Page 1 OPERATING & MAINTENANCE MANUAL EXSM 230 C and 350 C Clarus Control 438 9030-08/01 02.32 WARNING: ALL OPERATING AND MAINTENANCE PROCEDURES SHOWN ON THE NEXT PAGE OF THIS MANUAL MUST BE FOLLOWED DAILY FOR PROPER OPERATION OF YOUR WASCOMAT MACHINE.
Page 2 Be sure to keep the machine(s) in proper working order: Follow all maintenance and safety procedures. Further information regarding machine safety, service and parts can be obtained from your dealer or from Wascomat through its Teletech Service Telephone - 516/ 371-0700.
Page 3 Be certain to relock after remounting the top panel. MANUFACTURED BY WASCATOR DISTRIBUTED BY WASCOMAT, INWOOD, NEW YORK, USA 471 766202-04 LOCATED ON THE DOOR: If you need to order more safety or warning signs, call Wascomat's parts department at 516-371-2000, or call your local dealer.
Page 5: Table Of Contents
EXSM 230 C and 350 C Contents Introduction ....................7 Technical data ....................8 Installation ....................11 Function control and safety checklist ............22 Safety rules ....................24 Mechanical and electrical design ............... 25 Procedure for use ..................51 Fault-finding ..................... 102 Maintenance .....................
Page 7: Introduction
Introduction Introduction The EXSM-C model solid mounted washer/extractor has been developed to Fig. cover the heavy duty requirements of hotels, motels, nursing homes, hospitals, professional laundries, restaurants, airlines, ships, schools, colleges and all on-premises laundries where flexibility and quick formula variation, coupled with high quality automatic washing, are required.
Page 8: Technical Data
Technical data EXSM 230 C Dry load capacity up to 65 lbs Overall dimensions Width 935 mm Depth 870 mm (at the top) Height 1430 mm Net weight 365 kg 805 lbs Max. floor load at extraction 5,0±11.5 kN 1200±2760 lbs.force...
Page 9 Technical data EXSM 350 C Dry load capacity up to 80 lbs Overall dimensions Width 1085 mm Depth 1095 mm (at the top) Height 1540 mm Net weight 545 kg 1200 lbs Max. floor load at extraction 6.5±14 kN 1560±3147 lbs.force Frequency (dynamic force) 10,8 Hz Crated Dimensions...
Page 10 Technical data Outline and dimensions 4897 1. Electrical cable connection EXSM 230 C EXSM 350 C 2. Steam connection (option) 3. Drain connection inches inches 4. Hot water connection 5. Hot water connection 36 13/16 1085 42 11/16 6. Cold water connection 7.
Page 11: Installation
Installation Installation Machine foundation The machines are designed to be bolted in position to a concrete floor or specially prepared concrete foundation. A template showing the size of the foundation and positioning of the foundation bolts is available. For installation on an existing concrete floor, the floor must be at least 8'' thick and of good quality.
Page 12 Installation EXSM 230 C Measurements for foundation in inches and (mm). Fig. A 39 (990) I 6 5/8 (168) B 37 (940) K 4 29/32 (125) C 36 3/8 (925) L 31 1/2 (800) D 33 7/8 (860) M 32 1/2 (825)
Page 13 Installation EXSM 350 C Measurements for foundation in inches and (mm). Fig. A 42 29/32" (1090) H 3" (77) B 43 15/64" (1100) K 36 13/16" (935) C 3" (75) L 37 1/64" (940) D 3 15/16" (100) M 41 9/16" (1056) E 15 23/64"...
Page 14 See illustration below. 1757 • Tighten the nuts in sequence as shown. Fig. • Check and tighten the nuts every week for the first month. EXSM 230 C 1758 2408 EXSM 350 C 1759 2399...
Page 15 Installation Electrical installation Although the machines are fitted with a thermal overload in the motor windings and fuses for the control circuit, a separate circuit breaker must be installed for each machine. For proper overcurrent protection, check the data plate at the rear of the machine. Also consult local electrical code for special requirements.
Page 16 Installation Connection of external units (optional equipment) 1 2 3 4 1 2 3 4 1 2 Electrical installation must be carried out by an authorized personnel! 1 2 3 4 1 2 1 2 3 4 X149-1 X148-1 X146-1 471 76 97 01 1 2 3 4 1 2 3 4...
Page 17 Installation Water connections All plumbing must conform to national and local plumbing codes. 4705 All intake connections to the machine are to be fitted with manual shut-off valves and filters, to facilitate installation and servicing. In certain cases non-return valves will need to be fitted before the machine to comply with local plumbing regulations.
Page 18 Installation Drain connection Connect a 3'' (75 mm) flexible hose to the drain Fig. outlet of the machine. The drain hose must not have any sharp bends and must slope from the machine to assure proper drainage. The outlet must open freely to the main drains.
Page 19 Installation Steam connection (optional steam heating) The steam inlet pipe must be fitted with a manual Fig. cut-off valve in order to facilitate installation and service operations. Attach the filter supplied with the machine to the manual cut-off valve. Conncection hoses should be of the quality required according to regulations in the country of use.
Page 20 Installation Installing top-mount manifold for connection of liquid supplies Remove the cover and cover support over the soap box. If comp 3 has a metal plate at the rear, bend it all the way as shown. Pull the manifold knobs up and forward. Fig.
