probst AL-43/SH-21 User Manual

Hydraulic block cutter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
V2
User manual
Hydraulic Block Cutter
Type:
AL-43/SH-21
AL-43/SH-21-110
AL-43/SH-21-V
AL-43/SH-21-V-110
AL-43/SH-21-H-V
51200038
51200057
51200052
51200058
51200062
DE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AL-43/SH-21 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for probst AL-43/SH-21

Summary of Contents for probst AL-43/SH-21

  • Page 1 User manual Hydraulic Block Cutter Type: AL-43/SH-21 51200038 AL-43/SH-21-110 51200057 51200052 AL-43/SH-21-V AL-43/SH-21-V-110 51200058 AL-43/SH-21-H-V 51200062...
  • Page 2 Bitte beachten Sie, dass das Produkt ohne vorliegende Betriebsanleitung in Landessprache nicht eingesetzt / in Betrieb gesetzt werden darf. Sollten Sie mit der Lieferung des Produkts keine Betriebsanleitung in Ihrer Landessprache erhalten haben, kontaktieren Sie uns bitte. In Länder der EU / EFTA senden wir Ihnen diese kostenlos nach.

  • Page 3: Table Of Contents

    Inhalt 2 / 21 Table of contents Foreword ..........................4 1.1. Name of machine ......................4 1.2. Warning ........................4 1.3. Target group for each chapter ..................4 1.4. Symbols ........................5 1.5. Re-ordering the user manual ..................5 1.6. Deficiencies in this user manual ..................
  • Page 4 Inhalt 3 / 21 8.1. General information for trouble .................. 20 8.2. Trouble indications and signals ................... 20 Disposal..........................20 EU Declaration of Conformity for machines ................21 The Hydraulic Block Cutters ..................21 Table 1.3-1: Overview of the target groups for each chapter ....................4 Table 7.2-1: Checkpoints and lubrication schedule ......................

  • Page 5: Foreword

    Inhalt 4 / 21 Foreword This foreword contains general information about and for this user manual. 1.1. Name of machine The name of the machine is "Hydraulic block cutter". 1.2. Warning Read this user manual carefully before use and before maintenance of the machine is carried out.

  • Page 6: Symbols

    1.5. Re-ordering the user manual Extra copies of the user manual can be ordered from Probst . When ordering, indicate the document number and the number of copies. The document number is indicated in the footer area. 1.6.

  • Page 7: Introduction

    Maintenance of the machine may only be carried out by specially trained personnel from the maintenance department. The maintainer must read the chapters indicated in 1.3 carefully. 2.2. The manufacturer The manufacturer of the machine is: Probst GmbH Gottlieb-Daimler-Straße 6 71729 Erdmannhausen, Germany info@probst-handling.de www.probst-handling.de 2.3.

  • Page 8: Function Of The Machine

    Inhalt 7 / 21 Probst GmbH Pump specifications Type: AL43SH21 Voltage: Year of 2016 manufacture: Serial no.: listed on the side Weight 125 kg plate behind hydraulic hose Figure 2.3-1: Sample type plate with CE-mark For the location of the attached CE-mark and type plate, see Figure 2.3-2.
  • Page 9 Inhalt 8 / 21 Figure 2-4.1: Maximum roughness stone. Figure 2.4-2: Forbidden stone. Figure 2.4-1: Blade types for different types of stone slabs...

  • Page 10: Machine Options

    For service contact your dealer or your own maintenance department. 2.8. Warranty conditions If within 6 months of delivery Probst GmbH is notified of deficiencies in the delivered art. 1 machine that are caused by defects in materials or workmanship and is provided with the serial number and the original receipt, Probst will repair these defects.

  • Page 11: Safety Regulations

    Inhalt 10 / 21 Safety regulations This chapter provides information concerning the general safety regulations. This chapter is intended for the owner, the operator and the maintainer of the machine. Read this chapter carefully before use of the machine and before carrying out repairs on the machine. 3.1.

  • Page 12: General Safety Regulations

    Inhalt 11 / 21 Sticker 2: Use eye and hearing protection Sticker 3: Read the user manual first Sticker 4: Only transport the machine in the upright position Sticker 2, 3 and 4 Sticker on front and backside Figure 3.2-1: Warning symbols on the machine General safety regulations Although the machine satisfies the fundamental health and safety requirements of the...

  • Page 13: The Operator

    Inhalt 12 / 21 Follow the warnings and indications on the machine. For the explanation of the symbols, see section 3.2. Always think of the safety of yourself and others! 3.3. operator The machine may only be operated by personnel who are qualified to do so. Personnel that have this qualification are referred to in the rest of this user manual as the operator.

  • Page 14: Description

    Inhalt 13 / 21 As maintainer of the machine, you must be aware of the information that is relevant for you in these operation and maintenance regulations. Refer to section 1.3 “Target group for each chapter”. Always remain alert for possible dangerous situations. Be careful of projecting portions of the machine.

