SmartSafe AC519 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NOTE:
1)
Carefully read the user manual before using, and keep it well for future reference.
2)
Carefully check the device parts list before using. For any doubt, contact SmartSafe distributor immediately.
3)
Due to the product upgrade, tiny difference between the user manual and the device will not be further noticed. Take the device
as standard.
Copyright reserved! Without written agreement from SmartSafe Tech Co., Ltd (Hereinafter refer to "SmartSafe"), any company or
person is not allowed to copy and duplicate this user manual in any format (electronic, mechanical, video, record or other
formats).The user manual is designed only for SmartSafe products. Any consequence caused by using the user manual to guide
other device operation is not under the responsibility of SmartSafe.
SmartSafe and its branches are not responsible for the fees and expense of the device damage and loss due to private accident or
from third party, misuse and abuse of the device, unauthorized change and repair, or any operation and maintenance not following
SmartSafe standard.
SmartSafe is not responsible for device damage or problem due to the usage of any optional parts or consumables instead of
SmartSafe original products or SmartSafe recognized products.
Declaration: Other product names mentioned in the user manual are aimed to describe the device usage. The registered trademarks
still belong to the original company.
The device is for professional technicians or maintenance and repair personnel.
Registered Trademark
SmartSafe has registered its trademark in China and several other countries, logo is
service marks,
dot names, Icons, company names mentioned in the user manual all belong to SmartSafe and its subsidiaries. In those countries
where SmartSafe trademark, service mark, dot name, icon, company name not registered yet, SmartSafe declaim the right for its
unregistered trademark, service mark, dot name, icon, and company name. Trademarks of the other products and company names
mentioned in the user manual still belong to original registered company. Without written agreement from the owner, no person is
allowed to use the trademark, service mark, dot name, icon and company name of SmartSafe or of other mentioned companies. You
can visit http://www.newsmartsafe.com or write to Customer Service Center of SHENZHEN SMARTSAFE TECH. CO., LTD. at 3310,
Building 11, Tianan Cloud Park, Bantian Street, Longgang District, Shenzhen, Guangdong, China, to get contact with SmartSafe for
the written agreement on the usage of the User Manual.
AC519 User Manual
. Other SmartSafe trademarks,
i
