- Page 1 User Manual D2-260-PS Power Supply Revision 01 14988 W. 6th Ave., Suite 700 Golden, CO 80401 www.vescent.com...
-
Page 2: Table Of Contents
D2-260-PS User Manual Contents Contents 1 Introduction ..........................3 1.1 Symbol Definitions ..............................3 1.2 Safety ..................................4 2 Hardware ............................5 2.1 Package Contents ..............................5 2.2 Connections ................................5 3 Getting Started ..........................6 A Specifications ..........................7 B Additional Resources ........................8 C Service & Maintenance .........................9 D Warranty ............................ -
Page 3: Introduction
PS provides a DC voltage for powering the D2-260 Beat Note Detector. This section has information for safely operating the D2-260-PS. Please carefully read this section before using the D2-260-PS. Section 2 introduces the user to the instrument and defines all hardware connections. Section 3 explains normal operation of the D2-260-PS. -
Page 4: Safety
If this instrument is used in a manner not specified by the manufacturer in this manual or other relevant literature, protection provided by the instrument may be impaired. The D2-260-PS is not intended for fail-safe operation in hazardous environments or life- threatening situations. The user assumes full responsibility for correct and safe usage of the D2-260-PS in accordance with any applicable laws, codes, regulations, and standards pertaining to their specific application. -
Page 5: Hardware
Carefully remove and inspect the following items that are contained in the shipping box: 1. Power Supply Adapter 2. AC Power Cord, region specific 2.2 Connections The D2-260-PS adapter has the following connections: 3. Hirose Port Male 6-pin Hirose connector that provides +5 VDC. 4. Power Port Use the provided AC power cord to connect this port to a properly grounded mains receptacle. -
Page 6: Getting Started
To supply power to a D2-260 Beat Note Detector, follow these instructions. • Plug the D2-260 Hirose connector into the POWER port on the D2-260. • Plug one end of the AC power cord into the D2-260-PS power supply and the other end into a properly grounded mains receptacle. -
Page 7: A Specifications
D2-260-PS User Manual Specifications A Specifications Parameter Value Units Input Voltage 100 - 240 Input Frequency 50 or 60 Vescent Technologies Inc. - Page 7 - Revision 01... -
Page 8: B Additional Resources
Details Vescent Home https://vescent.com/ Additional resources are available at vescent.com D2-260-PS Product Page https://vescent.com/us/d2-260-ps.html Check here for more information about the D2-260-PS D2-260 Manual https://www.vescent.com/manuals/doku.php?id=d2:260_beat_note_detector Manual for the D2-260 Beat Note Detector Vescent Technologies Inc. - Page 8 - Revision 01... -
Page 9: C Service & Maintenance
RMA form. 4. Return the unit, postage prepaid, to Vescent. Do not forget to return a hard copy of the completed RMA form with the unit and write the RMA number on the shipping label. -
Page 10: D Warranty
“Warranty Period” during which this warranty applies varies with Product type as follows: a. For standard Vescent lasers in which a counter is incorporated (i.e. lasers with counters for which Vescent has published a datasheet and which have not been obsoleted by the time of order placement): one (1) year after the date of original shipment or 3,000 hours of use, whichever occurs first;... - Page 11 D2-260-PS User Manual Warranty e. For Products that are discontinued, Vescent’s liability shall terminate at the end of the applicable Warranty Period or one (1) year from the date of discontinuity, whichever occurs first. f. Except for the warranty stated herein and to the extent permitted by applicable law...
