senva IoTBuddy Installation Instructions

INSTALLATION INSTRUCTIONS
IOT Buddy
Power Over Ethernet (POE), Ethernet,
or Wireless 2.4 GHz
PRODUCT APPLICATION LIMITATION:
Senva products are not designed to be used as the lone device for life or safety
applications. Senva products are not intended for use in critical applications
such as nuclear facilities, human implantable device or life support. Senva
believes a systems approach to safety is necessary for these types of applica-
tions. Senva is not liable, in whole or in part, for any claims or damages arising
from such uses.
IMPORTANT!
IMPORTANT WARNINGS
• Only qualified trade installers should install this product
• This product is not intended for life-safety applications
• Do not install in hazardous or classified locations
• The installer is responsible for all applicable codes
• De-energize power supply prior to installation or service
• Forming a "drip-loop" (allowing tubing to dip below the
level of the sensor hose barbs) is recommended to protect
the sensor from damage caused by condensation.
DIMENSIONS
senvainc.com 1-866-660-8864
INSTALLATION
1.Wire device according to wiriding diagrams section.
2. Once powered, the WiFi version of the IoTBuddy will host an
access point for 5 minutes. To re-enable the access point, press
the button on the IOTBuddy.
For set up with smart phone:
1. Scan the QR code on the label of the IoTBuddy device. Join
the network.
2. Open a browser; go to https://4.3.2.1
3. Your browser may indicate a non-private connection. Please
proceed. You may need to hit "refresh" on your browser.
4. Log in using the default credentials:
• username: admin
• password: admin
5. Navigate using the 3-line "hamburger" menu on the top right
to set up network, datapoints, and cloud service information.
For set up with computer:
1.If you are setting up the device using a computer, open your
WiFi network page and find the IOTB that matches the serial
number printed on your IoTBuddy label.
2. Enter the network security key: password
3. Go to https://4.3.2.1
4. Your browser may indicate a non-private connection. Find
the "proceed" button near the bottom of the warnings; you may
need to click the subtle link labeled "advanced" or "show more"
first.
5. Log in using the default credentials:
• username: admin
• password: admin
6. You may change your username and password on the
first screen. Once you click "save", you will be logged out and
prompted to log in again with the new credentials.
7. Access the user interface guide bellow with the QR code for
network setup.
LED STATUS/INDICATION
Normal Mode:
Off = Not Configured / No power
Steady = Configured / Powered, not conencted to network
Slow Blink = Connected to network
Fast Blink = Connected to cloud service
Setup Mode:
Off = Button pressed, commissioning mode enabled
Slow Blink = Button held for 3 seconds, reboot device
Fast Blink = Button held for 10 seconds, initiate factory reset
1825 NW 167th Place Beaverton Oregon 97006
