protech Prox BE-U236 User Manual

3.5” intel 12th gen. core i7 / i5 / 83 / celeron soc sbc
Hide thumbs Also See for Prox BE-U236:
Table of Contents

Advertisement

Quick Links

Download this manual
USER
MANUAL
BE-U236 M1
BE-U236
3.5" Intel
12th Gen. Core
®
I7 / i5 / 83 / Celeron
®
SoC SBC
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Prox BE-U236 and is the answer not in the manual?

Questions and answers

Related Manuals for protech Prox BE-U236

Summary of Contents for protech Prox BE-U236

  • Page 1 USER MANUAL BE-U236 3.5” Intel 12th Gen. Core ® ® I7 / i5 / 83 / Celeron SoC SBC ® BE-U236 M1...
  • Page 2 BE-U236 ® ® 3.5" Intel 12th Gen. Core i7 / i5 / i3 / ® Celeron SoC SBC COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in Mar. 2023. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Contents Introduction ..................1-1 About This Manual ..............1-2 Getting Started ..................2-1 Package List ................2-2 BE-U236 Specifications ............. 2-3 Safety Precautions ..............2-5 Hardware Configuration ..............3-1 JUMPER & CONNECTOR QUICK REFERENCE TABLE ..3-2 COMPONENT LOCATIONS ............. 3-4 3.2.1 BE-U236 Top View ............
  • Page 5 3.4.10 M.2 2280 PCI Express Slot (M2_PCIE1) (M-Key) ..3-21 3.4.11 M.2 B-KEY 3042 Slot (M2_B1) ........3-23 3.4.12 BATTERY WAFER (JBAT1) ..........3-25 3.4.13 INTERNAL USB 2.0 WAFER (JUSB1) ......3-26 3.4.14 MICRO SIM CARD CONNECTOR (JSIM1) ....3-27 3.4.15 B2B CONNECTOR (J2) ..........
  • Page 6 ® Intel Management Engine Components Driver Installer Installation ................. 4-6 Installing LAN Driver Utility ............4-7 ® Installing Intel Human Interface Devices Driver Utility .... 4-8 ® Installing Intel Serial I/O Driver Utility ........4-9 BIOS SETUP ..................5-1 Introduction ................5-2 Accessing Setup Utility ..............
  • Page 7 5.4.11 Advanced – Network Stack Configuration ....... 5-28 5.4.12 Advanced – NVMe Configuration ........5-30 Chipset ..................5-31 5.5.1 Chipset – System Agent (SA) Configuration ....5-32 System Agent (SA) Configuration – Memory Configuration ..5-33 System Agent (SA) Configuration – VMD setup menu ....5-34 System Agent (SA) Configuration –...
  • Page 8 Revision History The revision history of BE-U236 User Manual is described below: Version No. Revision History Date 2023/03/30 Initial Release...

  • Page 9: Introduction

    Introduction This chapter provides the introduction for BE-U236 board as well as the framework of the user manual. The following topic is included: • About This Manual BE-U236 SERIES USER MANUAL Page: 1-1...

  • Page 10: About This Manual

    Chapter 1 Introduction 1.1 About This Manual Thank you for purchasing our BE-U236 system. BE-U236 provides faster processing speed, greater expandability and can handle more tasks than before. This manual is designed to assist you how to install and set up the whole system. It contains 5 chapters and 2 appendixes.

  • Page 11: Getting Started

    Getting Started This chapter provides the information for BE-U236 board. It describes the package contents and outlines the BE-U236 specifications. The following topics are included: • Package List • BE-U236 Specification • Safety Precautions Experienced users can go to Chapter 3 Hardware Configuration on page 3-1 for a quick start.

  • Page 12: Package List

    Chapter 2 Getting Started 2.1 Package List If you discover any of the items listed below are damaged or lost, please contact your local distributor immediately. Item Q’ty BE-U236 Quick Reference Guide Manual / Driver DVD Jumper (2.0 mm) Fillister Head Screw for M.2 HEX CU BOSS for M.2 SATA &...

  • Page 13: Be-U236 Specifications

    Chapter 2 Getting Started 2.2 BE-U236 Specifications System ®  Intel Core i7-1265UE, 2P8E, 96EU ® ntel Core i5-1245UE, 2P8E, 80EU  CPU Support ®  Intel Core i3-1215UE, 2P6E, 64EU ® ®  Intel Celeron 7305E, 1P4E, 48EU ® ...
  • Page 14 Chapter 2 Getting Started  1 x M.2 E-Key 2230 (PCIe x1, USB2.0)  1 x M.2 B-Key 3042 LTE/ 5G (PCIe x1, USB2.0) w/ SIM Expansion Bus signal  1 x M.2 M-Key 2280 (PCIe Gen4 x4 NVMe) Graphics HDMI ...

  • Page 15: Safety Precautions

    Chapter 2 Getting Started 2.3 Safety Precautions Follow the instructions below to avoid your system from damages: Keep your system away from static electricity on all occasions. Prevent electric shock. Don’t touch any components of this board when it is powered on.

  • Page 16: Hardware Configuration

    Hardware Configuration This chapter contains helpful information about the jumper & connector settings, and component locations. The following sections are included: • Jumper & Connector Quick Reference Table • Component Locations • Configuration and Jumper Settings • Connector Pin Assignments BE-U236 SERIES USER MANUAL Page: 3-1...

  • Page 17: Jumper & Connector Quick Reference Table

    Chapter 3 Hardware Configuration 3.1 JUMPER & CONNECTOR QUICK REFERENCE TABLE JUMPER Description NAME Clear CMOS Data Selection PWM Brightness Control Selection JP2 (Function1) USB Power Selection JP2 (Function 2) SPI Override Protection Selection Inverter LED Power Selection LVDS Power Selection CONNECTOR Description NAME LAN Ports...
  • Page 18 Chapter 3 Hardware Configuration CONNECTOR Description NAME System Fan Connector SYS_FAN1 Power Button JBUTTON1 BUZZER Wafer JBZ1 I2C Wafer JI2C1 M.2 E-Key WLAN LED Wafer LED_WLAN1 BE-U236 SERIES USER MANUAL Page: 3-3...

  • Page 19: Component Locations

    Chapter 3 Hardware Configuration 3.2 COMPONENT LOCATIONS 3.2.1 BE-U236 Top View LAN2 LAN1 HDMI USB2 USB1 USB3 DP_HDMI1 JFP1 JBUTTON1 JUSB1 AUDIO1 M.2 2230 (Wi-Fi+BT) JSIM1 JBZ1 M2_B1 JI2C1 M2_E1 LED_WLAN1 M.2 3042 (4G/5G/SSD) DIMM1 JMPS1 JCOM1 M.2 2280 NVMe SSD JSATA_PWR1 PWR1 M2_PCIE1...

  • Page 20: Be-U236 Jumper Setting

    Chapter 3 Hardware Configuration 3.2.2 BE-U236 Jumper Setting LAN2 LAN1 HDMI USB2 USB1 USB3 DP_HDMI1 JFP1 JBUTTON1 JUSB1 AUDIO1 M.2 2230 (Wi-Fi+BT) JSIM1 JBZ1 M2_B1 JI2C1 M2_E1 LED_WLAN1 M.2 3042 Clear CMOS Data (4G/5G/SSD) DIMM1 Selection JMPS1 Normal Clear CMOS (default) JCOM1 M.2 2280...