Page 21 Installation 1. Drop the knob into the larger opening in the Fig. supply manifold lid. 2. Tighten securely. Do not overtighten! Do not use pliers or other tools to tighten the knobs! Fig. 1. Select the correct size rubber ring which will fit snugly on the chemical tube you are using.
Page 22: Function Control And Safety Checklist
The warranty card should be completed and sent to Wascomat. All other items should be placed in a safe place for future reference. The machine should be cleaned when the...
Page 23 If no problems were encountered, the machine is ready for use. All machines are factory tested prior to shipment. Occasionally, some residual water may be found when the machine is installed. Before servicing Wascomat equipment, disconnect electrical power.
Page 24: Safety Rules
Safety rules Safety rules • This machine is designed for water washing only. • All installation operations are to be carried out by qualified personnel. Licensed personnel are necessary for all electric power wiring. • The interlock of the door must be checked daily for proper operation and must not be bypassed.
Page 25: Mechanical And Electrical Design
Mechanical and electrical design General The door and the electronic timer with display and keyboard are fitted at the front of the machine. All control and indicating components, i.e. relays, delay unit, etc are assembled under the top cover, easily accessible from the top of the machine for simplified servicing.
Page 26 Mechanical and electrical design Machine construction Panels The machines are equipped with a top panel and front panel made of stainless steel. The coloured panels are made of phosphatized steel plate. For servicing purposes, the panels can easily be removed. Outer shell The outer shell is made of heavy gauge surgical steel and is attached to a Fig.
Page 27 The extension of the bearing trunnion housing supports the rear bearing holding the shaft. A grease seal is mounted to prevent escape of grease. The bearings are permanently lubricated and need no maintenance. EXSM 230 C 5014 EXSM 350 C...
Page 28 Mechanical and electrical design Description The machine door lock consists of the following: Fig. • The locking unit, located behind the front panel below the detergent dispenser. The unit consists of a solenoid which locks the door, and two microswitches. Switch S4A indicates that the door is locked and switch S3 indicates that the door is closed.
Page 29 Mechanical and electrical design Door lock control unit The sole function of this control unit is to oversee the correct functioning of Fig. the door lock. The CPU board receives information from the motor control unit about motor rotation, and has its own level-monitoring device. The control unit also detects water level and motor speed through separate level measurement devices and the rotation guard (speed-monitoring device).
Page 30 Mechanical and electrical design Error indication patterns Fig. If the door lock is working correctly, this is indicated by the red LED, by a pattern of flashes which indicates “OK”. The error indication patterns revealed by the LED flash at various frequencies for the various errors or faults.
Page 31 Mechanical and electrical design 4942 Fig. Motor control unit, microprocessor-controlled. Controls direction of rotation and speed of motor. The MCU is also used for imbalance detection and calculating weight of wash load. Emergency stop switch...
Page 32 Mechanical and electrical design Control unit X300 X105 A200-1 X145 X202 X144 X147 X149 X100 X146 101635 A3-A5 I/O boards 1-3 Fig. A200-1 CPU board Level sensing device, door opening Transformer, power supply to circuit boards Rotation-monitoring device Suppression filter Connectors X144 9-pole, recycling, I/O board 2...
Page 33 Mechanical and electrical design Supply unit F21 F12 X149-1 X148-1 1 2 3 4 1 2 3 4 1 2 X146-1 1 2 3 4 1 2 1 2 3 4 X149-1 X148-1 X146-1 471 76 97 01 1 2 3 4 1 2 3 4 5 6 7 8 9 11 12...
Page 34 Mechanical and electrical design Motor In machines with frequency control the same Fig. motor is used for wash speed, distribution speed and extraction. The motor is located on a motor mounting plate, and drives the drum via a belt. The tension of this drive belt can be altered by moving the entire motor thanks to the mounting slots on one side.
Page 35 Mechanical and electrical design Repair instructions Overheated motor, motor not running • Wait till motor has cooled down. Motor guards are automatically reset after 30 minutes. Restart. • Possible cause of motor guards releasing repeatedly: short circuiting. Very noisy motor •...
Page 36 Mechanical and electrical design Motor control unit E10 X312 X301 X302 X304 X308 X311 4744 Suppression filter Fig. Connectors X301 Serial communication with CPU X302 Input, lock sequence X304 Relay output X308 Imbalance input X311 Main input X312 Connection, motor and thermal protection device (Klixon)
Page 37 Mechanical and electrical design Motor control unit The motor control unit communicates with the CPU board via a serial Fig. duplex interface. With the aid of the MCU, the CPU board can not only control the speed the motor is to have at any given moment, but also control Fig.
Page 38 Mechanical and electrical design There is a cooling fan on the MCU. The fan starts up automatically when the heat sink reaches a temperature of approx. 65°C, which can arise during extraction if the load is unfavourable or if the ambient temperature is high.
Page 39 Mechanical and electrical design X311: Main input Input voltage: Single-phase or DC three-phase: 200 V-15%(=170 V) - 240 V+10% (264 V) X312: Output to motor and input thermal protection device (Klixon) The output is connected to a thermal protection device, located on the motor windings, with a connection back to the input.
