBI5 FBB_DBI6 FBB_DBI7 FBB_EDC[7..4] FBVDDQ FBB_EDC[7..4] FBB_EDC4 FBB_EDC5 FBB_CMD[52..28] FBB_CMD[52..28] FBB_EDC6 FBB_EDC7 FBB_D[63..32] FBB_D[63..32] FBB_CMD33 FBB_VREFC_H CA0_A VREFC FBB_CMD45 CA1_A FBB_CMD35 CA2_A FBB_CMD46 CA3_A R660 FBB_CMD36 FBVDDQ NORMAL NORMAL...

  • Page 72: Vga Nvvdd Coupling

    Schematic Diagrams VGA NVVDD Coupling FBVDDQ FBVDDQ 10uF x 6 C629 FBVDDQ 1uF x 12 *PSLB30E227M FBVDDQ 22uF x 5 NVVDD 10uF x 34 NVVDD 1uF x 13 NVVDD 22uF x 15 Place Under GPU FBVDDQ FBVDDQ 10uF x 2 1uF x 6 Partition A Place Under GPU...

  • Page 73: Straps, Xtal

    Schematic Diagrams Straps, XTAL GPU_PLLVVD 1uF x4 XTAL GPU_PLLVVD 4.7uF x1 GPU_PLLVVD 22uF x 1 Near GPU U25Q Under GPU 1V8_RUN 11/17 XTAL_PLL 40mil GPU_PLLVDD HCB1608KF-300T60 CORE_PLL_AVDD GPCADC_AVDD 30ohm ESR 10mohm bead 1V8_AON C288 C276 C257 C256 M-L0603 SP_PLLVDD C313 C328 1u_6.3V_X6S_04 1u_6.3V_X6S_04...

  • Page 74: Ifp I/O Interface

    Schematic Diagrams IFP I/O Interface DP to TYPE-C IFP I/O INTERFACE U25L 5/17 IFPAB HDMI U25M SL/DL 6/17 IFPC HDMI IFPA_L3 TXC/TXC R210 *1K_1%_04 TXC/TXC IFPA_L3 IFPCD_RSET R219 *1K_1%_04 IFPAB_RSET HDMI TXD0/0 IFPA_L2 Under GPU TXD0/0 IFPA_L2 IFPC_AUX_SDA 40 mil IFPC_AUX_SCL Under GPU IFPAB_PLLVDD...

  • Page 75: Misc - Gpio, I2C, Rom

    Schematic Diagrams Misc - GPIO, I2C, ROM MISC: GPIO, I2C, and ROM 1V8_AON N18P GN20P U25P NV3V3 GN20P 10K_04 12/17 MISC2 10K_04 R772 10K_04 VGA_ROM_CS# 1V8_AON N18P ROM_CS 1V8_AON VBIOS ROM 1M VGA_ROM_SI GPIO26_ROM_WP# R759 R758 ROM_SI VGA_ROM_SO VGA_ROM_SI (OPTIMUS) ROM_SO VGA_ROM_SO 10K_04...

  • Page 76: Nvidia Power Sequence

    Schematic Diagrams NVIDIA Power Sequence DEFAULT HW POWER SEQUENCE 3.3VS R841 3.3VA 100K_04 BAT54AS3 FBVDDQ_PW RGD NV_FBVDDQ_EN FBVDDQ_EN 19,29 DGPU_PW RGD PEX_VDD_PW RGD NV_EN_DOW N VIN_DOWN PEX_VDD_EN NV_PEXVDD_EN NV_NVVDDS_EN T122 OVERT# OVERT# NVVDDS_EN NV_NVVDD_EN 58,59 R773 *0_04 1V8_AON_PW RGD SUSB# NVVDD_EN R786 0_04...

  • Page 77: Gpu Nvvdd, Fbvddq

    Schematic Diagrams GPU NVVDD, FBVDDQ NVVDD NVVDD U25G NVVDD NVVDD U25J FBVDDQ FBVDDQ 4/17 VDDMS U25H 14/17 FBVDDQ AA12 AJ22 VDDMS VDDMS 13/17 VDD AA29 AJ23 AA31 VDDMS VDDMS FBVDDQ FBVDDQ AB12 AJ24 AA13 AA36 VDDMS VDDMS FBVDDQ FBVDDQ AB29 AJ25 AA14 AB33...

