- Page 19 Model Number: OC-1230P Fanless 12Volt 30Amp Switched-Mode Microprocessor Controlled Programmable Automatic Battery Charger and Power Supply AS/NZS 60335.2.29 (21.102) compliant You are now the owner of one of the most advanced, reliable and feature packed chargers available today. Please take the time to read and understand this manual, even though it may have already been installed for you.
- Page 20 Installation and User’s Manual. FEATURES Congratulations on purchasing an OzCharge fully automatic switched-mode battery charger. OzCharge battery chargers comprise of the latest technology and incorporate the following features: High efficiency, high frequency Switched Mode with pulse charge output Microprocessor controlled ...
-
Page 21: Control And Indicators
CONTROL AND INDICATORS 1. LCD. Shows software version when first connected. Constantly shows the battery voltage or charging amps current depending on the Amp/Volt button (see point 7 below) when AC mains is applied. Display and backlight automatically extinguishes when there is no AC mains present after one minute. -
Page 22: Installation
INSTALLATION This product is designed to be installed in a secure, hardwired situation only. Because this charger has no fan it is ideal to mount it in an upright position to take advantage of convection cooling. Nothing should located be within 100mm (4 inches) of the main charger unit to ensure natural cooling takes place. -
Page 23: Dip Switch Programming
DIP SWITCH PROGRAMMING The default out-of the-box factory setting will probably suit most new installations which are; Absorbed Glass Mat (AGM) battery type Charge Voltage: 14.5V Float Voltage: 13.7V DIP switch: 1 = Off, 2 = Off, 3 = On, 4 = Off, 5 = On, 6 = Off, 7 = On, 8 = On. If your battery type is different, or you have replaced the battery these are the available adjustments;... - Page 24 RECOMMENDED BATTERY CAPACITY & CHARGE CURRENT This product is designed to be installed in a hardwired situation therefore the battery capacity will normally be a fixed size and determined by the vehicle manufacturer. If the battery was supplied and installed in a caravan or RV, ask the manufacturer what make and model they have supplied as the battery is often out of sight and/or in a protective box.
-
Page 25: The Charging Process
OPERATING INSTRUCTIONS This OzCharge battery charger has been designed to be easy to operate and very simple to use. Please refer to the operating instructions below. 1. Pre-Charge Check (a) Check the Battery Electrolyte level (Non-sealed Batteries). If necessary, remove the vent caps and add distilled water so the levels are halfway between the upper and lower fill lines. - Page 26 Absorption This stage charges the battery using a constant voltage to get the battery state of charge over 85%. The charging voltage for this stage is determined by the Battery Type selection DIP switch (located on the bottom of the charger) (Indicated by the blue Absorption LED on solid) Equalising This is an automatic stage when the battery type is programmed for Calcium only.
-
Page 27: Charging Stages
CHARGING STAGES Note: The Charger automatically switches off after 24 hours if the Bulk charge cycle is not completed. CHARGER SPECIFICATIONS Input: 220~260Vac; 50Hz; Battery is not less than 3.0V (unit will start-up in ‘Power Supply’ mode if lower than 3.0V) Charging starting conditions: Rated output: 13.8Volts at 30Amps DC... - Page 28 It is recommended that returned products be sent by registered mail as Zylux Distribution Pty Ltd. (OzCharge) accepts no responsibility / liability for goods lost or damaged in transit.