  • Page 15: Construction Of The Machine

    Inhalt 14 / 21 4.2. Construction of the machine The machine consists primarily of the components shown in Figure 4.2-1 Adjustment handle, upper blade Lifting eye Upper blade Hydraulic block Lower blade Handles for placement of Battery cabinet machine Key switch and Push button, cutting Plug connection for Hydraulic unit housing...

  • Page 16: Operation

    Inhalt 15 / 21 4.6. Operation By turning the handle on the top of the machine, the distance between the upper and lower blades can be adjusted. The parallelism of the blades is always guaranteed because the spindles on both sides of the blades are linked by a chain drive.

  • Page 17: Technical Data

    M319-03-12V-6660-N/O Castrol Carelube SES 32 Synthetic Bio Degradable Battery VMF battery 12-volt (maintenance-free) Battery charger F15EBS 12A Electronic Connection voltage AL-43/SH-21 bzw. 230 V/60Hz AL-43/SH-21-V Connection voltage AL-43/SH-21-110 bzw. 110 V/60Hz AL-43/SH-21-V-110 Scope of delivery, transport, storage, placement and initial setup This chapter provides information about the scope of delivery, transport, storage, placement and initial setup of the machine.

  • Page 18: Placement Of The Machine

    Inhalt 17 / 21 Make sure that the machine is horizontal and stable during storage. Prevent tilting. If the cutter is tilted, oil may leak from the vent hole. 5.3. Placement of the machine Make sure that the machine is horizontal and stable during use. Prevent tilting. Lock the swivel casters.

  • Page 19: Shut Down

    Inhalt 18 / 21 Slide the stone into position, approximately in the middle of the blade. See also the pictogram shown on the machine. Figure 6.3-1: Pictogram "placing the stone in the middle of the blade" Push the push button to move the upper blade downward. BE CAREFUL! Keep body parts out of the area between the stone and the blade! When the push button is released, the upper blade returns to its original position.

  • Page 20: Replacement Of Components

    Inhalt 19 / 21 If desired, the plug connection between the battery and the hydraulic unit can be disconnected and the entire battery cabinet can be removed to simplify charging. For the location of the plug, see Figure 4.2-1 check oil level in the oil reservoir of the hydraulic Monthly unit The oil level must be between 2 and 3 cm under...
  • Page 21 Inhalt 20 / 21 8.1. General information for trouble When trouble occurs, switch off the machine and contact your dealer or your own maintenance department. Comply with the instructions in chapter 3 and the maintenance instructions in chapter 3. 8.2. Trouble indications and signals The machine controls do not include trouble indications or other signals.
  • Page 22 Address: Probst GmbH; Gottlieb-Daimler-Straße 6; 71729 Erdmannhausen, Germany Authorized person for UK-documentation: Name: Nigel Hughes Address: Probst Ltd ; Unit 2 Fletcher House; Stafford Park 17; Telford Shropshire TF3 3DG, United Kingdom Signature, information to the subscriber: Erdmannhausen, 02.08.2021................(Eric Wilhelm, Managing director)
  • Page 23 Algemene toleranties volgens ISO 2768-2 TOL. GEBIED : MATERIAAL : BEHANDELING : Vormtoleranties volgens ISO 2768-1 TOL. GEBIED : BENAMING : MASSA (kg): AL-43/SH-21 51200038 AANTAL : GET. : DATUM : 4-10-2010 SCHAAL : MAATEENHEID : MM Blad FORMAAT : TEKENING NR.
  • Page 24 Algemene toleranties volgens ISO 2768-2 TOL. GEBIED : MATERIAAL : BEHANDELING : Vormtoleranties volgens ISO 2768-1 TOL. GEBIED : BENAMING : MASSA (kg): AL-43/SH-21 51200038 AANTAL : REVISIE TABEL GET. : DATUM : 16-10-2009 SCHAAL : 1:7 MAATEENHEID : MM Blad REV.
  • Page 25 Opmerking TOLERANTIE : Algemene toleranties volgens ISO 2768-2 TOL. GEBIED : MATERIAAL : BEHANDELING : Vormtoleranties volgens ISO 2768-1 TOL. GEBIED : MASSA (kg): AL-43/SH-21 51200038 AANTAL : GET. : DATUM : 4-10-2010 SCHAAL : 1:4 MAATEENHEID : MM Blad FORMAAT : TEKENING NR.
  • Page 26 After each completed performance of a maintenance interval the included form must be fill out, stamped, signed and send back to us immediately 1) via e-mail to service@probst-handling.de / via fax or post Operator: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
  • Page 27 After each completed performance of a maintenance interval the included form must be fill out, stamped, signed and send back to us immediately 1) via e-mail to service@probst-handling.de / via fax or post Operator: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
  • Page 28 After each completed performance of a maintenance interval the included form must be fill out, stamped, signed and send back to us immediately 1) via e-mail to service@probst-handling.de / via fax or post Operator: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...

This manual is also suitable for:

Al-43/sh-21-110Al-43/sh-21-vAl-43/sh-21-v-110Al-43/sh-21-h-v5120003851200057 ... Show all