  • Page 78: Gpu Gnd

    Schematic Diagrams GPU GND U25D U25E 15/17 GND_1/2 16/17 GND_2/2 AN10 AN31 AN33 AN34 AN35 GPU GND AN39 AP12 AP14 AB13 AP16 U25F AB14 AP18 AB15 9/17 Configurable AB16 AP20 Power Channels NVVDD NVVDD AB17 AP32 AB18 AP37 XVDD XVDD AB19 XVDD XVDD...

  • Page 79: Audio Codec

    Schematic Diagrams Audio Codec D01 CHANGE IC TO ALC256-CG HEADPHONE_L LINE1-VREFO-L HEADPHONE_R LINE1-VREFO-R MIC2_VREFO AUDIO CODEC ALC256 AUDG C510 10u_6.3V_X5R_06 AUDG R514 100K_04 5VS_AUD ANALOG DIGITAL HCB1005KF-121T20 Place next to pin 26 C528 C530 C529 AZ5125-01H TVS Realtek ,Ivy11 30 1.8VS *ZD5232BS2 AUDG...

  • Page 80: M Key Pcie Ssd

    Schematic Diagrams M Key PCIE SSD NGFF_M (M2) SSD (PCIE 4X) 3.3VS >120 mil R585 SSD1_3.3VS SATAGP1 J_SSD1 100K_04 C590 C589 C581 C574 H: PCIe(only) GND13 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 10u_6.3V_X5R_04 10u_6.3V_X5R_04 GND12 3.3V8 GND11 3.3V7 FOR OPTANE SUPPORT SATAGP1 PEDET(NC-PCIe/GND-SATA) 3.3V6 ,22u c hange to1 0 u NC18...

  • Page 81: Usb Charger, Tpm

    Schematic Diagrams USB Charger, TPM USB 3.0 port (CHARGER) VDD5 USBVCC_CH Smart CDP 80 mil pin8 pin4 Function VOUT DCP autodetect with C790 C795 mouse/keyboard wake up 10u_6.3V_X5R_04 SY6288C20AAC S0 Charging with SDP 2A/90mohm USB 3.2 Gen 1 USB_DD_ON# S0 Charging with CDP USB PORT Charge USB3.0 Max Trace length Follow Design Guide...

  • Page 82: Usb W/Ith Redriver

    Schematic Diagrams USB w/ith Redriver 3.3V 3.3V R301 *4.7K_04 R302 *0_04 R310 4.7K_04 R312 *0_04 with Redriver R311 4.7K_04 R313 *0_04 C386 C355 C385 R333 *4.7K_04 R335 2K_1%_04 0.01u_16V_X7R_04 0.1u_6.3V_X5R_02 1u_6.3V_X5R_02 R334 *4.7K_04 R336 0_04 I2C_SDA_20 I2C_SCK_20 USB CONNECTOR SIDE PCH SIDE USB3_TXN1_R USB3_TXN1_RM...

  • Page 83: It5570

    Schematic Diagrams IT5570 MODEL_ID IT5570 EC_ERST# R352 0_04 Voltage Debug Port ESPI_RESET_N R353 75K_04 d_GPIO9_ALERT_FAN 28,43 NV40PNK(GN20-P1) 100K 3.3V 10,29,33,34,37,38,39,41 BUF_PLT_RST# R383 *62K_1%_04 VDD3 VDD3 J_80DEBUG1 NV40PNJ(GN20-P0) 61.9K 100K KBC_AVDD MODEL_ID VDD3 R543 100K_04 3IN1 NV40PNH(N18P-G61-A) 100K C420 C497 C436 C430 NV40PNK/NH, NJ=61.9K=6-13-61921-28C 33,36...

  • Page 84: Lan Rtl8111G

    Schematic Diagrams LAN RTL8111G , S HO R T LAN (RTL8111H LDO MODE ONLY) (W>60mil R830 0_06 VDD10 L<200mil) REGOUT VDD10 (>60mil) C776 *SWF2520CF-4R7M-M C757 C750 RTL8111H R406 2.49K_1%_04 0.1u_6.3V_X5R_02 *4.7u_6.3V_X5R_06 *0.1u_6.3V_X5R_02 2015/11/26 VDD3 3.3V_AUX Mode : La , Ca , Cb , Ra , C c L D O L a , C a , C b...

