Murdock A191-BF Series Quick Start Manual

A191-BF Series
BARRIER FREE, WALL MOUNTED
DRINKING FOUNTAIN WITH BOTTLE
FILLER AND TRIM PANEL
STANDARD FEATURES
n Both Child or Adult ADA Compliant (When Properly Installed)
n 304 Stainless Steel Basin and Chrome Plated Brass Button
n
Polished Stainless Steel, Anti-Rotation Non-Squirt Bubbler
or Flexible Low Flow Bubbler
n
100-Mesh Inlet Strainer
n
Mounting Plate with Hardware (A0000000-MP9)
n
Trim Panel
n 1 GPM Fill Rate (Bottle Filler)
n Laminar Flow Water Supply (Bottle Filler)
n 115v Plug-in Transformer (Bottle Filler with Sensor Op)
n Auto-Stop Allows Cartridge and Strainer Service Without
Shutting Off Water Supply
SUGGESTED SPECIFICATIONS
Drinking Fountain
Model A191400S-BF is a wall mounted, Drinking Fountain
Bottle Filler combination. Basin shall be constructed from 304
Stainless Steel and have an Integral Drain. Cabinet
from 18 gauge, 304 stainless steel with a brushed finish. Unit shall
be activated by Chrome Plated Brass Pushbutton using less than 5
pounds of force. Bubbler shall be polished stainless steel with a
non-squirt feature and operate on a water pressure range of
20-105 PSIG. Unit shall have a uniquely designed, two-piece
contoured Bowl with P-trap integral to the unit.
to Public Law 111-380 (NO-LEAD) and NSF/ANSI/CAN 61. Fixture
meets ADA, ADA Standing Person, and ADA Child requirements
when mounted appropriately.
Bottle Filler
Bottle Filler housing construction will be 20 gage Stainless Steel
with a satin finish and will also include components manufactured
from Antimicrobial, impact resistant ABS. Bottle Filler shall provide
approximately 1 GPM flow rate with a Laminar Flow Spout to
minimize splashing.
Bottle Filler -BF11 shall include Pushbutton Operated activation.
Bottle Filler -BF12 shall include Sensor Operated activation with a
20 second maximum run time. LED Lights illuminate the Bottle Fill
area and brighten when a bottle is detected. Optional -BCD Bottle
Counter Display indicates the quantity of 16 oz disposable Plastic
Bottles saved from a land fill and also displays the Water Filter
status.
*NOTE:
Option includes an additional enclosure, refer to Installation
Manual for details.
Complies
with the
following
standards:
NSF/ANSI/CAN 61-2020
®
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone 800-453-7465 • www.murdockmfg.com
CONTEMPORARY HYDRATION
and
shall be made
Unit shall be certified
Federal
Public Law
111-380
(No Lead)
Model A191400S-BF11 Shown
Patent D873,606 #10,100,933
MODEL:
(Must Specify Drinking Fountain)
FLEXIBLE BUBBLER
o
A191400F-BF11
o
A191400F-BF12
STAINLESS STEEL BUBBLER
o
A191400S-BF11
o
A191400S-BF12
OPTIONS
(additional costs may be incurred)
o -BF12-BAT Bottle Filler with Battery Operated Sensor
Operation (N/A With -BCD)
o-BF12-BCD Bottle Filler with Sensor Operation with
Bottle Counter Display
ACCESSORIES
(additional costs may be incurred)
o -BP12
Back trim panel for single wide basin fountain
o -WF1
1500-gallon capacity Water Filter (See Note *)
o -Wf3000
Coming soon 3000-gallon capacity Water Filter (See Note *)
o
A9100080-A 8 GPH Remote Water Chiller
(Recommended to be with 10 Feet of Fixture)
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
A191-BF
"INDOOR USE ONLY"
Drinking Fountain and Bottle Filler with
Pushbutton Operation
Drinking Fountain and Bottle Filler with
Sensor Operation
Drinking Fountain and Bottle Filler with
Pushbutton Operation
Drinking Fountain and Bottle Filler with
Sensor Operation
Product Warranty
Member of
Revised: 01/16/2024