  • Page 21: Be-U236 Bottom View

    Chapter 3 Hardware Configuration 3.2.3 BE-U236 Bottom View Alder Lake U15 LVDS/eDP Processor Connector BE-U236 SERIES USER MANUAL Page: 3-6...

  • Page 22: Be-U236 I/O View

    Chapter 3 Hardware Configuration 3.2.4 BE-U236 I/O View USB 2.0 USB 3.2 USB 3.2 LAN1 LAN2 HDMI Gen2 x 1 Gen2 x 1 BE-U236 SERIES USER MANUAL Page: 3-7...

  • Page 23: How To Set Jumpers

    Chapter 3 Hardware Configuration 3.3 HOW TO SET JUMPERS You can configure your board by setting jumpers. A jumper is consists of two or three metal pins with a plastic base mounted on the board. By using a small plastic "cap", (also known as the jumper cap (with a metal contact inside)), you are able to connect the pins.
  • Page 24 Chapter 3 Hardware Configuration Jumper Diagrams Jumper Cap looks like this 2 pin Jumper looks like this 3 pin Jumper looks like this Jumper Block looks like this Jumper Settings 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block...

  • Page 25: Setting Connectors And Jumpers

    Chapter 3 Hardware Configuration 3.4 SETTING CONNECTORS AND JUMPERS 3.4.1 LAN PORT (LAN1, LAN2) Port Location: LAN1, LAN2 Description: LAN Ports (rear I/O) LAN1 / LAN2 LAN1 / LAN2 LED Indicator: Left Side LED: Green Color On 2500 LAN Speed Indicator Orange Color On 1000 LAN Speed Indicator 10/100 or no LAN connected...

  • Page 26: Displayport And Hdmi Port (Dp_Hdmi1)

    Chapter 3 Hardware Configuration 3.4.2 DISPLAYPORT and HDMI PORT (DP_HDMI1) Port Location: DP (located on the upper side) Description: DisplayPort DP signals: ASSIGNMENT ASSIGNMENT DP_LANE0_DP DP_LANE0_DN DP_LANE1_DP DP_LANE1_DN DP_LANE2_DP DP_LANE2_DN DP_LANE3_DP P 12 DP_LANE3_DN DP_C_AUX_ENJ DP_CONFIG_2 DP_C_AUX_P_C DP_C_AUX_N_C DP_HPD V3P3_DP Please see the next page for the pin assignment information of HDMI PORT connector (located on the bottom side).
  • Page 27 Chapter 3 Hardware Configuration HDMI Port Connector (HDMI) Port Location: HDMI (located on the bottom side) Description: HDMI Connector (rear I/O) HDMI ASSIGNMENT ASSIGNMENT HDMI_D2P HDMI_D2N HDMI_D1P HDMI_D1N HDMI_D0P HDMI_D0N HDMI_CLKP HDMI_CLKN HDMI1_CEC_HM_R HDMI_SCL HDMI_SDA V5P0_HDMI HDMI_HPD BE-U236 SERIES USER MANUAL Page: 3-12...

  • Page 28: Dual Usb 3.2 Port (Usb1)

    Chapter 3 Hardware Configuration DUAL USB 3.2 PORT (USB1) 3.4.3 Port Location: USB1 Description: Dual Type-A USB 3.2 Gen 2x1 Ports Dual USB 3.2: ASSIGNMENT VCC5_USB1 USB2_P1_DN_L USB2_P1_DP_L USB3_P1_RX_DN USB3_P1_RX_DP USB1 USB3_P1_TX_DN_CL USB3_P1_TX_DP_CL VCC5_USB2 USB2_P2_DN_L USB2_P2_DP_L USB3_P2_RX_DN USB3_P2_RX_DP USB3_P2_TX_DN_CL USB3_P2_TX_DP_CL BE-U236 SERIES USER MANUAL Page: 3-13...

  • Page 29: Dual Usb 3.2 Port (Usb2)

    Chapter 3 Hardware Configuration DUAL USB 3.2 PORT (USB2) 3.4.4 Port Location: USB2 Description: Dual Type-A USB 3.2 Gen 2x1 Ports Dual USB 3.2: ASSIGNMENT VCC5_USB3 USB2_P3_DN_L USB2_P3_DP_L USB3_P3_RX_DN USB3_P3_RX_DP USB2 USB3_P3_TX_DN_CL USB3_P3_TX_DP_CL VCC5_USB4 USB2_P4_DN_L USB2_P4_DP_L USB3_P4_RX_DN USB3_P4_RX_DP USB3_P4_TX_DN_CL USB3_P4_TX_DP_CL BE-U236 SERIES USER MANUAL Page: 3-14...

  • Page 30: Dual Usb 2.0 Port (Usb3)

    Chapter 3 Hardware Configuration DUAL USB 2.0 PORT (USB3) 3.4.5 Port Location: USB3 Description: Dual Type-A USB 2.0 Ports Dual USB 2.0: ASSIGNMENT ASSIGNMENT VCC5_USB5 VCC5_USB6 USB2_P5_DN_L USB2_P6_DN_L USB2_P5_DP_L USB2_P6_DP_L USB3 BE-U236 SERIES USER MANUAL Page: 3-15...

  • Page 31: Com & Dio Connector (Jcom1)

    Chapter 3 Hardware Configuration 3.4.6 COM & DIO CONNECTOR (JCOM1) Connector Location: JCOM1 Description: COM & DIO Connector ASSIGNMENT ASSIGNMENT COM1_DCD COM2_DCD COM1_RX COM2_RX COM1_TX COM2_TX COM1_DTR COM2_DTR COM1_DSR COM2_DSR COM1_RTS COM2_RTS COM1_CTS COM2_CTS COM1_RI COM2_RI SIO_DI1 SIO_DO1 SIO_DI2 SIO_DO2 JCOM1 SIO_DI3 SIO_DO3...

  • Page 32: Front Panel Connector (Jfp1)

    Chapter 3 Hardware Configuration Front Panel Connector (JFP1) 3.4.7 Connector Location: JFP1 Description: Front Panel Connector ASSIGNMENT HDD LED+ HDD LED- PWR_LED+ PWR_LED- PWR Button+ PWR Button- Reset Button+ Reset Button- JFP1 BE-U236 SERIES USER MANUAL Page: 3-17...

  • Page 33: Dc-In Connector (Pwr1)

    Chapter 3 Hardware Configuration DC-IN Connector (PWR1) 3.4.8 Connector Location: PWR1 Description: DC-IN Connector ASSIGNMENT ASSIGNMENT 12V/24V 12V/24V PWR1 BE-U236 SERIES USER MANUAL Page: 3-18...