  • Page 85: Wlan/Bt

    Schematic Diagrams WLAN/BT CNVI WLAN/BT R606 10K_04 VDD3 10,19,33,36,37,39 PCIE_W AKE# RB751S-40G J_W LAN1 >60 mil GND13 3.3V3 W LAN_3.3V W T_CLKP CNVI_W T_CLKP WT_CLKP 3.3V2 W T_CLKN CNVI_W T_CLKN WT_CLKN PEWAKE1_N GND12 CLKREQ1_N W T_D0P CNVI_W T_D0P WT_D0P PERST1_N CNVi W T_D0N T132...

  • Page 86: Oz711Lv2

    Schematic Diagrams OZ711LV2 PCIE_RXN9_CARD OZ711LV2 SP7: internal pull-down 200k PCIE_RXN9_CARD PCIE_RXP9_CARD micro SD socke t , 3.3VS PCIE_RXP9_CARD S D _ W P ( # 2 9 ) G N D 3V3AUX 3V3AUX SD_W P# CLK_PCIE_CARD# CLK_PCIE_CARD# VDD3 CR1_LEDN R845 10K_04 CLK_PCIE_CARD 40 mil...

  • Page 87: Type-C Usb3.0

    Schematic Diagrams Type-C USB3.0 USB3_TYPEC TYPE-CRedriver TYPE C USB3.2 Gen 2 USBVCC3.1_1 100 MIL 3.3V_PB1 with Redriver 3.3V SW A_PB1 3.3V_PB1 R416 *1K_04 C868 C869 FGA_PB1 R429 *1K_04 R456 *1K_04 EQA_PB1 C854 0.1u_10V_X5R_04 *0.1u_10V_X5R_04 HCB1005KF-121T20 SW B_PB1 R386 *1K_04 FGB_PB1 R413 *1K_04 10u_6.3V_X5R_06...

  • Page 88: Retimer 2/2

    Schematic Diagrams Retimer 1/2 U22B Burnside Bridge U22A INS16842080 INS16841958 TBT_EE_CLK EE_CLK I2C_SDA RETIMER_I2C_SDA TBT_EE_CS_N EE_CS_N I2C_SCL RETIMER_I2C_SCL C580 0.22u_10V_X5R_02 TCP0_TX0_C_DP TBTA_TXRX1_P_R TBT_EE_DI TCP0_TX0_DP ASSRXP1 BSSRXP1 EE_DI I2C_INT RETIMER_I2C_INT TCP0_TX0_C_DN TBTA_TXRX1_N_R TBT_EE_DO TC_RETIMER_FORCE_PW R C579 0.22u_10V_X5R_02 TCP0_TX0_DN ASSRXN1 BSSRXN1 EE_DO FORCE_PWR BB_TCP01_FLASH_BUSY_N FLASH_BUSY_N...
  • Page 89 Schematic Diagrams Retimer 2/2 Burnside Bridge +VCC3P3_LC_TCP0 +VCC0V9_SVR_TCP0 +VCC3V3_SX_TCP0 +VCC3V3_SX_TCP0 +VCC3V3_SVR_TCP0 U22D +VCC3V3_SVR_TCP0 INS16840369 U22C +VCC3P3A_SVR_TCP0 C864 INS16840509 SVR_VSS_2 VCC3P3_SX C542 C550 C558 C843 C845 SVR_VSS_1 +VCC3P3_ANA_TCP0 2.2u_6.3V_X5R_04 VCC3P3_ANA VCC3P3_SVR 2.2u_6.3V_X5R_04 2.2u_6.3V_X5R_04 VCC3P3_LC VCC3P3_SVR VSS_ANA VSS_ANA +VCC0P9_SVR_TCP0_PHASE SVR_IND_2 VCC3P3A VSS_ANA VSS_ANA C851 C858...

  • Page 90: Type-C Con

    Schematic Diagrams Type-C Con VCC3V3_PD TBTA_VBUS R432 *0_04 VBUS Source 5V,3A TBT_PA_VBUS HCB2012KF-800T80 80Ohm, 0.01Ohm DCR, 8A Idc MTDK5S6R main:6-21-B4KB0-024 Q45A second:6-21-B4K20-024 ACE_I2C_SDA2 R947 C612 SMD_VGA_THERM 28,36 J_TYPEC2 10K_04 UCF3T-4TN30-0P0B 1u_25V_X5R_06 *CSOD140BSH CSOD140BSH TBTA_TX_1_P TBTA_TXRX_1_P TBT_RESET_N LDO_3V3 GPIO0_TBT_RESET_N TBTA_TX_1_N TX0_P RX0_P TBTA_TXRX_1_N TX0_N...

