Page 1 EFOY Pro Hybrid Solution User Manual – EFOY ProCabinet 4060S/SX + 4120SX sfc-energy.ca...
Page 2 EFOY Pro Hybrid Solution User Manual ! Warning ! Protect Your EFOY Fuel Cell from Freezing To avoid complications or potential damage, while doing preliminary work and setting up please ensure any EFOY fuel cells are kept in a your EFOY system in cold temperatures, please ensure any EFOY fuel cells are kept in a warm environment such as a vehicle or building until they are ready to be installed.
Page 3: Table Of Contents
EFOY Pro Hybrid Solution User Manual Table of Contents Installation & Commissioning Checklist ________________ 1 System Start-Up Instructions ________________________ 5 Solar Array Set-Up _______________________________ 12 Cluster Functionality _____________________________ 14 Assigning an IP Address____________________________ 21 Transport Mode __________________________________ 23 Recommended System Settings _____________________ 24 Fuel Cartridge Replacement ________________________ 25 Do’s and Don’ts _________________________________ 29 Resources ____________________________________________29...
Page 4: Installation & Commissioning Checklist
EFOY Pro Hybrid Solution User Manual Installation & Commissioning Checklist Customer/End User Site Location Site ID Installed By: Company Name Installed By: Technician Name Installation Date EFOY Panel Serial # EFOY Fuel Cell Serial # Fuel Manager Serial # Fuel Manager Type (FM2, FM4 or FM8) Fuel Cartridge Type (M10, or M28) Fuel Cartridge Quantity EFOY Enclosure Check...
Page 5 User Manual Installation & Commissioning Checklist Value EFOY System: Found using the Operating Panel (display) *Do not adjust these settings without first consulting the SFC Energy Service Team* EFOY Firmware Version Switch-On Voltage Setting Switch-Off Voltage Setting Absorption Time Setting...
Page 6 EFOY Pro Hybrid Solution User Manual Installation & Commissioning Checklist Solar Charge Controller Complete / Value Solar Controller Programmed with proper settings Yes □ No □ DIP Switch Settings High Voltage Disconnect Setting Low Voltage Disconnect Setting Absorption Time Setting System Documentation Complete Yes □...
Page 7 Signature Date Signature Submission Upon successful completion of system commissioning please submit this signed and completed form to the SFC Energy Service department at service-support@sfc.com for record keeping. If you require assistance, please contact the SFC Energy Canada Service Department at...
Page 8: System Start-Up Instructions
EFOY Pro Hybrid Solution User Manual System Start-up Instructions Verify PV array wiring configuration is correct according to Check PV array for proper voltage and polarity. the specific site design. (An example diagram is included in the drawing package). Set up and secure the batteries in to place as per the Verify all field wiring according to drawing package and turn designated system voltage configuration using the cables all breakers to the OFF position.
Page 9 EFOY Pro Hybrid Solution User Manual System Start-up Instructions Secure the EFOY fuel cell into place by running the strap though 5. Place the methanol fuel cartridges into the enclosure. You the mounting brackets. should have enough cartridges to connect one to each fuel hose.
Page 10 EFOY Pro Hybrid Solution User Manual System Start-up Instructions Connect the Fuel Manager data cable to the bottom right port Connect the Fuel Manager power cable to the top right port on the EFOY Fuel Cell. labeled SFC Bus on the EFOY Fuel Cell. M28 cartridges with the P/N 150 905 100 require adapters to Connect the fuel manager hose to the cartridge (or the M28 attach the fuel manager hoses to the cartridge.
Page 11 EFOY Pro Hybrid Solution User Manual System Start-up Instructions Connect the OP3 Operating Panel (touchscreen display) Remove the protective cap from the EFOY fuel cell exhaust cable to the SFC Bus port on the Fuel Manager. spout and connect the exhaust hose. Perform a quick visual check to ensure there is no pinching or kinking in the hose, and that it is positioned at a downward angle.
Page 12 EFOY Pro Hybrid Solution User Manual System Start-up Instructions Switch ON the breakers for the EFOY, and the Batteries Attach the Off-Heat Elbow to the EFOY warm air exhaust port which are both clearly labelled. Refer to the drawings for pointed up at a 45 degree angle facing towards the EFOY Fuel more information.
Page 13 EFOY Pro Hybrid Solution User Manual System Start-up Instructions 19b. Close the panel door(s) and wake up the Operating Panel (LED Display) on the door by touching the screen. Follow the prompts to complete the initial configuration. See detailed configuration steps below. Select Transport Lock Standby Confirm Deactivation...
Page 14 EFOY Pro Hybrid Solution User Manual System Start-up Instructions Inside the EFOY is a mixing tank containing a methanol and water mixture which is used in the chemical reaction to create power. Over long periods of time if the EFOY isn’t operating, the water can evaporate.
Page 15: Solar Array Setup
Accounting for Solar Components If your order included a solar package from SFC Energy, there are several items to account for. Solar Panels, pairs of PV cables, a Panel Mounting System, a Solar Combiner box with Disconnect, Breakers, a GFCI breaker, and a Lightening Arrestor are all items we often provide.