  • Page 34: E-Key 2230 Slot (M2_E1)

    Chapter 3 Hardware Configuration 3.4.9 M.2 E-Key 2230 Slot (M2_E1) Connector Location: M2_E1 M.2 E-Key Connector for Wi-Fi +BT Description: M2_E1 ASSIGNMENT ASSIGNMENT V3P3A_WLAN USB2_P10_DP_L V3P3A_WLAN USB2_P10_DN_L M.2_WLAN_LED1_N CNV_WR_D1_DN GPPC_F4_CNV_RF_RESET_N CNV_WR_D1_DP GPPC_F5_CNV_MODEM_CLKREQ CNV_WR_D0_DN M.2_BT_LED2_N CNV_WR_D0_DP KEYE_UART_WAKE_N CNV_WR_CLK_DN KEYE_CNV_BRI_RSP CNV_WR_CLK_DP KEYE_CNV_RGI_DT KEYE_CNV_RGI_RSP M2_WLAN_TX_DP KEYE_CNV_BRI_DT...
  • Page 35 Chapter 3 Hardware Configuration ASSIGNMENT ASSIGNMENT GPPC_D6_SRCCLKREQ1_N BT_KILL_N WLAN_PEWAKE0_N WIFI_KILL_N CNV_WT_D1_DN CNV_WT_D1_DP CNV_WT_D0_DN CNV_WT_D0_DP CNV_WT_CLK_DN V3P3A_WLAN CNV_WT_CLK_DP V3P3A_WLAN BE-U236 SERIES USER MANUAL Page: 3-20...

  • Page 36: 2280 Pci Express Slot (M2_Pcie1) (M-Key)

    Chapter 3 Hardware Configuration 3.4.10 M.2 2280 PCI Express Slot (M2_PCIE1) (M-Key) Connector Location: M2_PCIE1 M.2 2280 PCI Express Slot (M-Key, PCIe Gen4 x4 NVMe) Description: M2_PCIE1 ASSIGNMENT ASSIGNMENT V3P3S_M2_CPU V3P3S_M2_CPU PCIEX4_A_P3_RX_DN PCIEX4_A_P3_RX_DP M.2_CPU_SSD_PLN_N M2_M_LED PCIE4_P3_M.2_SSD_TX_DN V3P3S_M2_CPU PCIE4_P3_M.2_SSD_TX_DP V3P3S_M2_CPU V3P3S_M2_CPU PCIEX4_A_P2_RX_DN V3P3S_M2_CPU PCIEX4_A_P2_RX_DP...
  • Page 37 Chapter 3 Hardware Configuration ASSIGNMENT ASSIGNMENT PCIE4_P3_CLK_DN PM_WAKE_N PCIE4_P3_CLK_DP PCIE_M.2_CPU_SSD_DETECT V3P3S_M2_CPU V3P3S_M2_CPU V3P3S_M2_CPU BE-U236 SERIES USER MANUAL Page: 3-22...

  • Page 38: B-Key 3042 Slot (M2_B1)

    Chapter 3 Hardware Configuration 3.4.11 M.2 B-KEY 3042 Slot (M2_B1) Connector Location: M2_B1 M.2 B-Key Connector (4G/5G/SSD) Description: M2_B1 ASSIGNMENT ASSIGNMENT KEYB_WWAN_DET_1 V3P3A_WWAN V3P3A_WWAN GPPC_F15_WWAN_FCP_OFF_N USB2_P9_DP_L GPPC_D15_WWAN_KEYB_DISABLE USB2_P9_DN_L M.2_WWAN_LED_N KEYB_WWAN_CONFIG0 SAR_DPR_WWAN KEYB_GNSS_DISABLE SIM1_RESET SIM1_CLK SIM1_DATA SIM1_PWR SIM_GPIO_0 PCIE3_P11_RX_R_DP PCIE3_P11_RX_R_DN BE-U236 SERIES USER MANUAL Page: 3-23...
  • Page 39 Chapter 3 Hardware Configuration ASSIGNMENT ASSIGNMENT PCIE3_P11_TX_C_DN PCIE3_P11_TX_C_DP M.2_WWAN_PERST_R_N GPPC_F19_SRCCLKREQ6_N PCIE3_P6_CLK_DN GPPC_D16 PCIE3_P6_CLK_DP WLAN_WWAN_COEX3 WLAN_WWAN_COEX2 WLAN_WWAN_COEX1 M.2_SIM1_DET GPPC_F14_KEYB_RST_N KEYB_WWAN_SSD_DET V3P3A_WWAN V3P3A_WWAN V3P3A_WWAN KEYB_WWAN_DET_75 BE-U236 SERIES USER MANUAL Page: 3-24...

  • Page 40: Battery Wafer (Jbat1)

    Chapter 3 Hardware Configuration BATTERY WAFER (JBAT1) 3.4.12 Wafer Location: JBAT1 Description: Battery Wafer ASSIGNMENT VBAT+ JBAT1 BE-U236 SERIES USER MANUAL Page: 3-25...

  • Page 41: Internal Usb 2.0 Wafer (Jusb1)

    Chapter 3 Hardware Configuration INTERNAL USB 2.0 WAFER (JUSB1) 3.4.13 Wafer Location: JUSB1 Description: Internal USB 2.0 Type-A Wafer ASSIGNMENT ASSIGNMENT USB2_P7_DN USB2_P8_DN USB2_P7_DP USB2_P8_DP JUSB1 BE-U236 SERIES USER MANUAL Page: 3-26...

  • Page 42: Micro Sim Card Connector (Jsim1)

    Chapter 3 Hardware Configuration MICRO SIM CARD CONNECTOR (JSIM1) 3.4.14 Connector Location: JSIM1 Description: Micro SIM Card Connector ASSIGNMENT SIM_PWR SIM1_RESET SIM1_DET_CONN SIM1_DATA SIM1_CLK JSIM1 BE-U236 SERIES USER MANUAL Page: 3-27...

  • Page 43: B2B Connector (J2)

    Chapter 3 Hardware Configuration 3.4.15 B2B CONNECTOR (J2) Connector Location: J2 Description: B2B Connector ASSIGNMENT ASSIGNMENT 5V_SB HD_FRONT_L_B2B 5V_SB HD_FRONT_R_B2B 3.3V_SB 3.3V_SB I2C2_SCL I2C2_SDA PCIE3_P10_RX_DP LCLK_DIG2 PCIE3_P10_RX_DN SERIRQ_SEG_A LFRAME_SEG_B PCIE3_P10_TX_DP LRESET_SEG_C PCIE3_P10_TX_DN LAD0_SEG_D LAD1_SEG_F PCIE3_P5_CLK_DP LAD2_SEG_E PCIE3_P5_CLK_DN LAD3_SEG_G PCIE3_P9_RX_DP SIO_GPIO_12 PCIE3_P9_RX_DN SIO_GPIO_13 SIO_GPIO_93...

  • Page 44: Sata 3.0 & Sata Power Connectors (Sata1, Jsata_Pwr1)

    Chapter 3 Hardware Configuration 3.4.16 SATA 3.0 & SATA Power Connectors (SATA1, JSATA_PWR1) Connector Location: SATA1 Description: Serial ATA 3.0 Connector ASSIGNMENT SATA1_TX_DP_C SATA1_TX_DN_C SATA1 SATA1_RX_DN_C SATA1_RX_DP_C Connector Location: JSATA_PWR1 Description: SATA Power Connector ASSIGNMENT JSATA_PWR1 BE-U236 SERIES USER MANUAL Page: 3-29...