Page 40 Mechanical and electrical design Error indication patterns If a fault or error occurs in the motor or motor control unit, the MCU sends Fig. an error signal to the CPU board. In addition to an error code showing on the display, errors/faults are revealed by the flashing of a yellow LED on the Fig.
Page 41 Mechanical and electrical design Fault-finding There are fault-finding charts for all error codes in Chapter 12, “Fault- finding”. X312 X313 In 170 and 220 l machines only X301 X302 X311 X308 X304 Yellow LED Green LED 4708 Error indication patterns, green LED The green LED on the MCU board is normally lit except for a brief pause Fig.
Page 42 Mechanical and electrical design Extraction Fig. During extraction, the motor speeds follow an extraction sequence which is always the same. This extraction sequence is used for all standard programs 991-999 for CLARUS machines. The table shows the extraction speeds during the various phases of the sequence, for various drum volumes.
Page 43 Mechanical and electrical design Imbalance measurement At the start of every extraction sequence the system monitors variations in the motor torque while the drum is operating at distribution speed. If these variations are too great, it indicates that the load is unevenly distributed in the drum.
Page 44 Mechanical and electrical design Supply injection valve Construction The valve has a single-inlet with either one, two Fig. or three outlets, each with its own solenoid coil. The body is made of heat-resistant polyamid plastic and the solenoids encased in water-tight plastic.
Page 45 Mechanical and electrical design Repair instructions Limescale can block the hole in the valve diaphragm and interfere with the function of the valve. It is therefore advisable to dismantle and clean Fig. the valve at certain regular intervals. The frequency depends on operating conditions and the level of contamination in the water.
Page 46 Mechanical and electrical design Inlet valve The water inlets have brass bodies with larger Fig. cross section of the outlet in order to achieve a shorter filling time for the machine. Construction Fig. The valve housing is made of pressed brass. The spring-loaded plunger is made of stainless steel and located at its lower end.
Page 47 Mechanical and electrical design Description The drain valve is a motor-operated diaphragm Fig. valve which allows rapid emptying thanks to its large cross-section. This is a self-clearing design, Fig. so there is no need for a lint filter. Main parts of the valve: •...
Page 48 Mechanical and electrical design When the motor is activated and begins to rotate, the piston rod is turned upwards via the gear, the diaphragm is pressed upwards with the piston and presses against the valve seat: the valve closes. The connection for overfilling is connected to the upper part of the wash drum, water and foam are diverted straight to the drain if the intake valves or level control should malfunction.
Page 49 Mechanical and electrical design Tensioning of return spring With the valve housing removed: - Turn the return spring so that the “tongue” of the spring is resting against the stop screw. - Position the valve housing over the return spring so that the pin on the spring will fit into the recess on the piston rod.
Page 50 Mechanical and electrical design Soap supply box The three-compartment soap supply box is located at the top of the machine. Fig. Viewed from the front, the compartments marked with figures 1, 2 and 3 are used as follows: Compartment 1 This compartment is used for adding detergent directly to the wash at the beginning of a cycle or at any time during the cycle when extra supplies are required.
Page 51: Procedure For Use
Procedure for use Here you can see how the machine can be controlled when a wash program is not This is your starting running point when you wish to run a wash program If you are not sure of which program can be performed while a program is running Preparations...
Page 52 Procedure for use General introduction This washer extractor is controlled by a microprocessor-based program Fig. control unit. There are many advantages to this equipment, including: • timing, levels and temperatures are controlled with great precision and flexibility • detailed information on wash programs, machine status and operations, wash times and temperatures can be accessed in plain language on the large display screen •...
Page 53 Procedure for use Preparations • Sort the load, paying attention to the textile care labels on the items. Empty all pockets and do up zip fasteners. • Open the machine door, check that the drum is empty, load the items into the machine and close the door.
Page 54 Procedure for use The ”Move back” key The "Move back" function If you find you are in the Each press of the ”Move back” key moves you back wrong place, or if you want to one menu, in reverse order. By pressing this key undo earlier key presses: repeatedly you can return to this menu at any time: 3627...
Page 55 Procedure for use Here you can select programs from the program libraries. RUN A WASH PROGRAM See the section entitled ”To ENTER A PROGRAM NUMBER: start a wash program from the program library”. Displayed here will be the SELECT FROM LIBRARY number of the most frequently PCS SMC If you have entered the wrong number...
Page 56 Procedure for use RUN A WASH PROGRAM ENTER A PROGRAM NUMBER: Delayed start time (hrs:mins) 00:00 Program name NORMAL 95°C STD TEXT START Pressing ”Text” displays more information If you want to see the 3582 The text displayed is a description of the wash description of the program: TEXT program selected.
Page 57 Procedure for use To terminate a program before it has finished The following information is displayed during the wash • Select RAPID ADVANCE and press SELECT. program: Advance to ”END OF PROGRAM” and press SELECT. Current program step • Wait until ”THE DOOR IS OPEN” appears on the Time left for this program display.
Page 58 Procedure for use To start a wash program from the program library What is the program library? The program library lists all wash programs, both If this menu is not currently RUN A WASH PROGRAM user and standard programs, showing their GO TO THE MENU displayed: program numbers and a description, for example:...