Page 16 EFOY Pro Hybrid Solution User Manual Solar Array Setup Guidelines and Example Typical 24VDC Combiner Box Wiring Note: 4 Panel Example Shown Above Scenarios of 1 and 3 solar panels are connected in parallel only (equal number of panels and breakers) Scenarios of sets of 2 panels are always connected in series-parallel (pairs of panels connected together, terminated on 1 breaker).
Page 17: Cluster Functionality
EFOY Pro Hybrid Solution User Manual Dual EFOY Systems Activating the Cluster Functionality Our 250W EFOY ProCabinet 4120SX solution contains (2) EFOY Fuel Cells. In this configuration we want each EFOY to run at the same time to ensure each EFOY uses the same amount of fuel and accumulates the same number of runtime hours. This ensures optimum system perfor- mance and allows you to refuel both EFOYs at the same time, minimizing trips to site.
Page 18 EFOY Pro Hybrid Solution User Manual Dual EFOY Systems Activating the Cluster Functionality Ensure the (2) EFOY Fuel Cells are connected via their onboard ethernet ports and the breaker for the network switch is turned on. Then, on the Operating Panel, select EFOY Fuel Cell, then Cluster. Choose which EFOY will be the ‘Controller’...
Page 19 EFOY Pro Hybrid Solution User Manual Dual EFOY Systems Activating the Cluster Functionality The system will assign an IP address to the Controller. If you are using your ProCabinet on a network with other pieces of equipment, it may be necessary to input a customer IP address for the EFOYs. Take note of the IP address and Cluster PIN of the Controller, as the other EFOY will need this to find it on the network.
Page 20 EFOY Pro Hybrid Solution User Manual Dual EFOY Systems Activating the Cluster Functionality It will prompt you to enter the IP address of the Controller EFOY, and then the Cluster PIN so it can establish a connection. Note: The connection may be blocked if the DHCP Client is currently enabled. To rectify this, you can return to the ‘EFOY Fuel Cell’ menu and go into the ‘Ethernet Configuration’...
Page 21 It is important that each EFOY is set up with the same charging parameters. Please refer back to Step 19a of the initial set-up instruc- tions, and additionally, review the information in the Battery Menu. Do not change any settings without first consulting an SFC Energy Service Team representative.
Page 22 EFOY Pro Hybrid Solution User Manual Dual EFOY Systems Activating the Cluster Functionality Each EFOY must have Modbus TCP Enabled. To verify this, you can go to the ‘EFOY Fuel Cell’ menu and then into the ‘Ethernet Configuration’ menu. There you will see a toggle switch called Modbus TCP. Ensure it is turned on, and is green. Note: The CC2 will put every EFOY that is in the cluster in the Automatic operation mode using the Modbus protocol.
Page 23 EFOY Pro Hybrid Solution User Manual Dual EFOY Systems Activating the Cluster Functionality Note: There are two LEDs on its front panel that are controlled by the CC2 app, as shown in Figure 2. These are labelled A1 and A2. Definition A1 Green/Off The CC2 app is running, and there are no problems.
Page 24: Assigning An Ip Address
EFOY Pro Hybrid Solution User Manual EFOY IP Address Assignment Assigning an IP Address to an EFOY Pro Fuel Cell In some communication scenarios, you may wish to manually assign an EFOY a specific IP Address. Please see the following steps for doing so. On the EFOY Operating Panel (LED touchscreen) select the icon with 3 lines in the top left corner to access the Menu, and then click on ‘Settings’.
Page 25 EFOY Pro Hybrid Solution User Manual EFOY IP Address Assignment From here, you can see the DHCP client setting. To be able to manually input an IP Address, this switch needs to be set to the off position, as seen here. Then, you can select ‘IP address’...
Page 26: Transport Mode
EFOY Pro Hybrid Solution User Manual EFOY Transport Mode The EFOY Pro 2800 has a protective mode we can enable if its to either be transported or stored for long periods of time. Activate Transport Mode by following the below steps. This may take a few minutes, depending on the state of your EFOY. Find more information on efoy-pro.com sfc-energy.ca...
Page 27: Recommended System Settings
Recommended System Settings It’s important to remember that set points will be pre-set with our recommended system settings by the team at SFC Energy. While these settings are adjustable, before modifying any on your own we advise having a discussion with an SFC Energy Service Team member about what you’d like to change and why.
Page 28: Fuel Cartridge Replacement
EFOY Pro Hybrid Solution User Manual Fuel Cartridge Replacement EFOY Fuel Cartridge Replacement Process Please review the following basic steps to ensure your fuel cartridges are replaced and reconnected correctly. Disconnect the empty cartridge and remove it. Place the new cartridge in position and reconnect the fuel hose connector hand tight – avoid overtightening as this can cause connection issues.
Page 29: Do's And Don'ts
EFOY Pro Hybrid Solution User Manual Do’s and Don’ts Do’s Set a partially full fuel cartridge as the active cartridge when refuelling. Ensure fuel cartridges are connected hand tight only. Avoid overtightening as this can lead to issues. Install the Off Heat Elbow to the EFOY warm air exhaust to direct warm air away from the thermostats. Maintain proper spacing around the EFOY for airflow.