  • Page 45: Lvds / Edp Connector (Cn1)

    Chapter 3 Hardware Configuration 3.4.17 LVDS / eDP Connector (CN1) Connector Location: CN1 Description: LVDS Connector (located on the bottom side of BE-U236 board) ASSIGNMENT EDP_BKLT_EN EDP_BKLT_CTRL PANEL_SEL_4 DDIA_TX3_DP DDIA_TX3_DN DDIA_TX2_DP DDIA_TX2_DN LVDS_YAP0 LVDS_YAM0 LVDS_YAP1 LVDS_YAM1 LVDS_YAP2 LVDS_YAM2 LVDS_YAP3 LVDS_YAM3 LVDS_CLKAP LVDS_CLKAM LVDS_YBP0...

  • Page 46: Inverter Wafer (Jinv1)

    Chapter 3 Hardware Configuration ASSIGNMENT LVDS_YBM3 LVDS_CLKBP LVDS_CLKBM LVDS_VCC LVDS_VCC INV_VLED INV_VLED INV_VLED 3.4.18 INVERTER WAFER (JINV1) Wafer Location: JINV1 Description: Inverter Wafer ASSIGNMENT LVDS_BKLTEN_R LVDS_BKLTEN_R LVDS_BKLTEN_R JINV1 BRCTR_PWM1 BKLTEN BE-U236 SERIES USER MANUAL Page: 3-31...

  • Page 47: Hd Audio Pin Header (Audio1)

    Chapter 3 Hardware Configuration 3.4.19 HD AUDIO PIN HEADER (AUDIO1) Pin Header Location: AUDIO1 Description: HD Audio Pin Header ASSIGNMENT ASSIGNMENT MIC_L LINE-IN_L AUDIO1 LINE-OUT_L MIC_R LINE-IN_R LINE-OUT_R 3.4.20 SYSTEM FAN CONNECTOR (SYS_FAN1) Connector Location: SYS_FAN1 Description: System Fan Connector ASSIGNMENT VCC12 SYS_FAN1...

  • Page 48: Power Button (Jbutton1)

    Chapter 3 Hardware Configuration 3.4.21 POWER BUTTON (JBUTTON1) Wafer Location: JBUTTON1 Description: Power Button ASSIGNMENT PWRBTN+ PWRBTN- JBUTTON1 3.4.22 BUZZER WAFER (JBZ1) Wafer Location: JBZ1 Description: Buzzer Wafer ASSIGNMENT SPKR+ SPKR- JBZ1 BE-U236 SERIES USER MANUAL Page: 3-33...

  • Page 49: Pwm Brightness Control Selection (Jp2) (Function 1)

    Chapter 3 Hardware Configuration 3.4.23 PWM Brightness Control Selection (JP2) (Function 1) Jumper Location: JP2 (Function 1) Description: PWM Brightness Control Selection Jumper Setting Selection Jumper Illustration (Pin Closed) 3.3V (Default Setting) 3.4.24 USB Power Selection (JP2) (Function 2) Jumper Location: JP2 (Function 2) Description: USB Power Selection Jumper Setting Selection...

  • Page 50: Spi Override Protection Selection (Jp3)

    Chapter 3 Hardware Configuration 3.4.25 SPI OVERRIDE PROTECTION SELECTION (JP3) Jumper Location: JP3 Description: SPI Override Protection Selection Jumper Setting Selection Jumper Illustration (Pin Closed) Enabled Open Disabled (Default Setting) BE-U236 SERIES USER MANUAL Page: 3-35...

  • Page 51: Inverter Led Power Selection (Jp4)

    Chapter 3 Hardware Configuration 3.4.26 INVERTER LED POWER SELECTION (JP4) Jumper Location: JP4 Description: Inverter LED Power Selection JUMPER JUMPER SELECTION SETTING ILLUSTRATION 1-3, 3-5, (Default Setting) 3.4.27 LVDS POWER SELECTION (JP5) Jumper Location: JP5 Description: LVDS Power Selection JUMPER JUMPER SELECTION SETTING...

  • Page 52: I2C Wafer (Ji2C1)

    Chapter 3 Hardware Configuration 3.4.28 I2C WAFER (JI2C1) Wafer Location: JI2C1 Description: I2C Wafer ASSIGNMENT 3.3V I2C1_SCL I2C1_SDA JI2C1 3.4.29 M.2 E-KEY WLAN LED WAFER (LED_WLAN1) Wafer Location: LED_WLAN1 Description: M.2 E-Key WLAN LED Wafer ASSIGNMENT M.2_WLAN_LED+ M.2_WLAN_LED- LED_WLAN1 BE-U236 SERIES USER MANUAL Page: 3-37...

  • Page 53: Clear Cmos Data Selection (Jp1)

    Chapter 3 Hardware Configuration 3.4.30 CLEAR CMOS DATA SELECTION (JP1) Jumper Location: JP1 Description: Clear CMOS Data Selection Step 1. Turn off the main power of the PC. Step 2. Close JP1 (pins 1-2) for 6 seconds by a cap. Step 3.

  • Page 54: Software Utilities

    Software Utilities This chapter provides the detailed information that guides users to install driver utilities for BE-U236 board. The following topics are included: ® • Installing Intel Chipset Software Installation Utility • Installing Graphics Driver Utility • Installing Sound Driver Utility ®...

  • Page 55: Introduction

    Chapter 4 Software Utilities 4.1 Introduction Enclosed with the BE-U236 Series package is our driver utilities contained in a DVD-ROM disk. Refer to the following table for driver locations: Filename (Assume that Purpose DVD- ROM drive is D :) D:\Driver\Platform\1_Main Chip\Win10(2021)_Win11 Intel(R) Chipset Device Software installer D:\Driver\Platform\2_Graphics\...

  • Page 56: Installing Intel ® Chipset Software Installation Utility

    Chapter 4 Software Utilities ® 4.2 Installing Intel Chipset Software Installation Utility Introduction ® The Intel Chipset Software Installation Utility installs the Windows *.INF files to the target system. These files outline to the operating system how to configure the Intel chipset components in order to ensure that the following functions work properly: Core PCI and ISAPNP Services •...

  • Page 57: Installing Graphics Driver Utility

    Chapter 4 Software Utilities 4.3 Installing Graphics Driver Utility To install the Graphics driver utility, follow the steps below: Connect the USB DVD-ROM device to BE-U236 and insert the driver disk. Enter the 2_Graphics \ Win10(2021)_Win11 folder where the driver is located. Click the Installer.exe file for driver installation.

  • Page 58: Installing Sound Driver Utility

    Chapter 4 Software Utilities 4.4 Installing Sound Driver Utility To install the Sound Driver, follow the steps below: Connect the USB DVD-ROM device to BE-U236 and insert the driver disk. Open the 3_Sound \ Win10(2021)_Win11 folder where the driver is located. Click the Setup.exe file for driver installation.

  • Page 59: Intel ® Management Engine Components Driver Installer Installation

    Chapter 4 Software Utilities ® 4.5 Intel Management Engine Components Driver Installer Installation ® Installation Instructions for Intel Management Engine Components Driver Installer Connect the USB DVD-ROM device to BE-U236 and insert the driver disk. Enter the 4_ME \ Win10(2021)_Win11 folder where the driver is located.

