Fire Alarm Systems
Manuel Call Points*
USER'S GUIDE
Efire-EYIB
Efire-EYIB-Nc/No
Fire Alarm
Fire Alarm
Button
Button (Dry Contact )
WARNING: PLEASE READ THESE INSTRUCTION CAREFULLY
PRIOR TO OPERATING OR COMMISSIONING THIS DEVICE
*Conventional Manuel Call Points according to the EN 54-11
Advertisement
Related Manuals for ELEKS Efire-EYIB
Summary of Contents for ELEKS Efire-EYIB
- Page 1 Fire Alarm Systems Manuel Call Points* USER’S GUIDE Efire-EYIB Efire-EYIB-Nc/No Fire Alarm Fire Alarm Button Button (Dry Contact ) WARNING: PLEASE READ THESE INSTRUCTION CAREFULLY PRIOR TO OPERATING OR COMMISSIONING THIS DEVICE *Conventional Manuel Call Points according to the EN 54-11...
- Page 2 • Connect the cables coming from the line to + and – on the contactor for the Efire-EYIB. Perform the Nc and/or No connections respectively for Efire-EYIB-Nc/No. • • When a button protective cover is intended to be used, mount it on the upper casing.
- Page 3 Representative Product Scheme (Efire-EYIB) 4. Warnings • Pay attention to the specific mounting schemes of Efire-EYIB and Efire-EYIB-Nc/No. • Don't supply anything except 12/24 V DC to Efire-EYIB. • Never make any connection above 1 A to the product Efire-EYIB-Nc/No.
- Page 4 AUTHORIZED SERVICE MANUFACTURER COMPANY / Central Service TITLE ELEKS Elektrik Elektronik Sistemleri Sanayi Ve Ticaret Limited Sirketi ADDRESS: Şerifali Mah. Bayraktar Bulvarı Emin Sok. No:3 Yukarı Dudullu - Ümraniye / İSTANBUL +90 0216 463 47 28 - 29 - 30...
