- Page 1 Owner’s Manual Model 780GPS GPS Attachement Forage Harvester 780GPS-23-Owners 4/23...
-
Page 2: Table Of Contents
Harvest Tec 780GPS Table of Contents PAGE Introduction Overview Installation of GPS Receiver & Harness Installation of GPS Receiver Installation of GPS Harness Wiring Diagram Setup Instructions Setup Instructions – ISOBUS VT Setup Instructions – Tablet App Operating Instructions Job Records & Yield Files – ISOBUS VT Job Records &... -
Page 3: Introduction
GPS data pertaining to where each bale was completed and will be stored to your job records. The model 780GPS includes the Garmin 16xHVS receiver and harness to connect to your Harvest Tec system. - Page 4 Figure 3 3. The GPS expansion harness (006-765GPS-EXT) has a 3 Pin triangular plug with 3 wires leads terminated with socket connectors. Install the socket connectors by identifying each colored wire on the GPS expansion Harness and pushing them into the corresponding open cavity in the back side of the 18 Pin connector (Figure 3).
-
Page 5: Wiring Diagram
700 Series with 780GPS WIRING DIAGRAM ptional Har est ec ispla Harness 6 65 H e Power Harness 6 65CPH ptional Ha Indicator Harness ptional 6 5 H Ha Indicators Power Harness on ractor 6 65IC xpansion Plug Harness 6 65 P... -
Page 6: Setup Instructions
Setup Instructions – ISOBUS VT 1. Turn the control system on. After a few seconds, the Main Menu screen will load. Press Setup, the Setup screen will then appear. 2. Press the Yield Map tab. Yield Mapping Setup will now be displayed. 3. -
Page 7: Operating Instructions
Operation Instructions 1. Once installation and setup are complete, the system is ready for baling. The status of the GPS system is indicated by the color of the border around the moisture histogram on the main run screen in both Auto and Manual modes. •... - Page 8 b. ISOBUS VT - Job records can be accessed on the ISOBUS VT by selecting JOBS from the menu options on the right side of the main screen, then selecting VIEW PREVIOUS JOBS from the menu options on the right side. Job records can be managed individually (View, Download to USB, Delete, or Add to Job), if selected, or all at once (Export or Delete).
-
Page 9: Job Records & Yield Files - Tablet App
Tablet - Job records and Yield Files can be accessed on the Tablet by selecting RECORDS from the menu options on the right side of the main screen. This will open the View Job List. If P was connected properl a “Y”... -
Page 10: Troubleshooting
Troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION GPS icon not displaying green 1. GPS is not enabled. 1. Check Yield Mapping Setup in Auto or Manual modes to make sure that the GPS is enabled. 2. GPS signal blocked by 2. Move baler to a location obstruction (trees, building, where GPS signal is not etc). -
Page 11: Parts Breakdown For Model 780 Gps
Parts Breakdown for Model 780GPS Description Part# GPS Receiver w harness 006-7650GPS GPS Receiver Mount 001-2012GPS GPS Expansion Harness 006-765GPS-EXT USB stick 006-5650USB Pin Locations 006-762/3/5B Baler Plug – destinations for 765GPS Expansion Plug Pin 16 Gray Garmin 12V+ Pin 15 White... -
Page 12: Warranty
Harvest Tec, LLC. within 30 days of the failure. If it is determined that a non-Harvest Tec branded hay preservative has been used inside the Harvest Tec applicator system where the failure occurred, then Harvest Tec reserves the right to deny the warranty request at their discretion.
