- Page 1 27-03-2019 Installation manual KIRKHOLM www.sunshade-experts.com service@sunshade-experts.com...
-
Page 3: Product Description
Product description *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności THE PERFECT CASSETTE FOR CONTEMPORARY ARCHITECTURE Contemporary architecture, with its sharp, straight shapes, poses a challenge when it comes to fitting features into the façade. The RETTA cassette system is specially designed with a view to the needs of specifications professionals. -
Page 4: Product Parts
Product parts o ś o ś ( ś o ż d ł y ć u ż e ż a ż Nomenclature Support set and caps Retta Cassette profiles kit Rubber sealant Luxline 400 arms Rolling tube Roller end bearing Led lighting kit with electric transformer 4 channels RX 4 channels TX Motor and coupling... - Page 5 Section dimensions *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności FRONTAL MOUNTING CEILING MOUNTING www.sunshade-experts.com *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności...
- Page 6 Allowances for profiles and fabric Projection (m) 2,00 2,50 3,00 3,50 30 Nm 35 Nm 40 Nm Rolling tube Ø 70mm Rolling tube Ø 80mm 40 Nm 50 Nm Selection motor table Width Class Arm projection (m) 3,50 5,00 Selection motor table The arms have a protective band for correct identification: GREEN: Right hand side viewed from outside...
- Page 7 Compatibilities *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności Compatibilities Support fixation; front or ceiling mounting L = 90 mm Distancia entre taladros de los 2 soportes Distance between holes of the 2 supports The supports are complemented with the CLEVERFIX leveling systems Total width measurement between drill centers...
-
Page 8: Front Mounting
Assembly instructions o ś o ś ( ś o ż d ł y ć u ż e ż a ż Supports installation front or ceiling Celling mounting The maximum insertion of the threaded rods inside the support must not exceed 30 mm Front mounting Assembly instructions Both sides are at the same distance parallel to the cap supports... - Page 9 Assembly instructions *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności It is possible to unlock the cassette from the support whenever is needed Insert a flat screwdriver between the support and the steel plate, then lever to release the clipping Beware at handling the cassette when it is not clipped on the steel plate, as it may fall.
- Page 10 Assembly instructions o ś o ś ( ś o ż d ł y ć u ż e ż a ż Adjust the slope and the alignment through the arm support Using an Allen key M-10, turn the front screws of the arm support, as shown in the image Assembly instructions IMPORTANT: Observe the final position of the front rail connector once it’s been placed in its housing...
- Page 11 Assembly instructions *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności The placement distance for the front rail connectors is 205 mm from the cutting end of the front profile to the end of the front rail connector This measurement is fine for the following models of arms: Luxline 400, Vector 400, Assembly instructions Fixing the arm in the arm support each side...
- Page 12 Assembly instructions o ś o ś ( ś o ż d ł y ć u ż e ż a ż Press the sliders into the front profile, making them match with the position of the elbow, when the cassette closes ATENTION: The sliders will help the cassette to close perfectly provided they are in their proper placement Assembly instructions...
- Page 13 Assembly instructions *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności The led strip sticks in the slot through its self-adhesive layer Assembly instructions Connection examples for led strips operated by hand transmitter Power supply Single colour led strip RGB colour led strip...
- Page 14 BASIC NOTES ON ASSEMBLY AND INSTALLATION: *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności Assembly and installation should be done by trained personnel. • IMPORTANT SAFETY CONSIDERATIONS: For proper installation of the awning, •...
- Page 16 www.sunshade-experts.com...