  • Page 60: Installing Lan Driver Utility

    Chapter 4 Software Utilities 4.6 Installing LAN Driver Utility Follow the steps below to install LAN Driver: Go to Computer Management of your PC and select Device Manager. Select Network adapters > Intel(R) Ethernet Connection (3) I225-LM. Enter “D:\Driver\Platform\5_LAN Chip\ Win10(2021)_Win11”...

  • Page 61: Installing Intel ® Human Interface Devices Driver Utility

    Chapter 4 Software Utilities ® 4.7 Installing Intel Human Interface Devices Driver Utility To install the Human Interface Devices Driver, follow the steps below: Connect the USB DVD-ROM device to BE-U236 and insert the driver disk. Open the 6_HID \ Win10(2021)_Win11 folder where the driver is located.

  • Page 62: Installing Intel ® Serial I/O Driver Utility

    Chapter 4 Software Utilities ® 4.8 Installing Intel Serial I/O Driver Utility To install the Serial I/O Driver, follow the steps below: Connect the USB DVD-ROM device to BE-U236 and insert the driver disk. Open the 7_Serial IO \ Win10(2021)_Win11 folder where the driver is located.

  • Page 63: Bios Setup

    BIOS SETUP This chapter guides users how to configure the basic system configurations via the BIOS Setup Utilities. The information of the system configuration is saved in BIOS NVRAM so that the Setup information is retained when the system is powered off. The BIOS Setup Utilities consist of the following menu items: Main Menu •...

  • Page 64: Introduction

    Chapter 5 BIOS Setup 5.1 Introduction The BE-U236 board uses an AMI (American Megatrends Incorporated) Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the built-in BIOS setup program, Power-On Self-Test (POST), PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.

  • Page 65: Accessing Setup Utility

    Chapter 5 BIOS Setup system and allows technicians to troubleshoot the occurred errors when the hardware is faulty. The BIOS setup menu allows users to view and modify the BIOS settings for the computer. After the system is powered on, users can access the BIOS setup menu by pressing <Del>...
  • Page 66 Chapter 5 BIOS Setup BIOS Setup Menu Initialization Screen You may move the cursor by <↑> and <↓> keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear on the right side of the screen. The language of the BIOS setup menu interface and help messages are shown in US English.
  • Page 67 Chapter 5 BIOS Setup BIOS Setup Description Navigation Key <←> and <→> Select a different menu screen (move the cursor from the selected menu to the left or right). <↑> and <↓> Select a different item (move the cursor from the selected item upwards or downwards) <Enter>...

  • Page 68: Main

    Chapter 5 BIOS Setup 5.3 Main Menu Path Main The Main menu allows you to view the BIOS Information and change the system date and time. Use tab to switch between date elements. Use <↑> or <↓> arrow keys to highlight the item and enter the value you want in each item. This screen also displays the BIOS version (project) and BIOS Build Date and Time.
  • Page 69 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose Stepping No changeable options Displays the stepping of the PCH. System Language No changeable options Displays the system language. System Date Month, day, year Sets the system date. The format is [Day Month/ Date/ Year].

  • Page 70: Advanced

    Chapter 5 BIOS Setup 5.4 Advanced Advanced Menu Path This menu provides advanced the sub-menu items such as Connectivity Configuration, CPU Configuration, PCH-FW Configuration, Trusted Computing, ACPI Settings, F81967 Super IO Configuration, Hardware Monitor, F81967 Watchdog, S5 RTC Wake Settings, USB Configuration, Network Stack Configuration and NVMe Configuration.

  • Page 71: Advanced - Connectivity Configuration

    Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose NVMe Configuration Sub-Menu NVMe Device Options Settings 5.4.1 Advanced – Connectivity Configuration Menu Path Advanced > Connectivity Configuration The Connectivity Configuration provides advanced CNVi settings and some information about CNVi. Connectivity Configuration Screen BIOS Setting Options Description/Purpose...
  • Page 72 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose This is an option intended to Wi-Fi Core No changeable options Enable/Disable Wi-Fi Core in CNVi. This is an option intended to BT Core No changeable options Enable/Disable BT Core in CNVi. This is an option to Enable/Disable BT Audio Offload which enables audio input from BT device in HFP...

  • Page 73: Advanced - Cpu Configuration

    Chapter 5 BIOS Setup 5.4.2 Advanced – CPU Configuration Advanced > CPU Configuration Menu Path The CPU Configuration provides advanced CPU settings and some information about CPU. CPU Configuration Screen BIOS Setting Options Description/Purpose Efficient-core Information Sub-Menu Displays the E-core Information Performance-core Information Sub-Menu Displays the P-core Information...

  • Page 74: Advanced > Cpu Configuration> Efficient-Core Information

    Chapter 5 BIOS Setup Advanced – CPU Configuration – Efficient-core Information Menu Path Advanced > CPU Configuration> Efficient-core Information The Efficient-core Information provides E-Core information. Efficient-core Information Screen BIOS Setting Options Description/Purpose Frequency No changeable options Displays the Processor Frequency. Displays the Processor L1 Data L1 Data Cache No changeable options...

  • Page 75: Advanced - Cpu Configuration - Performance-Core Information

    Chapter 5 BIOS Setup Advanced – CPU Configuration – Performance-core Information Advanced > CPU Configuration> Performance-core Menu Path Information The Performance-core Information provides P-Core information. Performance-core Information Screen BIOS Setting Options Description/Purpose Frequency No changeable options Displays the Processor Frequency. Displays the Processor L1 Data L1 Data Cache No changeable options...

  • Page 76: Advanced - Pch-Fw Configuration

    Chapter 5 BIOS Setup 5.4.3 Advanced – PCH-FW Configuration Menu Path Advanced > PCH-FW Configuration The PCH-FW allows users to view the information about ME (Management Engine) firmware information, such ME firmware version, firmware mode and firmware SKU. PCH-FW Configuration Screen BIOS Setting Options Description/Purpose...

  • Page 77: Advanced - Pch-Fw Configuration - Ptt Configuration

    Chapter 5 BIOS Setup Advanced – PCH-FW Configuration – PTT Configuration Menu Path Advanced > Trusted Computing > PTT Configuration PTT Configuration Screen BIOS Setting Options Description/Purpose Selects TPM device: PTT or dTPM. PTT - Enables PTT in SkuMgr dTPM - dTPM 1.2 - Disables PTT in SkuMgr TPM Device Selection...

  • Page 78: Advanced - Trusted Computing

    Chapter 5 BIOS Setup 5.4.4 Advanced – Trusted Computing Menu Path Advanced > Trusted Computing The Trusted Computing allows users to enable/disable BIOS support for security device. The operating system will now show Security Device. The TCG EFI protocol and INT1A interface will not be available. Trusted Computing Screen BIOS Setting Options...

  • Page 79: Advanced - Acpi Settings

    Chapter 5 BIOS Setup 5.4.5 Advanced – ACPI Settings Menu Path Advanced > ACPI Settings The ACPI Settings allows users to configure relevant ACPI (Advanced Configuration and Power Management Interface) settings, such as enable/disable ACPI Auto Configuration and enable/disable Hibernation. ACPI Settings Screen BIOS Setting Options...