  • Page 91: Fan, Ccd, Tp, White Kb

    Schematic Diagrams Fan, CCD, TP, White KB TP Connect TP_VCC TP_VCC TP_VCC To T/P TP_VCC R932 *20mil short-p 3.3VS J_TP1 R520 C832 C841 C823 TP_SMB_DATA_JJ 100K_04 R539 R528 R927 R922 1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 TP_SMB_CLK_JJ SMB_TP I2C_TP Q44A *10u_6.3V_X5R_04 1K_04 1K_04 10K_04 10K_04 TP_ATTN# *SM2004KDW H...

  • Page 92: Ac-In

    Schematic Diagrams AC-In PD_IN PWR_CHARGER DC_JACK_R MDU1721 MDU1517 JDC_AC J_DC_IN1 ULTRASO-8 ULTRASO-8 5.0A JDC_AC EML1 HCB2012KF-800T80 PC135 PC136 PR214 PR213 PC137 PC139 PC140 PC138 4.7_06 4.7_06 SMAJ20A PR45 PN = 6-20-B3J00-003 100_06 Value = 2DC3061-045111F PC141 PCB Footprint = 2DC3061-045111F PC20 PR37 LM5050MK(X)-1/NOP8...

  • Page 93: Led, Lid, Pwr Sw

    Schematic Diagrams LED, LID, PWR SW LED function : LED_BAT_CHG LED_PW R 36,46 LED_BAT_FULL LED_ACIN LED1 LED2 LED3 CLEVO POWER VAIO POWER ESD73034D P/N = 6-24-40001-022 VAIO R669 CLEVO POWER ON LED CLEVO VAIO R183 R186 R184 R185 R187 R188 1.5K_04 / AC IN VAIO...

  • Page 94: Mp2964 Controller

    Schematic Diagrams MP2964 Controller D01 CHANGE IC TO MP2964GQKT-2900-Z ADL-P 15W IA 2PHASE + GT 1PHASE ADL-P 28W IA 3PHASE + GT 2PHASE VCORE VCORE_CS1 VCORE_CS2 VCORE_CS3 PR152 0_04 PR14 1K_1%_04 VRACPU_VOSEN VCC_VCORE_SENSE PR13 1K_1%_04 PR151 0_04 VRACPU_VORTN VSS_VCORE_SENSE PWR_2PH=NC, 3PH=1K_1%_04 PR12 1K_1%_04...

  • Page 95: Vcore

    Schematic Diagrams VCore VCORE OUTPUT STAGE phase 1 3.3V PC86 PC89 close to ic PU10 MP86941-AGQVT-Z PC106 EMC10 1u_25V_X7R_06 VIN1 0.01u_50V_X7R_04 PC88 VIN2 1u_6.3V_X6S_04 VCORE_BST_PW M1 VCCIN AGND VCORE VCORE_PW M1_R PR150 0_04 VCORE_PW M1 1u_25V_X7R_06 120A VTEMP_C_1 VCORE_SW _PWM1 PR156 0_04 47,48,49...

  • Page 96: Vccgt

    Schematic Diagrams VCCGT 1.3A phase 1 PC102 PC70 PC71 3.3V close to ic PRIMARY SIDE EMC11 MP86941-AGQVT-Z 0.01u_50V_X7R_04 VCCGT VIN1 PC101 VIN2 1u_6.3V_X6S_04 GT_BST_PW M1 VCCGT AGND PC123 PC131 VCCGT_PW M6_R PR162 0_04 VCCGT_PW M6 1u_25V_X7R_06 VTEMP_C_6 GT_SW _PW M1 Sheet 49 of 63 PR172 0_04...

  • Page 97: Vccin Aux

    Schematic Diagrams VCCIN AUX D02A CHANGE AOS TO MPS MP2961GL VREG3 PC268 PC270 PC271 PC269 PR288 2_06 PR289 10K_04 PJ19 *CV-40mil 3.3V PC274 PR290 0_04 TDC 18A ICCMAX 34A 1u_16V_X7R_06 PC272 1.8VA_PW RGD 0.22u_16V_X7R_06 BST1 VCCIN_AUX VCCIN_AUX_AGND 3.3VA CCCA-0630-R15-MR PC17 PC15 PC273 PR173...

