bluworld of water BELLEZZA WATERFALL Quick Start Manual

Download this manual

BELLEZZA WATERFALL

INSPECT FOR SHIPPING DAMAGE – ANY DAMAGE FROM SHIPPING SHOULD BE IMMEDIATELY REPORTED

TO THE DELIVERY AGENT. DO NOT ATTEMPT TO OPERATE IF UNIT IS DAMAGED.

PARTS LIST

1 – PUMP

1 – LOW VOLTAGE LIGHT

TOOLS REQUIRED

LEVEL

PENCIL

PHILLIPS SCREWDRIVER

MOUNTING THE BELLEZZA

Note: This wall bracket can be mounted without studs. If you encounter a stud while mounting the wall

bracket, use the provided wood screw. Use easy anchors for the holes without studs. Each easy anchor

holds up to 50lbs.

1. DETERMINE THE DESIRED LOCATION ON THE WALL.

2. HOLD MOUNTING BAR TO THE WALL (THE TOP OF THE MOUNTING BAR SHOULD ANGLE AWAY

FROM THE WALL AND THE HOLES WILL BE TOWARD THE WALL). MARK CENTER HOLE ON THE

WALL (THE TOP OF THE BELLEZZA WILL BE APPROXIMATELY 17" ABOVE THE CENTER HOLE

AFTER MOUNTING). FIGURE A

FIGURE A

3. TO INSTALL EASY ANCHOR, GENTLY TAP THE TIP INTO THE DRYWALL, AND SLOWLY SCREW THE

ANCHOR THE REST OF THE WAY. BE CAREFULL NOT TO OVER TIGHTEN AS SHOWN IN FIGURE B.

FIGURE B

4. MOUNT THE WALL BRACKET WITH THE CENTER SCREW INTO THE EASY ANCHOR FROM STEP 3.

3 – ANCHORS WITH SCREWS

3 – WOOD SCREWS

1 – MOUNTING BRACKET

Need help?

Do you have a question about the BELLEZZA WATERFALL and is the answer not in the manual?

Page 1 BELLEZZA WATERFALL INSPECT FOR SHIPPING DAMAGE – ANY DAMAGE FROM SHIPPING SHOULD BE IMMEDIATELY REPORTED TO THE DELIVERY AGENT. DO NOT ATTEMPT TO OPERATE IF UNIT IS DAMAGED. PARTS LIST 1 – PUMP 3 – ANCHORS WITH SCREWS 1 – MOUNTING BRACKET 1 –...
Page 2 5. LEVEL THE MOUNTING BRACKET AND MARK HOLES OF THE SIDES. FIGURE C FIGURE C 6. TURN THE BRACKET 90 DEGREES, INSTALL SIDE ANCHORS. FIGURE D FIGURE D 7. TURN BRACKET BACK TO LEVEL AND INSTALL SCREWS, TIGHTEN ALL THREE SCREWS. FIGURE E FIGURE E 8.
Page 3 TURN YOUR BELLEZZA ON 1. AFTER MOUNTING YOUR BELLEZZA TO THE WALL, FILL WITH WATER. NOTE: WATER LEVEL MUST BE MAINTAINED AT LEAST 1” ABOVE PUMP. IF WATER LEVEL DROPS BELOW TOP OF PUMP, DAMAGE TO THE PUMP MAY OCCUR. 2.
Page 4 L I M I T E D W A R R A N T Y Bluworld of Water warrants this product to be free from defects in material and workmanship for one (1) year from the original date of purchase by the consumer.