Page 59 Procedure for use RUN A WASH PROGRAM ENTER A PROGRAM NUMBER: Select library via menu You can also select the program library via the option ”GO TO THE MENU”. Then select ”WASH FROM PCS OR SMC? To select a program from the PROGRAM LIBRARY”.
Page 60 Procedure for use RUN A WASH PROGRAM ENTER A PROGRAM NUMBER: Delayed start time (hrs:mins) 00:00 Program name NORMAL 95°C STD TEXT START Pressing ”Text” displays more information If you want to see the 3582 description of the program: The text displayed is a description of the wash TEXT program selected.
Page 61 Procedure for use To change parameters in the current program step 991 NORMAL 95°C STD You can alter the following program steps: During program operation the PROGRAM STEP: MAIN WASH display will look like this (see STEP TIME: 720 SEC Prewash, Main wash, Rinse, Drain, Soak 85 °C SET TEMPERATURE:...
Page 62 Procedure for use Rapid advance To terminate a program before it has finished • Select RAPID ADVANCE and press SELECT. Advance to ”END OF PROGRAM” and press During program operation 991 NORMAL 95°C STD SELECT. PROGRAM STEP: MAIN WASH the display will look like this STEP TIME: 720 SEC •...
Page 63 Procedure for use 991 NORMAL 95°C STD RAPID ADVANCE Rapid advance works in both directions PREWASH Rapid advance works in both directions, using b EXTRACT MAIN WASH EXTRACT and c. RINSE SELECT Using rapid advance to move forwards allows you to skip one or more program steps.
Page 64 Procedure for use For machines with weighing equipment installed only! Show weight Show weight During program operation 991 NORMAL 95°C STD The actual weight is shown in large digits on the display PROGRAM STEP: MAIN WASH the display will look like (weight display mode).
Page 65 Procedure for use For machines with weighing equipment installed only! No water reduction No water reduction 991 NORMAL 95°C STD During program operation The wash load is weighed during the program and the PROGRAM STEP: MAIN WASH the display will look like water level is adjusted automatically according to its STEP TIME: 720 SEC...
Page 66 Procedure for use Pause Two ways of pausing during a wash program Note that you must be in normal wash mode to be 991 NORMAL 95°C STD During program operation the able to pause in this way. If, for example, you are PROGRAM STEP: MAIN WASH STEP TIME:...
Page 67 Procedure for use Manual operation during a program Two types of manual operation 991 NORMAL 95°C STD There are two types of manual operation, which During program operation the PROGRAM STEP: MAIN WASH should not be confused: display will look like this (see STEP TIME: 720 SEC SET TEMPERATURE...
Page 68 Procedure for use Automatic return to normal display MANUAL FUNCTIONS MAKE A CHOICE: Once you have selected any of the functions below, WATER/DRAIN you must make any changes required within 20 HIGH EXTRACT MOTOR seconds. If no further keys are pressed within 20 DETERGENT/FLUSH EXIT seconds, the display will revert automatically to its...
Page 69 Procedure for use Water/drain To access this function, see MANUAL FUNCTIONS WATER/DRAIN instructions in section COLD WATER "Manual operation". MIXED WATER HOT WATER COLD HARD WATER WATER FROM TANK 1 WATER FROM TANK 2 LEVEL: 63 UNITS Water level in drum OPEN 3680 Use b and c to select...
Page 70 Procedure for use To limit the program’s highest extraction speed Maximum extraction speed This function allows you to modify the highest To access this function, see extraction speed allowed during the program. MANUAL FUNCTIONS instructions in section HIGH EXTRACT Example: "Manual operation".
Page 71 Procedure for use Motor on after wash Motor to rotate after program has ended MANUAL FUNCTIONS To access this function, see If you answer Yes (Y): MOTOR instructions in section The motor will continue to rotate in alternative MOTOR ON AFTER WASH "Manual mode".
Page 72 Procedure for use Detergent signals and water flushing To access this function, see MANUAL FUNCTIONS DETERGENT/FLUSH instructions in section WATER FLUSH "Manual mode". FLUSH COLD POWDER POWDER SIGNAL 1 POWDER SIGNAL 2 POWDER SIGNAL 3 POWDER SIGNAL 4 OPEN 3684 Detergent signals and water flushing Use b and c to select FLUSH WATER:...
Page 73 Procedure for use Text Pressing ”Text” displays more information The text displayed is a description of the wash 991 NORMAL 95°C STD During program operation program selected. This text description is inserted PROGRAM STEP: MAIN WASH the display will look like this STEP TIME: 720 SEC when a new wash program is created.
Page 74 Procedure for use To change the wash program after program operation has commenced During program operation the 991 NORMAL 95°C STD To change the wash program after program PROGRAM STEP: MAIN WASH display will look like this (see STEP TIME: 720 SEC operation has commenced 85 °C...
Page 75 Procedure for use ° ° To change temperature scale ° ° To change temperature scale 991 NORMAL 95°C STD During program operation the This function changes the temperature scale used PROGRAM STEP: MAIN WASH display will look like this (see for all temperatures displayed during the wash STEP TIME: 720 SEC...
