Summary of Contents for Scooterpac Atom Power
-
Page 4: Table Of Contents
Anti-Tip Wheels ..............12 12.3 Warranty Policy ..............25 Joystick Controller Lever..........13 13 Specifications .................. 26 Folding & Unfolding the Atom Power ......14 14 Servicing ..................... 27 Controls ....................15 15 Notes..................... 30 Operating Your Atom Power ..........16 Using the Powerchair ............. -
Page 5: Welcome
Dealer Name ________________________ Congratulations on purchasing your Scooterpac Atom Power. With regular maintenance and proper operation your Atom Power will give you many years and Address 1 ________________________ countless miles of rewarding experiences. This manual contains the information that you and your authorised... -
Page 6: Safety Information
There are certain situations including some medical conditions where the user will need to practice operating the powerchair in the presence of a trained attendant. A trained attendant can be defined as a family member or care professional, specially trained in assisting the user in various daily living activities. Scooterpac Atom Power | User Manual... -
Page 7: Safety Warnings
Avoid driving over loose surfaces such as gravel. Do not drive the Atom Power up or down steps. Do not turn the Atom Power around on a slope. Never sit on the footplate or allow more than one person on the chair. This will damage the powerchair. -
Page 8: Safe Inclines
3.1 Safe Inclines The Atom Power can climb inclines of up to 10˚ without danger. On this 10˚ incline, the Atom Power can stop, brake and turn. It is possible to attempt steeper inclines, but we strongly suggest that you do not. To reduce the possibility of tipping backwards on inclines, lessen the load on the back of the scooter by sliding the seat forward as much as possible and leaning forward. -
Page 9: Unintentional Movement
4 Unintentional Movement Before operating, the Atom Power should always be stationary. When the Atom Power is switched on, it will remain stationary until the joystick is pushed or pulled. Do not attempt to operate the powerchair when standing. Scooterpac Atom Power | User Manual... -
Page 10: The Atom Power
5 The Atom Power Joystick Armrest Hand lever Controls Backrest Cushion Seat Belt Frame Seat Cushion Batteries & Black Controller Box Folding Lever Anti-Tip Wheels Rear Wheel Footplate Front Wheel Scooterpac Atom Power | User Manual... -
Page 11: Assembly & Expansion
6 Assembly & Expansion 1. Remove the Atom Power from the packaging box. 2. Holding the handle with one hand, press the front of the downward with the other hand. 3. Push until the seat and back of the chair are at 90 degrees and the lock is in place. -
Page 12: Anti-Tip Wheels
6.1 Anti-Tip Wheels The Atom Power is fitted with rear anti-tip wheels. These are an emergency failsafe that should never be relied upon in normal operation. These are designed to stop the Atom Power tipping backwards on a steep incline. To install the anti-tip wheels, follow the below steps: 1. -
Page 13: Joystick Controller Lever
1. Insert the joystick controller lever into the holder. 2. Adjust it to the preferred position for the user. 3. Tighten the locking nut. Insertion point Locking nut Insert the controller handset this way. Scooterpac Atom Power | User Manual... -
Page 14: Folding & Unfolding The Atom Power
7 Folding & Unfolding the Atom Power To fold the Atom Power follow the below steps: 1. Ensure the powerchair is stationary. 2. Fold the footplate. 3. Turn the front wheels horizontally. 4. Pull the yellow folding lever located under the front of the seat. -
Page 15: Controls
Buttons not in use power button. Press the Freewheel button. The red LED will activate. The powerchair Joystick can now be manually pushed. To re-enable the powered mode, press the power button. Scooterpac Atom Power | User Manual... -
Page 16: Operating Your Atom Power
To stop the powerchair while moving, simply release your hand and reposition the joystick to the central position. The powerchair will automatically come to a stop and engage the electromagnetic brakes. Scooterpac Atom Power | User Manual... - Page 17 To safely leave the powerchair in standby mode, press and hold the power on/off button on the controller. Turn off the green switch located on the black controller box. Fold the footplate into the upright position and then stand up. Scooterpac Atom Power | User Manual...
-
Page 18: Charging
When the red light on the battery indicator flashes the power level available is extremely low. Do not use the powerchair. Plug in and charge the powerchair as soon as possible. Scooterpac Atom Power | User Manual... -
Page 19: Charging The Batteries
5. The powerchair will now start charging the batteries. Main Power Switch Power Socket The red light on the charger indicates it is charging. The green light on the charger indicates it is fully charged. Scooterpac Atom Power | User Manual... - Page 20 Battery Location We recommend charging your batteries 6-8 hours – charging overnight is good practice. When the Atom Power is in charge mode it will not enter drive mode. Charge Port TOP TIP – For best practice, please ensure to charge your batteries after each use.
-
Page 21: Troubleshooting & Fault Codes
The powerchair does not move or Controller or motor failure Contact authorised seller/ manufacturer moves unexpectedly Charger failure Contact authorised seller/ manufacturer Battery does not charge Battery failure Change / replace batteries. Scooterpac Atom Power | User Manual... -
Page 22: Maintenance
Before performing maintenance work, turn off the powerchair and remove the batteries. Component Daily Weekly Monthly Every 3 Months Every 6 Months Battery Power Connection Tire Pressure Frame Clean Seat Cushion Bearings Tyres Electromagnetic Brakes Scooterpac Atom Power | User Manual... -
Page 23: Cleaning
11.2 Cleaning 11.2.1 Framework To care for the framework, wipe the Atom Power using soft microfibre cloths. TOP TIP – Please do not use water or wash the framework. 11.2.2 Seat Cushions To care for the seat cushions, remove them from the powerchair. Clean the seat cushions with warm water and diluted soapy water. -
Page 24: Warranty
To ensure validity, the Warranty must be registered to Scooterpac within 14 days of purchase. 12.1 One-Year Warranty From one year from the date of delivery, Scooterpac will provide a warranty on the frame, motors and controller. 12.2 Warranty Exclusions 1. -
Page 25: Warranty Policy
The warranty does not extend to the consequential costs resulting from fault clearance, freight and travel costs, loss of earnings, expenses, etc. The manufacturer will not accept responsibility for any damage or injury caused by misuse or non- observation of the instructions set out in this user manual. Scooterpac Atom Power | User Manual... -
Page 26: Specifications
Turning Radius 600mm Footrest Fold-away Due to manufacturing tolerances and continuous product improvement this specification can be subject to variance of +/-3%. Varies with user weight, terrain type, battery charge, battery condition, tyre condition. Scooterpac Atom Power | User Manual... -
Page 27: Servicing
In order to ensure continued safe operation, the Atom Power must be serviced every 12 months. We recommend recording the servicing dates and locations on the sheets below. Always have your Atom Power serviced at an authorised Scooterpac dealer, using original Scooterpac parts. - Page 28 Next Service Year Service Dealer Name Technician Name Date of service Notes Signed Next Service Year Service Dealer Name Technician Name Date of service Notes Signed Scooterpac Atom Power | User Manual...
- Page 29 Next Service Year Service Dealer Name Technician Name Date of service Notes Signed Next Service Year Service Dealer Name Technician Name Date of service Notes Signed Scooterpac Atom Power | User Manual...
-
Page 30: Notes
15 Notes Scooterpac Atom Power | User Manual... - Page 31 Scooterpac Atom Power | User Manual...
- Page 32 SP/APC/M/EN/2024-C...