  • Page 80: Advanced - F81967 Super Io Configuration

    Chapter 5 BIOS Setup 5.4.6 Advanced – F81967 Super IO Configuration Menu Path Advanced > F81967 Super IO Configuration The F81967 Super IO Configuration allows users to configure the serial ports 1-2. F81967 Super IO Configuration Screen BIOS Setting Options Description/Purpose Configures Parameters of Serial Port 1 Serial Port 1 Configuration...

  • Page 81: F81967 Super Io Configuration - Serial Port 1 Configuration

    Chapter 5 BIOS Setup F81967 Super IO Configuration – Serial Port 1 Configuration Advanced > F81967 Super IO Configuration > Serial Port 1 Menu Path Configuration Serial Port 1 Configuration Screen BIOS Setting Options Description/Purpose - Disabled Serial Port Enables or Disables Serial Port 1. - Enabled [Default] Displays the current settings of Device Settings...

  • Page 82: F81967 Super Io Configuration - Serial Port 2 Configuration

    Chapter 5 BIOS Setup F81967 Super IO Configuration – Serial Port 2 Configuration Advanced > F81967 Super IO Configuration > Serial Port 2 Menu Path Configuration Serial Port 2 Configuration Screen BIOS Setting Options Description/Purpose - Disabled Serial Port Enables or Disables Serial Port 2. - Enabled [Default] Displays the current settings of Device Settings...

  • Page 83: Advanced - Hardware Monitor

    Chapter 5 BIOS Setup 5.4.7 Advanced – Hardware Monitor Advanced > Hardware Monitor Menu Path The Hardware Monitor allows users to monitor the health and status of the system such as CPU temperature, system temperature and voltage levels in supply. Hardware Monitor Screen BIOS Setting Options...

  • Page 84: Smart Fan Mode Configuration

    Chapter 5 BIOS Setup Smart Fan Mode Configuration Menu Path Advanced > Hardware Monitor > Smart Fan Mode Configuration Smart Fan Mode Configuration Screen BIOS Setting Options Description/Purpose System Fan Smart Fan - Disabled Smart Fan Function. Control - Enabled [Default] Auto fan speed control.

  • Page 85: Advanced - F81967 Watchdog

    Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose Auto fan speed control. Fan speed Numeric (from 1 to 100), Duty Cycle 3 will follow different temperature 40[Default] by different duty cycle 1-100. Auto fan speed control. Fan speed Numeric (from 1 to 100), Temperature 4 will follow different temperature 45[Default]...

  • Page 86: Advanced - S5 Rtc Wake Settings

    Chapter 5 BIOS Setup 5.4.9 Advanced – S5 RTC Wake Settings Menu Path Advanced > S5 RTC Wake Settings The S5 RTC Wake Settings enables/disables the system to wake up at a preset time of a day from S5 State using RTC alarm. S5 RTC Wake Settings Screen BIOS Setting Options...
  • Page 87 Chapter 5 BIOS Setup Advanced > S5 RTC wake Settings (Fixed Time) Menu Path S5 RTC Wake Settings Screen (Fixed Time) BIOS Setting Options Description/Purpose Allows enabling scheduled S5 to S0 (option: enabled). • Fixed Time: System will wake on - Disabled Wake system from S5 - Fixed Time...
  • Page 88 Chapter 5 BIOS Setup Advanced > S5 RTC Wake Settings (Dynamic Time) Menu Path S5 RTC Wake Settings Screen (Dynamic Time) BIOS Setting Options Description/Purpose Allows enabling scheduled S5 to S0 (option: enabled). • Fixed Time: System will wake on - Disabled Wake system from S5 - Fixed Time...

  • Page 89: Advanced - Usb Configuration

    Chapter 5 BIOS Setup 5.4.10 Advanced – USB Configuration Advanced > USB Configuration Menu Path The USB Configuration allows users to configure advanced USB settings such as USB mass storage driver support USB Configuration Screen BIOS Setting Options Description/Purpose Enables Legacy USB support. AUTO - Disabled Legacy USB Support option disables legacy support if no...

  • Page 90: Advanced - Network Stack Configuration

    Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose - 1 sec - 5 sec USB mass storage device Start Unit Device reset time-out - 10 sec command time-out. - 20 sec Device power-up delay in Multiple options Delay range is 1..65535 milliSec in milliSec ranging from 0 to 65535 one millisecond increments.
  • Page 91 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose - Disabled [Default] Enables or Disables UEFI Network Network Stack - Enabled Stack. Enables Ipv4 PXE Boot Support. If - Disabled [Default] Ipv4 PXE Support disabled, Ipv4 PXE boot option will - Enabled not be created.

  • Page 92: Advanced - Nvme Configuration

    Chapter 5 BIOS Setup 5.4.12 Advanced – NVMe Configuration Menu Path Advanced > NVMe Configuration The NVMe Configuration allows users to view the information about NVMe Device. NVMe Configuration Screen BIOS Setting Options Description/Purpose NVMe Configuration No changeable options Displays NVMe device. BE-U236 SERIES USER MANUAL Page: 5-30...

  • Page 93: Chipset

    Chapter 5 BIOS Setup 5.5 Chipset Chipset Menu Path This menu allows users to configure advanced Chipset settings such as System Agent (SA) and PCH-IO configuration parameters. Chipset Screen BIOS Setting Options Description/Purpose System Agent (SA) Parameters Sub-Menu System Agent (SA) Parameters. PCH-IO Configuration Sub-Menu PCH Parameters.

  • Page 94: Chipset - System Agent (Sa) Configuration

    Chapter 5 BIOS Setup 5.5.1 Chipset – System Agent (SA) Configuration Menu Path Chipset > System Agent (SA) Configuration System Agent (SA) Configuration Screen BIOS Setting Options Description/Purpose Memory Configuration Sub-Menu Memory Configuration. VMD setup menu Sub-Menu VMD Configuration settings. Display setup menu Sub-Menu Display Configuration settings.

  • Page 95: System Agent (Sa) Configuration - Memory Configuration

    Chapter 5 BIOS Setup System Agent (SA) Configuration – Memory Configuration Chipset > System Agent (SA) Configuration > Menu Path Memory Configuration Memory Configuration Screen BIOS Setting Options Description/Purpose Memory Frequency No changeable options Displays the Frequency of Memory. tCL-tRCD-tRP-tRAS No changeable options Memory Timings.

  • Page 96: System Agent (Sa) Configuration - Vmd Setup Menu

    Chapter 5 BIOS Setup System Agent (SA) Configuration – VMD setup menu Menu Path Chipset > System Agent (SA) Configuration > VMD setup menu VMD setup menu Screen BIOS Setting Options Description/Purpose - Disabled Enable VMD controller Enable/Disable to VMD controller. - Enabled[Default] - Disabled Enable/Disable to VMD Global...