Page 76 Procedure for use Auto restart What is Auto restart? Auto restart means that the same program will be 991 NORMAL 95°C STD PROGRAM STEP: MAIN WASH repeated one or more times, according to the STEP TIME: 720 SEC 85 °C SET TEMPERATURE number set.
Page 77 Procedure for use Manual operation Two types of manual operation There are two types of manual operation, which To select manual operation should not be confused: • Manual operation when no program is If this menu is not currently running displayed: These functions are described in this section.
Page 78 Procedure for use MANUAL FUNCTIONS MAKE A CHOICE: MOTOR/DOOR WATER/DRAIN HEATING DETERGENT/FLUSH EXIT Manual operation when no program is running SELECT Motor/door (see section "Motor/door") 3686 Lock/unlock door. Switch motor on/off (normal drum action). MOTOR/DOOR WATER/DRAIN Water and drain valves (see section "Water/ drain") HEATING Operation of drain valve and all water valves.
Page 79 Procedure for use Water/drain MANUAL FUNCTIONS To access this function, see WATER/DRAIN DRAIN CLOSED instructions in section "To COLD WATER MIXED WATER select manual operation". HOT WATER COLD HARD WATER WATER FROM TANK 1 WATER FROM TANK 2 LEVEL: 0 UNITS 3688 Use b or c to select Drain or one of the six...
Page 80 Procedure for use Heating To access this function, see instructions in section "To MANUAL FUNCTIONS select manual operation". HEATING SELECT SET TEMPERATURE Temperature 0° C selected ACTUAL TEMPERATURE 24° C Actual temperature START 3689 Use the numeric keys to enter the temperature the water is to be heated to.
Page 81 Procedure for use Detergent signals and water flushing MANUAL FUNCTIONS To access this function, see DETERGENT/FLUSH instructions in section "To WATER FLUSH FLUSH COLD POWDER POWDER SIGNAL 1 select manual operation". POWDER SIGNAL 2 POWDER SIGNAL 3 POWDER SIGNAL 4 OPEN 3684 Detergent signals and water flushing...
Page 82 Procedure for use Statistics To select Statistics If this menu is not currently displayed: RUN A WASH PROGRAM Press a repeatedly. GO TO THE MENU MAKE YOUR CHOICE WITH AND PRESS SELECT WEIGHT, KG: 000,0 SELECT 3589 Press b to highlight ”GO TO THE MENU”.
Page 83 Procedure for use The Statistics function The Statistics function gives you access to the following information: STATISTICS TOTAL RUN TIME HOURS: TOTAL RUN TIME HOURS TOTAL TRIP RUN TIME HOURS HOURS SINCE LAST SERVICE Shows the total operating time for the machine LAST 5 ERROR CODES PROGRAM HOURS...
Page 84 Procedure for use Resetting statistic registers Statistics registers which can be reset to zero If this menu is not currently The following registers in the statistics function can displayed: be cleared (reset to zero): RUN A WASH PROGRAM Press a repeatedly. GO TO THE MENU •...
Page 85 Procedure for use MENU MAKE A CHOICE: WASH PROGRAM LIBRARY PROGRAMMING MODE SETTINGS 1 The service program may only be used MEMORY CARD SERVICE MODE STATISTICS by authorised personnel, because all SELECT safety interlocks are disabled when it 3693 is in use. Press b..four times..
Page 86 Procedure for use Time counter, hours after last service Both counters can be reset in SERVICE MODE MAKE A CHOICE: the same way. SERVICE PROGRAM CLEAR TRIP HOUR COUNTER CLEAR SERVICE COUNTER CLEAR WASH PROGRAM COUNTER IN PCS CLEAR WASH PROGRAM COUNTER IN SMC EXIT SELECT Press b so that CLEAR...
Page 87 Procedure for use Number of washes for program in timer or memory card SERVICE MODE You can reset program in MAKE A CHOICE: both timer and the memory SERVICE PROGRAM card (if inserted). CLEAR TRIP HOUR COUNTER CLEAR SERVICE COUNTER CLEAR WASH PROGRAM COUNTER IN PCS CLEAR WASH PROGRAM COUNTER IN SMC EXIT...
Page 88 Procedure for use CLEAR COUNTER FROM PROGRAM NUMBER: TO PROGRAM NUMBER: TO END: TO PROGRAM NUMBER = 0 EXIT 4046 Enter digits corresponding to the program number (inclusive) up to which you wish to clear the total counter. Press ERASE. ERASE CLEAR COUNTER First you have the chance to...
Page 89 Procedure for use Memory card General introduction A memory card is a plastic card, the size of a credit card, with an electronic memory chip inside it. This memory card is capable of storing 10 to 15 wash programs of normal size. If the programs are mostly small ones, more of them can be stored, whereas larger programs will reduce the number which can be held by the memory card.
Page 90 Procedure for use To select the ”Memory card” function Memory Turn the memory card so chip its memory chip is at the far end, and on the left of the card... 3606 Card reader ...then insert the memory card into the program control unit.
Page 91 Procedure for use MENU MAKE A CHOICE: WASH PROGRAM LIBRARY PROGRAMMING MODE SETTINGS 1 MEMORY CARD Press b three times... SERVICE MODE STATISTICS SELECT 3596 ...to highlight ”MEMORY CARD”. WASH PROGRAM LIBRARY PROGRAMMING MODE SETTINGS 1 MEMORY CARD SERVICE MODE STATISTICS MANUAL MODE SETTINGS 2...