  • Page 98: 1.8Va, 1.8Vs

    Schematic Diagrams 1.8VA, 1.8VS VREG5 1.8VA PU21 PR109 AOZ2261NQI-11 0_06 POWER CHANGE PC194 PC184 PC190 3.3VA PC216 4.7u_6.3V_X5R_04 PR257 180K_1%_04 PR106 10K_1%_04 PR268 0_06 PC215 0.1u_16V_X7R_04 1.8VA_PWRGD PGOOD 1.8VA_PW RGD PR102 *10K_1%_04 VREG5 PS_1V8_PFM 1.8VA empty PFM* PR259 10K_1%_04 PL16 chip BCIHP5420HC-1ROM Sheet 51 of 63...

  • Page 99: 3.3V, 5V, 3Vs, 5Vs, Ctl

    Schematic Diagrams 3.3V, 5V, 3VS, 5VS, CTL DD_ON# SUSB VDD3 VDD3 R380 R769 100K_04 10K_04 SUSB SUSB DD_ON# 2SK3018S3 2SK3018S3 C760 10,34,51,55 SUSB# C730 34,36,40,53 DD_ON *CV-40mil *30p_25V_NPO_02 *0.1u_6.3V_X5R_02 R381 JUMP-1MM R774 100K_04 100K_04 C793 1000p_50V_X7R_04 C842 *1000p_50V_X7R_04 2nd source G5016 Sheet 52 of 63 FA7601 VDD5...

  • Page 100: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 LDO_3V3 RB751S-40G EN_3V PR270 PR271 XLP_OUT RB751S-40G 39K_1%_04 51K_1%_04 EN_3V EN_5V PC244 *CV-40mil 1000p_50V_X7R_04 2.5A VREG3 PU23 POWER CHANGE POWER CHANGE PC236 PC237 PC235 PC213 PC207 PC258 PC257 PC259 PC221 VDD3 1u_6.3V_X5R_04 VREG3 PGOOD PC233 PR276 0_06 PR280 0_06...

  • Page 101: Vddq, Vddq_Vtt

    Schematic Diagrams VDDQ, VDDQ_VTT POWER CHANGE PC239 PC241 PC240 VDDQ_R *RB0540S2 VDDQ_VTT(0.6V) G5616BRZ1U VDDQ(1.2V) PC48 VDDQ_VBST DEFAULT PC47 10u_6.3V_X5R_04 VDDQ_VTT VLDOIN VBST SHORT 0.1u_16V_X7R_04 DEFAULT PR113 VTT_MEM_R VDDQ_DRVH VDDQ_DRVH_R VDDQ SHORT DRVH PL18 VDDQ_R 0_04 PJ18 PR111 EM-10AM05V16 *20mil short-p VTTGND PC45 PC46...

  • Page 102: 2.5V, Vccst, Vcc1P8

    Schematic Diagrams 2.5V, VCCST, VCC1P8 VCCST VCC1P05_OUT_FET VCC1P8_CPU VDD3 PU12 FA7601 C665 VCC1P8_CPU 10u_6.3V_X5R_06 VCCST 20 mil 20 mil PU13 R742 VOUT OUT1 OUT2 0_04 OUT1 OUT2 VDD3 C701 C654 C341 0.1u_6.3V_X5R_02 VDD3 R244 0.1u_10V_X5R_04 *33_04 SHDN# 1u_6.3V_X5R_04 *47K_1%_04 AW 3705D180STR *220p_50V_NPO_04 U74AHC1G08G-AL5-R *SM2004DW H...

  • Page 103: Charger, Ac-In

    Schematic Diagrams Charger, AC-In D01 CHANGE IC TO BQ24800RUYR POWER CHANGE PQ13 MDU1721 PQ16 PQ17 AC Detect 17.2V ULTRASO-8 MDU1517 PDC3906Z ULTRASO-8 PRS1 WMCSL0612R005FETA DC_19V VIN_L PC76 PC13 PC87 PC238 PC226 PC231 PC232 PC266 PC267 PC227 PC230 PC263 PC249 PC255 PC261 PR123 PR124...

