- Page 1 RowFlow Liquid Manual 955205_01 11/11...
- Page 2 Notice of Non-Waiver: The failure by Precision Planting, at any one or more time, to insist upon the strict performance by the Customer of the covenants, conditions and/or terms of this agreement, shall not be construed as a waiver of Precision Planting’s right to demand strict compliance with and performance of all covenants, conditions and/or terms hereof.
-
Page 3: Safety Information
Safety Information Always wash your hands after working on or around agricultural equipment prior to eating, drinking, smoking, chewing, etc… Always use the proper Personal Protective Equipment (PPE) for any task. Examples include: Gloves when handling sharp or abrasive materials Eye protection when handling contents or systems under pressure (ie. -
Page 4: System Overview
System Overview Planter Starter Application The RowFlow Liquid system will consist of at least four parts to be added to an existing RowFlow system (see RowFlow Installation Guide for information on the RowFlow base system) for planter starter application. These parts include: a Pressure Sensor, a Flow Meter, a Pressure Sensor Harness, and a Flow Meter Harness. - Page 5 System Overview Flow Meter 727305 & 727306 The Flow Meter measures the rate at which the liquid is flowing through the system and is used to indicate the application rate of the product. The Flow Meter should be installed vertically inline between the liquid pump and distribution.
- Page 6 Sidedress Application The RowFlow Liquid Sidedress system will consist of one of two harness option. In addition, the system will include two major components of the RowFlow Liquid Planter system. The Pressure Sensor, the Flow Meter and select components of the RowFlow base system will be identified below.
- Page 7 Refer to RowFlow Installation Guide to install components of the RowFlow system. Hydraulic Motor If installing a new Precision Planting Hydraulic Motor (727105), please refer to installation guide included with motor for installation instructions. The motor may be attached to the liquid pump with a direct coupler or a chain &...
- Page 8 Installing RowFlow Liquid System (Planter) Planter Connection Layout 955205_01 11/11...
- Page 9 Sidedress Base Harness. Hydraulic Motor If installing a new Precision Planting Hydraulic Motor (727105), please refer to installation guide included with motor for installation instructions. The motor may be attached to the liquid pump with a direct coupler or a chain &...
- Page 10 Installing RowFlow Liquid System (Side dress) Sidedress Connection Layout #1 – Sidedress Base Harness 955205_01 11/11...
- Page 11 Installing RowFlow Liquid System (Side dress) Sidedress Connection Layout #2 – Sidedress Sensor Harness 955205_01 11/11...
- Page 12 Full System Layouts (Planter) 955205_01 11/11...
- Page 13 Full System Layouts (Planter) 955205_01 11/11...
- Page 14 Full System Layouts (Planter) 955205_01 11/11...
- Page 15 Full System Layouts (Sidedress) 955205_01 11/11...
- Page 16 Full System Layouts (Sidedress) 955205_01 11/11...
- Page 17 Setup and Operation (Planter) Planting Setup Motor Setup Setup for liquid control motors can be accessed from both the standard motor setup screen for RowFlow or by going to Setup-Systems-RF Liquid. Select the correct Drive Motor that is driving the liquid pump and press Liquid. Select the correct motor brand and then enter the default rate at which you would like your product to be applied and then press Enter.
- Page 18 The flow calibration value is stamped on the metal tag attached to the Flow Meter. Press Enter and then enter the Pressure Sensor Range (200 psi for Precision Planting Pressure Sensor). Press Enter again to finish the Sensor Setup.
- Page 19 Setup and Operation (Planter) Planting Operation Field Prescription Selection Select field from field selection menu (Setup-Field Name), and press the Prescription button to select the prescription with seeding rate and liquid rates. First choose the seeding attribute and press Enter. Select the liquid attribute, and press Enter.
- Page 20 Setup and Operation (Planter) RowFlow Liquid Control Page The RowFlow Liquid Control page can be accessed by pressing the RF Liquid button from the home screen or by pressing Setup-Systems-RF Liquid (Control). This page allows you to toggle between automatic variable rate liquid application and manual rate control by pressing the Variable Rate button near the top left.
- Page 21 Setup and Operation (Planter) Dashboard – Large Map While the Large Map is up on the Home Screen, you can toggle between a seeding map and liquid map by touching the map, bringing up the map menu. In the top right, press Next Map to toggle.
- Page 22 Setup and Operation (Sidedress) Sidedress Setup Sidedress Mode The first step in setting up the 20/20 SeedSense for sidedressing is to put it into Sidedress Mode (Setup-Systems-Display-Display Mode). Select Sidedress Mode and press Enter. Your display is now ready for Sidedress Setup and Operation. Lift Switch Calibration, Radar Calibration, and RFM Direction Setup Sidedress Mode requires you to calibrate the...
- Page 23 Setup and Operation (Sidedress) GPS Setup – Sidedress Bar From the Home Screen, press Setup-Systems- GPS-Sidedress Bar to enter the GPS measurements for the bar. Frame Type is locked on Single. Press Hitch Style to select Drawn, 2-Point Pivot, or 3-Point and press Enter. The “A”...
- Page 24 The flow calibration is stamped on the metal tag attached to the Flow Meter. Press Enter and then enter the Pressure Sensor Range (200 for Precision Planting Pressure Sensor). Press Enter again to finish the Sensor Setup. Rate Presets and Quick Adjust To setup preset rates or change the quick adjust values press Preset Application Rates.
- Page 25 Setup and Operation (Sidedress) Sidedress Operation Home Screen – Dashboard Sidedress mode operates in a partial replay mode. You will see grayed out areas on the screen that is replayed planting data while you run. Areas not grayed out contain live data. This mode also gives access to two new 4x4 buttons: Planting Speed and Hybrids.
- Page 26 Setup and Operation (Sidedress) Miscellaneous The coverage map on the home screen will be based on the rate being applied according to the Flow Sensor. Be aware that there may be a one to four second lag time when starting and stopping.