Page 92 Procedure for use "The ”Memory card” functions MEMORY CARD Run wash program straight from memory card (see section "To run a wash program straight EXECUTE WASH PROGRAM FROM MEMORY CARD from a memory card") COPY PROGRAM FROM MEMORY CARD TO PCS COPY PROGRAM FROM PCS TO MEMORY CARD A wash program can be run from the memory DELETE PROGRAM IN MEMORY CARD...
Page 93 Procedure for use To run a wash program straight from a memory card To run a program from the memory card MEMORY CARD To access this menu, follow In broad terms, the program control unit has two the instructions in section "To different memories.
Page 94 Procedure for use To copy a program from a memory card to the machine’s program control unit What is a restricted-use program? To access this menu, follow MEMORY CARD A wash program which has been created on a PC the instructions in section "To can be made a ”restricted-use”...
Page 95 Procedure for use MEMORY CARD Choose 1 or 2: COPY PROGRAM FROM MEMORY CARD TO PCS 1 If you want to give the NOW YOU CAN CHANGE NUMBER. program a different JUST PRESS SELECT IF NUMBER IS OK program number (from the one it had on the memory SELECT card):...
Page 96 Procedure for use MEMORY CARD After the program has been copied (it takes only a few COPY PROGRAM FROM MEMORY CARD TO PCS seconds) the menu will look PROGRAM LOADED like this: PRESS ANY KEY TO CONTINUE... If you want to copy more programs: Press any key to continue.
Page 97 Procedure for use To copy a program from the program control unit to a memory card What happens when a program is copied? MEMORY CARD To access this menu, follow Both the memory card and the program control unit the instructions in section have memory chips capable of storing wash EXECUTE WASHPROGRAM FROM MEMORY CARD "To select the "Memory card"...
Page 98 Procedure for use MEMORY CARD COPY PROGRAM FROM PCS TO MEMORY CARD Choose 1 or 2: 1 If you want to give the NOW YOU CAN CHANGE NUMBER. program a different JUST PRESS SELECT IF NUMBER IS OK program number (from the one it had on the SELECT machine):...
Page 99 Procedure for use After the program has been MEMORY CARD copied (it takes only a few COPY PROGRAM FROM MEMORY CARD TO PCS seconds) the menu will look PROGRAM LOADED like this: PRESS ANY KEY TO CONTINUE... If you want to copy more programs: Press any key to continue.
Page 100 Procedure for use To delete a program on a memory card What is a restricted-use program? To access this menu, follow A wash program which has been created on a PC MEMORY CARD the instructions in section "To can be made a ”restricted-use” program. This means select the "Memory card"...
Page 101 Procedure for use To delete all programs on a memory card What is a restricted-use program? MEMORY CARD A wash program which has been created on a PC To access this menu, follow can be made a ”restricted-use” program. This means the instructions in section "To EXECUTE WASH PROGRAM FROM MEMORY CARD that:...
Page 102: Fault-Finding
Fault-finding Error code, error message Fault-finding Cause/Action Check that the manual water valves (taps) are open. 01, NO WATER Water level has not reached set Taps turned on. Taps turned off. level with 10 minutes. Open taps. Restart program. Check that there is a water Red LED (voltage) option (function) in the pro- gram.
Page 103 Fault-finding Error code, error message Fault-finding Cause/Action 01, NO WATER Continued from previous page. Close the drain valve via the service program and Connection, level tube check that it really is closed, i.e. that water level is rising in drum. Drain valve closed.
Page 104 Fault-finding Error code, error message Fault-finding Cause/Action Press a. 02, DOOR OPEN Error message returns No error message Door status switch open during Transient fault in door lock, CPU wash. PCB or I/O PCB. Access service program to view indicator for “DOOR CLOSED”.
Page 105 Fault-finding Error code, error message Fault-finding Cause/Action Test whether door is really unlocked. 03, DOOR UNLOCKED Door not locked Door locked Acknowledgement signal from door lock switch absent at program start or during program. Check voltage (= feed voltage to machine) on I/O PCB 1, PCB connector X5 between terminals 1 and 5.
Page 106 Fault-finding Error code, error message Fault-finding Cause/Action 03, DOOR UNLOCKED Continued from previous page. SERVICE PROGRAM LEVEL TEMP 22°C SPEED DRAIN CLOSED Access the service program and activate the door lock. 38 TURBO EXTRACTION 39 NORMAL DRAIN Does it lock? 50 DOOR LOCK/OIL LUBRICATION 54 HEATING 63 BUZZER/FLASHLIGHT...
Page 107 Fault-finding Error code, error message Fault-finding Cause/Action Use ato reset. Start a program. 04, NTC LOW TEMPERATURE Temperature sensor indicating a Error message returns No error message temperature below lowest Transient fault. allowable value. This suggests open circuit (continuity fault) in Short-circuit the temperature sensor by the sensor.
Page 108 Fault-finding Error code, error message Fault-finding Cause/Action Use a to reset. 05, NTC HIGH TEMPERATURE Start a program. Temperature sensor indicating a Error message returns No error message temperature above highest Transient fault. allowable value. This suggests short-circuit in sensor or wiring. Disconnect PCB connector X1 on CPU PCB.