  • Page 97: System Agent (Sa) Configuration - Display Setup Menu

    Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose Intel Rapid Recovery - Disabled Enables/Disables Intel Rapid Technology - Enabled[Default] Recovery Technology. RRT volumes can span - Disabled Enables/Disables RRT volumes can internal and eSATA drives - Enabled[Default] span internal and eSATA drives. Enables/Disables System Acceleration - Disabled Intel(R) Optane(TM) Memory...

  • Page 98: Chipset - Pch Io Configuratioin

    Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose - 1280x800, 83.5 MHz, Single, 6bit - 1280x960, 108 MHz, Single, 6bit - 1280x1024, 108 MHz, Dual, 8bit - 1366x768, 85.5 MHz, Single, 6bit - 1366x768, 85.5 MHz, Single, 8bit - 1440x900, 106.5 MHz, Dual, 8bit - 1400x1050, 121.75 MHz, Dual, 8bit - 1600x900, 119 MHz, Dual, 8bit - 1680x1050, 146.25 MHz, Dual, 8bit...

  • Page 99: Pch-Io Configuration - Sata Configuration

    Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose SATA Configuration Sub-Menu SATA Configuration settings. - Power On Specifies what state to go to when Restore AC Power Loss - Power Off power is re-applied after a power [Default] failure (G3 state). PCH-IO Configuration –...

  • Page 100: Security

    Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose Serial ATA Port 1 No changeable options Displays the SATA device’s name. - Disabled Enables or Disables SATA Port Port 1 - Enabled [Default] Device. Enables or Disables Hot Plug function - Disabled [Default] HotPlug to designate a SATA port device as - Enabled...
  • Page 101 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose Administrator Password Password can be 3-20 Specifies the administrator alphanumeric characters. password. User Password Password can be 3-20 Specifies the user password. alphanumeric characters. Create an Administrator or User Password Select the Administrator Password / User Password option from the Security menu and press <Enter>, and the password dialog entry box appears.

  • Page 102: Boot

    Chapter 5 BIOS Setup 5.7 Boot Menu Path Boot This menu provides control items for setting system boot configuration and boot priorities. Boot Screen BIOS Setting Options Description/Purpose Numeric Number of seconds to wait for setup Setup Prompt Timeout (from 1 to 65535) activation key.

  • Page 103: Save & Exit

    Chapter 5 BIOS Setup 5.8 Save & Exit Menu Path Save & Exit The Save & Exit allows users to save or discard changed BIOS settings as well as load factory default settings. Save Changed BIOS Settings To save and validate the changed BIOS settings, select Save Changes from the Save &...
  • Page 104 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose Exits and saves the changes in Save Changes and Exit No changeable options NVRAM. Exits without saving any changes Discard Changes and Exit No changeable options made in BIOS settings. Saves the changes in NVRAM and Save Changes and Reset No changeable options resets.

  • Page 105: Appendix A Technical Summary

    Appendix A Technical Summary This appendix will give you a brief introduction of the allocation maps for BE-U236 resources. The following topics are included: • BE-U236 Block Diagram • Interrupt Map • I/O Map • Memory Map • Configuring WatchDog Timer •...

  • Page 106: Be-U236 Block Diagram

    Appendix A Technical Summary BE-U236 Block Diagram DDR5-4800 @4800MHz Non-ECC 262-pin SO-DIMM 32GB RJ45 I255-LM GbE PCIe3-P7 Controller Channel A RJ45 I255-LM GbE PCIe3-P8 2.5” SATAIII SSD Controller SATA#1 [Header] Audio Codec High Definition Audio 1 x Line-Out ALC888 1 x MIC-In DDI A:eDP 1 x Line -In CH7513A...

  • Page 107: Interrupt Map

    Appendix A Technical Summary Interrupt Map ASSIGNMENT IRQ 0 System timer IRQ 3 Communications Port (COM2) IRQ 4 Communications Port (COM1) IRQ 14 Intel(R) Serial IO GPIO Host Controller - INTC1055 IRQ 16 High Definition Audio Controller Intel(R) Active Management Technology - SOL IRQ 19 (COM3) IRQ 27...
  • Page 108 Appendix A Technical Summary ASSIGNMENT IRQ 82 Microsoft ACPI-Compliant System IRQ 83 Microsoft ACPI-Compliant System IRQ 84 Microsoft ACPI-Compliant System IRQ 85 Microsoft ACPI-Compliant System IRQ 86 Microsoft ACPI-Compliant System IRQ 87 Microsoft ACPI-Compliant System IRQ 88 Microsoft ACPI-Compliant System IRQ 89 Microsoft ACPI-Compliant System IRQ 90...
  • Page 109 Appendix A Technical Summary ASSIGNMENT IRQ 120 Microsoft ACPI-Compliant System IRQ 121 Microsoft ACPI-Compliant System IRQ 122 Microsoft ACPI-Compliant System IRQ 123 Microsoft ACPI-Compliant System IRQ 124 Microsoft ACPI-Compliant System IRQ 125 Microsoft ACPI-Compliant System IRQ 126 Microsoft ACPI-Compliant System IRQ 127 Microsoft ACPI-Compliant System IRQ 128...
  • Page 110 Appendix A Technical Summary ASSIGNMENT IRQ 160 Microsoft ACPI-Compliant System IRQ 161 Microsoft ACPI-Compliant System IRQ 162 Microsoft ACPI-Compliant System IRQ 163 Microsoft ACPI-Compliant System IRQ 164 Microsoft ACPI-Compliant System IRQ 165 Microsoft ACPI-Compliant System IRQ 166 Microsoft ACPI-Compliant System IRQ 167 Microsoft ACPI-Compliant System IRQ 168...
  • Page 111 Appendix A Technical Summary ASSIGNMENT IRQ 198 Microsoft ACPI-Compliant System IRQ 199 Microsoft ACPI-Compliant System IRQ 200 Microsoft ACPI-Compliant System IRQ 201 Microsoft ACPI-Compliant System IRQ 202 Microsoft ACPI-Compliant System IRQ 203 Microsoft ACPI-Compliant System IRQ 204 Microsoft ACPI-Compliant System IRQ 256 Microsoft ACPI-Compliant System IRQ 257...
  • Page 112 Appendix A Technical Summary ASSIGNMENT IRQ 289 Microsoft ACPI-Compliant System IRQ 290 Microsoft ACPI-Compliant System IRQ 291 Microsoft ACPI-Compliant System IRQ 292 Microsoft ACPI-Compliant System IRQ 293 Microsoft ACPI-Compliant System IRQ 294 Microsoft ACPI-Compliant System IRQ 295 Microsoft ACPI-Compliant System IRQ 296 Microsoft ACPI-Compliant System IRQ 297...
  • Page 113 Appendix A Technical Summary ASSIGNMENT IRQ 327 Microsoft ACPI-Compliant System IRQ 328 Microsoft ACPI-Compliant System IRQ 329 Microsoft ACPI-Compliant System IRQ 330 Microsoft ACPI-Compliant System IRQ 331 Microsoft ACPI-Compliant System IRQ 332 Microsoft ACPI-Compliant System IRQ 333 Microsoft ACPI-Compliant System IRQ 334 Microsoft ACPI-Compliant System IRQ 335...
  • Page 114 Appendix A Technical Summary ASSIGNMENT IRQ 367 Microsoft ACPI-Compliant System IRQ 368 Microsoft ACPI-Compliant System IRQ 369 Microsoft ACPI-Compliant System IRQ 370 Microsoft ACPI-Compliant System IRQ 371 Microsoft ACPI-Compliant System IRQ 372 Microsoft ACPI-Compliant System IRQ 373 Microsoft ACPI-Compliant System IRQ 374 Microsoft ACPI-Compliant System IRQ 375...
  • Page 115 Appendix A Technical Summary ASSIGNMENT IRQ 405 Microsoft ACPI-Compliant System IRQ 406 Microsoft ACPI-Compliant System IRQ 407 Microsoft ACPI-Compliant System IRQ 408 Microsoft ACPI-Compliant System IRQ 409 Microsoft ACPI-Compliant System IRQ 410 Microsoft ACPI-Compliant System IRQ 411 Microsoft ACPI-Compliant System IRQ 412 Microsoft ACPI-Compliant System IRQ 413...
  • Page 116 Appendix A Technical Summary ASSIGNMENT IRQ 445 Microsoft ACPI-Compliant System IRQ 446 Microsoft ACPI-Compliant System IRQ 447 Microsoft ACPI-Compliant System IRQ 448 Microsoft ACPI-Compliant System IRQ 449 Microsoft ACPI-Compliant System IRQ 450 Microsoft ACPI-Compliant System IRQ 451 Microsoft ACPI-Compliant System IRQ 452 Microsoft ACPI-Compliant System IRQ 453...
  • Page 117 Appendix A Technical Summary ASSIGNMENT IRQ 483 Microsoft ACPI-Compliant System IRQ 484 Microsoft ACPI-Compliant System IRQ 485 Microsoft ACPI-Compliant System IRQ 486 Microsoft ACPI-Compliant System IRQ 487 Microsoft ACPI-Compliant System IRQ 488 Microsoft ACPI-Compliant System IRQ 489 Microsoft ACPI-Compliant System IRQ 490 Microsoft ACPI-Compliant System IRQ 491...