  • Page 104: 3.3Va, Nv3V3

    Schematic Diagrams 3.3VA, NV3V3 NV3V3 ,10u c 2nd source G5016 3.3VA discharge EM5290 VDD3 3.3V PCBfootprint: 3.3VA TDFN14-2X3MM-A 3.3VA C502 VDD3 3.3VA FA7601 NV3V3 C503 0.1u_6.3V_X5R_02 NV3V3 10u_6.3V_X5R_04 R965 R964 3.3VA 3.3VA OUT2 OUT1 *100K_04 *100_04 OUT2 OUT1 NV3V3 Q89A C496 *MTDK5S6R VDD3...

  • Page 105: Nvvdd1

    Schematic Diagrams NVVDD1 N H 5 0 R A N H 7 0 R A Q 6 - 0 2 - 2 9 8 8 0 - C Q 0 - 2 3 , 6 - 0 2 - 2 9 8 8 0 - C Q 0 - 2 2 P C I E , I v y 0 8 / 0 8 MP2988_NV_PWM1...

  • Page 106: Nvvdd2

    Schematic Diagrams NVVDD2 PWR_SRC_NV PC191 PC195 EMC13 PC169 1u_25V_X7R_06 0.1u_25V_X5R_04 M-C0603 PU17 3.3V PC170 1u_25V_X7R_06 M-C0603 NVVDD_DRMOS_VCC PR251 0_06 NVVDD PL11 PR245 PC175 HPRM-1074-R22-M MP86941-AGQVT-Z 2K_04 1u_6.3V_X6S_04 AGND PR233 SYNC VTEMP/FLT 2.2_06 NVVDD_PHASE1_PWM PC168 2200p_50V_X7R_04 NVVDD_DRMOS_VTEMP 58,59 NVVDD_PHASE1_CS PWR_SRC_NV Sheet 59 of 63 NVVDD2 PC192 PC196...

  • Page 107: Pex_Vdd

    Schematic Diagrams PEX_VDD D01 CHANGE IC TO EM5841BVT PEX_VDD PEX_VDD_PW RGD Open VREG Type 0 3.3V PC159 0.95V PC158 PR47 PR17 0105 10_06 3.3V 22u_6.3V_X5R_08 0.1u_10V_X7R_04 10K_1%_04 PU14 INS30554409 EM5841BVT 0.200 DFN10 COMMON PR26 *160K_04 3.0mps @ 0.95V PR221 10K_04 PGOOD PEX_VDD OpenVReg...

  • Page 108: Fbvddq

    Schematic Diagrams FBVDDQ GN20-P0-P1,N18P-G61-A FBVDDQ: P0: 1.25V MP2988_FB_PWM1 PR76 0_04 FBVDD_PHASE1_PWM MP2988_FB_SDA PWM1 P3/P5/P8: 1.2V PR54 0_04 29,58 I2CC_SDA_PP MP2988_FB_PWM2 FBVDD_PHASE2_PWM PR80 0_04 PWM2 FBVDDQ MP2988_FB_SCL PR53 0_04 29,58 I2CC_SCL_PP PWM3 MP2988_FB_EN NV_FBVDDQ_EN PR56 10K_04 PR71 *10K_1%_04 PC134 PC152 PC151 NV3V3 EC_GPIO 29,36,47,58...

  • Page 109: Ovr-M

    Schematic Diagrams OVR-M Default value= ON G1 NV3V3 VDD3 3.3VS Output power MEASUREMENT R899 R898 R341 *0_04 *0_04 0_04 OVR-M OVR-M OVR-M ON:G1 = NC ON:G1 = NC ON:G1 = 0_04 uPI:G1 = NC uPI:G1 = NC uPI:G1 = 0_04 uPI:G2 = NC uPI:G2 = NC uPI:G2 = 0_04...

  • Page 110: 1V8_Aon/Run

    Schematic Diagrams 1V8_AON/RUN 1.8VA C788 C787 1.8VA 10u_6.3V_X5R_06 *10u_6.3V_X5R_06 C816 FA7601 1V8_RUN 10u_6.3V_X5R_06 1V8_AON N18P R870 0_06 1V8_AON 1V8_RUN OUT1 OUT2 OUT1 OUT2 N18P GN20P R879 10K_04 R869 0_06 1V8_AON_PWRGD 1V8_AON C801 C800 GN20P 100p_25V_NPO_02 100p_50V_NPO_04 Sheet 63 of 63 1V8_AON_ON 1V8_RUN_ON N18P...
