Styrofoam-Cutter STYRO-CUT 230
Contents

Explanation of symbols

This instruction manual is part of this product. Please read this instruction manual carefully and keep it for future
use!
Warnings and safety instructions!
Accessible surfaces can get hot when the device is in operation!
Warning of dangerous electrical voltage!
Use eye protection!
Use protective clothing!
Use protective gloves!
The symbol of the "crossed-out garbage can" means that the device must not be disposed of in the household
waste!
HSGM GmbH
Industriestraße 30
D-65366 Geisenheim
Heißschneide-Geräte
u.- Maschinen GmbH
Page
1
2
2
3
4/5
5
5
5
5
6
6
7
7
7
Telefon: +49 (0) 6722 99993-0
Telefax: +49 (0) 6722 99993-40
E-Mail: info@hsgm.com
http://www.hsgm.com
Edition: 23.01.2024
Print: 09.02.2024
Seite: 1