Page 109 Fault-finding Error code, error message Fault-finding Cause/Action 06, WATER IN DRUM Is there any water in the drum? (Even if no water is visible in the inner drum, check for presence of The water level is higher than water in outer drum by inserting suitable object the EMPTY level at start of through inner drum perforations.) program.
Page 110 Fault-finding Error code, error message Fault-finding Cause/Action Continued from previous page. 06, WATER IN DRUM Check voltage (= feed voltage to machine) on I/O PCB 1, X7: 1 - 2. 3 2 1 Voltage present No voltage Probably faulty drain valve or wiring to drain valve.
Page 111 Fault-finding Error code, error message Fault-finding Cause/Action Turn the machine’s wall switch off so that the water 07, MACHINE OVERFILLED empties from the machine. Turn on the wall switch The water level is above the set and start a program. Error message returns No error message safety level during program...
Page 112 Fault-finding Error code, error message Fault-finding Cause/Action Is there any water in the drum? (Even if no water is 10, NOT DRAINED visible in the inner drum, check for presence of water in outer drum by inserting suitable object The water level is higher than through inner drum perforations.) the EMPTY level after drain sequence.
Page 113 Fault-finding Error code, error message Fault-finding Cause/Action Continued from previous page. 10, NOT DRAINED Restart and run the program. Error message No error message Transient fault. No action re- quired. Check to see if drain valve is partially blocked or not opening fully.
Page 114 Fault-finding Error code, error message Fault-finding Cause/Action Turn the machine’s wall switch off and on again. 13, NO MOTOR COMM. Start a program. Communication between PCU Error message returns No error message and motor control unit interrupted Transient fault.No action re- or disturbed quired.
Page 115 Fault-finding Error code, error message Fault-finding Cause/Action If the level system has not been calibrated at the 14, LEVEL CALIBRATION factory the error message will appear for five seconds immediately after every program start-up. Level system not calibrated at The machine can be operated, but the levels will be factory.
Page 116 Fault-finding Error code, error message Fault-finding Cause/Action After the problem which caused the 15, EMERGENCY STOP emergency stop has been put right, you can reset the emergency stop button by The emergency stop button has turning it until it pops back out. Reset been pressed.
Page 117 Fault-finding Error code, error message Fault-finding Cause/Action Turn the machine’s wall switch off and on again. 17, DOOR LOCK Start a program. Error message returns No error message No signal from door status switch, although door is locked. Transient fault. No action Access the service program and check the door required.
Page 118 Fault-finding Error code, error message Fault-finding Cause/Action Turn the machine’s wall switch off and on again. 20, INTERLOCK STATUS Start a program. MCU not receiving interlock Error message returns No error message signal during program operation. Transient fault. No action re- Check the voltage between terminals 1 and 2 at quired.
Page 119 Fault-finding Error code, error message Fault-finding Cause/Action Turn the machine’s wall switch off and on again. 21, I/O COMMUNICATION Start a program. Error message returns No error message Communication between the CPU board and one of the I/O Transient fault. No action required. boards disturbed or lost, or Check the red LEDs on all I/O PCBs.
Page 120 Fault-finding Error code, error message Fault-finding Cause/Action Continued from previous page. 21, I/O COMMUNICATION Measure also between the four connections in X5 and X2 respectively, to eliminate possibility of short- circuits between two conductors. If the wiring has connectors, disconnect these one by one and Wiring sound Wiring faulty continue fault tracing to identify...
Page 121 Fault-finding Error code, error message Fault-finding Cause/Action An input on I/O PCB 1 (X16:7-8) can be connected 23, PHASE to external equipment for monitoring the mains power supply (for voltage levels, loss of phase etc.) If this input is activated, the error message will Error message from equipment appear.
Page 122 Fault-finding Error code, error message Fault-finding Cause/Action This error message can occur if the ambient temper- 31, HEAT SINK ature has been extremely high. If so, lower the TOO HOT temperature, e.g. by opening a window. Check that the vanes on the MCU heat sink are not clogged and that the fan is working.
Page 123 Fault-finding Error code, error message Fault-finding Cause/Action Turn off the machine’s wall switch. Check that the 32, MOTOR TOO HOT drum and motor rotate smoothly. Drum/motor OK Drum/motor not rotating Thermal protection for motor has smoothly cut out. Bearing failure in drum or motor, or objects between inner and Wait at least 10 minutes to let motor cool, then outer drum.
Page 124 Fault-finding Error code, error message Fault-finding Cause/Action Turn the machine’s wall switch off, wait at least 10 33, NO INTERLOCK seconds, then turn it on again. Check that the door Motor control unit receiving start is actually closed. command from program control Start a program.
Page 125 Fault-finding Error code, error message Fault-finding Cause/Action Turn the machine’s wall switch off and on again. 35, MOTOR SHORT Start a program. Error message returns No error message Motor control unit indicating short-circuit between outputs for Transient fault. No action re- motor windings.
Page 126 Fault-finding Error code, error message Fault-finding Cause/Action Turn the machine’s wall switch off and on again. 36, INTERLOCK HARDWARE Start a program. Error message returns No error message Motor control unit indicates fault in receiving circuitry for lock Transient fault. No action re- acknowledgement signal.
