SIEBE CP-8191-456 General Instructions Manual

CP-6191-456
CP4391-456 -
SIB ENVIRONMENTIAL CON7ROLS
1354
Clifford Avenue
Electronic Actuator Drive
p.0.
Box 2940
Loves Park, IL U.S.A. 6 1132-2940
General Instructions
Application
Electronic actuator drive is used to provide proportional
control of an electric gear train actuator from a variable
voltage DC signal from a controller.
Features
l
Accepts variable Vdc signal and drives certain
MP-400, MP-4000, MP-2100, and MP-9000 series
actuators in a proportional manner.
l
Rugged aluminum case.
l
Panel mount (CP-8191-456) and actuator mount
(CP-8391-456) models.
l
Adjustable start point, span, and hysteresis.
l
Typical controller can drive up to three actuator
drives.
Applicable Literature
l
Environmental Controls Cross-Reference Guide
F-23638
l
Environmenta
F-21 683
l
Environmenta
F-21 335
Controls Reference Manual
Controls Application Manual
Litho in U.S.A. 9-91
F-241 90-I