  • Page 118: I/O Map

    Appendix A Technical Summary ASSIGNMENT Intel(R) USB 3.10 eXtensible Host Controller - 1.20 IRQ 4294967290 (Microsoft) IRQ 4294967291 Standard SATA AHCI Controller IRQ 4294967292 Intel(R) PCI Express Root Port #1 - 51B8 IRQ 4294967293 Intel(R) PCI Express Root Port #7 - 51BE IRQ 4294967294 Intel(R) PCI Express Root Port #8 - 51BF IRQ 0...
  • Page 119 Appendix A Technical Summary ASSIGNMENT 0x00000050-0x00000053 System timer 0x00000061-0x00000061 Motherboard resources 0x00000063-0x00000063 Motherboard resources 0x00000065-0x00000065 Motherboard resources 0x00000067-0x00000067 Motherboard resources 0x00000070-0x00000070 Motherboard resources 0x00000080-0x00000080 Motherboard resources 0x00000092-0x00000092 Motherboard resources 0x000000A0-0x000000A1 Programmable interrupt controller 0x000000A4-0x000000A5 Programmable interrupt controller 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller...

  • Page 120: Memory Map

    Appendix A Technical Summary ASSIGNMENT 0x00000030-0x00000031 Programmable interrupt controller 0x00000034-0x00000035 Programmable interrupt controller Memory Map MEMORY MAP ASSIGNMENT 0xFEDC0000-0xFEDC7FFF Motherboard resources 0xFEDA0000-0xFEDA0FFF Motherboard resources 0xFEDA1000-0xFEDA1FFF Motherboard resources 0xC0000000-0xCFFFFFFF Motherboard resources 0xFED20000-0xFED7FFFF Motherboard resources 0xFED90000-0xFED93FFF Motherboard resources 0xFED45000-0xFED8FFFF Motherboard resources 0xFEE00000-0xFEEFFFFF Motherboard resources Intel(R) USB 3.20 eXtensible Host 0x1110000-0x111FFFF...
  • Page 121 Appendix A Technical Summary MEMORY MAP ASSIGNMENT 0xFED40000-0xFED44FFF Trusted Platform Module 2.0 0x81300000-0x81301FFF Standard SATA AHCI Controller 0x81303000-0x813030FF Standard SATA AHCI Controller 0x81302000-0x813027FF Standard SATA AHCI Controller Intel(R) USB 3.10 eXtensible Host 0x1100000-0x110FFFF Controller - 1.20 (Microsoft) 0x81100000-0x812FFFFF Intel(R) PCI Express Root Port #8 - 51BF Intel(R) Serial IO I2C Host Controller - 0xFFEF9000-0xFFEF9FFF 51E9...

  • Page 122: Configuring Watchdog Timer

    Appendix A Technical Summary Configuring WatchDog Timer The I/O port address of the watchdog timer is 2E (hex) and 2F (hex). 2E (hex) is the address port. 2F (hex) is the data port. Users must first assign the address of register by writing address value into address port 2E (hex), then write/read data to/from the assigned register through data port 2F (hex).
  • Page 123 Appendix A Technical Summary Code example for watch dog timer Enable watchdog timer and set timeout interval to 30 seconds. ; ------------------------- Enter to extended function mode ------------------------------- ; ----------------------- Select Logical Device 7 of watchdog timer --------------------- ;---------------------------------Enable Watch dog feature ------------------------------ ;...

  • Page 124: Flash Bios Update

    Appendix A Technical Summary Flash BIOS Update I. Prerequisites Prepare a bootable media (e.g. USB storage device) which can boot system to EFI Shell. Note: Copy UEFI Shell into the storage device under specific directory path. (/efi/boot/bootx64.efi) Download and save the BIOS file (e.g. U2360PP1.bin) to the bootable device.
  • Page 125 Appendix A Technical Summary II. AFUEFI Command For System BIOS Update AfuEfix64.efi is the AMI firmware update utility. The command line is shown as below: AfuEfix64 <ROM File Name> [option1] [option2]…. Users can type “AfuEfix64/ ?” to view the definition of each control option.
  • Page 126 Appendix A Technical Summary Shell> fs0: fs0:\>AfuEfix64 U2360TP8.bin /p /b /n /x /r1 Reading flash ....done - ME Data Size Checking . ok - FFS checksums ..ok - Check RomLayout ..ok. Erasing Boot Block ..done Updating Boot Block ..done Verifying Boot Block ..

  • Page 127: Appendix B Mating Connectors

    Appendix B Mating Connectors This appendix contains the list table of connector vendors and model numbers for BE-U236 mating connectors. The following topic is included: • Mating Connectors Table BE-U236 SERIES USER MANUAL Page: B-1...

  • Page 128: Mating Connectors

    Appendix B Mating Connectors Mating Connectors Mating Connector Connector Label Function Pitch Vendor Model NO. AUDIO1 Audio 1.27 H210800388 LVDS/eDP Aces 50473-0400M-001 Connector Board-to-Board Amphenol 61082-064402LF connector JBAT1 Battery 1720218060 Power Button JBUTTON1 1790205061 Cable JBZ1 Buzzer Signal 1.25 1760205067 COM1, JCOM1 1.25...

Table of Contents