Page 127 Fault-finding Error code, error message Fault-finding Cause/Action Turn the machine’s wall switch off and on again. 37, LOW DC VOLTAGE Start a program. Error message returns No error message Motor control unit indicating DC Transient fault. No action re- voltage level too low. quired.
Page 128 Fault-finding Error code, error message Fault-finding Cause/Action Turn the machine’s wall switch off and on again. 38, HIGH DC VOLTAGE Start a program. Error message returns No error message Motor control unit indicating DC Transient fault. No action re- voltage level too high. Check the feed voltage to the MCU (230 V) at quired.
Page 129 Fault-finding Tracing faults in display unit keys Error code, error message Fault-finding Cause/Action For every press of a key in the PCU set, two of the outputs from the PCU set of keys close. To check the function of any given key in this set, disconnect the ribbon cable connecting the key set to the display circuit board, press the key you wish to check, and measure the resistance between the outputs which should be short-circuited.
Page 130 Fault-finding To replace the CPU board Error code, error message Fault-finding Cause/Action If the CPU board is faulty and has to be replaced, the correct software for the particular washer extractor will have to be downloaded onto the new CPU board. For this you need: 1.
Page 131 Fault-finding 4. Switch off the machine’s main power switch. Fig. Error code, error message Fault-finding Cause/Action Install the new CPU board and connect all the PCB connectors. Connect the correct cable between the computer (COM1 or COM2 port) and the interface connector X7 on the CPU board.
Page 132 Fault-finding 8. Once the new program file is ready, it will start to Error code, error message Fault-finding Cause/Action be downloaded onto the CPU board immediately. The PC screen will show: DOWNLOADING PC PROGRAM CPU circuit board to keep you informed. At the bottom of the screen you can see how many of the total of 1020 “pages”...
Page 133 Fault-finding To replace an I/O board Error code, error message Fault-finding Cause/Action The procedure described here is for machines with more than one I/O board. On machines with only one I/O board, that board can be replaced without any need for this procedure. 5 4 3 If there is more than one I/O circuit board, the processor must know whether the new circuit board...
Page 134 Fault-finding 7. Enter the two-digit code for the new I/O board Error code, error message Fault-finding Cause/Action you wish to program (e.g. I/O board 1) and press Button for ENTER. The PC will respond with instructions programming corresponding to this message: PROGRAMMING OF I/O BOARD PRESS PROGRAM BUTTON ON I/O BOARD 1 8.
Page 135 Fault-finding Error message: I/O COMMUNICATION Error code, error message Fault-finding Cause/Action Communication between the CPU board and one of the I/O boards disturbed or lost. 1. Turn the machine’s wall switch off and on again. Start a program. Does the error message return? Transient fault.
Page 136: Maintenance
Maintenance Maintenance Preventive maintenance has been reduced to a minimum by the careful design of reliable components and material. However, the following measures should be taken at regular intervals and in proportion to the hours of service. Make certain that all electrical power to the machine is shut off before removing top or rear panels.
Page 137 Maintenance Weekly • Remove hose from drain connection and clean inside drain valve. Every three months • Remove the cover plates of the machine and Fig. check that the V-belt of the motor is undamaged and correctly tensioned. • Check that all tubing, piping and connections are free from leaks.
Page 138: Trouble-Shooting
Trouble-shooting The purpose of the trouble-shooting guide is to facilitate the location an correction of the most common machine problems. Before the top panel is removed, power to the machine is to be switched off at the main source or at the separate circuit breaker. At each trouble-shooting attempt, the plug in connectors on the control panel should be moved in and out in order to eliminate improper contact due to faulty connection.
Page 139 Trouble-shooting If machine does not start Fig. A Check circuit breaker in the power feed line to the machine. B Check door safety switches. C Check glass cartridge fuse. E Check for fault indication on display (see under the heading ''Fault finding'').' If water does not drain A Check for fault indication on display (see Fig.
Page 140 Trouble-shooting If machine does not extract A Check for fault indication on display (see under Fig. the heading ''Fault finding''). If motor does not operate at wash speed. A Check for fault indication on display (see under Fig. the heading ''Fault finding''). B Check motor and V-belts.
Page 141 Trouble-shooting If machine runs slowly on wash speed or there is a slapping or thumping noise: Fig. Replace V-belts. If a metallic noise can be heard at rear of machine: Fig. Tighten pulley on motor shaft. If the door is leaking: Check door gasket.
Page 142 Trouble-shooting If there is leaking around the glass. Fig. A Re-cement glass in door gasket, if worn. B Replace door gasket if worn. If water does not enter the machine. Fig. A Check the valve coils on inlet valves. B Check wires leading to electric coils. C Be sure manual shut-off valves are in open position.
Page 143 Trouble-shooting If water continues to fill without stopping. A Check for incorrect programming. B Check hose attached to level control unit on the printed circuit board. C Check inlet valves for dirt underneath the valve diaphragm. To localize, shut off power. If water continues to flow, inlet valves have foreign material in them and should be thoroughly cleaned.
Page 144 Trouble shooting If machine vibrates excessively: Fig. A Tighten mounting bolts. 2408...
