AES WD Mobile Instruction Manual

Instruction Manual
Compac wheel dolly, model WD Mobile.
Congratulations:
Congratulations on your new WD Mobile, which we are sure will live up to your expectations. Please
read these operating instructions carefully to get the most out of your WD Mobile for years to come.
Warranty:
Compac offers a 3 year warranty from the date of purchase. The warranty is only valid if all of the
measures specified in these operating instructions are observed. The warranty covers any defects in
the workmanship and materials.
Wearing parts are not covered by the 3 year warranty. For the terms of the warranty, see
www.compac.dk.
In case of problems, contact the Compac dealer you purchased the product from.
Liability:
These operating instructions must be stored together with the WD Mobile. They must always be
available to the user for perusal. The manufacturer of the WD Mobile shall not be liable for any lack of
familiarity with the content of the operating instructions. If the user does not understand Danish, the
owner must ensure that an explanation is provided in the user's native language, so the machine may
be used in a safe and responsible manner.
Use:
WD Mobile is a mobile lifting cart for carrying large wheels with a max. wheel size of 22.5" and outer
diameter of up to 1120 mm.
250 kg capacity. Remove the wheel by placing the WD Mobile under the wheel (as illustrated √). Next
tip WD Mobile down onto the smallest wheels, so there is contact between the wheel and the castors
on the
WD Mobile. Continue to tip WD Mobile down onto the smallest wheels until the wheel is free of the
axle.
It can now be carted away with the WD Mobile.
Use the unit on a plane and stable surface.
Place the wheel so that it is in contact with both castors.
After use WD Mobile may be stored on its support foot.
